Black Box SCAN LAN VI TS6000A User manual

1
Supports a variety of
cable standards to
100 MHz, including
CAT5e.
ptional performance
modules plug into the
tester so you can tailor
the SCAN-LAN to your
testing needs.
Tamper-proof Report
Manager format.
Tests and certifies
cable.
Stores up to 450 test
reports per scanner.
S
CAN-LAN VI is the network
cable-testing tool that meets
your testing needs now and will
evolve to meet your future needs.
he SCAN-LAN system consists
of two handheld units (one
functions as a main unit, the other
as a remote unit) and your choice
of optional plug-in modules.
SCAN-LAN tests a variety of
cable types, including Category
5e. It supports these cable
standards to 100 MHz: SB-67
CA 3, 4, and 5, SB-95 CA 5, IA
CA 5e—and more! See the
Specifications section on the
next page for details.
F1F2F3F4
ESC
ENTER
AUTOTEST
PRINT
REMOTE
CAL
SETUP
TRAFFIC
LENGTH
WIRE
MAP
QUICK √
SCAN-LAN VI
EXTENDED
FUNCTIONS
Get unequaled power and measurement
precision with this easy-to-use tester.
KeyFeatures
SCANLANVI
Network standards supported
at 100 MHz include IEEE 802.3,
IEEE 802.5, IEEE 802.12, ANSI
X3 9.5, and A M 155 Mbps.
And in addition to complying
fully with IA SB-67
requirements for certifying
CA 5/Class D links, the SCAN-
LAN performs several important
new measurements to 100 MHz,
including Power Sum Near-End
Crosstalk (PS-NEX ) and Power
Sum Attenuation-to-Crosstalk
Ratio (PS-ACR).
o test multimode fiber in
pairs, the alk and est Module
compares bidirectional dual-
wavelength 850/1300-nm loss,
length, and propagation-delay
measurements against several
industry standards.
With SCAN-LAN’s included
microphones, you can talk to your
testing partner over the same
cable that you’re testing.
Plus, the SCAN-LAN can store
up to 450 test reports (900 total per
pair of scanners).
Black Box Corporation • 1000 Park Drive • Lawrence, PA 15055-1018 • ech Support: 724-746-5500 • www.blackbox.com • e-mail: [email protected]
© 2004. All rights reserved.
Black Box Corporation.
1/12/2004 #21140

2
General
Display: Backlit graphic LCD, 128 x
64 pixels
Operating Controls: 10-position
rotary function selector;
elastomeric keypad
Audible Alarm: Operator
Enabled/Disabled
Compliance: Directive 89/336/EEC
per CF CC/KID/048/98
Supported Network Standards:
IEEE 802.3: 10BASE2, 10BASE5,
10BASE- , 100BASE- 4,
100BASE- X, 1000BASE- ;
IEEE 802.5: oken Ring 4 Mbps or
16 Mbps;
IEEE 802.12: 100VG-AnyLAN;
ANSI X3 9.5: P-PMD;
A M 155 Mbps
Supported Cable Standards: SB-67
CA 3, 4, and 5; SB-95 CA 5;
IA Category 5e; EN50173 Class
D; ISO 11801 Class C, D; Sc P
Class C, D; AS/NZS 3080 Class C,
D; BICC Millenium; F P 120 ohms;
JIS X 5150
Operating Temperature: 32 to 122°F
(0 to 50°C)
Storage Temperature: -4 to +140°F
(-20 to +60°C)
Relative Humidity: Up to 90%,
noncondensing
TBF: >50,000 hours
Size: 9.6"H x 3.9"W x 2.5"D (24.4 x
9.9 x 6.4 cm)
Weight: 2 lb. (0.9 kg)
Power
Battery: (8) AA alkaline batteries per
unit or (1) NiMH rechargeable
battery pack per unit
Battery Life: 8 to 10 hours
continuous use or >800 Autotests
(typical)
Low Battery Indicator: Audible
alarm plus LCD display
Automatic Power-Down: 2 to
30 minutes (selectable) or
disabled
AC/ ains Adapter: 12 to 15 VDC,
300 mA
Input: 120V or 230V ±15%
Output: 60 or 50 Hz
Frequency: 12 or 14 VDC
Lithium Coin Cell (Autotest Results
Storage) Life: 2 years
PerformanceModules
Performance Module inputs
withstand telco ring voltages;
175V peak, 20–60 Hz
superimposed on 56 VDC,
maximum. hey also withstand
electrostatic discharges per IEC
801-2 severity level 4 (8KV
contact).
