BIRO B350MV Instruction Manual

B350MV
GRAVITY FEED FOOD SLICER
INSTALLATION, USE, MAINTENANCE
& PARTS MANUAL
MARBLEHEAD, OHIO 43440-2099 U.S.A.
Ph. 419-798-4451 Fax [phone]
[email protected] [email protected]
http://www.birosaw.com

GZ5L4G
Blade
GZ9MSB
Cleaning stone
GG111
Water-ring protection
GGRSTA
Electrical Box Assembly Mono-Phase 115V-60Hz
GZ9TCA
Single phase card 115V-60Hz
GAF03US
Sharpening assembly
GG5CIN
Trasmission Belt
Sharpening stone
GZ9MAF
BIRO
B 350 MV
Manual Slicer
Recommended Spare Parts
GZ9PIE
Foot
1

G9361
BIRO
B 350 MV
Manual Slicer X0180C
Z9PIE
G119C
X0560
2
Complete Assembly
Z8BCN
G0170
W6CUS
X0270
X0290
G102
G110
Z8BCN
G122
F9331500
CODE DESCRIPTION Q,TY
F9331500 SPRING d 10 L 55 1
G0170 ROD - INDEX SLIDE 1
G102 SLIDE - INDEX MECHANISM 1
G110 ROD - INDEX ANTI ROTATION 1
G119C SLIDE ROD - 25 x 578 1
G122 PIN - INDEX CAM 1
G9361 SLIDE INDEX COMPLETE ASSEMBLY
W6CUS SS BEARING 6000 ZZ 10 x 20 X 6 1
X0180C SS BAR - TRANSPORT ROLLER 1
X0270 BEARING PING 10 x 30 M6 1
X0290 GUIDE - INDEX MECHANISM 1
X0560 SS FOOT SPACER 25 x 44 M8 2
Z8BCN BUSHING 20 23 20E 2
Z9PIE FOOT 4

3
BIRO
B 350 MV
Manual Slicer
C2032
G9IMP
V160
V158
Z9MBP
V159
C2041 C2080
C2080
C2091
X030
CODE DESCRIPTION Q,TY
C2032 MEAT GRIP HOLDER 1
C2041 MEAT GRIP 1
C2080 BUSHING 2
C2091 HANDLE ASSY 1
V159 CARRIAGE TRAY 1
V160 SLIDE ROD ASSY 1
G9IMP HANDLE 1
V158 SUPPORT - TRAY ASSY 1
X030 KNOB SHAFT 1
Z9MBP KNOB - SUPPORT TRAY 1

4
X0260
X0520
X0271
X0210
X0120
Z9BCR
Z9BCR
M9307
G104
G114
X0110
G116
Z9FUN
X0240
X0230
G113
X0272
X0250
BIRO
B 350 MV
Manual Slicer G200 COMPLETE ASSEMBLY
CODE DESCRIPTION Q.TY
G104 CARRIAGE 1
G113 SHAFT - PIVOT RETURN 1
G114 COVER - CARRIAGE 1
G116 LOCKING CARRIAGE SHAFT 1
G200 COMPLETE CARRIAGE ASSEMBLY
M9307 BEARING 1
X0110 BRACKET 1
X0120 GUIDE PIN 1
X0210 CAP SCREW 1
X0230 LOCKING SUPPORT TRAY ASSY 1
X0240 LOCKING SHAFT MECHANISM 1
X0250 SPRING - LOCKING CARRIAGE 1
X0260 SPRING - CARRIAGE 2
X0271 SPACER - BEARING 1
X0272 BEARING PIN 1
X0520 LOCKING SHAFT MEC. PART 2 1
Z9BCR BUSHING 25 28 25 E 2
Z9FUN BUMPER - SLIDE ROD 2

