BlackVue DR900X-1CH Plus User manual

DR900X-1CH Plus I DR900X-2CH Plus
©2021
DR900X-1CH Plus, DR900X-2CH Plus
instagram.com/blackvueofficial
Address 4F ABN Tower, 331, Pangyo-ro, Bundang-gu, Seongnam-si,
Gyeonggi-do, Republic of Korea, 13488
FCC ID : YCK-DR900XP / HVIN : DR900X-2CH Plus
DR900X-2CH Plus:
FCC ID : YCK-DR900XP / HVIN : DR900X-1CH Plus
DR900X-1CH Plus:
ENGLISH/ESPAÑOL

BLACKVUE
DR900X-1CH Plus I DR900X-2CH Plus
For manuals, customer support and FAQs go to www.blackvue.com
Para consultar los manuales, las preguntas frecuentes o solicitar ayuda, vaya a
www.blackvue.com

Important safety information
For user safety and to avoid property damage, read through this manual and follow
these safety instructions to use the product correctly.
yDo not disassemble, repair, or modify the product yourself.
Doing so may cause re, electric shock, or malfunction. For internal inspection and
repair, contact the service center.
yDo not adjust the product while driving.
Doing so may cause an accident. Stop or park your car in a safe place before
installing and setting up the product.
yDo not operate the product with wet hands.
Doing so may cause electric shock.
yIf any foreign matter gets inside the product, detach the power cord immediately.
Contact the service center for repair.
yDo not cover the product with any material.
Doing so may cause external deformation of the product or re. Use the product
and peripherals in a well-ventilated location.
yIf the product is used outside the optimal temperature range (-20°C - 70°C / -4°F - 158°F),
performance can decline or malfunctions may occur.
yWhen entering or exiting a tunnel, when directly facing into bright sunlight, or when
recording at night without lighting the quality of recorded video may deteriorate.
yIf the product is damaged or the power supply is cut due to an accident, video may
not be recorded.
yDo not remove the microSD card while the microSD card is saving or reading data.
yThe data can be damaged or malfunctions may occur.
DR900X-1CH Plus I DR900X-2CH Plus 3

FCC Compliance Information
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protections against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception
which can be determined by turning the equipment o and on, the user is encouraged
to ty to correct the interference by one or more of the following measures.
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
yConsult the dealer or an experienced radio, TV technician for help.
yOnly shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not expressly
approved by the grantee or manufacture could void the user’s authority to operate
such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation of this device.
FCC ID: YCK-DR900XP
4BLACKVUE

CAUTION
Any changed or modications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
There is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
CE WARNING
yChanges and modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
yIt is desirable that it be installed and operated with at least 20cm or more between
the radiator and a person’s body (excluding extremities: hand, wrists, feet, and
ankles).
Disposal of your BlackVue dashcam
1. All electrical and electronic products should be disposed of
separately from the municipal waste stream via designated
collection facilities appointed by the government or the local
authorities. Contact local authorities to learn about disposal and
recycling options available in your area.
2. The correct disposal of your BlackVue dashcam will help prevent
potential negative consequences for the environment and human
health.
3. For more detailed information about disposal of your BlackVue
dashcam, please contact your city oce, waste disposal service or
the shop where you purchased the product.
DR900X-1CH Plus I DR900X-2CH Plus 5

ICC Compliance
This Class [B] digital apparatus complies with Canadian ICES-003.
This radio transmitter has been approved by Industry Canada to operate with the
antenna types listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list,
having a gain greater than the maximum gain indicated for that type, are strictly
prohibited for use with this device.
- IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicable aux appreils
radio exempts de license.
L’exploitation est autoriséee aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l ’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, méme si
le brouillage est susceptible d’encompromettre le fonctionnement.
6BLACKVUE

DR900X-1CH Plus I DR900X-2CH Plus 7
In the box
Check the box for each of the following items before installing the BlackVue dashcam.
Front camera Rear camera
(DR900X-2CH Plus only)
Cigarette lighter
power cable
Hardwiring power
cable
microSD card microSD card reader
Double-sided tape
for the front camera
mounting bracket
Double-sided tape
for the rear camera
mounting bracket
(DR900X-2CH Plus only)
Quick start guide
Rear camera
connection cable
(DR900X-2CH Plus only)
Pry tool 1CH: Cable clips (5 EA)
2CH: Cable clips (8 EA)
Need help?
Download the manual (including FAQs) and the latest firmware from www.blackvue.com
Or contact a Customer Support expert at [e-mail]
ENGLISH

