This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the
Vento Expert (Duo) A50/85/100 (Pro3) W V.2 unit and all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
The information in this user’s manual is correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time in order to
incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any information
search system or translated into any language in any form without the prior written permission of the Company.

www.blaubergventilatoren.de

3
SAFETY REQUIREMENTS
• Please read the user’s manual carefully prior to installing and operating the unit.
• All user’s manual requirements as well as the provisions of all the applicable local and national
construction, electrical, and technical norms and standards must be observed when installing
and operating the unit.
• The warnings contained in the user’s manual must be considered most seriously since they
contain vital personal safety information.
• Failure to follow the rules and safety precautions noted in this user’s manual may result in an
injury or unit damage.
• After a careful reading of the manual, keep it for the entire service life of the unit.
• While transferring the unit control, the user’s manual must be turned over to the receiving
operator.
UNIT INSTALLATION AND OPERATION SAFETY PRECAUTIONS
• Disconnect the unit from
power mains prior to any
installation operations.
• Unpack the unit with care.
• The unit must be grounded!
• While installing the unit, follow
the safety regulations specific
to the use of electric tools.
• Do not change the power
cable length at your own
discretion.
• Do not bend the power cable.
• Avoid damaging the power
cable.
• Do not put any foreign objects
on the power cable.
• Do not lay the power cable of
the unit in close proximity to
heating equipment.
• Do not use damaged
equipment or cables when
connecting the unit to power
mains.
• Do not operate the unit
outside the temperature range
stated in the user’s manual.
• Do not operate the unit
in aggressive or explosive
environments.

www.blaubergventilatoren.de 
4
• Do not touch the unit controls
with wet hands.
• Do not carry out the
installation and maintenance
operations with wet hands.
• Do not wash the unit with
water.
• Protect the electric parts of the
unit against ingress of water.
• Do not allow children to
operate the unit.
• Disconnect the unit from
power mains prior to any
technical maintenance.
• Do not store any explosive or
highly flammable substances
in close proximity to the unit.
• When the unit generates
unusual sounds, odour, or
emits smoke, disconnect it
from power supply and contact
the Seller.
• Do not open the unit during
operation.
• Do not direct the air flow
produced by the unit towards
open flame or ignition sources.
• Do not block the air duct when
the unit is switched on.
• In case of continuous
operation of the unit,
periodically check the security
of mounting.
• Do not sit on the unit and
avoid placing foreign objects
on it.
• Use the unit only for its
intended purpose.
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.

www.blaubergventilatoren.de

5
PURPOSE
The ventilator is designed to ensure continuous mechanical air exchange in flats, cottages, hotels, cafés and other domestic and public
premises. The ventilator is equipped with a regenerator that enables supply of fresh filtered air heated by means of extract air heat energy
recovery. The ventilator is designed for wall flush mounting.
The unit is rated for continuous operation without disconnection from the power supply.
THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED
PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE
TRAINING.
THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED
PERSONNEL AFTER THE APPROPRIATE BRIEFING.
THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORIZED
ACCESS BY UNATTENDED CHILDREN.
Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials,
coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust,
pathogenic germs).
NAME NUMBER
Vento Expert Vento Expert Duo
Indoor unit of the ventilator 1 pc. 1 pc.
Air duct 1 pc. 1 pc.
Air flow separator - 3-6 pcs.
Sound-absorbing material 1 pc. -
Assembled cartridge 1 pc. 1 pc.
Outer ventilation hood 1 pc. 1 pc.
Remote control 1 pc. 1 pc.
Cardboard template 1 pc. 1 pc.
Fastening set 2 packings 2 packings
Foam wedges 1 set 1 set
User's manual 1 pc. 1 pc.
Mounting hood installation instruction 1 pc. 1 pc.
Packing box 1 pc. 1 pc.
Vento Expert A-85 -1 Pro3 WV.2 Unit version
V.2: Wi-Fi controllable, connection to PC is not required
Control system type
W: Wi-Fi connection of ventilators
Availability of protective shutters
_: model with automatic protective shutters
Pro3: model without automatic shutters, with manual blocking of air flow
Front panel modication
1: flat front panel
Rated air capacity [m3/h]
Air duct section shape
A: round
Ventilator series
Expert: series of reversible ventilators with unidirectional air flow
Expert Duo: series of reversible ventilators with bidirectional air flow
DELIVERY SET
DESIGNATION KEY

