Black Box AVS-HDB-WPTX User manual

Order toll-free in the U.S. or for FREE 24/7 technical support: Call 877-877-BBOX
(outside U.S. call 724-746-5500)
www.blackbox.com • [e-mail]
Contact
Information
User Manual
Provides a wallplate interface for HDMI/VGA
input sources.
Video Extender - 4K HDMI, VGA, RS-232, Wallplate Transmitter with Audio
AVS-HDB-WPTX

Page 2 877-877-2269 | blackbox.com
Trademarks Used in this Manual
Trademarks Used in this Manual
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc.
Any other trademarks mentioned in this manual are acknowledged to be
the property of the trademark owners.

Page 3
877-877-2269 | blackbox.com
FCC and IC RFI Statements/NOM Statement
FEDERAL COMMUNICATIONS COMMISSION AND
INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy,
and if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case
the user at his own expense will be required to take whatever measures may be
necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation
of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de la classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par Industrie Canada.
Normas Oficiales Mexicanas (NOM)
Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.

Page 4 877-877-2269 | blackbox.com
NOM Statement
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe
colocar en libreros o gabinetes que impidan el flujo de aire por los orificios
de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.

Page 5
877-877-2269 | blackbox.com
NOM Statement
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

Page 6 877-877-2269 | blackbox.com
Safety Precautions
Safety Precautions
For reliable operation of the equipment and personnel safety, follow the guidelines
below for installation, use, and maintenance of the device.
1. The system must be grounded properly. Do not use two-blade plugs and ensure the
alternating power supply ranges from 100 to 240 VAC and 50 to 60 Hz.
2. Do not put the control panel in an environment that is not within the its temperature
tolerance.
3. Because the switch’s power generates heat when running, be sure the working
environment is properly ventilated to avoid damage caused by equipment
overheating.
4. Turn off the general power switch in humid weather or when the control panel will
be left unused for long time.
5. Before operating, be sure that the alternating current wire is pulled out of the power
supply.
6. NEVER open the casing of the equipment, DO NOT repair it on your own. This might
be harmful to persons or the equipment.
7. DO NOT splash any liquids on or around the equipment.

Page 7
877-877-2269 | blackbox.com
Table of Contents
Table of Contents
1. Specifications ..............................................................................................8
2. Overview .....................................................................................................9
2.1 Introduction .....................................................................................9
2.2 Features ...........................................................................................9
2.3 What's Included..............................................................................10
2.4 Hardware Description .....................................................................10
2.4.1 Front Panel.............................................................................10
2.4.2 Side Panel ..............................................................................12
2.4.3 Back Panel .............................................................................12
3. System Connection ....................................................................................14
3.1 Usage Precautions...........................................................................14
3.2 Connection Procedure ....................................................................14
3.3 Powering On the Unit.....................................................................15
3.4 PoC Solution...................................................................................15
3.5 Application .....................................................................................16
4. Operation................................................................................................... 17
4.1 Front-Panel Buttons ........................................................................ 17
4.2 RS-232 Communications Command............................................... 19
5. Troubleshooting and Maintenance.............................................................23

Page 8 877-877-2269 | blackbox.com
Chapter 1: Specifications
1. Specifications
Video
Input (1) HDMI, (1) VGA
Input Connector (1) 19-pin Type A HDMI F, (1) 15-pin VGA
Output (1) HDBaseT
Output Connector (1) RJ-45
Transmission Mode HDBaseT
Audio
Input (1) synchronous VGA audio
Input Connector (1) 3.5-mm stereo jack
Frequency Response 20 Hz–20 kHz
Impedance >10 ohms, ASNR, >85 dB @ 20 Hz–20 kHz
Control Ports
Control Ports (1) 3-pin RS-232 socket on front panel,
(1) 3-pin RS-232 socket on rear panel (shares the grounding
pole with 12 V output)
General
Resolution VGA: 800 x 600, 1024 x 768, 1280 x 800,1280 x 1024,
1440 x 900,1600 x 1200,
1920 x 1080, 1920 x 1200;
HDMI: 4K x 2K @ 30 Hz, 1080p 3D, 1080P(HD)/1080i/720
P/576P/576i/480P/480i
Transmission Distance 1080P < or = 60 m (PoC)
4K x 2K < or = 40 m (PoC)
Bandwidth 10.2 Gbps
HDMI Standard Support HDMI1.4 and HDCP
Hardware
Chassis Style Decora-style wall-gang
Dimensions 4.1"H x 3.5"W x 1.7"D (10.4 x 8.9 x 4.4 cm)
Weight 0.63 lb. (0.29 kg)
Environmental
Operating Temperature -14 to 104° F (-10 to +40° C)
Operating Humidity 10–90%

