Birlea VALENTINO 2 DRAWER User manual

Vendor: S000013
Page 1 of 11
ASSEMBLY INSTRUCTIONS
VALENTINO 2 DRAWER 4’6 BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR VALENTINO 2
DRAWER 4’6 BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
lways use on a level, even surface.
WARNING: If his bed is placed on a non-carpe ed floor you mus place some pro ec ion under all legs o s op
he bed frame from moving. If his is no adhered o here is no guaran ee if he bed frame collapses.
CARE & MAINTENANCE:
ssemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
lways lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com

Vendor: S000013
Page 2 of 11
1 2 3
4 5 6
7 8 9
10 11 12
13 14 15
16 17 18
19

Vendor: S000013
Page 3 of 11
Par s Lis Hardware Lis (Found in box 3)
Par Descrip ion Box Q y Par Descrip ion Q y
1 Headend 1 1 A 8 x 25 mm Plastic Dowel 15
2 Footend 1 1 B M6 x 40 mm JCBC 9
3 Side Rail 2 2 C M6 x 40 mm JCBC 10
4 Solid Slats 4 1 D M6 x 60 mm JCBC
2
5 Centre Rail 2 1 E M3.5 x 16 mm CSK
24
6 Support Leg 3 2 F M4 x 25 mm CSK
1
7 Drawer Runner Pack 1 3 4 G M4 x 32 mm CSK 18
8 Drawer Runner Pack 2 3 4 H M4 x 50 mm CSK 16
9 Drawer Front 3 2 I M6 Flat Washer
2
10 Drawer Back 3 2 J Mini Fix Bolt 6
11 Drawer Base 3 2 K Mini Fix Housing 6
12 Drawer Side 3 4 L
Mini Fix Cap
6
13 Drawer Support 3 4 M 6/8 Tack 24
14 Drawer Frame Back 3 1
N
White Nail 9
15 Left Drawer Frame Side 3 1
O
llen Key 1
16 Right Drawer Frame Side 3 1
**You will need screwdriver nd sm ll
m llet (not provided)
17 Drawer Frame Divider 3 1
18 Left Drawer Frame Support 3 1
19 Right Drawer Frame Support 3 1
S ep 1: Join together the drawer front (9), drawer back (10) and drawer sides (12) using hardware part H and
a screwdriver (not provided). Repeat for the remaining drawer.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 4 of 11
S ep 2: Slide the drawer base (11) into position on both drawers. Secure with hardware part M and a small
mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 3: Secure the drawer supports (13) using hardware part G and a screwdriver.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 4: ttach the drawer runners from pack 1 (7) using hardware part E and a screwdriver (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 5 of 11
S ep 5: Insert hardware parts and N to the drawer frame back (14) using a small mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 6: ttach the drawer runners from pack 2 (8) to the left drawer frame side (15) using hardware part E
and a screwdriver (not provided). Insert hardware parts and N using a small mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 7: ttach the drawer runners from pack 2 (8) to the right drawer frame side (16) using hardware part E
and a screwdriver (not provided). Insert hardware parts and N using a small mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 6 of 11
S ep 8: ttach the drawer runners from pack 2 (8) to both sides of the drawer frame divider (17) using
hardware part E and a screwdriver (not provided). Insert hardware parts and N using a small mallet (not
provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 9: Insert hardware part to the left drawer frame support (18) using a small mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 10: Insert hardware part to the left drawer frame support (19) using a small mallet (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 7 of 11
S ep 11: Insert the left drawer frame side (15), right drawer frame side (16) and drawer frame divider (17) to
the drawer frame back (14).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 12: Secure using hardware parts B and O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 13: Insert and secure the left drawer frame support (18) using hardware parts B and O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 8 of 11
S ep 14: Insert and secure the right drawer frame support (19) using hardware parts B and O. Secure the
supports in the centre using hardware parts , K, J and O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 15: Insert hardware part to the footend (2) using a small mallet (not provided), then insert hardware
part J using a screwdriver (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 16: Undo the screws and washers in the headend (1) and footend (2), then attach them to the frame
using the screws, washers and hardware part J.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 9 of 11
S ep 17: Secure the frame using hardware parts C, G, I and O with a screwdriver (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 18: Insert hardware part J to the side rails (3) using a screwdriver (not provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 19: Secure the frame using hardware parts C and J.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 10 of 11
S ep 20: Loosen the pre-inserted screws on the headboard (1) using hardware part O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 21: Secure the frame using hardware parts L, K and O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 22: ttach the headend (1) using the pre-assembled screws and hardware part O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.

Vendor: S000013
Page 11 of 11
S ep 23: ttach the support legs (6) to the centre rail (5) and solid slats (4) using hardware parts D and O.
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
S ep 24: Place the slat section into the assembled frame and secure to the headend (1) using hardware part
F and a screwdriver (not provided). Secure the solid slats (4) using hardware part G and a screwdriver (not
provided).
DO NOT use any power ools as his may damage he frame and will invalida e any claim.
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
