Binks Model 21 (Brass Body) AUTOMATIC SPRAY GUN
General Arrangement Diagram and Hook-Up
Fluid Atomizing Air
Side Port
Control
Mounting
Lockscrew
Mounting Hole
(1/2" Dia.) Fluid
Adjustment
Control
Fluid
Inlet
3/8 NPS(m)
Atomizing
Air Inlet
1/4 NPS(m)
Oil and
Water
Extractor
Typical Air
Compressor
Typical
Pressure
Tank Typical
Pump w/
Container
Cylinder
Operating
Air Inlet
1/4 NPS(m),
(50-60 PSI Min.)
Atomizing Air
(Through Extractor)
Atomizing
Air
Atomizing
Air
Cylinder Air
Cylinder Air (Through Extractor)
Cylinder Air
Cylinder
Air
3-Way Valve
Fluid Fluid
3-Way
Valve
3-Way
Valve
Back
Pressure
Control
Pump
Speed
Control
To Fluid Supply
Air Supply from
Compressor or
Air Line
Air Supply
to Pressure
Tank Inlet
Air Supply
from
Compressor
or Air Line
Shut-Off
Cocks
For multiple gun installation, a fluid manifold may be used.
Fluid adjustments are made using the fluid control screw on
each gun. However, when precise fluid control is necessary,
a fluid regulator for each gun must be used.
1. Provide 50-60 PSI (minimum) air pressure for gun cylinder
operation.
2. Air line from gun to 3-way valve should be as short as
possible for maximum speed of operation.
3. Recommended hose sizes are 3/8" for fluid and 1/4" for air.
Oil and Water
Extractor

WARNING
!
In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows:
CAUTION
Hazards or unsafe practices which could
result in minor personal injury, product
or property damage.
!
WARNING
Hazards or unsafe practices which could
result in severe personal injury, death
or substantial property damage.
!
NOTE
Important installation, operation or
maintenance information.
Read the following warnings before using this equipment.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PROVIDE THIS INFORMATION TO
THE OPERATOR OF THE EQUIPMENT.
FOR FURTHER SAFETY INFORMATION REGARDING BINKS AND DEVILBISS EQUIPMENT,
SEE THE GENERAL EQUIPMENT SAFETY BOOKLET (77-5300).
READ THE MANUAL
Before operating finishing equipment, read and
understand all safety, operation and maintenance
information provided in the operation manual.
AUTOMATIC EQUIPMENT
Automatic equipment may start suddenly without
warning.
INSPECT THE EQUIPMENT DAILY
Inspect the equipment for worn or broken parts
on a daily basis. Do not operate the equipment
if you are uncertain about its condition.
NEVER MODIFY THE EQUIPMENT
Do not modify the equipment unless the
manufacturer provides written approval.
KNOW WHERE AND HOW TO SHUT OFF THE
EQUIPMENT IN CASE OF AN EMERGENCY
PRESSURE RELIEF PROCEDURE
Always follow the pressure relief procedure in the
equipment instruction manual.
NOISE HAZARD
You may be injured by loud noise. Hearing
protection may be required when using this
equipment.
STATIC CHARGE
Fluid may develop a static charge that must be
dissipated through proper grounding of the
equipment, objects to be sprayed and all other
electrically conductive objects in the dispensing
area. Improper grounding or sparks can cause a
hazardous condition and result in fire, explosion
or electric shock and other serious injury.
FIRE AND EXPLOSION HAZARD
Never use 1,1,1-trichloroethane, methylene
chloride, other halogenated hydrocarbon solvents
or fluids containing such solvents in equipment
with aluminum wetted parts. Such use could
result in a serious chemical reaction, with the
possibility of explosion. Consult your fluid
suppliers to ensure that the fluids being used are
compatible with aluminum parts.
WEAR SAFETY GLASSES
Failure to wear safety glasses with side shields
could result in serious eye injury or blindness.
DE-ENERGIZE, DISCONNECT AND LOCK OUT ALL
POWER SOURCES DURING MAINTENANCE
Failure to De-energize, disconnect and lock out
all power supplies before performing equipment
maintenance could cause serious injury or death.
OPERATOR TRAINING
All personnel must be trained before operating
finishing equipment.
EQUIPMENT MISUSE HAZARD
Equipment misuse can cause the equip ment to
rupture, malfunction, or start unexpectedly and
result in serious injury.
KEEP EQUIPMENT GUARDS IN PLACE
Do not operate the equipment if the safety
devices have been removed.
PROJECTILE HAZARD
You may be injured by venting liquids or gases
that are released under pressure, or flying debris.
PINCH POINT HAZARD
Moving parts can crush and cut. Pinch points are
basically any areas where there are moving parts.
PROP 65 WARNING
WARNING: This product contains chemicals known
to the State of California to cause cancer and
birth defects or other reproductive harm.
CA PROP
65
WARNINGS 3/23/11 12:14 PM Page 1
2