www.blaubergventilatoren.de 
6
A A
LL
Air duct length
Wall thickness
Wall thickness is above the minimum Wall thickness is minimal
Outer ventilation
hood
Front panel Front panel
Cartridge Cartridge
Air duct length
Wall thickness
Outer ventilation
hood
68
235
285
207
85
137
138
207
85
137
138
Vento Expert Vento Expert Duo
Длина воздуховода (толщина стены)
The unit is designed for indoor application at the following conditions:
• for Vento Expert: outside air temperature from -20 ˚C (-4 °F) up to +40 ˚C (104 °F) and relative indoor humidity up to 50 %
• for Vento Expert Duo: outside air temperature from -15 ˚C (5 °F) up to +40 ˚C (104 °F) and relative indoor humidity up to 65 %
The unit has Class II of protection against electric shock and must not be grounded.
Hazardous parts access and water ingress protection rating is IP24.
The unit design is constantly being improved, so some models may be slightly different from those ones described in this manual.
Technical data are stated on the rating plate on the casing individually for each ventilation unit.
A: protruding part of the air duct on the outer wall. Depends on the used
ventilation hood type.
L: cartridge length. Depends on the ventilator model.
The air duct length and the supplied ventilation hood model depend on the
ventilator model (refer to Designation key, page 5).
The overall and connecting dimensions of the outer ventilation hood, the
value of the protruding part of the air duct on the outside A and installation
steps for the outer hood are stated in the mounting instruction for the outer
hood.
Overall dimensions of the front panel are shown below
Ventilator model L [mm]
Vento Expert A50/85-1 (Pro3) W V.2 250
Vento Expert A100-1 (Pro3) W V.2 355
Vento Expert Duo A30-1 W V.2 280
TECHNICAL DATA

www.blaubergventilatoren.de

7
Filters
Clean the air flowing through
the ventilator of dust and
foreign objects.
Prevent contamination of the
regenerator.
Front part of the indoor unit with a front panel
Fulfils the decorative function. The design enables to
shut off the air duct in case of an extended downtime of
the ventilator.
The front part of the Vento Expert Duo unit is used for air
filtration.
Back part of the indoor unit
The unit includes a circuit control board and basic controls located on the side part.
Back part of the indoor unit
The unit includes a circuit control board and
basic controls located on the side part.
Vento Expert Duo cartridge
Construction consisting of fans and regenerators.
Generates air flow and provides heat recovery.
Vento Expert cartridge
Construction consisting of fans, a regenerator and air filters.
Generates air flow and provides heat recovery.
Air duct
Plastic air duct.
Air ow separators
Designed for separation of
supply and exhaust air streams.
Outer ventilation hood
Prevents ingress of water and foreign objects into the ventilator.
Each ventilator model has a matching ventilation hood model.
Sound absorbing material
A layer of sound-absorbing material for attenuation of noise
generated during the ventilator operation.
Vento Expert Duo
Vento Expert
FUNCTIONING OF THE AIR SHUTTERS FOR Vento Expert A50/85/100-1 W V.2
The shutters are closed The shutters are open
The ventilator consists of an indoor unit with a decorative front panel, a cartridge, an air duct with a sound absorbing mat and an outer
ventilation hood.
Cartridge is the basic functioning part of the ventilator. The cartridge consists of fans, a regenerator and two filters that ensure rough air
filtration and prevent ingress of dust and foreign objects into the regenerator and the fan.
The indoor unit is equipped with an automatic air shutters that close during power-off of the ventilator and prevents air backdraft.
Vento Expert Duo is equipped with a set of air flow separators. The design of the supplied ventilation hood ensures opposite direction
of extract and supply air flows.
The ventilation hood must be installed on the outer wall to prevent ingress of water and foreign objects into the unit.
The Vento Expert A50/85/100-1 W V.2 indoor unit is equipped with automatic air shutters. During operation of the ventilator the air
shutters open to let air flow through the ventilator. After the unit shutdown the shutters close within 2 minutes.
DESIGN AND FUNCTIONING

