USER MANUAL
24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
LH1690C-LC-R2
NETWORK
INTERFACE
ADAPTER PCIE

2
TABLE OF CONTENTS
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
ESD WARNINGS............................................................................................................................................................................................ 3
1. SPECIFICATIONS...................................................................................................................................................................................... 4
2. OVERVIEW................................................................................................................................................................................................. 5
2.1 Introduction.......................................................................................................................................................................................................... 5
2.2 Features ............................................................................................................................................................................................................... 5
2.3 What’s Included................................................................................................................................................................................................... 5
3. HARDWARE INSTALLATION.................................................................................................................................................................... 6
4. OPERATION............................................................................................................................................................................................... 8
4.1 LED Indicator Description................................................................................................................................................................................... 8
4.2 Wake On LAN (WOL)........................................................................................................................................................................................... 8
5. CLIENT INSTALLATION ......................................................................................................................................................................... 10
APPENDIX A: REGULATORY INFORMATION ........................................................................................................................................... 12
A.1 FCC Statement .................................................................................................................................................................................................. 12
A.2 NOM Statement ................................................................................................................................................................................................ 13
APPENDIX B: DISCLAIMER/TRADEMARKS ............................................................................................................................................ 14
B.1 Disclaimer .......................................................................................................................................................................................................... 14
B.2 Trademarks Used in this Manual..................................................................................................................................................................... 14

3
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
ESD WARNINGS
ELECTROSTATIC DISCHARGES (ESD)
A sudden electrostatic discharge can destroy sensitive components. Proper packaging and grounding rules must therefore be
observed. Always take the following precautions:
1. Transport boards and cards in electrostatically secure containers or bags.
2. Keep electrostatically sensitive components in their containers, until they arrive at an electrostatically protected workplace.
3. Only touch electrostatically sensitive components when you are properly grounded.
4. Store electrostatically sensitive components in protective packaging or on anti-static mats.
GROUNDING METHODS
The following measures help to avoid electrostatic damages to the device:
5. Cover workstations with approved antistatic material. Always wear a wrist strap connected to a properly grounded workplace.
6. Use antistatic mats, heel straps, and/or air ionizers for more protection.
7. Always handle electrostatically sensitive components by their edge or by their casing.
8. Avoid contact with pins, leads, or circuitry.
9. Turn off power and input signals before inserting and removing connectors or connecting test equipment.
10. Keep your work area free of non-conductive materials, such as ordinary plastic assembly aids and Styrofoam.
11. Use field service tools such as cutters, screwdrivers, and vacuum cleaners that are conductive.
ESD WARNINGS

4
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 1: SPECIFICATIONS
TABLE 1-1. SPECIFICATIONS
SPECIFICATION DESCRIPTION
Approvals FCC Class B, CE, RoHS, EMI
Standards
IEEE 802.3z Gbit/s 1000BASE-X;
IEEE 802.3x Full-Duplex Flow Control;
IEEE 802.1Q VLANs
Connectors (1) 850 nm LC Multimode
Fiber Cable Supported 62.5-/125-µm, 50-/125 µm multimode
Indicators LEDs on bracket: (1) Link/Act, (1) FDX
Data Transfer Mode
Full-duplex with flow control;
1000 Mbps speed
Bus Slot PCI-e 1.1 compliant
Power From the PCI-e bus; maximum 1.32 W +3.3 VDC at 0.4 A
Software Supported
Microsoft Windows XP, Vista, Server 2008/R2, Windows 7, Windows 8/8.1, Server 2012;
Novell Netware 5.x, 6.x Server;
Novell Netware DOS Client for ODI 16-bit;
NDIS2 driver Support DOS MS client, Lantastic, Lanman, Norton Ghost;
Linux driver for kernel up to 4.7;
FreeBSD 7.x and 8.0 driver
Dimensions
Card only: 4.5 x 2.75 in. (11.43 x 6.98 cm;)
With bracket: 5 x 4.75 in. (12.7 x 12.06 cm)
Weight 0.119 lb. (0.054 kg)
Environmental
Operating Temperature: 32 to 104° F (0 to 40° C);
Humidity: 5 to 90%