5
BIRO
B 350 MV
Manual Slicer
G111
X0360
Z3ATQ
V150
G117
G112
G124
X0080
X0280
Z8MGR V152
V156
ZZVOL
V157
V151
G105
G120
Z5L4G
Z9GHI
X0491
V9364
COD DESCRIPTION Q.TY
G105 RING STUDBOLT 1
G111 BLADE SEAL 1
G112 GUAGE PLATE SEAL 1
G117 RING SPACER 1
G120 BLADE GUARD RING 1
G124 CAM 1
V
9364 BLADE GUARD ROD - ASSEMBLY
V150 FRAME 1
V151 GAUGE PLATE 1
V152 MEAT HOLDER 1
V156 SS COVER 1
V157 BLADE GUARD ROD 1
X0080 CAM SPACER 1
X0280 CAM SPACER 1
X0491 HANDLE COVER BLADE 1
ZZVOL BLADE GUARD ROD KNOB 1
Z3ATQ BLADE GUARD LOCKING SCREW 12x12 1
Z5LMC BLADE 350/57 mm 100Cr6 1
Z6COP BLADE GUARD 1
Z8MGR ADJUSTABLE KNOB 0:21 1
Z9GHI KNOB SPACER 76,6 1

BIRO
B 350 MV
Manual Slicer
W2CUS
M9314
W6CUS
G5CIN
G109 G106
M9313
G108
M9315
M9310
X0070
X0060
W2CUS
W6CUS
M9376
115/60 Hz
IP65
Motor Assembly
6
A64GM
115/60Hz
IP65
CODE DESCRIPTION Q.TY
A64GM MOTOR ASSEMBLY IP 65
G106 PULLEY B 350 M 1
G108 SHAFT - KNIFE 25 x 97 1
G109 SPACER 1
G5CIN BELT 2350/2370 G TB2 11 x 400 1
M9310 PIN 10 x 22 1
M9313 SPRING PIN 5 x 25 1
M9314 BEARING TENS. SPRING 1
M9315 BEARING PIN 1
M9372 MOTOR - IP 65 115 VOLT 60 Hz 1
W2CUS SS TRANSMISSION BEARING 2
W6CUS SS BEARING 6000 ZZ 10 x 20 X 6 2
X0060 CAP SCREW 1
X0070 LOCKWASHER 1

BIRO
B 350 MV
Manual Slicer
Complete Assembly
GRSTA
MONO-PHASE
115V-60Hz
7
115V-60Hz
Z9PLH Stop Switch
Z9PLA Start Switch Illuminated
X0720
W3CON
Z9TCA
X0710
CODE DESCRIPTION Q.TY
GRSTA COMPLETE CONTROL BOX
W3CON CAPACITOR 20 Mf 1
X0710 ELECTRIC BOX - BASE 1
X0720 PLASTIC COVER 1
Z9PLA START SWITCH - IP 69 1
Z9PLH STOP SWITCH - IP 69 RED 1
Z9KAP SWITCH PROTECTION 2
Z9TCA CARD 115/60Hz - 1

BIRO
B 350 MV
Manual Slicer
Complete Assembly
8
ZZVOL
AF037
AF038
AF039
AF035
AF036
AF040 AF039
AF038
AF03US
AF008
Z9MSB
AF006
AF033
Z9MAF
AF008
AF011
AF023
AF022
AF006
AF0020
AF022
CODE DESCRIPTION Q.TY
AF006 SHAFT - SHARP + CLEANING STONE 2
AF008 NUT - SPECIAL 2
AF011 SPRING - CLEANING STONE 1
AF03US SHARPENER - COMPLETE ASSEMBLY
AF020 SPRING - SHARPENING STONE 1
AF022 SCREW - PLASTIC 3
AF023 SCREW - MAIN GUIDE - PLASTIC 1
AF033 ARM 1
AF037 HOUSING 1
AF035 SHARPENER CAM 1
AF036 KNOB - SHARPENER 1
AF038 WASHER - PLASTIC 2
AF039 RING - RETAINER - UNI 7434 2
AF040 SCREW - TC 5 x 10 2
Z9MAF STONE - SHARPENING 1
Z9MSB CLEANING STONE 1
ZZVOL KNOB - BLADE G. + SHARPENER 1

GRSTS
MONO-PHASE
220V-50Hz
A65GM
MONO-PHASE
220V/50Hz
Motor Assembly
9
M9377
MONO-PHASE
220V/50Hz
Complete Assembly
BIRO
B 350 MV
220V/50Hz Version
Z3CON
Z9SCH
Mono-Phase
CODE DESCRIPTION Q.TY
A65GM MOTOR ASSEMBLY IP 65 220 - 50Hz
GRSTS COMPLETE CONTROL BOX 220/50 Hz
M9373 MOTOR - IP 65 - 220/50 Hz IP 65 1
Z9SCH CARD 220/50 Hz 1
Z3CON CAPACITOR 10 Mf 1
