InlIne centrIfugal fan
USER’S MANUAL
EN
Box EC

Box ec
2
www.blaubergventilatoren.de
CONTENTS
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the Box EC unit and all
its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
Safety requirements..................................................................................................................................................................... 3
Purpose................................................................................................................................................................................................ 4
Delivery set........................................................................................................................................................................................ 4
Designation key.............................................................................................................................................................................. 4
Technical data.................................................................................................................................................................................. 5
Installation and set-up................................................................................................................................................................ 7
Connection to power mains .................................................................................................................................................. 8
Technical maintenance.............................................................................................................................................................. 9
Troubleshooting............................................................................................................................................................................. 10
Storage and transportation regulations.......................................................................................................................... 10
Manufacturer’s warranty........................................................................................................................................................... 11
Certificate of acceptance.......................................................................................................................................................... 15
Seller information.......................................................................................................................................................................... 15
Installation certificate.................................................................................................................................................................. 15
Warranty card................................................................................................................................................................................... 15

www.blaubergventilatoren.de
Box ec
3
SAFETY REQUIREMENTS
All operations described in this manual must be performed by qualified personnel only, properly
trained and qualified to install, make electrical connections and maintain ventilation units.
Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
This is unsafe and impossible without special knowledge.
Disconnect the power supply prior to any operations with the unit.
All user’s manual requirements as well as the provisions of all the applicable local and national
construction, electrical, and technical norms and standards must be observed when installing
and operating the unit.
Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and
repair operations.
Only qualied electricians with a work permit for electrical units up to 1000 V are
allowed for installation. The present user’s manual should be carefully read before
beginning works.
Check the unit for any visible damage of the impeller, the casing, and the grille before starting
installation. The casing internals must be free of any foreign objects that can damage the
impeller blades.
While mounting the unit, avoid compression of the casing! Deformation of the casing may result
in motor jam and excessive noise.
Misuse of the unit and any unauthorised modifications are not allowed.
Do not expose the unit to adverse atmospheric agents (rain, sun, etc.).
Transported air must not contain any dust or other solid impurities, sticky substances, or fibrous
materials.
Do not use the unit in a hazardous or explosive environment containing spirits, gasoline,
insecticides, etc.
Do not close or block the intake or extract vents in order to ensure the efficient air flow.
Do not sit on the unit and do not put objects on it.
The information in this user’s manual was correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration
of its products at any time in order to incorporate the latest technological developments.
Never touch the unit with wet or damp hands.
Never touch the unit when barefoot.
BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS.
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS
SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE

Box ec
4
www.blaubergventilatoren.de
DELIVERY SET
DESIGNATION KEY
NAME NUMBER
Fan 1 pc.
User's manual 1 pc.
Packing box 1 pc.
PURPOSE
The inline centrifugal fan is designed for supply and exhaust ventilation systems of commercial, office and other public or industrial
premises with high requirements to the noise level and limited space for mounting.
The unit is rated for continuous operation.
The unit is a component part and is not designed for stand-alone operation.
Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
Designation example: Box XX XXXxXXX XXXX
Series name
Motor type
EC: synchronous electronically
commutated motor
Rectangular duct size
30x15/40x20/50x25/50x30/60x30
60x35/70x40/80x50/90x50/100x50
Phases
1: single-phase
3: three-phase
Motor modication
_: medium pressure motor
max: high pressure motor
THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED
PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE
TRAINING.
THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED
PERSONNEL AFTER THE APPROPRIATE BRIEFING.
THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORISED
ACCESS BY UNATTENDED CHILDREN.

www.blaubergventilatoren.de
Box ec
5
TECHNICAL DATA
The unit is designed for indoor application with the ambient temperature ranging from 0 °C up to +45 °C and relative humidity up to
80 %. The unit is rated as a Class I electrical appliance.
Hazardous parts access and water ingress protection rating: for the unit connected to the air ducts – IPX4.
The unit design is constantly being improved, thus some models may be slightly different from those described in this manual.

