BioMedical Life Systems, Inc. QuadStar Elite User manual

1
PREFACE
The QuadStar®Elite is a unique Electrotherapy system incorporating
the following:
• Four modalities- T.E.N.S. (Transcutaneous Electrical Nerve
Stimulation), N.M.S. (NeuroMuscular Stimulation), I.N.F. (Inter-
ferential Stimulation) and HVPS (High Volt Pulsed Stimulation)
• Four waveforms- Symmetrical Biphasic Square Wave, Asym-
metrical Biphasic Square Wave, Sine Wave, and Monophasic
High-Volt, Twin Peak Wave.
• Four channels allowing the use of up to eight electrodes at a
time
• Pre-programmed and programmable functions
• "Sequential Stimulation" enabling the user to sequence two or
more modalities for complete treatment
• Patient Lock/Compliance System: enables the practitioner/phy-
sician to lock the parameters for ease of use for the patient, and
monitor hours of use.
• Timer - to time treatments
• Comes ready to use, with all accessories, and is powered by a
rechargeable battery pack (included) or Wall Adapter.
This booklet gives the health practitioner/physician an overview of
the QuadStar®Elite device functions. This information is offered in
condensed format; should you have further questions, please consult
your health practitioner or physical therapist.

2
WAVEFORMS - DEFINED
The amplitude, pulse rate, pulse
width and the mode selectors
operate independently of each
other, but interact to achieve
the desired result. As individual
syndromes differ, the controls
are adjusted to a setting which
gives optimal comfort and pain
relief.
Amplitude: The amplitude con-
trols the intensity and the depth
of the pulse. The higher the
amplitude, the higher the pulse
peak and the stronger the pulse.
If the electrodes are placed over
scar or over adipose tissue, care
should be taken that the am-
plitude is set at a level that is
both effective for the patient’s
treatment and does not cause the
patient any discomfort. Set the
QuadStar® Elite amplitude
to the appropriate level accord-
ing to patient comfort. There is
no benefit to painful stimulation.
.
Pulse Width: The pulse width
governs the width of the pulse.
A comfortable sensation cover-
ing the injured area is the main
purpose of the pulse width. The
pulse width has been fixed (pre-
set) in the QuadStar®Elite In-
terferential Modality and HVPS
Modality.
Pulse Rate: The pulse rate
controls the number of pulses
emitted through the electrode to
the skin.
The pulse rate is also referred
to as:
1. Frequency
2. Cycles per second (c.p.s.)
3. Pulses per second (p.p.s.)
4. Pulse Pairs per Second
(p.p.p.s, High-volt
modality only)
A Hertz (Hz) is a unit of fre-
quency equal to one pulse per
second, e.g. 50 Hertz = 50 p.p.s

3
QuadStar®Elite General Specications
Dimensions: 18.5 oz (574 g)
Weight: 5.55" x 5.25" x 1.65" (14.1 cm x 13.40 cm x 4.15 cm)
Power Supply: Internal Battery P/N QSE 601 NiCad Battery Pack;
External Specified Power Supply: P/N L60071 Medical
Grade Power Supply.
Channels: (4) for INF, N.M.S., and T.E.N.S.
(2) Active (red) & (1) Dispersive (black) for High Voltage
Timer: 0-99 minutes
*Use only in temperatures 0-40 degrees Celcius
ACCESSORIES
1. One QuadStar®Elite device
2. Electrodes
3. (4) Lead Wires - Style L00013MC
(2) GV0014R (red single wires) and
(1) GV0014B (Black single wire)
Please Note: Use only BioMedical Life Systems, Inc. approved accessories.
Non-approved accessories may damage your device.
Caution: Improper use of electrodes may cause burns. Care should be exer-
cised to use only electrodes specied by BioMedical Life Systems, Inc. Maxi-
mum output value allowed for the electrodes recommended is 2mA RMS/cm2.
For indoor use only.
Do not use electrodes smaller than those suggested in this manual.
Equipment not suitable for the use in the presence of a ammable anesthetic
mixture or with air or with oxygen or nitrous oxide.
CHANGING MODALITIES AND/OR MODES
"THE MAIN MENU"
Press the “”Mode” key (2) to access the Main Menu. Use keys (4) and (6) to
scroll through the modality choices; INF, NMS, TENS, Hi-Volt or Sequen-
tial. When the modality you wish to choose blinks, press the “Enter” key (8)
to accept, and a drop down menu will appear with the mode options for
the chosen modality. Use the (5) and (7) keys until the desired mode blinks
and press the “Enter” key (8) to choose the mode.
SPECIFICATIONS AND SAFETY INFORMATION:
4. Wall Adapter
5. One set of instructions

