Bitspower CR140 User manual

[ 1 ]
instruction manual
Accessories
Bitspower CR140 Reservoir V1
1BPM-WTCR140 1 SET
2Mounting bracket (short) 2 PCS
3Mounting bracket (long) 2 PCS
4M3x45mm Screw 4 PCS
5M3x5mm Screw 4 PCS
6M4x6mm Screw 4 PCS

[ 2 ]
Installation For Mounting bracket (short)
4
2
1
step 2
step 3
step 1
5
Assemble the M3x5mm screws Install the mounting bracket (short)
Dimension
Assembly steps
140
140
40
72.50
58
43
55
140

[ 3 ]
step 4
Installed in the chassis
Assembly steps
6

[ 4 ]
Assembly steps
step 3
step 2step 1
5
Installation For Mounting bracket (long)
step 3
Assemble the M3x5mm screws Install the mounting bracket (long)
Dimension
4
2
1
140
140
40
72.50
85
43
82
140

[ 5 ]
step 4
6
Installed in the chassis
Assembly steps

[ 6 ]
step 1
Recommend For Vertical stand(Additional purchases)
step 2
step 3
Method A
step 4
140
158
18
7
158

[ 7 ]
step 1 step 2
step 3
Method B
step 4
165
168
140
140
165
72.50 75.50

[ 8 ]
Recommend For Lighting module(Additional purchases)
step 1 step 2
step 3 step 4
Dimension (After installing the lighting module)
140
147 42.50
75
19
42.50
40
2.50
46
72.50
40
150

[ 9 ]
Dimension (After installing the lighting module and the vertical bracket)
The lighting module can be installed on surfaces in three di󽗈erent orientations.
140
140
61.70
165
168
140
140
165
72.50 75.50

[ 10 ]
記得上角要放對應的 LOGO!
Notice
Before filling in the water, please make sure all the components are
installed correctly. To prevent any leakage which may damage the PC
components, please perform a 24-hour leaking test with only the pump
connected to the power supply.
Bitspower reserves the right to change the product design and
interpretations. These are subject to change without notice. Product
colors and accessories are based on the actual product.
When using leak tester on water cooling loop, in order to avoid product
damage due to excessive pressure, the input pressure should not exceed
0.5kg/cm2 (Bar). If the product is damaged due to excessive pressure, it
will be the fault of the customer. DO NOT use the leak teser when there is
water in the loop or the pump is running.
Bitspower recommends that customers use Bitspower Pellucid Coolant
for their coolant fluid. It is also recommended to use Bitspower Dye to
create any desired color. If the customer chooses di󽗈erent liquid coolants,
the resulting impurities may cause peeling of the coating on some of the
hardware, water channel blockage by built-up residue, improper operation
of the water pump, water tank tube breakage, and o-ring deformation
leading to leakage. Any issues related to the use of inappropriate liquid
coolants will be the responsibility of the customer.

[ 11 ]
記得上角要放對應的 LOGO!
配件
Bitspower CR140 Reservoir V1
1BPM-WTCR140 1 組
2固定支架 2 個
3墊高支架 2 個
4M3x45mm 螺絲 4 支
5M3x5mm 螺絲 4 支
6M4x6mm 螺絲 4 支
使用說明書

[ 12 ]
使用說明 針對固定支架
步驟 2
步驟 3
步驟 1
組裝 M3x5mm 螺絲 安裝固定支架
尺寸參考
4
2
1
5
140
140
40
72.50
58
43
55
140
組裝步驟

[ 13 ]
安裝於機殼
步驟 4
組裝步驟
6

[ 14 ]
步驟 3
步驟 2步驟 1
使用說明 針對墊高支架
組裝步驟
組裝 M3x5mm 螺絲 安裝墊高支架
尺寸參考
5
4
2
1
140
140
40
72.50
85
43
82
140

[ 15 ]
安裝於機殼
步驟 4
組裝步驟
6

[ 16 ]
安裝方式 A
推薦 針對垂直支架 ( 額外購買 )
步驟 1 步驟 2
步驟 3 步驟 4
140
158
18
7
158

[ 17 ]
安裝方式 B
步驟 1 步驟 2
步驟 3 步驟 4
165
168
140
140
165
72.50 75.50

[ 18 ]
推薦 針對燈效模組 ( 額外購買 )
步驟 1 步驟 2
步驟 3
尺寸參考 ( 安裝燈校模組後 )
步驟 4
140
147 42.50
75
19
42.50
40
2.50
46
72.50
40
150

[ 19 ]
尺寸參考 ( 安裝燈效模組後裝至垂直支架 )
燈效模組有三個方向可選擇安裝
140
140
61.70
165
168
140
140
165
72.50 75.50

[ 20 ]
記得上角要放對應的 LOGO!
注意
跑水前，請先確認所有零件已安裝在正確的位置上，在不開主機，單開水
泵的情况下，進行 24 小時的跑水測試， 確保無漏水情况後再開主機，避
免發生漏水而導致電腦零件的損壞。
本公司保留對產品的設計更改以及解釋的權力，如有更動恕不另行通知，
產品顏色與配件以實物為準。
當使用測氣產品測試水路時，為避免由於壓力過大導致產品損壞，輸入的
壓力請不要超過 0.5kg/cm2 (Bar)，如因壓力過大造成產品損壞，將由客戶
自行承擔，嚴禁客戶在水路有水及水泵開啟的情況下進行氣體飽壓測試。
Bitspower 建議消費者使用 Bitspower 透明冷卻液。此外，也可以添加
Bitspower 染料到透明冷卻液中以滿足顏色要求。如果消費者選擇不同的
水冷液，可能會引起水路配件中的塗層剝落、積垢堵塞水道、水泵磨損、
水箱管破裂、破壞 O 型圈密封性導致漏水等。任何因使用不當水冷液導致
相關的問題將由消費者自行負責。
