Black & Decker BXSH37001GB User manual

BXSH37001GBwww.blackanddecker.co.uk
This product is only suitable for well-insulated
spaces or occasional use.

ENGLISH (Original instructions)
2
What’s in the box
Instruction Manual
Portable Heater
Features
1. Handle
2. Ventilation Grille
3. Thermostat Dial
4. Heat Setting Selection Dial
5. On/Off Indicator Light
6. Air Outlets
1
3
2
4
5
6

ENGLISH
(Original instructions)
3
Intended Use
Your BLACK+DECKER BXSH37001GB Portable
Heater has been designed for heating small and
medium spaces.
This appliance is intended for indoor household use
only.
Thank you for choosing BLACK+DECKER. We hope
that you will enjoy using this product for many years.
Safety Instructions
WARNING: Read all safety
warnings and all instructions.
Failure to follow the warnings and
instructions listed below may result
in electric shock, re and/or serious
injury.
♦ Read this manual carefully before
using the appliance.
♦ The intended use is described in
this manual.
♦ The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
♦ Retain this manual for future
reference.
♦ WARNING: When using mains-
powered appliances, basic safety
precautions, including the following,
should always be followed to
reduce the risk of re, electric
shock, personal injury and material
damage.
Using Your Appliance
Please read the operating
instructions carefully before using
your portable heater for the rst time.
♦ Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
♦ The heater must not be located
immediately below a socket outlet.
♦ Do not use this heater in the
immediate surroundings of a bath,
a shower or a swimming pool.
♦ In order to avoid overheating, do
not cover the heater.
♦ Children of less than 3 years should
be kept away unless continuously
supervised.
♦ Children aged from 3 years and
less than 8 years shall only switch
on/off the appliance provided that
it has been placed or installed
in its intended normal operating
position and they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children aged
from 3 years and less than 8 years
shall not plug in, regulate and clean
the appliance or perform user
maintenance.
♦ CAUTION: Some parts of this
product can become very hot and
cause burns. Particular attention
has to be given where children and
vulnerable people are present.
♦ Children shall not play with the
appliance.

ENGLISH (Original instructions)
4
♦ Do not let the cable hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
♦ The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
♦ Do not pull the plug out by the
cable as this may damage the plug
and/or the cable.
♦ Do not use this product for anything
other than its intended use.
♦ This appliance is for household use
only.
♦ Do not carry the appliance by the
power cable.
♦ Do not use the appliance outdoors.
♦ Do not operate with wet hands.
♦ Use of an extension cable with this
appliance is not recommended.
However, if it is necessary to use
an extension lead, ensure that
the lead is suited to the power
consumption of the appliance to
avoid overheating of extension
cable, appliance or plug point. Do
not place the extension cable in a
position where it can be pulled on
by children or animals or tripped
over.
♦ Always unplug the unit when not in
use or before cleaning.
♦ The manufacturer does not accept
responsibility for any damage
or injury caused by improper or
incorrect use, or for repairs carried
out by unauthorised personnel.
Safety Of Others
♦ Close supervision is necessary
when any appliance is used by or
near children.
♦ Children should not play with the
appliance.
♦ Cleaning and user maintenance
should not be undertaken by
children without supervision.
♦ Take care when any appliance is
used near pets.
♦ Do not allow the cord to become
twisted or come into contact with
children.
After Use
♦ While cleaning, DO NOT use a wet
cloth or use water on any part of
the unit, as this may cause a short
circuit or electrical shock.
♦ Keep this unit clean. Do not allow
objects to enter the ventilation
opening as this may cause electric
shock, or damage to the unit.
Switch off at the wall socket then
remove the plug from the socket
when not in use or before cleaning.
♦ Check all inlets and outlets from
time to time for accumulated dust.