4
INTERFERENTIAL(INF) STIMULATION
Selecting INF Stimulation: Turn the device on by pressing the Pow-
er key (1). Press the Mode key (2) to access the main menu. Use
keys (4) and (6) to navigate the menu until “INF” blinks. Press the
Enter key (8) to select INF.
12 3 4
12 13 14 15
2
13
9
10 11
4
5
7
6
8

5
INTERFERENTIAL SAFETY INFO.
Federal law (USA) restricts this device to sale or use by, or on the order of, a
physician so licensed by the state. For external use only. Keep out of reach
of children.
Indications: Interferential Stimulation is used for symptomatic relief and
management of chronic (long-term) intractable pain and/or as an adjunctive
treatment in the management of postsurgical and post-traumatic acute pain.
Contraindications: Interferential stimulation devices can affect the opera-
tion of demand-type cardiac pacemakers. TENS is not recommended for
patients with known heart disease without a physician's evaluation of risk.
Do not stimulate over the eyes or carotid sinus nerves. Do not apply Interfer-
ential stimulation devices for 1. undiagnosed pain syndromes until etiology is
established, 2. electrode placement that causes current to flow transcerebrally
(through the head).
Warnings: This device should be used only under the continued supervision
of a physician. Interferential stimulation is ineffective for pain of central
origin, (i.e. appendicitis, hepatitis). Interferential stimulation is of no cura-
tive value; it is a symptomatic treatment which suppresses pain sensation
which would otherwise serve as a protective mechanism on the outcome of
the clinical process. Safety of Interferential stimulation devices for use dur-
ing pregnancy or delivery has not been established. Electronic equipment
such as EKG monitors and EKG alarms may not operate properly when In-
terferential stimulation is in use. This device should not be used over metal
implants or sleep apnea monitors.
Precautions: Skin irritation may occur under electrodes in isolated cases
following long-term application. Consult physician if skin irritation devel-
ops. Avoid adjusting controls while operating machinery or vehicles. Turn
the stimulator off before applying or removing electrodes. Long-term stimu-
lation at the same electrode site may cause skin irritation. Use only for the
specific pain problem prescribed by the physician. Effectiveness is depen-
dent upon patient selection. Do not immerse device in water or other liquids.
Adverse Reactions: Possible allergic reaction to tape or gel. Possible skin
irritation or electrode burn under electrode.

6
Waveform: Continuous Sinusoidal
Output Voltage: 0-39 Volts peak to peak
Output Current: 0-78 milliamps peak to peak
Carrier Frequency: 4000 Hz, fixed
Interference Frequency: 4001-4150 Hz, adjustable
Difference Frequency: 1-150 beats per second, adjustable
Pulse Width: 125 microseconds for each phase
Max. Charge per Cycle: 12.5 micro coulombs
(Output parameters are across a 500 ohm resistance)
For Interferential stimulation use the 2 x 2 inch square electrodes
provided in the kit and the L00013 leadwires.
INTERFERENTIAL SPECIFICATIONS
A1 is the negative electrode
(black pin-end) and A2 is the
positive electrode (red pin-end)
from Channel 1 (or Channel 3).
B1 is the negative electrode and
B2 is the positive electrode from
Channel 2 (or Channel 4).
Figure (1), Opposite:

