Black & Decker BXSH37005GB User manual

BXSH37005GBwww.blackanddecker.co.uk
This product is only suitable for well-insulated
spaces or occasional use.

ENGLISH (Original instructions)
2
What’s in the box
Instruction Manual
Fan Heater
Features
1. Air Inlet
2. Heat Selection Control
3. Power Light
4. Thermostat Control
5. Air outlet
1
5
2
3
4

ENGLISH
(Original instructions)
3
Intended Use
Your BLACK+DECKERBXSH37005GB 2KW Fan
Heater has been designed for heating small and
medium spaces.
This appliance is intended for indoor household use
only.
Thank you for choosing BLACK+DECKER. We hope
that you will enjoy using this product for many years.
Safety Instructions
WARNING: Read all safety
warnings and all instructions. Failure
to follow the warnings and
instructions listed below may result in
electric shock, re and/or serious
injury.
♦ Read this manual carefully before
using the appliance.
♦ The intended use is described in
this manual.
♦ The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
♦ Retain this manual for future
reference.
♦ WARNING: When using mains-
powered appliances, basic safety
precautions, including the following,
should always be followed to
reduce the risk of re, electric
shock, personal injury and material
damage.
Using Your Appliance
Please read the operating
instructions carefully before using
your fan heater for the rst time.
♦ Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
♦ The heater must not be located
immediately below a socket outlet.
♦ Do not use this heater in the
immediate surroundings of a bath,
a shower or a swimming pool.
♦ Children of less than 3 years should
be kept away unless continuously
supervised.
♦ Children aged from 3 years and
less than 8 years shall only switch
on/off the appliance provided that
it has been placed or installed
in its intended normal operating
position and they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children aged
from 3 years and less than 8 years
shall not plug in, regulate and clean
the appliance or perform user
maintenance.
♦ CAUTION: Some parts of this
product can become very hot and
cause burns. Particular attention
has to be given where children and
vulnerable people are present.
♦ Children shall not play with the
appliance.

ENGLISH (Original instructions)
4
♦ Do not let the cable hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
♦ The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
♦ Do not pull the plug out by the
cable as this may damage the plug
and/or the cable.
♦ Do not use this product for anything
other than its intended use.
♦ This appliance is for household use
only.
♦ Do not carry the appliance by the
power cable.
♦ Do not use the appliance outdoors.
♦ Do not operate with wet hands.
♦ Use of an extension cable with this
appliance is not recommended.
However, if it is necessary to use
an extension lead, ensure that
the lead is suited to the power
consumption of the appliance to
avoid overheating of extension
cable, appliance or plug point. Do
not place the extension cable in a
position where it can be pulled on
by children or animals or tripped
over.
♦ Always unplug the unit when not in
use or before cleaning.
♦ The manufacturer does not accept
responsibility for any damage
or injury caused by improper or
incorrect use, or for repairs carried
out by unauthorised personnel.
Safety Of Others
♦ Close supervision is necessary
when any appliance is used by or
near children.
♦ Children should not play with the
appliance.
♦ This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
♦ Cleaning and user maintenance
should not be undertaken by
children without supervision.
♦ Take care when any appliance is
used near pets.
♦ Do not allow the cord to become
twisted or come into contact with
children.
After Use
♦ While cleaning, DO NOT use a wet
cloth or use water on any part of
the unit, as this may cause a short
circuit or electrical shock.

ENGLISH
(Original instructions)
5
♦ Keep this unit clean. Do not allow
objects to enter the ventilation
opening as this may cause electric
shock, or damage to the unit.
Switch off at the wall socket then
remove the plug from the socket
when not in use or before cleaning.
♦ Check all inlets and outlets from
time to time for accumulated dust.
♦ Disconnect the unit from mains
outlet when it is not in use, or
before relocating or cleaning it.
♦ Switch off, remove the plug from
the socket and let the appliance
cool down before leaving it
unattended and before changing,
cleaning or inspecting any parts of
the appliance.
♦ When not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspections And Repairs
♦ Do not attempt to dismantle, repair
or remould any part of the unit. This
should only be done by a qualied
service agent. Even the change of
power cable should be done by a
qualied person.
♦ In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the manufacturer.
♦ In case of technical problems,
switch off the product and do not
attempt to repair it yourself. Return
the appliance to an authorised
service facility for examination,
adjustment or repair. Always
insist on the use of original spare
parts. Failure to comply with the
above mentioned precautions and
instructions, could affect the safe
operation of this product.
Additional Safety Instructions for
This Appliance
♦ Install the unit on at and hard oor
to diminish vibration or noise.
♦ Always operate the appliance on a
smooth, even, stable surface. Do
not place the unit on a hot surface.
♦ Ensure that the unit is switched off
after use.
♦ Do not immerse cables, plugs or
any part of the appliance in water
or any other liquid.
♦ Operate the unit only at the voltage
specied.
♦ Do not use the unit near open
windows, as contact with rain and
other natural elements could cause
an electrical hazard
♦ Do not put heavy objects on the
appliance.