www.blaubergventilatoren.de 
8
OPERATION MODES
Vento Expert Vento Expert Duo
Ventilation: the ventilator runs either in extract or supply mode
at a set speed.
In this mode one group of the ventilators run in the supply mode
and the other in the extract mode, depending on position of the
DIP switch No. 3 (refer to page 13).
Boost: the ventilator goes to the maximum speed with the same
operation mode.
Regeneration: the ventilator runs in two cycles, 70 seconds each,
with heat and humidity regeneration.
Cycle I. Warm stale air is extracted from the room and flows
through the ceramic regenerator, which gradually absorbs heat
and humidity. 70 seconds after the ceramic regenerator starts to
get warm, the ventilator goes to the supply mode.
Cycle II. Fresh cold intake air from outside flows through the
ceramic regenerator, absorbs accumulated moisture and is
heated up to the room temperature by heat accumulated in the
regenerator. In 70 seconds after the regenerator cools down, the
ventilator goes again to the extract mode and the cycle starts
from the beginning. In this mode in case of installation of two
ventilators they operate with opposite rotation directions. While
one ventilator supplies air, the other one extracts air.
Air supply: the ventilator operates in the supply mode irrespective
of position of the DIP switch No. 3 (refer to page 13).
Ventilation: one fan runs in the air extract mode and the other fan
runs in the air supply mode at set speed. The fans do not change
the rotation direction.
Boost: in case of a sensor activation the ventilator follows one of
two functioning algorithms to be set during setup of the ventilator
with the DIP switch. For details, refer to the page 13.
DIP switch is set to OFF: the ventilator runs in the extract mode on
the third speed (both fans run in the extract mode).
DIP switch is set to ON: the ventilator goes to the maximum speed
in the same operation mode.
Regeneration: one fan runs in the extract mode and the other
one in the supply mode. Each 70 seconds the fans change the
rotation direction.

www.blaubergventilatoren.de

9
READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT.
DO NOT BLOCK THE AIR DUCT OF THE INSTALLED VENTILATOR WITH DUST
ACCUMULATING MATERIALS, SUCH AS CURTAINS, CLOTH SHUTTERS, ETC.
AS IT PREVENTS AIR CIRCULATION IN THE ROOM.
1. Prepare a round core hole in the outer wall. The hole size is shown in the figure below.
A
AA-A
ø 180
min 500
min 500
min 500
2. Insert the air duct in the wall hole. For ease of installation use the polystyrene wedges included in the delivery set. The air duct end must
protrude for the distance A that enables installation of the outer ventilation hood. The distance A is stated in the installation instruction
for the ventilation hood.
A
min 3 mm
Fill the gaps between the air duct
and the hole with mounting
foam.
Polystyrene wedge
Install the air duct with the minimum slope of 3 mm downwards to
the outer wall side.
To cut the air duct either make preliminary calculations of the
required duct length or make sure to have access to the outer wall
after fixation of the air duct.
MOUNTING AND SETUP