Binks Model 21 (BRASS BODY) AUTOMATIC SPRAY GUN
INTERNAL MIX HEAVY MATERIAL NOZZLES (OPTIONAL)
HOOK-UP
1. Air pressure of 50-60 PSI minimum required for cylin-
der operation.
2. For rapid operation, the air line between three-way
valve and the cylinder operating air connection should
be as short as possible.
3. All air supplied to the gun should be dirt and moisture-
free. An oil and water extractor mounted in the air
supply line is recommended.
4. If the gun is to stand idle for any length of time, shut
off. This will prevent small leaks throughout the
system from turning on the gun.
FAN SPRAY ADJUSTMENTS
The fan spray is easily controlled by means of the side
port control stem, (22). Turning this control to the right,
or clockwise, will give a round spray pattern. Turning it
to the left, or counter-clockwise, will widen the spray into
a fan shape of any desired width. Orientation of the fan
spray either horizontally or vertically (or to any position
in between) is obtained by loosening the retainer ring,
rotating the air nozzle to the desired position, and then
tightening the retainer ring.
FLUID FLOW ADJUSTMENTS
For best results, the fluid control screw (18) should be set
at the open position and the flow of the fluid controlled
by regulating the fluid pressure in the pressure tank. If
the conditions under which the gun is being used require
the fluid to be controlled at the gun, it may be accom-
plished by loosening locknut (19) and turning screw (18)
to the right (clockwise) to decrease the flow of fluid or
the left (counter-clockwise) to increase the flow of fluid.
LUBRICATION
The points that require lubrication on this gun are the
plunger (7), the air valve packing (11), and the fluid
packing (36). These parts should be kept soft and pliable
at all times. A light machine oil is recommended for this
lubrication.
CLEANING
Shut off the air supply to the tank and release its pressure.
Hold a piece of wadded cloth over the gun nozzle and
turn on the air to the cylinder. The air will back up
through the fluid nozzle and force fluid out of the hose
and into the tank.
Replace the paint in the pressure tank with clean solvent
and spray the solvent through the gun until it is clean.
Dry out the residual solvent in the fluid hose by blowing
air through it.
FAULTY SPRAY
Faulty spray is caused by dry coating material residue
around the fluid nozzle tip or inside the air nozzle. Soak
these parts in a solvent that will soften the dried residue
until it can be removed with a brush or a cloth.
32
35
40
41
42
NOZZLE TIP*
200, 201 & 206
NITRALLOY
NOZZLE BASE
WITH RING
54-372
AIR NOZZLE*
240 THRU 262
NITRALLOY
AIR NOZZLE*
706, 709SS,
713
FLUID NOZZLE*
59ASS, 59BSS, 59CSS
259 NEEDLE ASSEMBLY
AIR NOZZLE ASSEMBLY*
*When ordering please specify number
stamped on nozzle. See page 4.
CAUTION
Never submerge the gun in solvent. Solvent will wash the
oil off the lubricated parts and cause subsequent malfunc-
tioning of the gun.
!
CAUTION
Never use metal probes to clean the air or fluid nozzles
because scratches and burns on their precision machined
surfaces can cause faulty spray. If either the air or fluid
nozzle is damaged so as to give faulty spray, it must be
replaced.
!
3

