Instructions for use
General information for using the
vacuum cleaner
Use the vacuum cleaner in accordance with the laws in force
in the country where it is used.
Besides the operating instructions and the laws in force in
the country where the vacuum cleaner is used, the technical
regulations for ensuring safe and correct operation must
also be observed (Legislation concerning environmental and
labour safety, i.e. European Union Directive 89/391/EC and
successive Directives).
Do not perform any operation that could jeopardize the safety
of people, property and the environment.
Comply with the safety indications and prescriptions in this
instruction manual.
Proper uses
This vacuum cleaner is suitable for commercial use, in hotels,
schools, hospitals, factories, shops, oces and apartment
hotels for example, for hire and in any case for purposes
other than normal domestic use.
This vacuum cleaner is suitable for cleaning and vacuuming
solid materials in indoor and outdoor environments.
■Always leave enough room around the vacuum cleaner to
reach the controls easily.
The vacuum cleaner has been designed to be used by one
operator only.
This vacuum cleaner consists of an automated vacuum unit,
with a lter upstream and a container for collecting the
vacuumed material.
Read the operating instructions and comply with the important safety
recommendations identied by the word WARNING!
Operator’s safety
WARNING!
Before starting the vacuum cleaner, it
is absolutely essential to read these
operating instructions and to keep them
on hand for consultation.
The vacuum cleaner can only be used by people
who are familiar with the way it works and who
have been explicitly authorised and trained for the
purpose.
Before using the vacuum cleaner, the operators
must be informed, instructed and trained on how
to work it and for which substances its usage is
permitted including the safe method for removing
and disposing of the vacuumed material.
WARNING!
The use of vacuum cleaner by people (including
children) with limited physical and mental
capacities or lacking in experience and knowledge
is strictly forbidden, unless they are supervised by
a person who is experienced in the use and safe
handling of the machine.
Children must be supervised to make sure they will
not play with the vacuum cleaner.

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 3/16
I
US
Improper Use
WARNING!
The following use of the vacuum cleaner is strictly
forbidden:
■Outdoors in case of atmospheric precipitation.
■When not placed on horizontal levelled
grounds.
■When the ltering unit is not installed.
■When the vacuum inlet and/or hose are turned
to parts of the human body.
■Use without the cover on the vacuum unit.
■When the dust bag is not installed.
■Use without the guards, protective covers and
safety systems installed by the manufacturer.
■When the cooling vents are partially or totally
clogged.
■When the vacuum cleaner is covered with
plastic or fabric sheets.
■Use with the air outlet partially or totally
closed.
■When used in narrow areas where there is no
fresh air.
■Vacuuming liquids with vacuum cleaners
not equipped with specic original stopping
systems.
■Vacuuming the following materials:
1. Burning materials (embers, hot ashes, lit
cigarettes, etc.).
2. Naked ames.
3. Combustible gas.
4. Flammable liquids, aggressive fuels
(gasoline, solvents, acids, alkaline
solutions, etc.).
5. Explosive dust/substances and/or ones
liable to ignite in a spontaneous way (such
as magnesium or aluminium dusts, etc.).
IMPORTANT: Fraudulent use is not admitted.
General recommendations
WARNING!
If an emergency situation occurs:
■lter breakage
■re outbreak
■short-circuit
■motor block
■electric shock
■etc.
Turn the vacuum cleaner o, unplug it and request
assistance from qualied personnel.
WARNING!
The vacuum cleaners must not be used or stored
outdoors, or in damp places.
Only versions with the level sensor can be used for
liquids, if not, they can only be used to vacuum dry
materials.