www.blaubergventilatoren.de 
10
3. Fasten the supplied mounting template to the indoor wall using the adhesive tape. The large opening in the template must be coaxial
with the air duct. For aligning the template with respect to the horizon line it is recommended to use a builder’s level.
Then mark the fastening holes for installation of the supplied dowels and drill the holes to a required depth. Route the power cable of the
ventilator from the wall through the marked opening on the template.
207
Ø 5
Ø 180
87,5 138
103,5
137
85
Ø 23
Hole marking for fasteners
4 holes
4. Press the side tabs to detach the front part of the indoor unit from its rear part.
ATTENTION!
For the Vento Expert A50/85/100-1 W V.2
prior to mounting the front panel
make sure that the thermal actuator
rod is in the lowest position.
Blinking of the white led indicator
means that the thermal actuator is not
in the low position!
5. Fix the rear part of the indoor unit on the wall using the screws supplied with the mounting kit of the ventilator. Remove the two screws
that retain the transparent cover to enable access to the connection terminals.
6. Route the power cable as figured below and connect the
ventilator to power mains in compliance with the external wiring
diagram (refer to page 12).
Fix the power cable and the signal cables with a cable clamp.
After completion of the electrical connection re-install the
transparent terminal cover in site.
Cable clamp

www.blaubergventilatoren.de

11
7. Insert the cartridge in the air duct as shown below. During mounting make sure the pointer is directed upwards. Then fix the cable with
a clamp and connect the socket connector to the control board.
Lay the cables under the clamp
and connect the socket connector
to the control board.
The pointer must be
directed upwards
8. Install the front part of the indoor unit.
Vento Expert Vento Expert Duo
9. Insert the sound absorbing mat into the air duct. Roll the sound
absorbing mat to match the air duct diameter with the protecting
paper layer outside. Insert the roll in the air duct against stop to
the cartridge. Make a mark at the end of the air duct, remove the
sound absorbing mat and cut the roll according to the marking.
After that insert the ready roll into the air duct.
9. Install the sectional air flow separators from outside. Install a
required number of the air flow separators in the air duct against
stop to the cartridge. Mark the last air flow separator to be flush
with the air duct face, remove the last air flow separator from the
air duct and cut it according to the marking.
Install the adjusted air flow separators to the air duct.
10. Install the outer ventilation hood. For mounting guidelines of the ventilation hood please refer to the installation instruction for
the outer hood.

www.blaubergventilatoren.de 
12
N
L
N
L (~)
N (~)
L
In
Gnd
NO1
NO2
+12V
QF*
Power supply to
the next ventilator
Input for 0-10 V
analogue sensor
NO contact of an
external unit
(relay sensor)
Power supply
AC 100-240V
50/60 Hz
ON DIP
1 2 3 4
DIP switch and USB
socket under the
cover
EXTERNAL WIRING DIAGRAM
VENTILATOR SETUP
POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT.
THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN.
THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE
MANUFACTURER’S LABEL.
ANY TAMPERING WITH THE INTERNAL CONNECTIONS IS PROHIBITED
AND WILL VOID THE WARRANTY.
The unit is rated for connection to single-phase AC 100-240 V/ 50 (60) Hz power mains.
The installation of power and signal cables is described in the Installation and set-up section.
Connect the unit to power mains using durable, insulated and heat-resistant conductors (cables and wires). The total minimum cross
section for the power cable must be not less than 0.5 up to 0.75 mm2and 0.25 mm2for the signal cables. The above wire cross section
value is tentative. The signal cable must be shielded. The actual conductor cross section selection must be based on the wire type,
maximum wire temperature, insulation, length and installation method.
Use copper wires only for all the electric connections!
Connect the unit to power mains via the terminal block in compliance with the wiring diagram and terminal designation.
Connect the ventilator to power supply through an automatic circuit
breaker with electromagnetic trip integrated into the home wiring
system. The rated trip current of the automatic circuit breaker must
exceed the maximum current consumption of the unit, refer to the rating
plate on the unit casing.
The ventilator design enables connection of the external units with NO
contact, such as external CO2
sensor, humidity sensor, switch, etc.
When the NO contact of the external device is closed, the ventilator
switches to the maximum speed.
It is possible to connect an analogue sensor with output voltage 0-10 V
to the ventilator.
Prior to operating the ventilator set it up using the DIP switch. It is
located on the controller circuit board.
To access the DIP switch take off the front part of the indoor unit,
then uplift the rubber cover that closes the switch.
CONNECTION TO POWER MAINS