Box ec
6
www.blaubergventilatoren.de
Overall dimensions
Model Dimensions [mm] Weight [kg]
B B1 B2 H H1 H2 H3 L
Box EC 30x15-1 300 320 340 150 170 190 228 350 5.5
Box EC 30x15-1 max 300 320 340 150 170 190 228 350 6.0
Box EC 40x20-1 400 420 440 200 220 240 278 440 8.3
Box EC 40x20-1 max 400 420 440 200 220 240 278 440 10.0
Box EC 50x25-1 500 520 540 250 270 290 328 530 15.7
Box EC 50x25-1 max 500 520 540 250 270 290 328 530 17.9
Box EC 50x30-1 max 500 520 540 300 320 340 410 530 18.7
Box EC 60х30-1 max 600 620 640 300 320 340 370 680 26,5
Box EC 60x30-1 600 620 640 300 320 340 407 650 24.1
Box EC 60x35-1 600 620 640 350 370 390 457 650 25.2
Box EC 60x35-3 max 600 620 640 350 370 390 512 650 36.0
Box EC 70x40-1 700 720 740 400 420 440 496 750 42.2
Box EC 70x40-3 max 700 720 740 400 420 440 555 750 43.0
Box EC 80x50-3 800 820 840 500 520 540 614 850 62.3
Box EC 80x50-3 max 800 820 840 500 520 540 670 850 54.3
Box EC 90x50-3 max 900 920 940 500 520 540 656 950 72.0
Box EC 100x50-3 max 1000 1020 1040 500 520 540 656 950 77.0

www.blaubergventilatoren.de
Box ec
7
INSTALLATION AND SETUP
WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT
MAINTENANCE AND REPAIR.
BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN
OBJECTS E.G. FOIL, PAPER.
Check the fan power cables for integrity and make sure the impeller has smooth rotation prior to mounting.
The fans are mounted into the rectangular ducts and require no special fixing in case of direct connection.
Connect the fan to air ducts with M8 bolts and nuts.
The fans can be mounted in any position with respect to the airflow direction which is indicated with a pointer on the casing.
Access for the fan maintenance shall be provided.
The casing is equipped with a removable access cover for maintenance purposes.
1
3
2
4

Box ec
8
www.blaubergventilatoren.de
CONNECTION TO POWER MAINS
DISCONNECT THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT.
CONNECTION OF THE UNIT TO POWER MAINS IS ALLOWED BY A QUALIFIED
ELECTRICIAN WITH A WORK PERMIT FOR THE ELECTRIC UNITS UP TO 1000 V AFTER
CAREFUL READING OF THE PRESENT USER’S MANUAL.
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE
MANUFACTURER’S LABEL.
• The unit is rated for connection to 1~200-277V/50(60)Hz/3~380-480V/50(60)Hz power mains.
• The unit must be connected to power mains using insulated electric conductors (cables, wires). The actual wire cross section selection
must be based on the maximum load current, maximum conductor temperature depending on the wire type, insulation, length and
installation method.
• The external power input must be equipped with an automatic circuit breaker built into the stationary wiring to open the electric
circuit in case of overload or short-circuit. The circuit breaker installation place must provide quick access for emergency shutdown
of the unit. The trip current of the automatic circuit breaker must exceed the maximum current consumption of the unit (refer to
the technical data table). The recommended trip current of the circuit breaker is the next current in the standard trip current row
following the maximum current of the connected unit. The automatic circuit breaker is not included in the delivery set.
Wiring diagram of the fan with a single-phase motor Wiring diagram of the fan with a three-phase motor
CTR
+10V
GND
A1
0-10V
+10V
GND
N
PE
L
X2
X1
M1
L
N
PE
+10V
0-10V
GND
Tacho
Х2:4
Х2:3
Х2:2
Х2:1
Х1:3
Х1:2
Х1:1
white
blue
yellow
red
yellow-green
blue
black
~230 V
50/60 Hz
Tacho
GND
0-10V
+10V
PE
L3
L2
M1
X1
X2
L2
PE
L3
GND
+10V
0-10V
A1
GND
+10V
CTR
Х1:2
Х1:3
Х1:4
Х2:1
Х2:2
Х2:3
Х2:4
Х1:1
L1L1 blue
black
yellow-green
red
yellow
blue
white
brown
~400 V
50/60 Hz