7
INTERFERENTIAL GENERAL INFORMATION
Interferential Point
A1
A2 B2
B1
➞
BioMedical Life Systems, Inc.’s
Model QuadStar®Elite offers the latest
advances in Interferential Stimulation
Treatment. Interferential Stimula-
tion is different to that stimulation
received from using TENS or NMS.
In TENS and NMS stimulation, low
frequencies or pulses per second are
used over a wide area to achieve pain
relief. Most stimulation is directly
under the electrodes and radiates out.
In Interferential therapy, two medium
frequencies of different cycles are
used in such a way that they criss-
cross, delivering a low frequency at a
specific point.
The QuadStar®Elite has two types of frequency. One that is fixed at 4000
cycles per second and the other which is adjustable within the range 4001 to
4150 cycles per second. This in combination allows one to stimulate from 1
to 150 pulses per second, at a specific point.
The QuadStar®Elite has four channels, which can be used with two, four or
eight electrodes, and has four different stimulation patterns. At low levels
of stimulation the QuadStar®Elite‚stimulates the sensory nerve cells that are
used for pain relief.
Difference
Freq. Waveform
Output
Ch. 1 & 3
Output
Ch. 2 & 4
Ch. 1 & 3 and Ch. 2 & 4 added = difference frequency variable 1
- 150 pulses per second
(Refer to page 6 for explaination)
Figure (1)

8
INTERFERENTIAL OPERATING INSTRUCTIONS
The blinking option is able to
be selected at any given time.
Scroll through the modes by
using the (5) and (7) keys and
press (8) to Enter the selection.
Changing the Frequency
(Pulse Rate/Hz):
In the Interferential (INF)
modality,the frequency can be
changed in CONST Mode only,
to do so, press the (9) key and
the “Hz” value will blink. Use
the (5) and (7) keys to change
the value and the (8) key to ac-
cept the value.
Setting the Timer:
To set the timer to time the
treatment press the (3) key and
the timer function will blink.
Use the (5) and (7) keys to se-
lect desired time in minutes and
the (8) key to accept the value.
Choosing “Full Interferen-
tial” or “Pre modulated”
Stimulation:
Button (10) is used solely in
INF mode and allows one to
choose “pre modulated stimula-
tion” (using up to two channels
There are four Mode Choices
for Interferential on the drop
down menu:
CONST: Stands for Constant
Stimulation and can be defined
here as a continuous sinusoidal
waveform output set at a user
selected beat frequency. (Ad-
justable 1-150 Hz.)
SWEEP 1: Beat frequency of
the sinusoidal waveform modu-
lates from 1-10 Hz and back
over 12 seconds (6 second
increase; 6 second decrease).
Used for edema and inflamma-
tion reduction.
SWEEP 2: Beat frequency of the
sinusoidal waveform modulates
from 80-150Hz and back over
16 seconds (8 second increase; 8
second decrease). Used for pain
relief.
SWEEP 3: Beat frequency of
the sinusoidal waveform modu-
lates from 1-150Hz and back
over 20 seconds (10 second
increase; 10 second decrease).
Used for both pain relief and
edema/inflammation reduction.

9
INTERFERENTIAL OPERATING INSTRUCTIONS
where each channel operates as
an independent Interferential
pair and beat frequency is cre-
ated inside the device) or “full
interferential stimulation” (4
channels where channels 1&2
act as a pair and channels 3&4
act as a pair and beat frequency
is created inside the body).
When key (10) is pressed, the
diagram on the LCD will toggle
between two patterns. The two-
electrode pattern indicates pre-
modulated stimulation and the
four-electrode pattern indicates
full interferential stimulation
mode.
Interferential pairs in full Inter-
ferential Stimulation Mode:
Channels 1 & 2 (pair):
Channel 1 - fixed rate
Channel 2 - modulating/adjust-
able rate
Channels 3 & 4 (pair):
Channel 3 - fixed rate
Channel 4 - modulating/adjust-
able rate
Active Channels in Pre modu-
lated Stimulation Mode:
Channel 1 (Operates indepen-
dently)
Channel 3 (Operates indepen-
dently)
(Channels 2 and 4 are non-oper-
ational in Pre-modulated Mode)
Insertion of Lead Wires and
Electrodes
Insert pin connector of lead wire
into pig tail of electrode. (When
inserting or removing pin con-
nector, grasp connector—not
lead wire—to prolong lead wire
life.) For some electrode loca-
tions, it may be preferable to
insert the pin connection before
attaching the electrode to the
skin. Follow the directions on
the package of electrodes for
further information.
Beginning Stimulation:
When satisfied with all parame-
ters and nothing on the screen is
blinking or “active,” press keys
12, 13, 14 and 15 in the upward
direction repeatedly to set de-
sired intensity. Doing so starts
the stimulation through