Page 9
877-877-2269 | blackbox.com
Chapter 2: Overview
2. Overview
2.1 Introduction
The Video Extender —4K HDMI, VGA, RS-232, Wallplate Transmitter with Audio (AVS-
HDB-WPTX) is a Decora style transmitter that installs in a double-gang wall box to pro-
vide a convenient interface for HDMI/VGA input sources. It has (1) HDMI IN, (1) VGA IN
and (1) HDBaseT OUT with PoC connector. It supports VGA as a full HD scale. HDMI 1.4
with 4k and 3D input signals support auto-switching and manual-switching. The
HDBaseT output supports 60-m UHD video transmission with PoC, and enables bi-direc-
tional RS-232 communication between the AVS-HDB-WPTX and the remote device.
Using PoC, AVS-HDB-WPTX can be powered via a far-end PoC receiver.
2.2 Features
• Selectable HDMI/VGA with audio input
• Supports VGA output resolution up to 1920x1200
• High bandwidth: 10.2 Gbps
• Built-in scaler, scales HDMI/VGA signals to match the native resolution of the display.
• Transmits HDMI signals up to 4K
• Compliant with HDMI 1.4, support 1080p 3D
• HDCP compliance, equipped with HDCP auto-tracking solution
• Provides auto-switching capability
• Supports multiple control methods including front-panel buttons, and RS-232. The
extender supports bi-directional RS-232 passthrough control.
• Supports firmware upgrading via USB.
• Powered by a 12-VDC power output or PoC connection up to 60 m.
• Made of aluminum, so it cools faster.

Page 10 877-877-2269 | blackbox.com
Chapter 2: Overview
2.3 What's Included
Your package should include the following items. If anything is missing or damaged,
contact Black Box Technical Support at 877-877-2269 or [e-mail].
• (1) Video Extender —4K HDMI, VGA, RS-232, Wallplate Transmitter with Audio (AVS-
HDB-WPTX)
• (4) Screws (for AVS-HDB-WPTX)
• (3) Pluggable Terminal Blocks ([1] 2-pin block, [1] 3-pin block, and [1] 4-pin block)
• (1) Faceplate
• (4) Screws (for the faceplate)
• This printed user manual
2.4 Hardware Description
2.4.1 Front Panel
1
2
3
4
5
6
7 8
9
Figure 2-1. Front panel.

Page 11
877-877-2269 | blackbox.com
Chapter 2: Overview
Table 2-1. Components.
Number Name Description
1Power LED Lights red when power is on.
2SOURCE/AUTO button • Used as video source selection button (with backlight off): Press
to select one source, press again to select next source, switch-
ing circularly between HDMI and VGA. The indicator of the
selected input source will light green.
• Used as switching mode selection button (with backlight on):
Press and hold for 3 seconds or more to enter Auto-switching
mode. The LED lights green when the unit is in auto-switching
mode. Press and hold the button for 3 seconds or longer to
enter in Manual-switching mode.
3RS-232 Serial port, 3-pin
pluggable terminal block
This connects to the control terminal to control the AVS-HDB-
WPTX, and supports bi-directional RS-232 control (send control
signal from local or transmitter, send receive control signal from
far-end devices).
4VGA IN LED Connects to VGA source device.
• Lights yellow when there is a VGA signal input.
• Lights green when the signal source is chosen as the input
source.
• Off when there is no VGA input signal.
5AUDIO IN Connect with the audio output socket of VGA source device,
deliver synchronous audio source with VGA signal source when
choosing VGA as source signal.
6HDMI IN Connect to HDMI source device.
• Lights yellow when there is an HDMI signal input.
• Lights green when the signal source is the input source.
• Off when there is no HDMI input signal.
7LINK and HDCP LED LINK: Twisted Pair Link status indicator, lights green when suc-
cessfully connected.
• HDCP: HDCP compliance indicator, lights green when the
source signals is HDCP; blinks when it is not HDCP; and turns
off when there is no source signal.
8RESET button Press this button to reboot the AVS-HDB-WPTX.
9USB Used for firmware update. Plug a flash disk or other storage
device with update file (MERGE.bin), and send command
50698% to update the firmware.