www.blaubergventilatoren.de

13
VENTILATOR CONTROL
Turning ventilator on/off
Speed selection
Speed/Standby
The speed selection sequence
is follows: I-II-III-Standby.
Regeneration mode
The fan rotation direction changes to
opposite each 70 seconds.
This operation mode enables heat
regeneration.
Ventilation mode
Vento Expert
The ventilator runs in the extract or
in the supply mode at the set speed.
Vento Expert Duo
One fan runs in the extract mode and
the other one in the supply mode
at the same speed.
The air direction is not changed. Party mode. Activation of the
speed III according to the timer
(the default setting is 4 hours).
Night mode. Activation of the
speed I according to the timer
(the default setting is 8 hours).
The ventilator may be controlled with the following controls:
• infra-red remote controller
• the buttons located on the side of the indoor unit (see the figure below)
• the mobile application «Blauberg Vento V.2» installed on a smartphone or a tablet
POSITIONING OF THE DIP SWITCH
Setup of ventilator operation mode
1
OFF: Master unit.
1
ON: Slave unit.
Standby mode setup
2
OFF: the ventilator is off in the Standby mode.
2
ON: the ventilator is running at the first speed in the Standby mode.
Setup of air ow direction in Ventilation mode with running ventilators for Vento Expert
3
OFF: the ventilator runs in the extract mode.
3
ON: the ventilator runs in the supply mode.
Setup of Boost mode (actuation of any sensor) for Vento Expert Duo
3
OFF: after sensor actuation the ventilator runs in the extract mode at the third speed
3
ON: after sensor actuation the ventilator runs in the current mode at the third speed
Reset to factory settings
4
OFF: standard operation mode
4
ON: reset to factory settings. Turn the switch to the position ON while the ventilator is running. After the sound signal turn the switch
to the position OFF.

www.blaubergventilatoren.de 
14
VENTILATOR CONTROL WITH THE BUTTONS ON THE INDOOR UNIT
The speed selection sequence is as follows: I-II-III-Standby. All the units integrated in a network run with the speed
set with the Master unit.
I: permanent glowing of the indicator indicates operation of the unit with the first speed. Blinking of the indicator
indicates activation of the Night mode timer.
I and II: permanent glowing of the indicators I and II indicates running of the ventilator at the speed II.
I, II and III: permanent glowing of the indicators I, II and III indicates running of the ventilator at the speed III.
Synchronous blinking of the indicators I, II and III indicates activation of the timer in the Party mode or the turn-
off delay timer in the Boost mode in case of actuation of the connected external sensors or integrated humidity
sensor.
Alternate blinking of the indicators I, II and III indicates running of the ventilator at the speed set with the mobile
application using the slider selector for manual speed setting or activation of the scheduler.
Regeneration mode
Vento Expert
Rotation direction of the fan changes once in 70 seconds. Heat regeneration is accomplished in the Regeneration
mode. To enable operation of the ventilators in opposite directions change the position of the DIP switch No. 3.
Vento Expert Duo
Rotation direction of the fans change once in 70 seconds. Heat regeneration is accomplished in the Regeneration
mode.
Ventilation mode
Vento Expert
The ventilator runs in the extract or in the supply mode at the set speed. The fan rotation direction depends on
the position of the DIP switch 3.
Vento Expert Duo
One fan runs in the air extract mode and the other fan runs in the air supply mode at set speed. The fans do not
change the rotation direction.
No glowing of the indicators “Regeneration” and “Ventilation” indicates forced activation of the supply ventilation mode of the
ventilator. This mode may be activated via the mobile application only.
Filter
The filter clogging indicator starts blinking 90 days after installation of the cartridge. In this case clean or replace
the filters (see the “Technical maintenance” section).
After replacement of the filters reset the filter timer using the mobile application or press and hold the
button on the indoor unit of the Master unit for 5 seconds, until a signal beeps.
Alarm
Alarm indicator. In case of a failure the Alarm indicator on the indoor unit glows or blinks.
Reasons of alarm blinking:
• Battery charge is below the allowable limit
• No connection between the Master unit and the router
• Alarm shutdown of a ventilator.
If several interconnected ventilators are running in the same network, in case of alarm shutdown of one
Vento Expert ventilator all the other ventilators of this series also stop. The alarm indicator on the defective
ventilator blinks and glows on other stopped connected ventilators. All the ventilators of the Vento Expert Duo
series in the network continue to run.
In case of an emergency shutdown of the Vento Expert Duo ventilator in the network the defective ventilator
does not influence the operation of other connected ventilators in the network.
In case of communication loss of the Master unit with the router longer than 20 seconds the Master unit goes
to the Standby mode (blinking Alarm indicator) and the Slave units will communicate communication loss with
the Master unit (refer description of the Master indicator). After resumption of the connection the Slave units
automatically get synchronised with the Master unit.
Master
Permanent glowing of the indicator indicates the Master unit.
Blinking of the indicator indicates the Slave unit and no connection with the Master unit.
No glowing of the indicator means that this ventilator is a Slave unit and it is connected to the Master unit.
Synchronous blinking of all the indicators on the casing of the ventilator indicates activated Setup Mode.

