BIRO B350A Specification sheet

B350A
NSF 8-2010
Starting with Serial Number 12309
AUTOMATIC FEED SLICER
INSTALLATION, USE, MAINTENANCE
& PARTS MANUAL
REVISED 12-16-15

1

CONTENTS
FOREWARD 3
SCOPEOFTHISMANUAL 3
GENERAL SAFETY REGULATIONS 3
MANUFACTURER’S WARRANTY AND LIABILITY 4
PLATES-CONFORMITY MARKS 4
ENVIRONMENTAL CONDITIONS OF USE 4
PACKING 5
OPENING THE BOX 5
TECHNICAL DESCRIPTION AND PROPOSED CONDITIONS OF USE 6
GENERAL DESCRIPTION 6
MECHANICAL AND ELECTRICAL SAFETY DEVICES 6
WARNING: RESIDUAL RISKS 6
DIMENSIONS MAIN TECHNICAL DATA 7
SUPPLIED LITERATURE AND ACCESSORIES 8
PRODUCT THAT CAN BE SLICED 8
PRODUCT THAT MUST NOT BE SLICED 8
MAINCOMPONENTS 9
CONTROLPANEL 10
MACHINE COMMISSIONING AND FUNCTION TESTS 11
INSTALLING THE MACHINE 11
ELECTRICAL CONNECTION 11
MANUALUSE 11
USINGTHEMACHINE 12
LOADING THE PRODUCT ON THE TRAY AND SLICING 12
SLICING IN AUTOMATIC MODE 14
CLEANING THE MACHINE 17
GENERAL 17
DISASSEMBLING THE SLICER FOR CLEANING 17
DISASSEMBLING THE GUIDE BAR FOR CLEANING 19
CLEANING THE SLICER UNDERNEATH - LIFTING DEVICE 20
CLEANING AND SANITIZING THE BLADE 21
MAINTENANCE 22
GENERAL 22
INSPECTING THE SLICER FOR DAMAGED OR BROKEN PARTS 22
BLADESHARPENING 23
LUBRICATION 27
TROUBLESHOOTING AND REMEDIES 28
ELECTRICALDIAGRAMS 30
RECOMMENDED SPARE PARTS 32
SPARE PARTS DIAGRAMS 33
