Birlea CORONA 2 DOOR 5 DRW SIDEBOARD User manual

1880mm
1035mm
566mm
4 m
4m
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR
USING YOUR CORONA 2 DOOR WARDROBE.
ASSEMBLY INSTRUCTIONS
CORONA 2 DOOR WARDROBE
Vendor: S000238
!
f
You
Tube
www.birlea.com
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CARE & MAINTENANCE:
Assemble in the room of use.
To avoid damages assemble the item on a soft, clean surface
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the item as this will damage the base.
Always lift the item with two people to reposition.
Keep any sharp objects away from the item.
This product is manufactured in pine which is a wood with natural characteristics including knots, grains,
clusters or indentations.
On unpacking the item you may notice an odour due to production processes but this will disappear after a
period of time.
DO NOT place the item next to a radiator or direct sunlight – this item is susceptible to temperature change.
It is recommended an even room temperature be maintained with no sudden fluctuations.
DO NOT place hot or cold items directly onto the surface of the item as marking will occur
For general cleaning use a duster or damp cloth (almost dry) not wet – do not use soap and water,
detergents, aerosol sprays or any polish as use of these materials would invalidate any claims.
DO NOT place the item onto wet or damp flooring as staining may occur to the floor.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn.
DO NOT use this item unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
It is recommended that two people handle and assemble the item.
Birlea advise you use the wall straps provided to further enhance the safety of this product.
Page 1 of 12

1
2
3
3
4
5
9
10
11 11
14
19
6
7
8
20
17
16
13
12
15
18
Vendor: S000238
Page 2 of 12

Recycle
2m
01 2 345 6 7891 0
mm 1 1 1 2 1 3 1 4 1 5 1 6
** You will need a small mallet and a screwdriver.
Q
Wall Strap 1
Washer 2
P
PARTS LIST
Part Item Qty
HARDWARE LIST
Part Item Qty
11 Wooden dowel
14mm Screw
25mm Screw
35mm Screw
Hinge
Handle
19mm Bolt
Clip
Plug
Tack
Stud
A
D
G
K
B
E
H
L
C
F
J
12
51
19
10
3
2
2
6
2
Right Panel
Left Panel
Back Panel
Left Front Frame
Right Door
Left Door
Door Divider
Large Spine
Top Panel
Right Front Frame
Base/Shelf Panel
Outer Top Plinth
Inner Top Plinth
Bottom Front Frame
Front Plinth
Bottom Side Plinth
Top Side Plinth
Hanging Rail
Small Spine
Cleat
12
23
14
15
16
17
18
19
1
10
211
112
1
13
114
1
15
2
16
217
1
18
1
19
7
20
M
N
30mm Screw
36
50mm Screw
2
O40
2
2
Hanging Rail Support
Vendor: S000238
Page 3 of 12

Step 1: Insert the right panel (1) into the right front frame (4) ensuring parts are fully
pushed together and correctly lined up. Place the cleats (20) between the marks shown
and secure using hardware part E and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
150mm
100mm
100mm
590mm
590mm
100mm
150mm
1
20
4
Yes!No!
4
1
20
20
20
E
E
Top
Step 2: Insert the left panel (2) into the left front frame (5) ensuring parts are fully
pushed together and correctly lined up. Place the cleats (20) between the marks shown
and secure using hardware part E and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
150mm
100mm
100mm
590mm
590mm
100mm
150mm
20
Yes!No!
20
20
20
E
E
Top
2
5
5
2
Note: this side lined up.
Note: this side lined up.
Vendor: S000238
Page 4 of 12

Step 3: Insert hardware part A using a small mallet (not provided). Secure hardware part M to the
right panel (1) and left panel (2) using hardware part B and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
11
11
14
11
2
2x
14
11
1 2
and
M
B
A
A
AA
Step 4: Attach the base/shelf panels (11) to the left panel (2) using hardware part E and a screwdriver (not provided).
Insert the bottom front frame (14).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
E
E
E
Vendor: S000238
Page 5 of 12

Step 5: Attach the right panel (1) and a cleat (20) using hardware part E and a screwdriver
(not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
13
4
5
Step 6: Attach the inner top plinth (13) using hardware part C and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
C
13
C
20
11
14
1
11
E
E
E
11
11
14
E
E
Vendor: S000238
Page 6 of 12

Step 7: Attach the outer top plinth (12) using hardware part F. Attach the top side plinths (17)
using hardware part D. You will need to use a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 8: Attach the top panel (10) using hardware part C and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
b:
a:
7mm
17
D
12
F
17
17
D
D
F
12
Note:
10
C
10
10
Vendor: S000238
Page 7 of 12

Step 9: Attach the bottom side plinths (16) and front plinth (15) using hardware part D and
a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 10: Insert hardware part N using a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
15 16
16 D
D
D
52mm
46mm
46mm
N
N
N
Vendor: S000238
Page 8 of 12

8
8
6
7
Step 11: Insert the hanging rail (18).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
18
Step 12: Attach hardware part J to the right door (6) and left door (7) using hardware part B. Attach the door
divider (8) using hardware part D. You will need to use a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
B
JD
J
J
J
J
J
J
Vendor: S000238
Page 9 of 12

Step 13: Position the doors and secure using hardware part B and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 14: Attach hardware part H using hardware part G and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
H
G
6
7B
Vendor: S000238
Page 10 of 12
H
H

Step 16: Join the back panels (3) using the large spine (9) and small spine (19) and secure using hardware
part O and a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
319
9
3
3
3
O
9
19
6
B
B
Step 15: Attach hardware part K using hardware part B, ensuring the small wheels are flush
with the base edge. Insert hardware part L ensuring they are level, then push the door against
the hardware to make two small marks on the door. Secure hardware part L using hardware part B.
You will need to use a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
a: b:
c: d:
K
K
L
L
6
L
L
K
K
O
O
Vendor: S000238
Page 11 of 12

Step 17: Furniture must be fixed to a wall.
Fix wall strap P to top of furniture using washer Q and screw B .
With help, move furniture into position.
Wall plugs not supplied. The correct type of fixing must be used for your wall, seek professional
advice if in doubt.
Vendor: S000238
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
wall
B
Q
P
Q
Page 12 of 12
