Black Box LBS3041AE User manual

8+1 Managed Ethernet Switch
User's Manual
Release v1.13

ii
Table of Contents
CAUTION----------------------------------------------------------------------------------------------------------------------- VII
ELECTRONIC EMISSION NOTICES ------------------------------------------------------------------------------------------ VII
CHAPTER 1. INTRODUCTION --------------------------------------------------------------------------------------------2
1-1. OVERVIEW OF 8+1 MANAGED ETHERNET SWITCH ------------------------------------------------------------------2
1-2. CHECKLIST ----------------------------------------------------------------------------------------------------------------4
1-3. FEATURES -----------------------------------------------------------------------------------------------------------------4
1-4. VIEW OF 8+1 MANAGED ETHERNET SWITCH ------------------------------------------------------------------------5
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs) --------------------------------------5
1-4-2. User Interfaces on the Rear Panel -------------------------------------------------------------------------7
1-5. VIEW OF THE OPTIONAL MODULES ------------------------------------------------------------------------------------7
CHAPTER 2. INSTALLATION-------------------------------------------------------------------------------------------- 10
2-1. STARTING 8+1 MANAGED ETHERNET SWITCH UP----------------------------------------------------------------- 10
2-1-1. Hardware and Cable Installation -------------------------------------------------------------------------- 10
2-1-2. Cabling Requirements --------------------------------------------------------------------------------------- 11
2-1-2-1. Cabling Requirements for TP Ports---------------------------------------------------------------- 12
2-1-2-2. Cabling Requirements for 1000SX/1000LX/100FX Module --------------------------------- 12
2-1-2-3. Switch Cascading in Topology ---------------------------------------------------------------------- 14
2-1-3. Configuring the Management Agent of 8+1 Managed Ethernet Switch ------------------------ 18
2-1-3-1. Configuring the Management Agent of Switch through the Serial RS-232 Port ------- 19
2-1-3-2. Configuring Management Agent of Switch through Ethernet Port ------------------------- 21
2-1-4. IP Address Assignment -------------------------------------------------------------------------------------- 22
2-2. TYPICAL APPLICATIONS ------------------------------------------------------------------------------------------------ 27
CHAPTER 3. BASIC CONCEPT AND MANAGEMENT -------------------------------------------------------- 29
3-1. WHAT’S THE ETHERNET ----------------------------------------------------------------------------------------------- 29
3-2. MEDIA ACCESS CONTROL (MAC)------------------------------------------------------------------------------------ 32
3-3. FLOW CONTROL -------------------------------------------------------------------------------------------------------- 38
3-4. HOW DOES A SWITCH WORK? ----------------------------------------------------------------------------------------- 41
3-5. SNMP ------------------------------------------------------------------------------------------------------------------- 44
3-6. SPANNING TREE PROTOCOL ------------------------------------------------------------------------------------------ 53
3-7. VIRTUAL LAN ----------------------------------------------------------------------------------------------------------- 65
3-8. GARP VLAN REGISTRATION PROTOCOL (GVRP) --------------------------------------------------------------- 71
3-9. LINK AGGREGATION ---------------------------------------------------------------------------------------------------- 76
3-10. IGMP SNOOPING----------------------------------------------------------------------------------------------------- 84
3-11. DYNAMIC HOST CONFIGURATION PROTOCOL (DHCP)---------------------------------------------------------- 89
CHAPTER 4. OPERATION OF WEB-BASED MANAGEMENT ---------------------------------------------- 95
4-1. WEB MANAGEMENT HOME OVERVIEW ------------------------------------------------------------------------------ 96
4-2. PORT STATUS AND COUNTERS ------------------------------------------------------------------------------------- 100
4-2-1.Port Current Status ------------------------------------------------------------------------------------------ 100
4-2-2. Port Counters ------------------------------------------------------------------------------------------------ 104
4-2-3. Port Configuration------------------------------------------------------------------------------------------- 107
4-2-4. Port Mirror----------------------------------------------------------------------------------------------------- 109
4-2-5. Port Quality Statistic -----------------------------------------------------------------------------------------110
4-2-6. Port Quality Rule Setting -----------------------------------------------------------------------------------111
4-3. CONFIGURATION -------------------------------------------------------------------------------------------------------113
4-3-1. System Configuration ---------------------------------------------------------------------------------------113