Page 12 877-877-2269 | blackbox.com
Chapter 2: Overview
2.4.2 Side Panel
Figure 2-2. Side panel.
1. HDBaseT OUT: RJ-45 port, connect to a receiver via a CAT5e/6 cable to deliver
Audio/Video signals, supports PoC.
NOTE: AVS-HDB-WPTX supports unidirectional PoC. It can be powered the by far-end
receiver but it can’t power the far-end receiver.
2.4.3 Back Panel
Figure 2-3. Back panel.

Page 13
877-877-2269 | blackbox.com
Chapter 2: Overview
Table 2-2. Back panel components.
Number Name Description
1Power In Power in port, 2-pin pluggable terminal block, connects to
12-VDC power adapter.
2Power out Power out port, connects to AVS-CTRL8 to power it with a
12-VDC power output.
3RS-232 serial port Connects to a far-end receiver, supports bi-directional RS-232
control leads (sends the control signal from local devices or
receives the control signal sent from far-end devices.

Page 14 877-877-2269 | blackbox.com
Chapter 3: System Connection
3. System Connection
3.1 Usage Precautions
1. Install the system in a clean environment that has a proper temperature and humidity.
2. Make sure that all the power switches, plugs, sockets, and power cords are insulated
and safe.
3. Connect all devices before powering on.
Blu-ray™
AVS-HDB-RX
Figure 3-1. Connections.
3.2 Connection Procedure
Step 1: Connect an HDMI source device (e.g. Blu-ray DVD) to the HDMI input port of
the AVS-HDB-WPTX with HDMI cable. Connect a VGA source device (e.g. PC)
to the VGA input port of the AVS-HDB-WPTX with VGA cable.
Step 2: Connect a AVS-HDB-RX to the HDBaseT port on the rear panel with twisted
pair.
Step 3: Connect a HDMI display to the HDMI OUT port of AVS-HDB-RX.

Page 15
877-877-2269 | blackbox.com
Chapter 3: System Connection
Step 4: Connect a control terminal to the RS-232 port on the front panel of the
AVS-HDB-RX.
Step 5: Connect a control device (e.g. PC) to the RS-232 port of the AVS-HDB-WPTX or
the AVS-HDB-RX (bi-directional RS-232 control, either is available).
Step 6: Connect the 24-VDC power adapter to the power port of the AVS-HDB-RX.
AVS-HDB-WPTX can get power from AVS-HDB-RX via PoC.
NOTE: AVS-HDB-WPTX supports unidirectional PoC, i.e, AVS-HDB-WPTX can get power
from far-end PoC devices with PoC function, but it can’t power far-end PoC
devices when the power supply is connected to the AVS-HDB-WPTX.
3.3 Powering On the Unit
AVS-HDB-WPTX has a 12-V power output port on the rear panel. Connect the 12-VDC
power output port of the AVS-HDB-WPTX to the power port of the AVS-CTRL8 (refer
to the following figure). AVS-HDB-WPTX can power the AVS-CTRL8.
AVS-CTRL8
Figure 3-2. Power connections.
3.4 PoC Solution
AVS-HDB-WPTX has a HDBaseT OUTPUT port on the rear panel, which can extend
HDMI/ VGA signals up to 60 m. It also supports PoC, which allows several terminals to
share the same power supply and eliminates the need for an extra power supply at the
remote nodes.

Page 16 877-877-2269 | blackbox.com
Chapter 3: System Connection
Connect a 24-VDC power adapter to the power port of AVS-HDB-RX. AVS-HDB-WPTX
can be powered synchronously via PoC.
Figure 3-3. PoC connections.
3.5 Application
Use the AVS-HDB-WPTX for computer monitoring, conference rooms, large-screen
displays, television, education applications and more.