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 4/16
I
US
Vacuum cleaner description
Optional kits
Please contact the manufacturer’s sales network for
information on optionals.
Instructions for installing the optional are included in the
conversion kit.
WARNING!
Use only supplied and authorized genuine spare
parts.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorized by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force. Figure 2
Model BDC-23-230V-P
BDC-23-110V-P
A (mm) 700
B (mm) 860
C (mm) 1750
Weight with packing
(kg) 86
Vacuum Cleaner Parts and Labels
Figure 1
1. Identication plate which includes:
Code of the Model, Technical Specications (see table
on page 7), Serial No., EC Mark, Year of manufacture,
Nominal network voltage.
2. Longopac System
3. Inlet
4. Outlet
5. Attention plate
Draws the operator’s attention to the fact that the lter
must only be shaken when the vacuum cleaner is turned
o (see also par. “Primary lter shaker”).
6. Plug for connecting the vacuum cleaner to an electrical
socket.
7. Silica Dust Warning
Draws the operator’s attention to the fact that exposure
of a crystalline silicon ust can cause cancer or silicosis.
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (4- Fig. 1) and blown out through the
outlet (5- Fig. 1).
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part
(refer to the manufacturer’s accessory catalogue or Service
Centre).
The diameters of the authorised hoses are given in the
technical specications table.
The vacuum cleaner is equipped with a primary lter which
enables it to be used for the majority of applications.
Besides the primary lter, which retains the most common
types of dust, the vacuum cleaner can be tted with a
secondary lter (absolute H class) with a higher ltering
capacity for ne dusts and dusts that are hazardous to
health.

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 5/16
I
US
Unpacking, moving, use and storage
Operate on at, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight).
Setting to work - connection to the
power supply
WARNING!
■Make sure there is no evident sign of damage
to the vacuum cleaner before starting work.
■Before plugging the vacuum cleaner into the
electrical mains, make sure the voltage rating
indicated on the data plate corresponds to that
of the electrical mains.
■Plug the vacuum cleaner into a socket with a
correctly installed ground contact/connection.
■Make sure that the vacuum cleaner is turned
o.
■The plugs and connectors of the connection
cables must be protected against splashes of
water.
■Make sure that connections to the electrical
mains and plug are correct.
■Use the vacuum cleaners only when the cables
that connect to the electrical mains are in
perfect condition (damaged cables could lead
to electric shocks!).
■Regularly check there are no signs of damage,
excessive wear, cracks or ageing on the
electric cable.
WARNING!
When the vacuum cleaner is operating, do not:
■Crush, pull, damage or tread on the cable that
connects to the electrical mains.
■Only disconnect the cable from the electrical
mains by removing the plug (do not pull the
cable).
■Only replace the electric power cable with one
of the same type as the original: H07 RN - F.
The same rule applies if an extension is used.
■The cable must be replaced by the
manufacturer’s Service Centre sta or by
equivalent qualied personnel.
Extensions
If an extension cable is used, make sure it is suitable for the
power input and protection degree of the vacuum cleaner.
Minimum section of extension cables: 2.5 mm2
Maximum length = 20 m
Cable = H07 RN - F
WARNING!
Sockets, plugs, connectors and installation of the
extension cable must maintain the IP protection
degree of the vacuum cleaner, as indicated on the
data plate.
WARNING!
Never spray water on the vacuum cleaner: this
could be dangerous for persons exposed and could
short circuit the power supply.
WARNING!
The vacuum cleaner’s power socket must be
protected by a dierential circuit-breaker with
surge current limitation, that shuts o the power
supply when the current discharged to the ground
exceeds 30 mA for 30 msec. or an equivalent
protection circuit.

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 6/16
I
US
Wet and dry applications
[ NOTE ]
The supplied lters and the bag (if applicable) must be
installed correctly.
WARNING!
Comply with the safety regulations governing the
materials for which the vacuum cleaner is used.
WARNING!
If the version for liquids is used:
■Make sure the liquid level sensor is working
correctly before vacuuming liquids.
■If foam forms, turn o the vacuum cleaner
immediately and empty the container.
■Warning: Switch o the vacuum cleaner
immediately if foam or liquid leaks out.
■Regularly clean the liquid level limiting device
and check to make sure that there are no signs
of damage.
■Warning: Dirty liquid vacuumed up by
the vacuum cleaner must be considered
conductive.
WARNING!
Vacuum cleaner for liquids.
When vacuuming a mix of water and air, take care
to avoid overloading the motor of the vacuum unit.
Maintenance and repairs
WARNING!
Disconnect the vacuum cleaner from its power
source before cleaning, servicing, replacing parts or
converting it to another version/variant, the plug
must be disconnected from the socket.
■Carry out only the maintenance operations
described in this manual.
■Use only original spare parts.
■Do not modify the vacuum cleaner in any way.
Failure to comply with these instructions could
jeopardize your safety.