iii
4-3-1-1. Username / Password Setting ---------------------------------------------------------------------114
4-3-1-2. IP Configuration----------------------------------------------------------------------------------------115
4-3-1-3. System Time Setting----------------------------------------------------------------------------------117
4-3-1-4. Location/Contact Setting---------------------------------------------------------------------------- 120
4-3-2. SNMP Configuration---------------------------------------------------------------------------------------- 122
4-3-3. Max. Packet Length Setting ------------------------------------------------------------------------------ 124
4-3-4. Broadcasting Suppression -------------------------------------------------------------------------------- 125
4-3-5. IGMP Snooping---------------------------------------------------------------------------------------------- 126
4-3-6. Misc. Feature Configuration ------------------------------------------------------------------------------ 128
4-3-7. Spanning Tree Configuration----------------------------------------------------------------------------- 131
4-3-7-1. STP Status --------------------------------------------------------------------------------------------- 131
4-3-7-2. STP Configuration------------------------------------------------------------------------------------ 133
4-3-8. Port Trunking Configuration ------------------------------------------------------------------------------ 137
4-3-9. Filtering Configuration ------------------------------------------------------------------------------------- 144
4-3-10. VLAN Configuration--------------------------------------------------------------------------------------- 151
4-3-11. GVRP Configuration -------------------------------------------------------------------------------------- 160
4-3-12. 802.1x Configuration ------------------------------------------------------------------------------------- 167
4-3-13. Failover Configuration ------------------------------------------------------------------------------------ 185
4-3-14. Trap/Alarm Configuration-------------------------------------------------------------------------------- 187
4-3-15. Save Configuration---------------------------------------------------------------------------------------- 190
4-4. DIAGNOSTICS --------------------------------------------------------------------------------------------------------- 192
4-5. SHOW LOG DATA ----------------------------------------------------------------------------------------------------- 196
4-6. SOFTWARE UPGRADE ----------------------------------------------------------------------------------------------- 201
4-7. REBOOT --------------------------------------------------------------------------------------------------------------- 202
4-8. LOGOUT --------------------------------------------------------------------------------------------------------------- 203
CHAPTER 5. OPERATION OF MENU-DRIVEN CONSOLE -------------------------------------------------- 204
5-1. TEXT-BASED MENU-DRIVEN MANAGEMENT OVERVIEW --------------------------------------------------------- 205
5-2. PORT STATUS AND COUNTER --------------------------------------------------------------------------------------- 208
5-2-1.Port Current Status ------------------------------------------------------------------------------------------ 208
5-2-2. Port Counters ------------------------------------------------------------------------------------------------ 213
5-2-3. Port Configuration------------------------------------------------------------------------------------------- 216
5-2-4. Port Mirror----------------------------------------------------------------------------------------------------- 218
5-2-5. Port Quality Statistic ---------------------------------------------------------------------------------------- 219
5-2-6. Port Quality Rule Setting ---------------------------------------------------------------------------------- 220
5-3. CONFIGURATION ------------------------------------------------------------------------------------------------------ 222
5-3-1. System Configuration -------------------------------------------------------------------------------------- 222
5-3-1-1. Create Username / Password--------------------------------------------------------------------- 223
5-3-1-2. Username / Password Setting -------------------------------------------------------------------- 224
5-3-1-3. IP Configuration--------------------------------------------------------------------------------------- 225
5-3-1-4. System Time Setting--------------------------------------------------------------------------------- 227
5-3-1-5. Location/Contact Setting---------------------------------------------------------------------------- 232
5-3-2. SNMP Configuration---------------------------------------------------------------------------------------- 234
5-3-3. Packet Length------------------------------------------------------------------------------------------------ 238
5-3-4. Broadcasting Suppression -------------------------------------------------------------------------------- 239
5-3-5. IGMP Snooping---------------------------------------------------------------------------------------------- 240
5-3-6. Spanning Tree Configuration----------------------------------------------------------------------------- 242
5-3-6-1. STP State Setting------------------------------------------------------------------------------------- 242
5-3-6-2. STP Status --------------------------------------------------------------------------------------------- 243
5-3-6-3. STP Configuration------------------------------------------------------------------------------------ 245

