BIXOLON SPP-R200 Operating instructions

Application Programming Guide
OPOS Driver
Rev. 1.09
SPP-R200
SPP-R200II
SPP-R200III
SPP-R210
SPP-R220
SPP-R300
SPP-R310
SPP-R400
BM10E
http://www.bixolon.com

OPOS Driver
Rev. 1.09
- 2 -
■Table of Contents
1. Instruction ......................................................................................................................3
2. Development environment............................................................................................4
2-1 Communication Configuration ....................................................................................4
3. Property / Method ..........................................................................................................5
3-1 MSR Type...................................................................................................................5
3-2 Property Range / Default Value ..................................................................................5
3-2-1 Capability property setting value...........................................................................5
3-2-2 MSR Method.........................................................................................................5
4. Error Information ...........................................................................................................6
4-1 ResultCode List ..........................................................................................................6

OPOS Driver
Rev. 1.09
- 3 -
1. Instruction
This is a manual about how to set and configure device and to develop applications to use
BIXOLON MSR with BIXOLON OPOS driver.
Before use BIXOLON MSR, set and configure MSR by using BIXOLON OPOS driver
Setup Utility.
Throughout this manual, “OLE for Retail POS” is called “OPOS”.
Throughout this manual, “Unified for Retail POS” is called “UPOS”.
[Further Source]
OLE for Retail POS committee available from http://monroecs.com/opos.htm
Driver Update from http://www.bixolon.com
We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and
quality of all our products. In following, product specifications and/or user manual content
may be changed without prior notice..

OPOS Driver
Rev. 1.09
- 4 -
2. Development environment
2-1 Communication Configuration
1) Communication Configuration for serial interface
You will set communication configuration in BIXOLON OPOS Setup Utility.
Printer Model
Baud Rate
Product Type
SPP-R200
9600/19200/38400/57600/115200
Optional built-in Type
SPP-R200II
9600/19200/38400/57600/115200
Optional built-in Type
SPP-R200III
9600/19200/38400/57600/115200
Optional built-in Type
SPP-R210
Not Supported
Optional built-in Type
SPP-R220
Not Supported
Optional built-in Type
SPP-R300
9600/19200/38400/57600/115200
Optional built-in Type
SPP-R310
9600/19200/38400/57600/115200
Optional built-in Type
SPP-R400
9600/19200/38400/57600/115200
Optional built-in Type
BM10E
Not Supported
Stand alone Type
* Check the default communication setting. For more details refer to the user manual
included in the printer package.

OPOS Driver
Rev. 1.09
- 5 -
3. Property / Method
3-1 MSR Type
Property value will be determined by the MSR type, as shown in the below table.
3-2 Property Range / Default Value
3-2-1 Capability property setting value
Capability Property
SPP-R200_MSR
SPP-R200II_MSR
SPP-R200III_MSR
SPP-R210_MSR
SPP-R220_MSR
SPP-R300_MSR
SPP-R310_MSR
SPP-R400_MSR
BM10E
CapCompareFirmwareVersion
FALSE
FALSE
CapPowerReporting
TRUE
TRUE
CapStatisticsReporting
FALSE
FALSE
CapUpdateFirmware
FALSE
FALSE
CapUpdateStatistics
FALSE
FALSE
CapCardAuthentication
FALSE
FALSE
CapDataEncryption
FALSE
FALSE
CapDeviceAuthentication
FALSE
FALSE
CapISO
TRUE
TRUE
CapJISOne
FALSE
FALSE
CapJISTwo
FALSE
FALSE
CapTrackDataMasking
FALSE
FALSE
CapTransmitSentinels
TRUE
FALSE
CapWritableTracks
FALSE
FALSE
3-2-2 MSR Method
Method
SPP-R200_MSR / SPP-R200II_MSR
SPP-R200III_MSR / SPP-R210_MSR
SPP-R220_MSR / SPP-R300_MSR
SPP-R310_MSR / SPP-R400_MSR
BM10E
authenticateDevice
X
deauthenticateDevice
X
retrieveCardProperty
X
retrieveDeviceAuthenticationData
X
updateKey
X
writeTracks
X
O: Supported X: Not supported

OPOS Driver
Rev. 1.09
- 6 -
4. Error Information
This section is to explain returned error information when use MSR methods.
For more details, please refer to the UPOS specifications.
4-1 ResultCode List
ClaimDevice
Method
Result Code
ResultCodeExtended
ClaimDevice
OPOS_E_ILLEGAL
0
CheckHealth
Method
Result Code
ResultCodeExtended
CheckHealth
OPOS_SUCCESS
0
OPOS_E_CLOSED
0
OPOS_E_CLAIMED
0
OPOS_E_DISABLED
0
OPOS_E_ILLEGAL
0
OPOS_E_OFFLINE
0
OPOS_E_OFFLINE
0
ClearOutput
Method
Result Code
ResultCodeExtended
ClearOutput
OPOS_SUCCESS
0
OPOS_E_CLOSED
0
OPOS_E_CLAIMED
0
OPOS_E_NOTCLAIMED
0