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 7/16
I
US
Technical specications
Parameter Units
BDC-23-230V-P
BDC-23-110V-P
120 230
Voltage (60 Hz) V 120 230
Power supply type Number of phases 1
Maximum power kW 2.4 3
Nominal current input A 15.8 13
Max vacuum Inches H2O 71.5 84.7
Max air ow rate cfm 270 286
Noise level, @ 3’3" (1 m) dB(A) - vacuum unit 75
Protection IP 43
Insulation Class I
Inlet (diameter) in. 3
Hoses allowed (diameter) in. 2 / 3
Container capacity gal 26.4
Filter surface Sq. ft 21
Absolute lter surface Sq. ft 25.9
HEPA absolute lter eciency MPPS 99,995% @ 0.18 micron
Cable length ft 30
Weight (1) lbs. 157
(1) Net weight
(2) hPa = mbar
Storage conditions:
T : -10°C ÷ +40°C
Humidity: 85%
T : -10°C ÷ +40°C
Operating conditions:
Maximum altitude: 800 m
(Up to 2,000 m with reduced performances)
Humidity: 85%
Dimensions
(Fig. 3)
BDC-23-230V-P
BDC-23-110V-P A B C
in 31.3 23.6 61.8

www.blastrac.com ‒ [email protected]
Instruction manual BDC-23-230V-P_ BDC-23-110V-P 8/16
I
US
Primary lter shaker
Depending on the quantity of dust cleaned up, shake the
main lter by means of the knob “3” (Fig. 4).
WARNING!
Stop the vacuum cleaner before using the lter
shaker.
Do not shake the lter while the vacuum cleaner is
on, as this could damage the lter.
Wait before restarting the vacuum cleaner, to allow the dust
to settle.
Emergency stopping
Turn the switch “1” (Fig. 4) to “0” position.
Emptying the dust container
WARNING!
■Before proceeding with these operations, turn
the vacuum cleaner o and disconnect the plug
from the power socket.
■Check the class of the vacuum cleaner.
Before emptying the container it is advisable to clean the
lter (see “Primary lter shaker”).
■Standard version is not suitable for vacuuming
hazardous dust
▪Release the dust container (2, Fig. 1) using lever
(3, Fig. 1), then remove and empty it.
▪Make sure the seal is in perfect condition and
correctly positioned.
▪Place the container back in position and secure it
again.
Liquids vacuuming
WARNING!
Check that the vacuum cleaner is equipped with
liquids mechanical stop.
■The lter element will be wet after liquids have been
vacuumed.
A wet lter element can quickly become clogged if the
vacuum cleaner is then used to vacuum dry substances.
For this reason, make sure that the lter element is dry
or replace it with another one before using the vacuum
cleaner for dry materials.
Controls and indicators
Figure 4
1. Motor start/stop switch
2. Power indicator
3. Manual lter shaker knob
Figure 5
1. Inlet
Inspections prior to starting
Prior to starting, check that:
■the lters are installed;
■all the levers are locked in place;
■the vacuum hose and tools have been correctly tted to
the inlet (1- Fig. 5);
WARNING!
Do not use the vacuum cleaner if the lter is faulty.
Starting and stopping
Figure 4
WARNING!
Lock the castor brakes before starting the vacuum
cleaner.
■Turn the switch “1” (Fig. 4) to “I” position to start the
vacuum cleaner.
■Turn the switch to “0” position to turn the vacuum
cleaner o.
Vacuum cleaner operation
WARNING!
The air speed in the suction tube must not be less
than 20 m/s.
WARNING!
Consult the “Troubleshooting” chapter if faults
occur.