iv
5-3-7. Misc. Feature Configuration ------------------------------------------------------------------------------ 249
5-3-8. Port Trunking Configuration ------------------------------------------------------------------------------ 253
5-3-9. Filtering Configuration ------------------------------------------------------------------------------------- 261
5-3-10. VLAN Configuration--------------------------------------------------------------------------------------- 271
5-3-11. GVRP Configuration -------------------------------------------------------------------------------------- 281
5-3-12. 802.1x Configuration ------------------------------------------------------------------------------------- 288
5-3-13. Failover Configuration ------------------------------------------------------------------------------------ 303
5-3-14. Trap/Alarm Configuration-------------------------------------------------------------------------------- 305
5-3-15. Save Configuration---------------------------------------------------------------------------------------- 309
5-4. DIAGNOSTICS ----------------------------------------------------------------------------------------------------------311
5-5. SHOW LOG DATA ----------------------------------------------------------------------------------------------------- 315
5-6. SOFTWARE UPGRADE ----------------------------------------------------------------------------------------------- 320
5-7. REBOOT --------------------------------------------------------------------------------------------------------------- 321
5-8. LOGOUT --------------------------------------------------------------------------------------------------------------- 322
6. MAINTENANCE --------------------------------------------------------------------------------------------------------- 323
6-1. RESOLVING NO LINK CONDITION----------------------------------------------------------------------------------- 323
6-2. Q&A ------------------------------------------------------------------------------------------------------------------- 323
APPENDIX A TECHNICAL SPECIFICATIONS--------------------------------------------------------------------- 324
APPENDIX B NULL MODEM CABLE SPECIFICATIONS ------------------------------------------------------ 329
APPENDIX C MIB SPECIFICATIONS --------------------------------------------------------------------------------- 330

v
Revision History
Release Date Revision
1.13 09/01/2004 A1

vi

vii
Caution
Circuit devices are sensitive to static electricity, which can damage their delicate electronics.
Dry weather conditions or walking across a carpeted floor may cause you to acquire a static
electrical charge.
To protect your device, always:
•Touch the metal chassis of your computer to ground the static electrical charge before
you pick up the circuit device.
•Pick up the device by holding it on the left and right edges only.
Electronic Emission Notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A computing
device pursuant to Subpart J of part 15 of FCC Rules, which are designed to provide
reasonable protection against such interference when operated in a commercial environment.
European Community (CE) Electromagnetic Compatibility Directive
This equipment has been tested and found to comply with the protection requirements of
European Emission Standard EN55022/EN60555-2 and the Generic European Immunity
Standard EN50082-1.
EMC:
EN55022(1988)/CISPR-22(1985) class A
EN60555-2(1995) class A
EN60555-3
IEC1000-4-2(1995) 4K V CD, 8KV, AD
IEC1000-4-3(1995) 3V/m
IEC1000-4-4(1995) 1KV – (power line), 0.5KV – (signal line)