www.blaubergventilatoren.de

15
REMOTE CONTROL OF THE VENTILATOR
Turning on/Standby. The Standby mode depends on positioning of the DIP switch No. 2 (refer to page 13). The
same button is used to reset alarms (Alarm) and turn off the timers.
Speed selection: III-II-I speeds respectively.
Regeneration mode
Vento Expert
Rotation direction of the fan changes once in 70 seconds. Heat regeneration is accomplished in the Regeneration
mode. The fan rotation direction depends on the position of the DIP switch 3.
Vento Expert Duo
Rotation direction of the fans changes once in 70 seconds. Heat regeneration is accomplished in the Regeneration
mode.
Ventilation mode
Vento Expert
The ventilator runs in the extract or in the supply mode at the set speed. The fan rotation direction depends on
the position of the DIP switch 3.
Vento Expert Duo
One fan runs in the extract mode and the other one in the supply mode at the same speed. The air direction is
not changed.
Timer control buttons:
Party mode: the timer activates operation of the ventilator with the speed III, 4 hours by default. The time
setting may be edited with the mobile application.
Night mode: the timer activates operation of the ventilator with the speed I, 8 hours by default. The time
setting may be edited with the mobile application.
The ventilator reverts to operation with a previous speed setting upon the timer countdown.
Press any speed setting button to deactivate the timer or press the timer control button once again.

www.blaubergventilatoren.de 
16
VENTILATOR CONTROL WITH MOBILE APPLICATION
To enable ventilator control with a mobile device install the Blauberg Vento V.2.
Blauberg Vento V.2 - App Store Blauberg Vento V.2 Play Market
Your mobile device must have the operation system matching the following parameters:
• iOS: 8 or later. Compatible with iPhone, iPad, iPod.
• Android: 4 or later.
CONNECTION OF MOBILE APPLICATION TO THE VENTILATOR
Download the Blauberg Vento V.2 application and install it on the mobile device.
If there is no connection with the ventilator during launching of the application the mobile device displays the following message:
By default, the ventilator operates as a Wi-Fi access point. Connect the mobile device to the Wi-Fi access point with the name (FAN: + 16
ID Number characters) stated on the ventilator casing under the front panel.
Wi-Fi access point password: 11111111.
1 2 4 56 873
Enter the Blauberg Vento V.2 app and create a new connection as follows:
1. Enter the app menu.
2. Select Connection - At home.
3. If mobile device is connected to the Wi-Fi access point without router, select the default connection.
4. In case of connection via router start searching for ventilators in the network.
5. Find the new connection in the list and highlight its ID.
6. Edit the connection details.
7. If necessary, re-name the connection and enter the ventilator password.
By default the ventilator password is 1111 (is highlighted in the entry line automatically).
WARNING! At this stage the password for the ventilator cannot be changed.
8. Validate the entered data.
Once the connection has been established, go to the app menu and select Control.