Binks Model 21 (BRASS BODY) AUTOMATIC SPRAY GUN (Continued)
1
2
4
5
6
7
8
9
10
11
12 12
13
14
3
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
34
36 37
38
ITEM PART
NO. NO. DESCRIPTION QTY.
1 * NOZZLE
Air.................................... 1
2 * NOZZLE
Fluid ................................. 1
3 ** FLUID NEEDLE .............................. 1
4 54-232 LOCKNUT
Plunger .......................... 1
5 54-233 WASHER
Plunger ............................ 1
6 54-236 SPRING
Plunger .............................. 1
   Leather ........................... 1
8 54-302 GLAND
Packing ............................. 1
   Packing Follower .................. 1
10 54-306 NUT Air Packing .............................. 1
  Air.................................. 1
12 54-308 CONNECTION Air .......................... 2
  Air Valve.......................... 1
14 54-312 GUIDE Air Valve .............................. 1
17 54-321 BONNET........................................ 1
18 54-322 SCREW Fluid Control ........................ 1
19 54-323 LOCKNUT FLUID CONTROL ......... 1
20 54-324 WASHER Fluid Control Locknut.......... 1
21 54-326 BODY Side Port Control .................... 1
22 54-327 STEM Side Port Control ..................... 1
ITEM PART
NO. NO. DESCRIPTION QTY.
  Side Port Control................ 1
  Side Port Control .................. 1
  Side Port Control......................... 1
  Side Port Control............ 1
27 54-333 SIDE PORT CONTROL Complete ..... 1
  Packing ........................ 1
29 54-335 SCREW Set ..................................... 1
30 54-336 BODY Brass .................................... 1
31 54-337 VALVE Air ...................................... 1
32 54-542 LOCKNUT Front ............................. 1
   Needle Valve........................ 1
  Side Port Control ............... 1
35 54-763 LOCKNUT Rear .............................. 1
  Needle Valve .................... 1
37 54-765 NUT Packing ................................... 1
  Fluid Nozzle ....................... 1
39 54-1224 RING ............................................. 1
40 54-1583 BASE ............................................. 1
41 54-1584 RING ............................................. 1
42 54-2065 RING ............................................. 1
43 OMX-88 BRUSH Cleaning (Not Shown)............. 1
PARTS LIST
When ordering, please specify Part No.
*When ordering, please specify number stamped on nozzle. See pages 2 and 4.
**When ordering, please specify gun model and number stamped on needle. See pages 2 and 4.


Gun wrench, 5-476 is recommended for removing fluid nozzle. Please order separately.
4