10
INTERFERENTIAL OPERATING INSTRUCTIONS
the electrodes to the skin, and
controls the intensity of the
device. Do not press buttons
12-15 until the user is ready for
stimulation. In full interferential
mode, either button of a channel
pair (1&2 or 3&4) will change
the intensity of both channels.
The LCD display will begin
to show bars under the corre-
sponding channel to indicate the
intensity is being adjusted and
will remain illuminated.

11
NMS STIMULATION
12 3
12 13 14 15
2
13
9
10 11
4
5
7
6
8
4
Selecting NMS Stimulation: Turn the device on by pressing the
Power key (1). Press the Mode key (2) to access the main menu. Use
keys (4) and (6) to navigate the menu until “NMS” blinks. Press the
Enter key (8) to select NMS.

12
Federal law (USA) restricts this device to sale or use by, or on the
order of, a physician so licensed by the state. For external use only.
Keep out of reach of children.
Indications: External electrical neuromuscular stimulation using
biphasic output is indicated as therapeutic adjunct for: prevention
or retardation of muscle disuse atrophy; relaxation of muscle spasm;
muscle reeducation; maintaining and increasing the range of motion;
increasing local blood circulation and as immediate postsurgical
stimulation of calf muscles to prevent venous thrombosis.
Contraindications: Powered muscle stimulators should not be used
on patients with cardiac demand pacemakers.
Warnings: The long-term effects of chronic electical stimulation are
unknown. Stimulation should not be applied over the carotid sinus
nerves, particularly in patients with a known sensitivity to the ca-
rotid sinus reflex. Stimulation should not be applied over the neck or
mouth. Severe spasm of the laryngeal and pharyngeal muscles may
occur and the contractions may be strong enough to close the airway
or cause difficulty in breathing. Stimulation should not be applied
transthoracically in that the introduction of electrical current into
the heart may cause cardiac arrhythmias. Stimulation should not
be applied transcerebrally. Stimulation should not be applied over
swollen, infected, or inflamed areas or skin eruptions, e.g., phlebitis,
thrombophlebitis, varicose veins, etc. Stimulation should not be ap-
plied over, or in proximity to, cancerous lesions.
NMS SAFETY INFORMATION

13
NMS SAFETY INFORMATION
Precautions: Safety of powered muscle stimulators for use during
pregnancy has not been established. Caution should be used for pa-
tients with suspected or diagnosed heart problems. Caution should
be used for patients with suspected or diagnosed epilepsy. Caution
should be used in the presence of the following:
a.When there is a tendency to hemorrhage following acute trauma or
fracture;
b. Following recent surgical procedures when muscle contraction
may disrupt the healing process;
c. Over the menstruating or pregnant uterus; and
d. Over areas of the skin which lack normal sensation.
Some patients may experience skin irritation or hypersensitivity due
to the electrical stimulation or electrical conductive medium. The
irritation can usually be reduced by using an alternate conductive
medium, or alternate electrode placement. Electrode placement and
stimulation settings should be based on the guidance of the prescrib-
ing practitioner. Powered muscle stimulators should be used only
with the leads and electrodes recommended for use by the manufac-
turer. Portable powered muscle stimulators should not be used while
driving, operating machinery, or during any activity in which invol-
untary muscle contractions may put the user at undue risk of injury.
Adverse Reactions: Possible allergic reaction to tape or gel. Pos-
sible skin irritation or electrode burn under electrode.