www.blaubergventilatoren.de

17
DESCRIPTION OF MOBILE APPLICATION CONTROL BUTTONS
ON/Standby. The Standby mode is determined by the DIP switch No. 2
position (see page 13).
Selection of the pre-set speed: first, seconds, third speed respectively.
Manual speed setting. Check the scroll bar to activate it.
Ventilation
Vento Expert
The ventilator operates either in the extract or supply mode at the set
speed. The fan rotation direction depends on the position of the DIP
switch 3.
Vento Expert Duo
One fan runs in the extract mode and the other one in the supply mode
at the same speed. The air direction is not changed.
Regeneration mode
The fan rotation direction changes to opposite each 70 seconds. This
operation mode enables heat regeneration.
Supply mode
In this mode the Vento Expert ventilator runs exclusively in the supply
mode. The ventilator Vento Expert Duo goes to the Ventilation mode.
Night mode. Activation of the first speed timer (the default setting is 8
hours, adjustable in the menu Settings - Timers).
Scheduler.
Activation of the week scheduled operation.
Party mode. Activation of the third speed timer without changing the
ventilator operation mode (4 hours by default, adjustable in the menu
Settings-Timers).
DESCRIPTION OF MOBILE APPLICATION INDICATORS
Current type of connection to the ventilator.
Home connection or connection via a cloud server through Internet respectively.
Indicator of activation of the third speed after actuation of any sensor.
When this mode is active, all the other modes are disabled. After countdown of the turn-off delay timer (default
setting 30 minutes) the ventilator reverts to previous mode. Press the Power button to deactivate this operation
mode.
Humidity indicator. It indicates humidity above the set point.
External relay sensor indicator. It indicates actuation of the external relay sensor.
External analogue 0-10V sensor indicator. It indicates exceeding the set point on the external sensor.
Alarm indicator. In case of alarm glows the indicator with two colours:
The indicator glows red in case of alarm shutdown of the ventilator.
The indicator glows orange if battery is not available or the battery charge is low.
Filter replacement indicator. To reset the filter timer go to Menu - Settings - Filter.
When simultaneously activating several operation modes that exclude each other, the operation mode selection is done according to
the following priority:
1. Night mode timer or Party mode timer.
2. Standby.
3. Boost.
4. Schedule
5. Regular mode.

