Black Box LE7005A-UTP-R2 User manual

Simultaneous data/fax modem and Ethernet access
for your notebook computer.
Platform-independent—supports all PCMCI 2.1,
Type II-compliant PCs.
The Fax/Modem installs as a COM port, runs an
extended T command set, and works with all
major DOS and Windows®fax/modem software.
Supports K56flex™, ITU V.34, V.32 bis, V.32,
V.22 bis, V.22 /B, V.23, V.21 and Bell 212 and
103J data transmission.
Supports ITU V.17, V.29, V.27 ter and V.21 ch 2 send
and receive fax transmission (Class 1 & 2).
Increased modem throughput with V.42 bis and
MNP®5 data compression.
Error detection and correction using V.42 L PM
and MNP 2-4 protocol.
utomatic modem sleep mode for longer
PC battery life.
MNP10 data-throughput enhancement.
16550 U RT.
PCMCI Card and Socket Services support.
Direct Enablers to reduce memory
requirements included.
Superior Ethernet throughput performance using
Dynamic Pipelining Technology.
Supports all major network operating systems.
vailable with 10B SE-T or 10B SE2 and 10B SE-T
Ethernet Media Connections.
Easy installation and configuration.
Self-test and diagnostic.
T
he Ethernet+ 56-kbps Data/Fax
Modem Card integrates a high-
performance Ethernet Adapter
ith a 56-kbps Modem (K56flex™)
in one multi-function PC card.
With the Card, you can
connect to an Ethernet LAN
as you transfer data or fax
information. Using just one
PCMCIA slot, you can transfer
files and data directly from the
net ork to a remote location,
and vice versa.
You get PCMCIA compatibility
and plug-and-play convenience
thanks to the support of all major
KeyFeatures
ETHERNET+56-KBPSDATA/FAXMODEMCARD
Card and Socket Services
vendors. And the Card’s ide
range of ell-tested NOS drovers
gives you compatibility ith all
major Net ork Operating
Systems.
The Ethernet+ 56-kbps
Data/Fax Modem Card is installed
as a COM port and runs an
extended AT command set. It also
orks ith all major DOS and
Windo s fax/modem soft are.
So you can use the same
fax/modem soft are you
already have.
Black Box Corporation • 1000 Park Drive • La rence, PA 15055-1018 • Tech Support: 724-746-5500 • www.blackbox.com • e-mail: [email protected]
© 2001. All rights reserved.
Black Box Corporation.
09/18/1998 #16311
Telephone
Net ork
Ethernet
Ethernet+ 56-kbps Data/Fax
Modem Card (LE7005A-UTP-R2)

16550 UART: Enhanced UART
interface provides buffering of
data. This feature is essential in
providing reliable high-speed
communication, hen used in
multitasking environments such
as Windo s or OS/2.
Certifications: FCC Part 15, subpart
B class B FCC Part 68 CE Various
European PTTs
Communication Software:
All popular DOS and Windo s
soft are (including Remote
LAN Access)
Data Command Set: Fully AT
command compatible
Data Compression: ITU V.42 bis
(up to 4:1 compression ratio);
MNP®5 (up to 2:1 compression
ratio); MNP 10 (data-throughput
enhancement)
Data Rates:
K56flex (56 kbps),
ITU V.34 (33.6 kbps),
V.32 bis (14.4 kbps),
V.32 (9.6 kbps),
V.22 bis (2.4 kbps),
V.22A/B (1.2/0.6 kbps),
V.23 (1.2/0.6 kbps),
V.21 (300 bps),
Bell 212A (1.2 kbps),
Bell 103 (0-300 bps)
Diagnostic: Po er-on self-test
Error Correction: ITU V.42 LAPM,
MNP 2-4
Fa Command Set: ITU Group 3,
Class 1 (EIA-578), Class 2 (EIA-
592)
Fa Rates:
ITU V.17 (14.4 kbps),
V.29 (9.6 kbps),
V27 ter (4.8 kbps),
V.21 channel 2 (300 bps)
Interface Standards: PCMCIA 2.1,
Type II; IEEE 802.3
Nonvolatile RAM: Telephone-
numbers directory and stored
profiles
PCMCIA Software Support: Card
and Socket Services and Direct
Enablers
Power Consumption:
LE7005A-UTP-R2: 170 mA
(Active), 90 mA (Sleep);
LE7005A-CMB-R2: 380 mA
(Active), 300 mA (Sleep)
Connector: RJ-11C, female
Size: 3.4"H x 2.1"W x 0.2"D
(8.5 x 5.4 x 0.5 cm)
Weight: 0.08 lb. (0.03 kg)
Specifications
Ordering Information
ITEM CODE
Ethernet+ 56-kbps Data/Fax Modem Card
10BASE-T .................................................LE7005A-UTP-R2
Combo (UTP and BNC)........................LE7005A-CMB-R2
NDIS DOS OS/2 2.x
NDIS 2
NDIS
WIN NT 3.1
WIN NT 3.5x
WIN 95
NDIS 3 ODI CLIENT
ODI DOS
ODI PACKET
PACKET
Driver Protocols
Black Box Drivers
Network Operating Systems
• LANtastic®
• DEC M
Pathworks®
• Banyan®VINES®
• Windows®for
Workgroups
• Microsoft®LAN
Manager
• IBM®LAN
Server
• IBM PC LAN
• Chameleon®
NEW
• F P PC/ CP
• IBM OS/2®LAN
Server
• Microsoft LAN
Manager
• Windows 95
• Windows N 3.1
• Windows
N M 3.5x
• Windows N
Server
• Novel®NetWare®
2.x, 3.x, 4.x
• Novell DOS 7
• Novell NetWare
Lite M
• Windows 95
• Windows for
Workgroups
• Chameleon
NEW
• F P PC/ CP
• Wollongong
Pathway
• Wollongong
WIN/ CP
• PC NFS
• F P PC/ CP
