Black Box ACS2004A User manual

About Black Box
Black Box Network Services is your source for more than 118,000 networking
and infrastructure products. You’ll find everything from cabinets and racks and
power and surge protection products to media converters and Ethernet switches
all supported by free, live 24/7 Tech support available in 20 seconds or less.
©Copyright 2009. All rights reserved.
BL A C K B O X®
Great tech support is just 20 seconds away
at 724-746-5500 or blackbox.com.
Black Box Tech Support: FREE! Live. 24/7.
Tech support the
way it should be.

BL A C K B O X®
Extend a DVI signal over single fiber optic cable.
Includes local and remote units.
One-to-one data transfer: no compression, no delay, and ideal EDIC
handling.
DVI Extender
June 2009
ACS2004A
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
call 724-746-5500) • FREE technical support 24 hours a day, 7 days a
week: Call 724-746-5500 or fax [phone] • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
Customer
Support
Information

724-746-5500 | blackbox.com
FCC and NOM Statements
Page 1
FEDERAL COMMUNICATIONS COMMISSION
AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE
STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if
not installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart B of Part 15 of FCC rules, which are designed
to provide reasonable protection against such interference when the equipment
is operated in a commercial environment. Operation of this equipment in a residen-
tial area is likely to cause interference, in which case the user at his own expense
will be required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission
from digital apparatus set out in the Radio Interference Regulation of Industry
Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par Industrie Canada.

724-746-5500 | blackbox.com
Page 2
DVI Extender
Normas Oficiales Mexicanas (NOM) Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.

724-746-5500 | blackbox.com Page 3
NOM Statement
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que
no sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com
Page 4
DVI Extender
TRADEMARKS USED IN THIS MANUAL
BLACK BOX and the Double Diamond logo are registered trademarks of
BB Technologies, Inc.
Any other trademarks mentioned in this manual are acknowledged to be the
property of the trademark owners.

724-746-5500 | blackbox.com Page 5
Table of Contents
Table of Contents
Chapter Page
1. Specifications ............................................................................................ 6
2. Overview...................................................................................................7
2.1 Introduction ........................................................................................7
2.2 Left Side Panel....................................................................................8
2.3 Right Side Panel..................................................................................9
2.4 What’s Included................................................................................10
2.5 Features ............................................................................................10
3. Installation and Operation......................................................................... 11
3.1 Installing the Transmitter and Receiver............................................. 11
3.2 Operation ......................................................................................... 11
4. Troubleshooting......................................................................................... 12
4.1 Calling Black Box............................................................................... 12
4.2 Shipping and Packaging ................................................................... 12

724-746-5500 | blackbox.com
Page 6
DVI Extender
1. Specifications
Compatible Cable: 50-/125-µm multimode fiber, OM3 preferred;
Link distance using 50-/125-µm multimode fiber is up to 1280 ft. (400 m);
Link distance using 62.5-/125-µm fiber is reduced to 576 ft. (180 m)
Emulation Mode: Supports extended EDIDs up to 256 bytes
Housing: Metal, black powder-coated
Link Distance: Up to 1280 ft. (400 m)
Mounting Holes: (2) on bottom plate
Optical Wavelength: 6 ch. CWDM 725–925 nm
Output Laser Class: TX unit: 1M; RX unit: 1
Pixel Rates: Supports DVI 1.0 single-link signals with pixel rates from 25 MHz
to 165 MHz
Transparency Mode: EDID, including HDCP®support on most sources
User Controls: TX unit: (1) push button for EDID mode select
Interface: (1) TX; (1) RX
Connectors: TX interface: (1) DVI-D (24 + 1 pin), (1) HDMI (via optional
adapter), (1) SC, (1) 2.1/5.5-mm barrel connector for power;
RX interface: (1) DVI-D (24 + 1 pin), (1) HDMI (via optional
adapter), (1) SC, (1) 2.1/5.5-mm barrel connector for power
Indicators: TX interface: (1) multicolor LED shows signal presence and mode:
Blue: Transparent; Green: EDID; Red flashing: EDID read incorrect;
Green flashing: EDID read OK;
RX interface: (1) multicolor LED shows link quality and operation mode:
Green: Link OK; Red flashing: No link
Power: (2) wall adapters*: Input: 120 VAC, 60 Hz or 230 VAC, 50 Hz;
Output: 5 VDC, 0.5 A, 2.5 W on barrel connector, 2.1/5.5 mm positive
on inner contact
* Local unit usually does not require a power supply since it draws power from
the DVI interface.
Size: 1.5"H x 2.2"W x 2.2"D (2 x 5.5 x 5.5 cm)
Weight: Each unit: 0.19 lb. (85 g)

724-746-5500 | blackbox.com Page 7
Chapter 2: Overview
2. Overview
2.1 Introduction
The ACS2004A is a single fiber optic DVI extender set that consists of a transmit-
ter and a receiver. It overcomes the limits of traditional copper-based extenders and
even other fiber optic extenders. It extends DVI signals up to 1920 x 1200 pixels
using optical signals transmitted without signal degradation, without compression,
and without delays.
The ACS2004A transmitter (TX) uses six optical infrared lasers operating at dif-
ferent colors of light (CWDM) to convert the DVI 1.0 compliant video data of your
PC/workstation to pulses of laser light, which travel along one optical multimode
fiber. The receiver (RX) at the other end of the fiber, up to 1280 feet (400 meters)
and five patch connections away, detects the infrared light pulses and converts
them back to the electrical domain of DVI. The ACS2004A does not modify to the
data. This preserves the DVI video data’s quality. Because it is real-time transmission,
no delays and no compression will degrade your high-resolution viewing experience.
The ACS2004A provides three modes of EDID handling. By default, a factory-
provided EDID (which has all common video modes supported) is presented to the
video source. When you press the TX unit’s push button anytime during operation,
it reads back the remote display’s EDID info and presents it to the source, even if the
display or link is disconnected (mode 2). When you press the TX unit’s push button
while powering-on the unit, EDID handling switches to transparency mode (mode
3). This enables you to support content protection systems, such as HDCP and
display control channels. When a video source is supported, it’s called “clock
stretching.“

724-746-5500 | blackbox.com
Page 8
DVI Extender
2.2 Left Side Panel
Figures 2-1 and 2-2 show the left side panels of the ACS2004A transmitter and
receiver. Figures 2-3 and 2-4 show the right side panels.
Figure 2-1. ACS2004A transmitter left side panel.
Figure 2-2.ACS2004A receiver left side panel.
Table 2-1. Left side panel components.
Number Component Description
1 DVI-D connector Link DVI in on TX unit;
Link DVI out on RX unit
2 Multicolor LED Status LED on both TX and RX units
3 Microswitch For DDC mode on both TX and RX units
123
123