ENGLISH
(Original instructions)
5
♦ Disconnect the unit from mains
outlet when it is not in use, or
before relocating or cleaning it.
♦ Switch off, remove the plug from
the socket and let the appliance
cool down before leaving it
unattended and before changing,
cleaning or inspecting any parts of
the appliance.
♦ When not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspections And Repairs
♦ Do not attempt to dismantle, repair
or remould any part of the unit. This
should only be done by a qualied
service agent. Even the change of
power cable should be done by a
qualied person.
♦ In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the manufacturer.
♦ In case of technical problems,
switch off the product and do not
attempt to repair it yourself. Return
the appliance to an authorised
service facility for examination,
adjustment or repair. Always
insist on the use of original spare
parts. Failure to comply with the
above mentioned precautions and
instructions, could affect the safe
operation of this product.
Additional Safety Instructions for
This Appliance
♦ Install the unit on at and hard oor
to diminish vibration or noise.
♦ Always operate the appliance on a
smooth, even, stable surface. Do
not place the unit on a hot surface.
♦ Ensure that the unit is switched off
after use.
♦ Do not immerse cables, plugs or
any part of the appliance in water
or any other liquid.
♦ Operate the unit only at the voltage
specied.
♦ Do not use the unit near open
windows, as contact with rain and
other natural elements could cause
an electrical hazard
♦ Do not put heavy objects on the
appliance.
♦ Do not tip the unit on its side.
♦ Never insert any other object into
the unit body to avoid any hazard
or unit failure.
♦ Do not put the unit close to
heat-generating devices or
near ammable and dangerous
materials.
♦ If the supply cable is damaged,
it must be replaced by the
manufacturer or its service agent or
a similarly qualied person in order
to avoid a hazard.

ENGLISH (Original instructions)
6
♦ For optimal airow circulation,
leave a distance of at least 1 metre
around the appliance on every side.
Always direct the airow in order
to optimise heating. Avoid corners,
small objects and other surfaces
or objects which may impede the
airow.
♦ The appliance must be positioned
so that the plug is accessible.
WARNING: Do not place the unit
on or near a hot gas electric burner.
Electrical safety
Before use, check that the mains voltage
corresponds to the voltage on the rating plate.
This product must be earthed.
Always check that the mains voltage
corresponds to the voltage on the rating
plate.
♦ Appliance plugs must match the outlet. Never
modify the plug in any way.
♦ Do not use any adapter plugs with earthed (Class
1) appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
♦ To avoid the risk of electric shock, do not immerse
the cord, plug or appliance in water or other liquid.
Extension cables & class 1 product
♦ A 3 core cable must be used as your tool is
earthed and of class 1 construction.
♦ Up to 30m (100 ft) can be used without loss of
power.
♦ If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
BLACK+DECKER Service Centre in order to avoid
a hazard.
Labels on Appliance
The following pictograms along with the date code
are shown on the appliance:
WARNING: Hot surface
WARNING: Do not cover
WARNING: Before assembling, switch the
appliance off and remove the plug from the socket.

ENGLISH
(Original instructions)
7
Features
1. Handle
2. Ventilation Grille
3. Thermostat Dial
4. Heat Setting Selection Dial
5. On/Off Indicator Light
6. Air Outlets
Use
About the Controls
♦ Adjustable thermostat
♦ 2 heat settings and fan
Turning the Unit On or Off
♦ To power the unit on, turn the heat selection dial to
any position other than Off (O) and the thermostat
dial away from the ‘-’ position. The unit is on when
the On/Off indicator light at the front of the unit
comes on, hot air starts emitting from the grille
and the motor starts up.
♦ To power the unit off, turn the heat selection dial
to the Off position (O) and the thermostat dial to
the ‘-‘ position. The unit is off when the On/Off
indicator light at the front of the unit goes out, hot
air stops emitting from the grille and the motor is
no longer audible.
Heat Setting Selection
♦ This heater offers a choice of 2 heat settings, as
well as a fan mode, which gives off cool air.
♦ Turn the heat selection dial from left to right to
cycle between the Fan, Low or High heat settings.
Turn the dial from right to left to cycle between
High, Low and Fan settings.
♦ Turn the heat selection dial to the O position to
turn the unit off.
Tip-Over Switch
♦ This heater is equipped with a tip-over switch,
located at the base of the appliance. This switch
automatically cuts off the unit whenever it is
moved or tipped over, for safety.
♦ When the tip-over switch is activated, return
the heater to a at and stable position and turn
all dials to the Off position. Once the appliance
is stable, turn it back on as described above to
resume normal operation.
Cleaning and maintenance
WARNING: Before cleaning and maintenance,
switch the appliance off and remove the plug from
the socket, to prevent electric shock.
♦ Do not immerse any part of the appliance, power
cord or plug in liquids.
♦ Use a soft damp cloth to wipe the surface. Avoid
using detergent, spray or chemicals as these may
cause damage to the appliance.
Mains plug replacement
If a new mains plug needs to be tted:
♦ Safely dispose of the old plug.
♦ Connect the brown lead to the live terminal in the
new plug.
♦ Connect the blue lead to the neutral terminal.
♦ If the product is class I (earthed), connect the
green/yellow lead to the earth terminal.
Note! If your product is class II double insulated
(only 2 wires in the cord set), no connection is to be
made to the earth terminal.
Follow the tting instructions supplied with good
quality plugs. Any replacement fuse must be of the
same rating as the original fuse supplied with the
product.
Warning! The above section on mains plug
replacement is for authorized service centre
persons.