14
NMS SPECIFICATIONS
Waveform: Symmetrical, biphasic, square or Asymmetrical,
biphasic, square
Output Current: Continuously adjustable from 0-120 mA peak-peak
Output Voltage: Continuously adjustable from 0-60V peak-peak
Pulse Rate: Adjustable 1-120 Hz. A Pulse Rate of less than 60
Hz should be used if repeated muscle contractions
are desired. A Pulse Rate of at least 10 Hz should
be used if forceful, tetanic muscle contractions are
desired.
Pulse Width: Adjustable 50-400 uS
Modes: Constant: Use the Constant Mode or a Pulse
Rate greater than 60 Hz for the physiological
range (e.g.,greater than 60 Hz) could lead to
rapid onset of muscle fatigue, making the device
less effective in producing repeated forceful
muscle contractions.
Cycled
Reciprocating
Ramp On: 0-10 seconds
On Time: 0-99 seconds
Ramp Off: 0-10 seconds
Off Time: 0-99 seconds
Delay: 0-99 seconds
(Output parameters are across a 500 ohm resistance)

15
Neuromuscular Stimulation
(NMS) is the use of electrical
stimulation on muscle groups to
contract and reeducate muscles.
Some of the uses of NMS are as
follows:
1. The Prevention or Retarda-
tion of Muscle Disuse Atrophy:
Muscle disuse atrophy is a re-
duction in muscle contraction
and size due to disuse/lack of
use resulting from prolonged
impairment or joint immobility
from surgery or injury.
2. Relaxation of Muscle
Spasms: Muscle spasms often
occur in areas of localized pain
and tenderness. Stimulation is
used to fatigue the spasmodic
muscle.
3. Increasing Local Blood
Circulation:Rhythmic muscle
contraction helps improve local
blood circulation.
4. Immediate Post surgical
Stimulation of Calf Muscles to
Prevent Venous Thrombosis:
The use of NMS or EMS to
increase local blood circulation
assists in the prevention of ve-
nous thrombosis.
INTRODUCTION TO NEUROMUSCULAR STIMULATION
For Neuromuscular Stimulation
use the 2 x 2 inch square elec-
trodes provided in the kit.
Turn the device on by press-
ing the power key (1) Press the
“Mode” key (2) to access the
Main Menu.
To choose the NMS modality
use the (4) and (6) keys until
“NMS” blinks and press (8) to
select. (To choose a different
modality please skip to the sec-
tion that applies)
A drop-down menu appears and
there are four options:
I. PROGRAMMABLE
MODES:
1.CONST: Stands for Constant
Stimulation and can be defined
here as a continuous output of
a square waveform; output set
at a user selected pulse rate,
pulse width, and waveform type
(asymmetrical or symmetrical.)
2.CYCLED: Stands for Cycled
Stimulation. The output of user-
selected waveform will operate
in a series of timing functions
which will occur simultaneously
between channels.

16
PRESET THERAPIES
Therapy 1 (CYCLED)
35 Hz, 400 µS, Symmetrical Bi-
phasic Waveform
RAMP ON 2 sec.
RAMP OFF 2 sec.
CH 1/2/3/4 ON 10 sec.
CH 1/2/3/4 OFF 30 sec
Includes ON RAMP, ON TIME,
OFF RAMP, OFF TIME, and
DELAY. (See section on Cycled
Stimulation for more detail)
3.RECIP: Stands for Reciprocal
Stimulation. The output of user-
selected waveform will operate
in a series of timing functions
which will be delivered in an al-
ternating method. Includes ON
RAMP, ON TIME, OFF RAMP,
& OFF TIME. (See section on
Reciprocal Stimulation for more
detail)
II. PRESET THERAPIES/
FIXED:
4. Therapies 1-9: These are pre-
set therapies for common indi-
cations. The waveform options
and the timing options cannot be
altered when choosing a preset
therapy, however the user will
still be able to manipulate the
Intensity and the Timer.
Therapies 1-9 are preset NMS
therapies made up of Constant,
Cycled or Reciprocal modes
with fixed parameters
and timing options if applicable.
They are fixed therapies and
cannot be altered. To set differ-
ent settings, choose CONST,
CYCLED or RECIP, the pro-
grammable therapies in the unit.
To Choose one of the options
use the up and down keys (5)
and (7) until the option you wish
to select blinks, then press “E”
(8) to accept. Note: To scroll
through the Therapies press the
(7) key repeatedly when “Thpy”
is blinking and numbers 1-9 ap-
pear one at a time. To choose
one press “E” (8).
NMS OPERATING INSTRUCTIONS