8BLACKVUE
At a glance
The following diagrams explain each part of the BlackVue dashcam.
Front camera
36 mm
Camera lens
Mounting bracket Front security LED
: Lights on during (i)normal mode, (ii)an event is
being recorded (impact detected), (iii)manual
recording has started, or (iv)motion is detected
in parking mode.
: Blinks slowly during parking mode motion
detection standby.
Lock button
55 mm
118.5 mm

DR900X-1CH Plus I DR900X-2CH Plus 9
S
S
I
D
:
B
l
a
c
k
V
u
e
7
5
0
X
-
X
X
X
X
X
X
X
P
W
:
A
B
C
D
1
2
3
4
C
l
o
u
d
c
o
d
e
:
5
0
9
X
r
7
Y
1
Q
P
G
Y
V
GPS LED
: Lights blue when GPS is on.
: Blinks blue quickly when GPS is turning o.
Recording LED
: Lights orange in normal mode.
: Lights red when (i)an event is being recorded (impact detected), or
(ii)manual recording has started.
: Lights green in parking mode when motion is detected.
Speaker
B/W/L (Bluetooth,Wi-Fi,LTE)
: Lights yellow when LTE is connected.
: Lights white when Wi-Fi is connected.
: Blinks yellow slowly when Bluetooth is paired.
: Blinks yellow quickly when Bluetooth is in
paring mode.
Connectivity details label:
- Default Wi-Fi SSID
- Default Wi-Fi password
- Cloud code
- QR code
Serial number label
ENGLISH

10 BLACKVUE
Proximity Sensor:
Touch or wave a nger within 20mm of the sensor to
trigger a customizable function.
Available options:
- Turn on/o audio recording (default)
- Manual recording trigger
- O
Proximity Sensor LED
: Lights when proximity sensor is triggered.
Cover
Micro USB port
DC in (power connector)
microSD card slot
Wi-Fi button:
- Press once to turn on/o Wi-Fi.
Rear camera connection port

DR900X-1CH Plus I DR900X-2CH Plus 11
Rear camera (DR900X-2CH Plus only)
Rear security LED
: Stays on in all
recording modes but
can be turned o from
rmware settings.
V out (Front
camera
connection port)
Mounting bracket Camera lens
31 mm
67.4 mm
25 mm
Note
yFor DR900X-1CH Plus user, the BlackVue rear camera is an optional accessory.
ENGLISH

12 BLACKVUE
STEP 1 Install and power up
Install the front camera behind the rear view mirror. Install the rear camera at the top
of the back windshield. Remove any foreign matter and clean and dry the windshield
before installation.
Note
yFor DR900X-1CH Plus user, the BlackVue rear camera is an optional accessory.
yMake sure to peel the protective film off the front and rear camera. The
cameras could be damaged from overheating if the protective film is not
removed.
Warning
yDo not install the product in a location where it can obstruct the driver's eld
of vision.
Turn o the engine. Open the cover of the microSD card slot, gently push the
card into the slot until it locks into place and close the cover.

DR900X-1CH Plus I DR900X-2CH Plus 13
Peel off the protective film from the double-sided tape and attach the front
camera to the windshield behind the rear-view mirror.
Adjust the angle of the lens by rotating the body of the front camera. We
recommend pointing the lens slightly downwards (≈10° below horizontal), so as
to record video with a 6:4 road to background ratio.
S
S
I
D
:
B
l
a
c
k
V
u
e
7
5
0
X
-
X
X
X
X
X
X
X
P
W
:
A
B
C
D
1
2
3
4
C
l
o
u
d
c
o
d
e
:
5
0
9
X
r
7
Y
1
Q
P
G
Y
V
Peel off the protective film from the double-sided tape and attach the rear
camera to the rear windshield. Adjust the angle of the lens by rotating the body
of the rear camera.
Connect the front camera ('Rear' port) and the rear camera ('V out') using the rear
camera connection cable.
ENGLISH