Publication date: September, 2004
Revision A1
1
About this user’s manual
In this user’s manual, it will not only tell you how to install and connect your network
system but also configure and monitor the 8+1 MANAGED ETHERNET SWITCH
through the built-in console and web by RS-232 serial interface and Ethernet ports
step-by-step. Many explanations in detail of hardware and software functions are
shown as well as the examples of the operation for web-based interface and text-
based menu-driven console interface.
Overview of this user’s manual
Chapter 1 “Introduction” describes the features of 8+1 Managed
Ethernet Switch
Chapter 2 “Installation”
Chapter 3 “Operating Concept and Management”
Chapter 4 “Operation of Web-based Management”
Chapter 5 “Operation of Menu-driven Console”
Chapter 6 “Maintenance”

User Manual
Publication date: September, 2004
Revision A1
2
1. Introduction
1-1. Overview of 8+1 Managed Ethernet Switch
8+1 MANAGED ETHERNET SWITCH, implemented 8 10/100Mbps TP+ 1
module slot supporting Gigabit and Fast Ethernet modules, is a standard switch that
meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet and Ethernet specifications. The
switch can be managed through RS-232 serial port via directly connection, or
through Ethernet port using Telnet or Web-based management unit, associated with
SNMP agent. With the SNMP agent, the network administrator can logon the switch
to monitor, configure and control each port’s activity in a friendly way. The overall
network management is enhanced and the network efficiency is also improved to
accommodate high bandwidth applications. In addition, 8+1 MANAGED
ETHERNET SWITCH features comprehensive and useful function such as QoS
(Quality of Service), Spanning Tree, VLAN, Port Trunking, Port Security,
SNMP/RMON and IGMP Snooping capability, Failover and Illegal Access Report via
the intelligent software. It is suitable for both metro-LAN and office application.
• Key Features in the Device
QoS:
Support Quality of Service by the IEEE 802.1P standard. There are two
priority queue and packet transmission schedule using Weighted Round
Robin (WRR). User-defined weight classification of packet priority can be
based on Either a VLAN tag on packet or a user-defined port priority
Spanning Tree:
Support IEEE 802.1D, IEEE 802.1w (RSTP: Rapid Spanning Tree
Protocol) and IEEE 802.1s (MSTP: Multiple Spanning Tree Protocol)
standards.
VLAN:
Support Port-based VLAN, IEEE802.1Q Tag VLAN and IEEE802.1v
Protocol-based VLAN. Support 64 active VLANs and VLAN ID 1~4094.
Port Trunking:
Support static port trunking and port trunking with IEEE 802.3ad LACP.
Port Security:
Support allowed, denied forwarding and port security with MAC address.
SNMP/RMON
SNMP Agent: MIB-2 (RFC 1213)
Bridge MIB (RFC 1493)
RMON MIB (RFC 1757)-statistics Group 1,2,3,9
VLAN MIB (802.1Q)

User Manual
Publication date: September, 2004
Revision A1
3
IGMP Snooping:
Support IGMP version 2 (RFC 2236): The function IGMP snooping is used
to establish the multicast groups to forward the multicast packet to the
member ports, and, in nature, avoid wasting the bandwidth while IP
multicast packets are running over the network.
Failover:
Support failover function to provide a backup link for an existed link. This
function is different from Link Aggregation (Trunking) and LACP. 8+1
MANAGED ETHERNET SWITCH provides up to 2 failover pairs.
Illegal Access Report:
Support Illegal Access Report function to display the unauthorized users
accessing the switch. If Allowed forwarding or Denied forwarding was
configured, Illegal Access Report starts recording which illegal user(s) try to
access.
There is one slot used for high-speed connection expansion; six optional
module types provided for the switch are listed below:
10/100/1000Base-T Gigabit Copper Module
1000Base-SX Gigabit Fiber Module
1000Base-LX/LHX/XD/ZX Gigabit Fiber Module, up to 70Km
100Base-FX 100Mbps Fiber Module, up to 100Km
100Base-FX Single Fiber WDM Module
1000Base-LX Single Fiber WDM Module
10/100/1000Base-T Gigabit Copper Module fully complies with IEEE
802.3/u/x/z Gigabit, Fast Ethernet specifications. 1000Base-SX/LX/LHX/XD/ZX
Gigabit Fiber Module is a Gigabit Ethernet port that fully complies with all IEEE
802.3z and 1000Base-SX/LX/LHX/XD/ZX standards. 100Base-FX Fiber Module is a
100Mbps Ethernet port that fully complies with all IEEE 802.3u and 100Base-FX
standards.
100Base-FX/1000Base-LX Single Fiber WDM Module is designed with an
optic Wavelength Division Multiplexing (WDM) technology that transports bi-
directional full duplex signal over a single-strand fiber.
For upgrading firmware, please refer to the Section 4-6 or Section 5-6 for
more details. The switch will not stop operating while upgrading firmware and after
that, the configuration keeps unchanged.