ENGLISH (Original instructions)
6
♦ Do not tip the unit on its side.
♦ Never insert any other object into
the unit body to avoid any hazard
or unit failure.
♦ Do not put the unit close to
heat-generating devices or
near ammable and dangerous
materials.
♦ If the supply cable is damaged,
it must be replaced by the
manufacturer or its service agent or
a similarly qualied person in order
to avoid a hazard.
♦ For optimal airow circulation,
leave a distance of at least 1 metre
around the appliance on every side.
Always direct the airow in order
to optimise heating. Avoid corners,
small objects and other surfaces
or objects which may impede the
airow.
♦ The appliance must be positioned
so that the plug is accessible.
♦ Always turn the heater off and
unplug it from the mains before
attempting to move it.
WARNING: Do not place the unit
on or near a hot gas electric burner.
Electrical safety
WARNING: Before use, check that the mains
voltage corresponds to the voltage on the rating
plate.
This product must be earthed. Always
check that the mains voltage
corresponds to the voltage on the rating
plate.
♦ Appliance plugs must match the outlet. Never
modify the plug in any way.
♦ Do not use any adapter plugs with earthed (Class
1) appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
♦ To avoid the risk of electric shock, do not immerse
the cord, plug or appliance in water or other liquid.
Extension cables & class 1 product
♦ A 3 core cable must be used as your tool is
earthed and of class 1 construction.
♦ Up to 30m (100 ft) can be used without loss of
power.
♦ If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
BLACK+DECKER Service Centre in order to avoid
a hazard.
Labels on Appliance
The following pictograms along with the date code
are shown on the tool:
WARNING: Hot surface
WARNING: Do not cover
WARNING: Before assembling, switch the
appliance off and remove the plug from the socket.

ENGLISH
(Original instructions)
7
Features
1. Air Inlet
2. Heat Selection Control
3. Power Light
4. Thermostat Control
5. Air outlet
Use
About the Controls
♦ 2 heat settings and fan mode
♦ Adjustable thermostat
Turning the Unit On or Off
♦ To turn the unit on, rst connect it to a mains
power socket.
NOTE: Before plugging in, take care to ensure that
the heat setting control is set to the “0” position and
the thermostat to “*”.
♦ Once the unit is powered on adjust the dials away
from “0” & “*” and air will start to emit. The power
light will illuminate.
♦ To turn the unit off, set the dials back to “0” & “*”
and air will stop being emitted. The power light
will go off. Unplug the appliance if it is no longer
required.
NOTE: It is normal for heaters to emit some smell
and fumes when turned on for the rst time or after
having not been used for a long period of time. This
will disappear when the heater has been on for a
short while.
Heat Setting Selection
♦ This unit is equipped with a choice of 2 heat
settings and a cooling fan mode.
♦ Turn the heat selection control to cycle between
the available heating and cooling fan settings:
Cool air: turn the heat selection control to the
setting.
Heating at mid power: turn the heat selection
control to setting 1.
Heating at full power: turn the heat selection
control to setting 2.
Regulating the Thermostat
♦ Turn the thermostat control in a clockwise
direction until it reaches the maximum setting.
♦ When the room has reached the required
temperature turn the thermostat control slowly in
an anti-clockwise direction up to the point where
the appliance switches off, and not beyond.
♦ The heater will now automatically turn itself on
or off as required to maintain the selected room
temperature.
Automatic Cut-Off
♦ The heater is tted with a safety device which
will switch off the heater in case of accidental
overheating (e.g. obstruction of air intake and
outlet grilles, motor turning slowly or not at all).
♦ To reset, turn the heat selection control to the “0”
position, disconnect the plug from the power for a
few minutes and allow the unit to cool down. Then
plug the appliance in again and operate normally.
If the unit does not reset, contact the manufacturer
or its service agent or a qualied person.
Cleaning and maintenance
WARNING: Before cleaning and maintenance,
switch the appliance off and remove the plug from
the socket, to prevent electric shock.
♦ Ensure that the unit is cool before commencing
cleaning.
♦ Do not immerse any part of the appliance, power
cord or plug in liquids.
♦ DO NOT ALLOW water into the appliance.
♦ Use a soft damp cloth to wipe the surface. Avoid
using detergent, spray or chemicals as these may
cause damage to the appliance. Ensure the heater
is thoroughly dry before attempting to plug it back
into the mains.
♦ Clean the air inlet/outlet grilles frequently. If
necessary, use a vacuum cleaner on low power
to remove dust and uff from the inlet and outer
grille. If dust or dirt has collected inside the unit or
around the element, unplug it from the mains and
contact a qualied service technician. DO NOT
attempt to operate the heater when there is dust
or debris on the inside.
♦ Store in a cool dry place when not in use.

