Black & Decker BHD101 Series User manual

INSTRUCTION MANUAL
DESKTOP HEATER
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BHD101*

Page 2

Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your
heater.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions......................................................................................................................................... 4-6
Electrical Requirements.......................................................................................................................................................... 5
SET UP & USE
Parts & Features ......................................................................................................................................................................... 7
Operating Instructions ............................................................................................................................................................ 8
Care & Cleaning ..........................................................................................................................................................................9
TROUBLESHOOTING & WARRANTY
Troubleshooting........................................................................................................................................................................ 10
Limited Warranty .......................................................................................................................................................................11
Page 3
SPECIFICATIONS
Voltage: 120V, 60Hz
Power Consumption: 1500W
Unit Size (WxDxH): 5.3” x 8.5” x 9.4”

Page 4
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons,
including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. If provided, use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding,
papers, clothes, and curtains at least 3 feet (0.9m) from the front of
the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
Discard heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into bathtub or
other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trac area and where it will not be
tripped over.
9. To disconnect heater, first turn controls to o, then remove plug from
outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the
heater.
11. To prevent a possible fire, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where openings may
become blocked.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury

Page 5
12. A heater has hot and arcing or sparking parts inside. Do not use it in the
areas where gasoline, paint, or flammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or
injury to persons.
14. CAUTION: Always plug heaters directly into a wall outlet/receptacle.
Never use with an extension cord or relocatable power tap (outlet/power
strip).
15. This heater draws 12.5 amps during operation. To prevent overloading
a circuit, do not plug the heater into a circuit that already has other
appliances working.
16. The output of this heater may vary and its temperature may become
intense enough to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity to heat or an inability
to react to avoid burns.
17. Don’t leave the heater on unattended.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
SAFETY INFORMATION
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to t into a polarized outlet
only one way. If the plug does not t into the outlet, reverse the plug. If it still
does not t, contact a qualied electrician. Do not attempt to modify the plug in
any way.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage to the
product or personal injury resulting from failure to observe the electrical connection
procedures.
WARNING:To reduce the risk of electric shock, do not use with an extension cord.

Page 6
OVERHEAT SAFETY FEATURE
This heater is equipped with a overheat safety feature. When the heater’s internal
components reach a certain temperature that could cause overheating and
possible fire, the heater will automatically shut o. If this should occur, please
contact our Customer Satisfaction Center at 844-299-0879.
TIP-OVER SAFETY FEATURE
This heater is equipped with a tip-over safety feature. Once the heater is tipped
over, an internal switch will automatically shut the heater off. Once the heater is
restored to an upright position, the heater will reset. To continue operation, turn
heater back on.
WARNING
It is normal for the power cord to feel warm to the touch; however, a
loose fit between the outlet and the plug may cause overheating of
the plug. If this occurs, try inserting the plug into a dierent outlet.
Contact a qualified electrician to inspect the original outlet for
damage.
SAFETY INFORMATION

Page 7
PARTS & FEATURES
Adjustable
thermostat Fan/Heat settings
SET UP & USE
Power on indicator light
Tip-over switch

Page 8
SET UP & USE
OPERATING INSTRUCTIONS
Place the heater on a firm, level surface and plug the unit directly into a 120 V AC
electrical outlet.
NOTE: Only operate heater in upright position.
1. Turn the thermostat knob clockwise (right) direction until it reaches the maximum
setting.
2. Turn the heat control knob clockwise (right) from the OFF position to the
FAN ONLY ( ),LOW (LO ) (750 watts) or HIGH (HI ) (1500 watts).
The power indicator light turns on when either the, FAN, LOW or HIGH setting is
selected.
When the desired temperature/comfort level is reached, lower the thermostat knob
until the heater stops operating. The thermostat will automatically maintain the
desired temperature level by cycling the heater on and o.
NOTE: Turning the TEMPERATURE control knob clockwise will increase the
temperature setting.
Turn the fan/heat control knob to “OFF” to shut o the unit.
Thermostat Fan/Heat control knob
OFF
LO
HI
WHD101W CONTROL PANEL SILKSCREEN
SIZE: 96.9 X 42.1
PANTONE 433C

Page 9
MAINTENANCE
1. Turn power o before cleaning.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth.
You may use a mild detergent if necessary. After cleaning, dry the unit with a soft
cloth.
CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough brushes
to clean the heater. This may cause damage or deterioration to the surface of the
heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.
CARE & CLEANING

Page 10
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
IF THE HEATER/FAN FAILS TO OPERATE:
A) Check to make sure that the heater/fan is plugged in securely. If it is not,
remove the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem
to be operating properly, test the outlet with another appliance.
C) Check if electricity to the main power switch in the back of the unit appears
to be working.
D) Make sure the heater is in the upright position.
NOTE: For the heater to function properly, the desired temperature on the heater
must be set a few degrees higher than the temperature in the room. If the
unit seems to not be heating properly, increase the desired temperature
on the heater to fully engage the heating elements.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE HEATER/FAN
YOURSELF.
CUSTOMER SERVICE
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
W Appliance Co. Customer Satisfaction Center at
844-299-0879 or [e-mail]
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