User Manual
Publication date: September, 2004
Revision A1
4
1-2. Checklist
Before you start installing the switch, verify that the package contains the following:
8 10/100Mbps TP+1 Slot Ethernet Switch
Module(optional)
Mounting Accessory (for 19" Rack Shelf)
This User's Manual in CD-ROM
AC Power Cord
RS-232 Cable
Please notify your sales representative immediately if any of the aforementioned
items is missing or damaged.
1-3. Features
The 8+1 MANAGED ETHERNET SWITCH, a standalone off-the-shelf switch,
provides the comprehensive features listed below for users to perform system
network administration and efficiently and securely serve your network.
Management
• Port Status, Counter and Configuration.
• Display the basic System Information on user interface.
• System configuration which includes administrator, guest users and IP address
relative to parameters and SNMP basic parameters.
• Maximal packet length can be up to 1536 bytes.
• Support Broadcasting Suppression to avoid power lost and recovery while a
bunch of converter boxes register to NMS simultaneously.
• The trap events/alarm can be sent via e-mail and mobile phone short message.
• A configured setting can be saved into the on-board flash memory. And the
current setting can be recovered from the default setting or the previous
configured setting via Restore User Configuration.
• On-board diagnostics function can let administrator know the hardware status.
• On-board firmware can be updated via TFTP function.
• The Advanced Managed Ethernet Switch allows administrator to reboot system
from management station.
• The Advanced Managed Ethernet Switch will log the last 60 records in the main
memory and display on the local console. And the converter will send out the
record message while fiber connection recovered.

User Manual
Publication date: September, 2004
Revision A1
5
1-4. View of 8+1 Managed Ethernet Switch
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 8 TP Fast Ethernet ports and 1 optional module on the front panel
of 8+1 MANAGED ETHERNET SWITCH. LED displays, locating on the left side of
the panel, contains a Power LED which indicates the status of 8+1 MANAGED
ETHERNET SWITCH power and 8 sets of port status LED.
Fig. 1-2 Front View of 8 +1 Managed Ethernet Switch
Fig. 1-1 Full View of 8 +1 Managed Ethernet Switch
Power Indication LED TP Cable Plug
TP Port Status
Indication LEDs Optional Slot
RESET Button:
RESET button is used to reset the whole system

User Manual
Publication date: September, 2004
Revision A1
6
• LED Indicators
LED Color Function
System LED
POWER Green Lit when AC power is on and good
10/100Mbps Ethernet TP Port 1 to 8 LED
LNK/ACT Green
Lit when connection with remote device is good
Blinks when any traffic is present
Off when cable connection is not good
100Mbps Green Lit when 100Mbps speed is active
Off when 10Mbps speed is active
FDX/COL Amber Lit when full-duplex mode is active
Blinks when any collision is present
10/100/1000Mbps Gigabit TP Module LED
LNK Green Lit when connection with remote device is good
Off when cable connection is not good
1000 Green Lit green when 1000Mbps speed is active
Off when 10Mbps/100Mbps speed is active
ACT Green Blinks when any traffic is present
Off when any traffic is not present
FDX Green
Lit when full-duplex mode is active
Off when half-duplex mode is active
Blinks when any collision is present
100FX 100Mbps Fiber/Single Fiber WDM Module LED
LNK/ACT Green
Lit when connection with remote device is good
Off when cable connection is not good
Blinks when any traffic is present
100Mbps Green Lit when 100Mbps speed is active
FDX Amber
Lit when full-duplex mode is active
Off when half-duplex mode is active
Blinks when collision is present
1000SX/1000LX Gigabit Fiber/Single Fiber WDM Module LED
LNK/ACT Green
Lit when connection with the remote device is good
Off when module and cable connection is not good
Blinks when any traffic is present
Table1-1