ENGLISH (Original instructions)
8
Mains plug replacement
If a new mains plug needs to be tted:
♦ Safely dispose of the old plug.
♦ Connect the brown lead to the live terminal in the
new plug.
♦ Connect the blue lead to the neutral terminal.
♦ If the product is class I (earthed), connect the
green/yellow lead to the earth terminal.
Note! If your product is class II double insulated
(only 2 wires in the cord set), no connection is to be
made to the earth terminal.
Follow the tting instructions supplied with good
quality plugs. Any replacement fuse must be of the
same rating as the original fuse supplied with the
product.
WARNING: The above section on mains plug
replacement is for authorized service centre
persons.
Protecting the environment
Separate collection. Products and
batteries marked with this symbol must
not be disposed of with normal household
waste.
Products and batteries contain materials that can
be recovered or recycled, reducing demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
Technical data
BXSH37005GB
Input voltage V AC 220 - 240
Frequency Hz 50
Power input W1700-2000
Weight KG 1
Product Guarantee
This product comes with a 2 Year guarantee from the
original date of purchase. If any defect arises due to
faulty materials of workmanship, the faulty products
must be returned to the place of purchase. Refund or
replacement is at the discretion of the retailer. This
guarantee is in addition to and in no way prejudices
your statutory rights.
The Following Conditions Apply:
♦ The product must be returned to the retailer
with proof of purchase or a receipt within the
1st year of purchase. For any product related
issues after 12 months please contact our
customer services team.
♦ The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
♦ It must be used only for domestic purposes.
♦ It does not cover wear and tear, damage,
misuse or consumable parts.
♦ This guarantee is valid in the UK and Republic
of Ireland.
For all customer service enquires please contact
us below;
RKW,
Sutton House,
Berry Hill Road,
Stoke-on-Trent,
ST4 2NL
Email [e-mail]
Tel [phone]
Black & Decker® and BLACK+DECKER™ and the
Black & Decker® and BLACK+DECKER™ logos
are registered trademarks of The Black & Decker®
Corporation and are used under licence. All rights
reserved. Imported and Distributed by RKW LTD,
Sutton House, Berry Hill Industrial Estate, Berry Hill
Road, Stoke-on-Trent, ST4 2NL

ENGLISH
(Original instructions)
9
Model Identier(s): BXSH37005GB
Item Symbol Value Unit Item Unit
Heat Output Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output Pnom 1.85 kW Manual heat charge with integrated thermostat N/A
Minimum heat
output (indicative) Pmin 0.925 kW Manual heat charge control with room and/or outdoor temperature feedback N/A
Maximum
continuous heat
output
Pmax, c 1.85 kW Electronic heat charge control with room
and/or outdoor temperature feedback N/A
Auxiliary electricity
consumption Fan assisted heat output N/A
At nominal heat
output elmax 0.014 (fan motor) kW Type of heat output/room temperature control (select one)
At minimum heat
output elmin 0.014 (fan motor) kW Single stage heat output and no room temperature control No
In standby mode eISB 0kW Two or more manual stages, no room
temperature control No
With mechanic thermostat room
temperature control Yes
With electronic room temperature control No
Electronic room temperature control plus
day timer No
Electronic room temperature control plus
week timer No
Other control options (multiple selections possible)
Room temperature control with presence
detection No
Room temperature control with open
window detection No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: RKW LTD, Sutton House, Berry Hill Industrial Estate, Berry Hill Road,
Stoke-on-Trent, ST4 2NL

ENGLISH (Original instructions)
10

ENGLISH
(Original instructions)
11

11/2020
