Black Box WAP?300BGN User manual

UniversalRepeaterMode
WAP‐300BGN
All manuals and user guides at all-guides.com
all-guides.com

FactoryDefault
•ToFactoryDefault theWAP‐300BGNorWRT‐300BGN,
Poweronandwaitforunittofinishbootingup.
ThenPress&HoldtheReset/WPSbutton onthebackofthe
unitfor~12seconds (untilthePOWERLED startsBLINKING
Fast)thenReleasethe Reset/WPSbutton.Unitwillresetand
nowbeatfactorydefault.
Note: IfthePowerLEDdoesnotstartblinkingfast,disconnect
allEthernetcablesandrepeatprocess.
All manuals and user guides at all-guides.com

UniversalRepeaterMode
Configuration
Assign an IP address of 192.168.2.5 with a subnet mask
of 255.255.255.0 to your PC .
Connect an Ethernet cable from your PC to a LAN port
on the WAP-300BGN (Wireless Access Point).
Note: Afterconfiguration ‐InRepeaterModetheEthernet
portshouldonlybeusedtoaccessthe
WAP‐300BGN’smanagementandnotasaLANport !
All manuals and user guides at all-guides.com

OpenBrowser,enter192.168.2.1intheaddressbarand pressEnter.
Login username = admin, Password = 1234, Then Click OK.
All manuals and user guides at all-guides.com

BelowistheHomeScreen oftheWAP‐300BGN.
SelectBasicSettings
All manuals and user guides at all-guides.com

BasicSettingsscreen.
All manuals and user guides at all-guides.com
all-guides.com

Clickthedownarrowtotherightof ModeandSelect
“UniversalRepeater”
All manuals and user guides at all-guides.com

SelectSiteSurvey
All manuals and user guides at all-guides.com

SelectwhichAccessPointyouwanttorepeat.
All manuals and user guides at all-guides.com

AfterselectinganAP,ClickConnection.
All manuals and user guides at all-guides.com

ChangeMainESSIDfromdefault todesiredESSID,
ThenClickApply
All manuals and user guides at all-guides.com
all-guides.com

ClickContinue
All manuals and user guides at all-guides.com

ClickSecurity
All manuals and user guides at all-guides.com

Clickthedownarrowtotherightof EncryptionandSelect
EncryptiontypesameasonAPselectedinSiteSurvey.
All manuals and user guides at all-guides.com

ForWPA&WPA2SelectMixedMode,
NextSelectPassphrase or Hex(64characters)
All manuals and user guides at all-guides.com

EnterPre‐SharedKey,
NextClickApply
All manuals and user guides at all-guides.com
all-guides.com

ClickContinue
All manuals and user guides at all-guides.com

ClickSystemUtility
All manuals and user guides at all-guides.com

AssignanIPAddress,SubnetMask&Gateway.
All manuals and user guides at all-guides.com

ScrolldownandClickApply