www.blaubergventilatoren.de
Box ec
9
The technical maintenance includes periodic cleaning of the surfaces from accumulated dust and dirt.
Use a soft brush or compressed air to remove dust from metal surfaces of the fan. Use a vacuum cleaner to remove dust from the
sound insulating surface.
The impeller blades require thorough cleaning once in 6 months.
Detach air ducts from the fan before starting maintenance works.
Clean the impeller blades with a soft cloth wetted in mild water detergent solution. Avoid liquid dripping on the motor.
Wipe the fan surfaces dry after cleaning.
While cleaning the fan make sure the balance counterweights are not shifted and the impeller is not misaligned.
1
34
56
2
DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE
OPERATIONS!
MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE
PROTECTION
TECHNICAL MAINTENANCE

Box ec
10
www.blaubergventilatoren.de
STORAGE AND TRANSPORTATION REGULATIONS
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 ˚С to +40 ˚С and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and sealing
deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation and
mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures, allow the unit to warm up at operating temperature for at least
3-4 hours.
Problem Possible reasons Troubleshooting
The fan does not run. No power supply. Check the automatic circuit breaker.
Check the electric connections.
Noisy operation. Impeller imbalance. Clean the impeller.
TROUBLESHOOTING

www.blaubergventilatoren.de
Box ec
11
MANUFACTURER’S WARRANTY
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby
declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European
Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking
Council Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 24 months after the retail sale date provided the user's observance
of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the course of the unit operation
through the Manufacturer's fault during the guaranteed period of operation, the user is entitled to get all the faults eliminated by the
manufacturer by means of warranty repair at the factory free of charge. The warranty repair includes work specific to elimination of faults
in the unit operation to ensure its intended use by the user within the guaranteed period of operation. The faults are eliminated by means
of replacement or repair of the unit components or a specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the payment
paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact the Seller for warranty
service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission with missing
component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal components caused
by the user.
• Redesign or engineering changes to the unit.
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind, blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND
TROUBLEFREE OPERATION OF THE UNIT.
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON
PRESENTATION OF THE UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL
WITH THE PURCHASE DATE STAMP.

Box ec
12
www.blaubergventilatoren.de

www.blaubergventilatoren.de
Box ec
13

Box ec
14
www.blaubergventilatoren.de

www.blaubergventilatoren.de
Box ec
15
CERTIFICATE OF ACCEPTANCE
Unit Type Inline centrifugal fan
Model
Serial Number
Manufacture Date
Quality Inspector’s
Stamp
SELLER INFORMATION
Seller
Seller’s Stamp
Address
Phone Number
E-mail
Purchase Date
This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are
acknowledged and accepted.
Customer’s Signature
INSTALLATION CERTIFICATE
The _____________________________________ unit is installed pursuant to the requirements stated
in the present user's manual.
Installation Stamp
Company name
Address
Phone Number
Installation
Technician’s Full Name
Installation Date: Signature:
The unit has been installed in accordance with the provisions of all the applicable local and national construction,
electrical and technical codes and standards. The unit operates normally as intended by the manufacturer.
Signature:
WARRANTY CARD
Unit Type Inline centrifugal fan
Seller’s Stamp
Model
Serial Number
Manufacture Date
Purchase Date
Warranty Period
Seller

www.blaubergventilatoren.de
B197EN-02