Standard: Modular Plug ( S691 or
S691E)
Optional: Modular Jack ( S692)
Optional: Coax ( S693)
Memory
Test Storage: Storage of up to 450
Autotest results plus one raffic
Report in each SCAN-LAN VI
Imprint: Date on all tests
Non-Volatile emory: Lithium
battery-backed memory for
setup, test results, and NVP
values
WireMapping(Twisted-Pair
WiringOnly)
Displays the Following Errors:
Miswired pairs, shorts, opens,
shorted pairs, crossed pairs, and
split pairs. Includes test of shield
(if present).
Traffic(EthernetOnly)
Parameters onitored:
% Utilization, % Collisions, Peak
raffic
Other Features: Continuous bar
graph to display activity
Attenuation-to-CrosstalkRatio
ACR is calculated for each pair
over the full frequency range per
test specification selected.
SerialPort
Connector: DB9 male (pins)
PC Cable: Null modem, DB9 female
(socket) to DB9 female (socket)
and DB25 female serial port pin
assignments
Baud Rate: 1200 to 38,400 bps
(selectable)
Format: 8 bits, no parity, 1 stop bit,
(8N1)
Flow Control: X-ON/X-OFF,
Hardware (C S/D R), None
CableLength
Range: Up to 2000 ft. (610 m)
twisted pair
Accuracy:
Up to 1000 ft. (304.8 m): ±2 ft.
(0.6 m) ±2% ±NVP Uncertainty;
1001 to 2000 ft. (305.1 to 609.6 m):
±2 ft. (0.6 m) ±3% ±NVP
Uncertainty
NVP (Nominal Velocity of
Propagation): 0.5 to 0.99%
Cable Fault Types: Shorts, opens,
intermediate impedance
anomalies
Number Of Faults: End of cable and
two intermediate anomalies
Fault Threshold: User-defined, 4 to
10% (7% default)
TalkandTestModule
Length: 6600 ft. (2011.7 m)
Resolution: 1 ft. (0.3 m)
Length Accuracy: Up to 1000 ft.
(304.8 m) ±2 ft. (0.6 m) ±2% IR
Uncertainty; 1001 to 6600 ft.
(305.1 m to 2011.7 m) ±2 ft. (0.6 m)
±3% IR Uncertainty
Propagation Delay: 10 to 10,000 ns
Optical Loss: Dynamic Range:
+3 dBm to -55 dBm;
Resolution: 0.01 dB;
Accuracy: ±0.3 dB @ -20 dBm
Operating Temperature: 32 to 122°F
(0 to 50°C)
Storage Temperature: -4 to +140°F
(-20 to +60°C)
Humidity Tolerance: 10 to 90%,
noncondensing
Power: Derives power from the
SCAN-LAN VI
Weight: 5.1 oz. (144.6 g)
Specifications
rdering Information
ITEM CODE
SCAN-LAN VI
115-VAC.................................................................... S6000A
230-VAC ................................................................. S6000AE
alk and est Module................................................ S6001A
Optional Performance Modules
Modular Plug ............................................................... S691
Modular Jack .............................................................. S692
Coax Module................................................................ S693
FIBERoptic Kit (Performance Module and
Light Source)............................................................. S698A
FIBERoptic Kit Performance Module...................... S696A
FIBERoptic Light Source ............................................ S697A
Battery Pack (NiMH) ..................................................... S694
