UniversalRepeaterMode
WAP‐300BGN

FactoryDefault
•ToFactoryDefault theWAP‐300BGNorWRT‐300BGN,
Poweronandwaitforunittofinishbootingup.
ThenPress&HoldtheReset/WPSbutton onthebackofthe
unitfor~12seconds (untilthePOWERLED startsBLINKING
Fast)thenReleasethe Reset/WPSbutton.Unitwillresetand
nowbeatfactorydefault.
Note: IfthePowerLEDdoesnotstartblinkingfast,disconnect
allEthernetcablesandrepeatprocess.

UniversalRepeaterMode
Configuration
Assign an IP address of 192.168.2.5 with a subnet mask
of 255.255.255.0 to your PC .
Connect an Ethernet cable from your PC to a LAN port
on the WAP-300BGN (Wireless Access Point).
Note: Afterconfiguration ‐InRepeaterModetheEthernet
portshouldonlybeusedtoaccessthe
WAP‐300BGN’smanagementandnotasaLANport !

OpenBrowser,enter192.168.2.1intheaddressbarand pressEnter.
Login username = admin, Password = 1234, Then Click OK.

BelowistheHomeScreen oftheWAP‐300BGN.
SelectBasicSettings

BasicSettingsscreen.

Clickthedownarrowtotherightof ModeandSelect
“UniversalRepeater”

SelectSiteSurvey

SelectwhichAccessPointyouwanttorepeat.

AfterselectinganAP,ClickConnection.

ChangeMainESSIDfromdefault todesiredESSID,
ThenClickApply

ClickContinue

ClickSecurity

Clickthedownarrowtotherightof EncryptionandSelect
EncryptiontypesameasonAPselectedinSiteSurvey.

ForWPA&WPA2SelectMixedMode,
NextSelectPassphrase or Hex(64characters)

EnterPre‐SharedKey,
NextClickApply

ClickContinue

ClickSystemUtility

AssignanIPAddress,SubnetMask&Gateway.

ScrolldownandClickApply