NOZZLE AND NEEDLE SELECTION CHARTS
VERY THIN 63ss x 63P PE 4.5 7.5 10.0 5 263
14-16 secs. Zahn 2 Cup 63Bss x 63PB PE 9.0 14.3 20.0 14 263A
Wash primers, dyes, 66ss x 66SD SE 7.9 12.1 — 10.5 265
stains, solvents, 66ss x 66SK SE 11.0 15.2 19.5 13 265
water, inks 63Bss x 200 PI 3.1 5.2 6.4 12 263A
THIN 63Ass x 63P PE 5.1 8.37 12.2 11 263A
16-20 secs. Zahn 2 Cup 66ss x 66SK SE 11.0 15.2 19.5 13 265
Sealer, lacquers, primers, inks, 63Bss x 200 PI 3.1 5.2 6.4 12 263A
lubricants, zinc chromates,
acrylics
MEDIUM
19-30 secs. Zahn 2 Cup 63Bss x 63PB PE 9.0 14.3 20.0 14 263A
Synthetic enamels, varnishes, 66ss x 66SD SE 7.9 12.1 — 11 265
shellacs, fillers, primers, epoxies, 66ss x 66SK SE 11.0 15.2 19.5 13 265
urethanes, lubricants, 63Css x 200 PI 3.1 5.2 6.4 12 263A
wax emulsions, enamels
HEAVY (Cream-like) 67ss x 67PB PE 9.5 14.9 19.5 12 267
Over 28 secs. 68ss x 68PB PE 9.5 14.1 19.1 12 268
No. 4 Ford Cup 67ss x 206 PI 6.0 9.5 13.0 15 267
VERY HEAVY 68ss x 68PB PE 9.5 14.1 19.1 12 268
Texture coatings, 68ss x 206 PI 6.2 9.8 13.2 15 268
Road marking paint 59Ass x 244 PI 7.8 11.5 15.2 12 259
59Bss x 252 PI 7.8 11.5 15.2 6 259
59Css x 262 PI 7.3 11.0 14.7 6 259
68ss x 206 PI 6.2 9.8 13.2 15 268
ADHESIVES
Waterbase white vinyl glues 63Bss x 66SD-3 PE 7.9 12.1 16.2 4 263
Solvent base, neoprenes 67ss x 67PB PE 9.5 14.1 19.1 12 267
(contact cement) 66ss x 66SD-3 PE 7.9 12.1 16.2 10 265
CERAMICS
Similar abrasive materials, glazes, 67VT x 67PD PE 10.0 15.0 20.0 15 267VT
engobes, porcelain enamel 68VT x 68PB PE 9.5 14.1 19.1 12 268VT
BUFFING COMPOUNDS 64VT x 64PA PE 12.1 15.0 21.0 13 264VT
67VT x 67PD PE 10.0 15.0 20.0 15 267VT
CONCRETE CURING 66ss x 200 PI 3.1 5.2 6.4 15 265
COMPOUNDS 67ss x 206 PI 6.0 9.5 13.0 18 267
68ss x 206 PI 6.2 9.8 13.2 20 268
MULTICOLOR PAINTS 66ss x 200 PI 3.1 5.2 — 12 265
67ss x 206 PI 6.0 9.5 — 15 267
TEFLONS 63Ass x 63PB PE 9.0 14.3 20.1 10 263A
66ss x 66SD PE 7.9 12.1 — 7 265
HAMMERS 63ss X 63PB PE 9.0 14.3 — 14 263A
66ss X 63PB PE 9.0 14.3 — 14 265
66ss X 66SD PE 7.9 12.1 — 7 265
WRINKLE ENAMELS 63Css x 63PB PE 9.0 14.3 20.0 10 263A
66ss x 63PB PE 9.0 14.3 20.0 10 265
ZINC RICH COATINGS 66ss x 67PD PE 12.0 18.0 24.0 15 265
67VT x 67PB PE 9.5 14.1 19.1 12 267VT
Note: PE - Pressure External SP - Siphon External PI - Pressure Internal
TYPE OF FLUID FLUID NOZZLE CFM AT MAX. FLUID NEEDLE NOS.
TO BE SPRAYED X AIR TYPE 30 50 70 PATTERN FOR SPRAY GUN
NOZZLES PSI PSI PSI AT 8” MODEL 21
5

6
NOTES

7
NOTES

3/11 ©2011 ITW Finishing Equipment Americas All rights reserved. Printed in U.S.A.
U.S.A./Canada Customer Service
ITW Finishing Equipment Americas
195 Internationale Blvd.
Glendale Heights, IL 60139
630-237-5000
Toll Free Customer Service
and Technical Support
800-992-4657
Toll Free Fax
888-246-5732
Binks Sales and Service: www.binks.com
WARRANTY
This product is covered by Binks’ 1 Year Limited Warranty.
77-1143R-18 Revisions: (P2) Added warnings;
(P4) Updated Parts List; (P8) Updated contact
information.