Page 17
877-877-2269 | blackbox.com
Chapter 4: Operation
4. Operation
4.1 Front-Panel Buttons
AVS-HDB-WPTX has a channel switching button on the front panel, through which
users can switch input source signals.
It supports both manual switching and auto switching. (The default setting is Auto
switching.) Press and hold the switching button for 3 seconds or send command
“50770% “ and “50771%” to switch between the two modes.
Switching modes:
• Auto switching mode: In this mode, the indicator will light green, and
AVS-HDB-WPTX will recognize the last connected source device as the input source
automatically.
• Disconnect the present source device, and it will deliver the other source signal (if
there is an input signal on the other source).
• Manual switching mode: In this mode, the indicator will remain off. Press the
switching button to select the input source, it will switch circularly between HDMI and
VGA. Or switch it by sending RS-232 commands. The indicator of the selected input
source will light green.
4.2 RS-232 Control
RS-232 can be transmitted bi-directionally between AVS-HDB-WPTX and AVS-HDB-RX,
so it can control a third-party RS-232 device locally or control an AVS-HDB-WPTX from
remotely. To control a third-party RS-232 device, set the baud rate of this device to
2400, 4800, 9600, 19200, 38400, 57600, or 115200.

Page 18 877-877-2269 | blackbox.com
Chapter 4: Operation
Accessing through Serial
1. Using the client, select “serial” and enter “9600” for the speed (baud rate).
2. No username or password is required.
Set the COM number, baud rate, data bit, stop bit, and parity bit correctly so you can
send commands in the Command Sending Area of the screen.
NOTE: To control the AVS-HDB-WPTX via an RS-232 port, configure the communication
protocol parameters as: Baud rate: 9600; Data bit: 8; Stop bit: 1; Parity bit: none.

Page 19
877-877-2269 | blackbox.com
Chapter 4: Operation
4.2 RS-232 Communication Commands
Table 4-1. RS-232 commands.
Switch Commands
Command Function Feedback Example
50701% Switch to HDMI input Switch to HDMI
50704% Switch to VGA input Switch to VGA
50705% Change the horizontal polarity to the oppo-
site.
Hpolarity:0/1
50706% Change the vertical polarity to the opposite. Vpolarity:0/1
50707% Check the present resolution and polarity. 1920 x 1080
Hpolarity:1
Vpolarity:0
50770% Enable auto-switching Auto Switching
50771% Disable auto-switching Manual Switching
Resolution Commands
Command Function Feedback Example
50619% Change the EDID resolution to 1360 x 768
HD
Resolution: 1360 x 768
50626% Change the EDID resolution to 1024 x 768
XGA
Resolution: 1024 x 768
50627% Change the EDID resolution to 1280 x 720
720P
Resolution: 1280 x 720
50628% Change the EDID resolution to 1280 x 800
WXGA
Resolution: 1280 x 800
50629% Change the EDID resolution to 1920 x 1080
1080P
Resolution: 1920 x 1080
50620% Change the EDID resolution to 1920 x 1200
WUXGA
Resolution: 1920 x 1200
50621% Change the EDID resolution to 1600 x 1200
UXGA
Resolution: 1600 x 1200
NOTE: Commands with grey background are for VGA sources only.

Page 20 877-877-2269 | blackbox.com
Chapter 4: Operation
Table 4-1 (continued). RS-232 commands.
Setup Commands
Command Function Feedback Example
502xx% Set the brightness to xx. XX ranges
from 00 to 99.
Brightness: xx
503xx% Set the contrast to xx. XX ranges
from 00 to 99
Contrast: xx
504xx% Set the saturation to xx. XX ranges
from 00 to 99.
Saturation: xx
505xx% Set the sharpness to xx. XX ranges
from 00 to 99.
Sharpness: xx
50606% Auto-adjust the input parameter. VGA Input Auto
50607% Adjust the color temperature. Color Temperature: xx (xx can
be medium, warm, user, or
cool)
50608% Set the aspect ratio. Enter this
command to cycle through options.
Aspect Ratio: xx (xx can be
16:9, 4:3, or auto.)
50614% Set the picture mode. Enter this
command to cycle through options.
Picture Mode: xx (xx can be
dynamic, standard, mild, or
user.)
50699% Check the system version. Version Vx.x.x
50779% Switch to RS-232 mode 1, enable
scaler to control far-end devices.
RS-232 Mode 1: RS-232 Control
Scaler and Remote
50780% Switch to RS-232 mode 2, enable
far-end devices to control scaler.
RS-232 Mode 2: RS-232 and
Remote Control Scaler
50790% Set the HDCP status of the HDMI
output socket to Active.
HDCP Active
50791% Set the HDCP status of HDMI output
socket to On.
HDCP On
50792% Set the HDCP status of HDMI output
socket to Off.
HDCP Off
50698% Software update. —
NOTE: Commands with grey background are for VGA sources only.