ENGLISH (Original instructions)
8
Protecting the environment
Separate collection. Products and
batteries marked with this symbol must
not be disposed of with normal household
waste.
Products and batteries contain materials that can
be recovered or recycled, reducing demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
Technical data
BXSH37001GB
Input voltage V AC 220 - 240
Frequency Hz 50
Power input W1500
Weight KG 2.25
Product Guarantee
This product comes with a 2 Year guarantee from the
original date of purchase. If any defect arises due to
faulty materials of workmanship, the faulty products
must be returned to the place of purchase. Refund or
replacement is at the discretion of the retailer. This
guarantee is in addition to and in no way prejudices
your statutory rights.
The Following Conditions Apply:
♦ The product must be returned to the retailer
with proof of purchase or a receipt within the
1st year of purchase. For any product related
issues after 12 months please contact our
customer services team.
♦ The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
♦ It must be used only for domestic purposes.
♦ It does not cover wear and tear, damage,
misuse or consumable parts.
♦ This guarantee is valid in the UK and Republic
of Ireland.
For all customer service enquires please contact
us below;
RKW,
Sutton House,
Berry Hill Road,
Stoke-on-Trent,
ST4 2NL
Email [e-mail]
Tel [phone]
Black & Decker® and BLACK+DECKER™ and the
Black & Decker® and BLACK+DECKER™ logos
are registered trademarks of The Black & Decker®
Corporation and are used under licence. All rights
reserved. Imported and Distributed by RKW LTD,
Sutton House, Berry Hill Industrial Estate, Berry Hill
Road, Stoke-on-Trent, ST4 2NL

ENGLISH
(Original instructions)
9
Model Identier(s): BXSH37001GB
Item Symbol Value Unit Item Unit
Heat Output Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output Pnom 1.500 kW Manual heat charge with integrated thermostat No
Minimum heat
output (indicative) Pmin 0.0212 kW Manual heat charge control with room and/or outdoor temperature feedback No
Maximum
continuous heat
output Pmax, c 1.500 kW Electronic heat charge control with room
and/or outdoor temperature feedback No
Auxiliary electricity
consumption Fan assisted heat output No
At nominal heat
output elmax N/A kW Type of heat output/room temperature control (select one)
At minimum heat
output elmin N/A kW Single stage heat output and no room temperature control No
In standby mode eISB N/A kW Two or more manual stages, no room
temperature control No
With mechanic thermostat room
temperature control Yes
With electronic room temperature control No
Electronic room temperature control plus
day timer No
Electronic room temperature control plus
week timer No
Other control options (multiple selections possible)
Room temperature control with presence
detection No
Room temperature control with open
window detection No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: RKW LTD, Sutton House, Berry Hill Industrial Estate, Berry Hill Road,
Stoke-on-Trent, ST4 2NL

ENGLISH (Original instructions)
10