User Manual
Publication date: September, 2004
Revision A1
7
1-4-2. User Interfaces on the Rear Panel
There is one fan on the left side for cooling, one 100-240V 50-60 Hz AC Plug
and a RS-232 DB-9 interface for configuration or management.
1-5. View of the Optional Modules
There are many types of module supported in 8+1 MANAGED ETHERNET
SWITCH. For TP type, only Gigabit port is supported. For fiber type, the switch
supports both 100Mbps fiber module and Gigabit fiber module with different meters,
including multi-mode fiber and single-mode fiber, and connection types, such as SC,
ST, LC, BiDi-LC, BiDi-SC and so on.
• Supports one Gigabit TP port
• Supports 10/100/1000Mbps with full duplex for 1000Mbps, full/half for 100Mbps
and 10Mbps
• Supports category 5e or higher grade cable up to 100 meters
Fig. 1-3 Rear View of 8 +1 Managed Ethernet Switch
Fig. 1-4 Front View of 10/100/1000Base-T Gigabit Copper Module
RS-232 DB-9
Connec
tor
AC Line 100-240V 50-60 Hz

User Manual
Publication date: September, 2004
Revision A1
8
• Supports one Gigabit Fiber SC port
• Supports full duplex for 1000Mbps
• Supports Single/Multi-mode Fiber Cable
• Supports one 100Base-FX Fiber SC port
• Supports full/half duplex for 100Mbps
• Supports Single-mode Fiber Cable
• Supports one 100Base-FX Fiber SC port
• Supports full/half duplex for 100Mbps
• Supports Single-mode and Single wire Fiber Cable
Fig. 1-5 Front View of 1000Base-SX/LX/LHX/XD/ZX Gigabit Fiber Module
Fig. 1-6 Front View of 100Base-FX 100Mbps Fiber Module
Fig. 1-7 Front View of 100Base-FX Single Fiber WDM Module

User Manual
Publication date: September, 2004
Revision A1
9
• Supports one Gigabit Fiber SC port
• Supports full duplex for 1000Mbps
• Supports Single-mode and Single wire Fiber Cable
Fig. 1-8 Front View of 1000Base-LX Single Fiber WDM Module

User Manual
Publication date: September, 2004
Revision A1
10
2. Installation
2-1. Starting 8+1 Managed Ethernet Switch Up
This section will give users a quick start for:
- Hardware and Cable Installation
- Management Station Installation
- Software booting and configuration
2-1-1. Hardware and Cable Installation
At the beginning, please do first:
⇒Wear a grounding device to avoid the damage from electrostatic discharge
⇒Verify that the AC-DC adapter conforms to your country AC power requirement
and then insert the power plug
• Installing Optional Modules to the 8+1 Managed Ethernet Switch
Note: If you have no modules, please skip this section.
•Connecting the Module to the Chassis:
The optional modules are hot-swappable, so you can plug or unplug it before or
after powering on.
1. Unscrew and remove the vacant slot dummy panel
2. Verify that the module is the right model and conforms to the chassis
3. Slide the module along two guides in the slot and fasten the thumb knob.
Also be sure that the module is properly seated against the slot socket/
connector
Fi
g
. 2-1 Installation of O
p
tional Modules