17
Therapy 2 (CYCLED)
35 Hz, 400 µS, Assymmetrical
Biphasic Waveform
RAMP ON 2 sec.
RAMP OFF 2 sec.
CH 1/2/3/4 ON 10 sec.
CH 1/2/3/4 OFF 30 sec
Therapy 3 (RECIPROCAL/
ALTERNATING)
40 Hz, 400 µS, Symmetrical Bi-
phasic Waveform
RAMP ON 4 sec.
RAMP OFF 4 sec.
CH 1/2 ON 10 sec.*
CH 1/2 OFF 10 sec.*
CH 3/4 ON 10 sec.*
CH 3/4 OFF 10 sec.*
*CH 1/2 and CH 3/4 alternate.
CH 1 and 2 will cycle together,
CH 3 and 4 will cycle together.
Therapy 4 (CYCLED)
40 Hz, 400 µS, Symmetrical Bi-
phasic Waveform
RAMP ON 4 sec.
RAMP OFF 4 sec.
CH 1/2/3/4 ON 10 sec.
CH 1/2/3/4 OFF 10 sec.
Therapy 5 (CYCLED)
140 Hz, 400 µS, Alternating Ay-
smmetrical Biphasic Waveform
RAMP ON 2 sec.
RAMP OFF 2 sec.
CH 1/2/3/4 ON 10 sec.
CH 1/2/3/4 OFF 30 sec.
Therapy 6 (CYCLED)
30 Hz, 400 µS, Symmetrical Bi-
phasic Waveform
RAMP ON 2 sec.
RAMP OFF 2 sec.
CH 1/2/3/4 ON 15 sec.
CH 1/2/3/4 OFF 20 sec
Therapy 7 (CYCLED)
50 Hz, 180 µS, Symmetrical Bi-
phasic Waveform
.
NMS OPERATING INSTRUCTIONS

18
RAMP ON 2 sec
RAMP OFF 2 sec.
CH 1/2/3/4 ON 10 sec.
CH 1/2/3/4 OFF 20 sec.
Therapy 8 (CYCLED)
20 Hz, 250 µS, Symmetrical Bi-
phasic Waveform
RAMP ON 2 sec.
RAMP OFF 2 sec.
CH 1/2/3/4 ON 5 sec.
CH 1/2/3/4 OFF 10 sec.
Therapy 9 (CONSTANT)
10 Hz, 50 µS, Symmetrical Bi-
phasic Waveform
(There are no timing options in
CONSTANT)
PROGRAMMABLE
THERAPIES:
CONSTANT STIMULATION:
Press the “Mode” Key (2) scroll
using the (4) and (6) buttons
until “NMS” blinks. Press the
“Enter Key” (8) to choose Con-
stant Stimulation.
To change parameters see
“Changing Pulse Width/Pulse
Rate and Waveform (Param-
eters)”
CHANGING PULSE WIDTH/
PULSE RATE AND WAVE-
FORM (PARAMETERS):
•To change the parameters of
the current setting; press the (9)
PR/PW key and the number next
to “Hz” will begin to blink. Hz
is the abbreviation for “Hertz”
also known as “Pulse Rate” or
“PR”
•To change the PR (Hz) press
buttons (5) or (7) to increase
or decrease the value until the
desired number is displayed. To
accept the value press the “Enter
Key” (8).
•The device automatically pro-
gresses to the next parameter
“µS” which stands for micro-
seconds also know as “Pulse
Width” or “PW”; and the cor-
responding number flashes.
•To change the PW (µS) press
buttons (5) or (7) to increase or
decrease the value until the de-
sired number is displayed. To
NMS OPERATING INSTRUCTIONS