5
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 2: OVERVIEW
2.1 INTRODUCTION
The Network Interface Adapter PCIe 1000BASE-SX LC (LH1690C-LC-R2) is a Gigabit Ethernet Board that fully complies with all
IEEE 802.3z and 1000BASE-X standards. Two LED indicators (LINK/ACT and FDX) on the bracket will help to oversee the board link,
activities and full-duplex status. The adapter has one 850-nm LC multimode fiber connector.
2.2 FEATURES
Supports high-bandwidth 1000 Mbps network speed
Complies with IEEE 802.3z 1000BASE-X fiber interface
Operates in full-duplex mode
Uses ieee 802.3x full-duplex flow control
Has (1) PCI-e bus, complies with PCIe rev 1.1 interface
Supports jumbo frame
Offers high-level VLAN filtering
Supports IP headers and TCP/UDP checksums offload
On-board screening of VLAN tagged ethernet frames
Supports Wake On LAN
Complies with RoHS standard
2.3 WHAT’S INCLUDED
Your package contains the following item:
(1) Network Interface Adapter PCIe 1000BASE-SX LC (LH1690C-LC-R2)
If this is missing or damaged, contact Black Box Technical Support at 877-877-2269 or [e-mail]

6
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 3: HARDWARE INSTALLATION
The following instructions apply to installing the Network Interface Adapter PCIe in most systems. Refer to the manuals that were
supplied with your system for details about performing these tasks on your particular system.
To install the network adapter card, perform the following procedure:
WARNING: Before installing the adapter, make sure the system power is OFF and unplugged from the power outlet, and that you
have followed proper electrical grounding procedures.
1. High voltage inside the system presents a safety hazard. Make sure the power is off before removing the cover.
2. Remove the system cover and select any empty PCIe slot. See Fig 3-1.
NOTE: If you do not know how to identify a PCIe slot, refer to your system documentation.
FIGURE 3-1. REMOVE THE SYSTEM’S COVER
3. Select an empty, non-shared PCIe slot and remove the faceplate. Keep the faceplate in a safe place. You may need it for future
use.
FIGURE 3-2. REMOVE THE PCIE SLOT’S FACEPLATE

7
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 3: HARDWARE INSTALLATION
NOTE: If you cannot locate or know how to find an PCIe slot, refer to the documentation that came with your system.
4. Remove the Network Interface Adapter PCIe from the shipping package and store the packaging material in a safe location.
CAUTION: Wear a grounding device and observe electrostatic discharge precautions when installing the network adapter card in a
system. Failure to observe this caution could result in damage to the card.
5. Applying even pressure at both corners of the card, push the adapter card until it is firmly seated in the PCIe slot. Make sure the
card is securely seated.
FIGURE 3-3. INSTALLING THE CARD IN A PCIE SLOT
6. Replace the system’s cover and secure it with the screws removed in Step 2.
7. Disconnect any personal anti-static devices.
8. Power the system on.

8
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 4: OPERATION
4.1 LED INDICATOR DESCRIPTION
The The table below describes the LED indicators and their functions.
TABLE 4-1. LED INDICATORS
LED COLOR FUNCTION
Link/Act Green Lights when cable connection is good and speed is 1000 Mbps.
Blinks when traffic is present.
FDX Green Lights when full-duplex mode is active.
4.2 WAKE ON LAN (WOL)
The Wake on LAN function on this adapter can recognize a wake-up frame and signal the PC to power up.
FIGURE 4-1. WAKE ON LAN VERIFY: BIOS SUPPORT SCREEN
If the PC’s motherboard supports WOL and PCIe, the Wake up-Link connector is not necessary).
To disable the WOL function (Default): Set WOL jumper (J1) to the OFF position.

9
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 4: OPERATION
FIGURE 4-2. LOCATION OF JUMPER J1 ON THE ADAPTER
To enable the WOL function: Set the WOL jumper (J1) to the ON position.
1
23
J1
ON OFF
(Default)
WoL
1
23
J1
ON OFF
WoL
FIGURE 4-3. JUMPER J1 SETTINGS

10
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 22 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
CHAPTER 5: CLIENT INSTALLATION
NIC CONFIGURATION
1. Enter into the operating system’s control panel.
2. From the Device Manager screen, configure the network adapters as shown in Figures 5-1 through 5-4.
3. Double-click on Realtek PCIe GBE Family Controller in the Device Manager screen.
FIGURE 5-1. DEVICE MANAGER SCREEN
4. The Properties screen appears.
4a. Select Shutdown Wake-on-LAN “Enabled“ as shown in Figure 5-2.
FIGURE 5-2. PROPERTIES SCREEN