14 BLACKVUE
Use the pry tool to lift the edges of the rubber window sealing and molding and
tuck in the rear camera connection cable.
Rear camera connection cable
Connectivity Module (Optional): Connect the connectivity module to the front
camera and attach it to the edge of the window. Use the pry tool to tuck in the
cable.
Plug the cigarette lighter power cable into the cigarette lighter socket and the
front camera. Skip to for Hardwiring Power Cable setup.
Use the pry tool to lift the edges of the windshield trim/molding and tuck in the
power cord.
Power cord
Rear camera connection cable
Turn on the engine. The BlackVue dashcam will power up and start recording.
Video les are stored on the microSD card.

DR900X-1CH Plus I DR900X-2CH Plus 15
Turn o the engine. The dashcam will automatically stop recording and power
down. To record in parking mode while the engine is off please connect the
Hardwiring Power Cable (included in the box) or install a Power Magic Battery
Pack (sold separately). A Hardwiring Power Cable uses the automotive battery
to power your dashcam when the engine is off. A low voltage power cut-off
function and a parking mode timer to protect the automotive battery from
discharge is installed in the device. Settings can be changed in the BlackVue App
or Viewer.
Locate the fuse box to connect the hardwiring power cable.
Note
yLocation of the fuse box dier by manufacturer or model. For details, refer to
the vehicle owner's manual.
-1After removing fuse panel cover, nd a fuse that powers on when engine
is turned on(ex.cigarette lighter socket, audio, etc) and another fuse that
remains powered on after the engine is turned o (ex.hazard light, interior
light). Connect the ACC+ cable to a fuse that powers on after engine start,
and BATT+ cable to a fuse that remains powered on after engine is turned
o.
Note
yTo use battery saver feature, connect the BATT+ cable to the hazard light
fuse. Functions of fuse dier by manufacturer or model. For details refer
to the vehicle owner's manual.
ENGLISH

16 BLACKVUE
-2Connect the GND cable to metal ground bolt.
MConnect the power cable to the DC in terminal of the front camera. BlackVue
will power up and start recording. Video les are stored on the microSD card.
Note
yWhen you run the dashcam for the first time the firmware is automatically
loaded onto the microSD card. After the firmware has been loaded onto
the microSD card you can customize settings using BlackVue Viewer on a
computer.

DR900X-1CH Plus I DR900X-2CH Plus 17
STEP 2 Playback
Playing video les on your smartphone (Android/iOS)
Search for the BlackVue app in the Google Play Store or Apple App Store and
install it on your smartphone.
Create an account
(i) Select Login if you have an account, otherwise tap Get started to create an
account. If you want to sign up later, press Sign up later.
(ii) During sign up, you will receive an e-mail with a conrmation code. Enter the
conrmation code to nish creating your account.
(iii) Tap Yes to enable push notications (this setting can be adjusted at any time
later).
(iv) Once sign-up process is done, you will be automatically logged into your
account. If you want to connect to BlackVue Cloud with your account, skip to
STEP 4
Connect to BlackVue Cloud.
ENGLISH

18 BLACKVUE
Add BlackVue dashcam to camera list via Seamless pairing.
(i) Select Connect to camera in the main page.
(ii) Make sure smartphone's Bluetooth is turned on and press +.
(iii) Select Seamless pairing support model.
(iv) Choose your BlackVue dashcam from the detected camera list.
(v) Put your hand on the camera's touch/proximity sensor to complete Seamless
pairing.

DR900X-1CH Plus I DR900X-2CH Plus 19
If you want to add BlackVue dashcam to camera list manually using credentials,
Please skip to .
Note
yBluetooth lets you connect your smartphone to your dashcam within a range
of 10m.
yDashcam SSID is printed in connectivity details label attached on your dashcam
or inside the product box.
(vi) Customize your camera name and press OK.
(vii) BlackVue dashcam is now added to the camera list.
ENGLISH

20 BLACKVUE
Add BlackVue dashcam to camera list manually
(i) If you want to connect to camera manually, press connect to camera
manually in the searching for camera page.
(ii) Enter credentials (Printed in connectivity details label attached on your
dashcam or inside the product box).