19
accept the value press the “Enter
Key” (8).
•The device automatically
progresses to the next adjust-
able parameter; the waveform.
•There are two waveform op-
tions in Muscle Stimulation;
Asymmetrical Biphasic Square
and Symmetrical Biphasic
Square. You can toggle between
the two waveforms by pressing
the (5) or (7) keys. When the
desired waveform is selected
press “Enter” (8) to make the
selection.
•When all flashing ceases; the
parameters have been set. Set
the timer if desired by pressing
the timer button (3) and using
the (5) and (7) keys to set the
desired amount of time in min-
utes. Press “Enter” (8) to accept
the value.
•You may, at this time, choose
to begin stimulation by pressing
buttons (12)-(15) upward to be-
gin to turn up the intensity.
CYCLED STIMULATION:
Press the “Mode” Key (2) scroll
using the (4) and (6) buttons
until “NMS” blinks. Press the
(7) key to scroll down to Cycled
and press “Enter Key” (8) to
choose Cycled Stimulation.
TIMING DEFINITIONS:
ON RAMP: The device’s inten-
sity will gradually build up to
maximum user-defined intensity
setting over a set number of
seconds.
ON TIME: How long the device
will be on - including the ramp
times in a cycle.
OFF RAMP:The device’s inten-
sity will gradually decrease to
intensity setting of zero over a
set number of seconds in a given
cycle.
OFF TIME: How long the de-
vice will be off before the cycle
is repeated.
DELAY: The amount of “pause”
time after CH 1/2 starts stimula-
tion before CH 3/4 begins it’s
cycle.
NMS OPERATING INSTRUCTIONS

20
The screen prompts the user
to define the timing options
for the cycle. The first part of
the blinking diagram indicates
RAMP ON and there is a value
on the bottom right hand side of
the screen. To change the num-
ber of seconds for the RAMP
ON value press the (5) or (7)
keys until desired time is shown
and then press the “Enter Key”
(8) to accept the value.
The screen will then prompt the
user to enter the OFF RAMP
time and there is a value on the
bottom right hand side of the
screen. To change the number
of seconds for the RAMP OFF
value press the (5) or (7) keys
until desired time is shown and
then press the “Enter Key” (8)
to accept the value
The screen will then prompt
the user to enter the ON TIME
for CH1/2. Remember, the ON
TIME includes both of the ramp
times the user has already en-
tered. For example, if you want
the stimulation to ramp up for 2
seconds, stay at peak amplitude
for 10 seconds, and then ramp
off for 2 seconds
the ON TIME would need to
read 14 seconds, or the sum of
the values. To change the num-
ber of seconds for the ON TIME
value press the (5) or (7) keys
until desired time is shown and
then press the “Enter Key” (8)
to accept the value.
The screen them prompts the
user to enter CH 1/2 OFF TIME.
To change the number of sec-
onds for the OFF TIME value
press the (5) or (7) keys until
desired time is shown and then
press the “Enter Key” (8) to ac-
cept the value.
The screen then prompts the
user to enter a DELAY time if
desired. To change the number
of seconds for the DELAY value
press the (5) or (7) keys until
desired time is shown and then
press the “Enter Key” (8) to ac-
cept the value.
Next, the display prompts the
user to enter CH 3/4 ON TIME.
This value must be EQUAL to
CH 1/2 ON TIME, so it cannot
be altered. Press “Enter Key”
(8) to accept the value.
NMS PROGRAMMABLE FUNCTIONS
