Birlea JESPER User manual

IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO
ASSEMBLE OR USE YOUR 150CM JESPER SPINDLE BED.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY:
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
HEALTH & SAFETY:
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Always use on a level, even surface.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push this product as this will cause damage.
Always lift this product with two people to repositions.
Keep any sharp objects away from this product.
1
ASSEMBLY INSTRUCTIONS
150cm JESPER SPINDLE BED
5

02
04
05
05
03
03
06
01
Headboard
Footboard
Siderails
Centre Rail
Support Legs
Slats
01 1 1 A 2
8
8
8
8
1
28
8
1
1
Bolt
Guide Screw
Plastic Washer
Spring Washer
Flat Washer
Allen Key
Screws
Wooden Dowel
M10# Spanner
M6 Nuts
B
C
D
E
F
G
H
I
K
1
2
1
2
1 Set
1
2
2
1
1
02
03
04
05
06
Part List Hardware List(Box-2)
Part Description Description
Box QTY QTY
Part
01
02
H
B
Attach the hardware part B&H to Headboard(01) and footboard(02)
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
5

K
I
01
02
03
03
CED
Use Spanner(I) fix the Siderails(03) together with Headboard(01)&Footboard(02) by Hardware C,E,D,K.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Attach Support legs(05) to Centre Panel(04) using HardwareF,A.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
04
05
F
A
5

4Attach the Centre panel (04) to Headboard(01)&Footboard(02) by Hardware(G) with a
screwdriver(not provided).
DO NOT sue any power tools as this may damage the frame and will invalidate any claim.
5Attach the Slats(06) to Siderails(03) by Hardware(G) with a screwdriver(not provided).
DO NOT sue any power tools as this may damage the frame and will invalidate any claim.
5
G
G
04
05
06

FINISHED
5 5