www.blaubergventilatoren.de 
18
VENTILATOR PASSWORD CHANGE
TIMER SETUP
SENSOR SETUP
To change the ventilator password in the mobile application go to
Menu – Connection – Home.
1. Select the connection type and press the Settings button.
2. Enter and confirm the password.
3. Press the Change Password button.
1 2 3
To set the "Night mode","Party mode" timer and the turn-off delay timer for the "Boost" mode, go to
Menu–Settings–Timers in the mobile application.
The "Night mode" timer sets transition time to the low speed after activation of the Night mode (8 hours
by default).
The “Party” timer sets transition time to the high speed after activation of the Party mode (4 hours by
default).
The turn-o delay timer for the "Boost" mode defines switch delay to the high speed after actuation of
any sensor and reset of the sensor to the standard status.
To set up sensor operation via the mobile application go to Menu - Settings -Sensors.
Humidity sensor: actuation of the humidity sensor. When the indoor humidity exceeds the set point, the
ventilator goes to the third speed. When the indoor humidity drops down below the set point, the turn-off
delay timer for the "Boost" mode is activated. After the delay timer countdown, the ventilator reverts to the
previous speed setting. Sensor 0-10 V: actuation of the analogue 0-10V sensor. If the 0-10 V control signal
exceeds the set value, the ventilator goes to the maximum speed. After decrease below the set value the
Boost delay timer is activated. After its operation is completed the ventilator reverts to the previous speed.
Relay sensor: actuation of the external relay sensor. As the NO contact of the external relay sensor
is closed, the ventilator goes to the high speed. As the NO contact opens, the turn-off delay timer for
the "Boost" mode is activated. After the ventilator operation in the Boost mode comes to the end, the
ventilator reverts to the previous speed setting.
Note: for activation/deactivation of the sensors and setup of the sensor threshold points for
Vento Expert Duo ventilators in the Slave mode follow the steps:
• turn the ventilator to the Master mode using the DIP switch No. 1 (refer to page 13)
• set the ventilator into the special setup mode (refer to page 22)
• connect to the unit via a mobile device (refer to page 16)
• set the sensors using the mobile application
• exit the special setup mode
• turn the ventilator to the Slave mode using the DIP switch No. 1

www.blaubergventilatoren.de

19
DATE AND TIME SETUP
WEEKLY SCHEDULE SETUP
To set up the ventilator date and time, go to Setting–Date and time.
Current time: set the current time.
Current date: set the current date.
FILTER TIMER RESET
RESET TO FACTORY SETTINGS
To set up the weekly schedule in the mobile application go to Menu–Settings–Scheduler.
The weekly schedule can be set by means of 4 time intervals available for each day of the week.
You can select one of the three fan speeds or Standby for each time interval.
To receive the current settings for the selected day of the week press the Receive button.
To apply the selected settings for the selected day of the week press the Apply button.
For proper operation of the week scheduler make sure of the correct settings for the date and time.
The ventilator filters must be serviced after every 90 hours of continuous operation.
The need to replace the filters is communicated by the indicator in the upper section of the Control
menu. Replace the filter and reset the filter timer.
To reset the filter timer via the mobile application go to Menu–Settings–Filter. Then press the Reset
lter timer button.
The 90 days are counted on the Master ventilator only. The filter replacement indication is replicated on all
the Slave units. In this case replace the filters on all the ventilators in the network. After filter timer reset, the
filter replacement indicator goes off on all the connected ventilators.
The filter timer can also be reset by means of the button on the indoor unit (see page 14).
To reset to the factory settings via the mobile application go to Menu - Setting - Factory settings. Then
press the Reset to factory settings button.
WARNING!
Reset to the factory settings may result in losing Wi-Fi connection with the device.

www.blaubergventilatoren.de 
20
WIRELESS CONNECTION OF SEVERAL VENTILATORS
The ventilator has two operation modes.
Master unit mode. The ventilator acts as a Master unit. The Slave units and the mobile devices are connected to the Master unit via the
Wi-Fi connection. The Master unit is controlled via the mobile application, remote control or the sensor buttons on the ventilator casing.
The control signal is automatically transmitted to all the Slave units in the network. In this mode the ventilator receives signals from the
sensors (humidity sensor, external digital sensor, external 0-10 V analogue sensor) and goes to a respective operation mode.
Slave unit mode. The unit acts as a Slave unit in the network. The ventilator responds to the control signals from the Master unit only.
Any other signals from other controls are ignored. In this mode the Vento Expert ventilators ignore signals from the sensors. In case of
communication loss with the Master unit longer than 20 seconds the ventilator goes to the Standby mode.
Sensor-actuated operation. The Vento Expert ventilators respond to the signal from the sensors in the Master mode only.
The Vento Expert Duo ventilators respond to the signal from the sensors in any mode (Master or Slave).
In case of actuation of any sensors for Vento Expert, all the connected Vento Expert ventilators go to the maximum speed. The
Vento Expert Duo ventilators continue to run with the same speed.
In case of actuation of any sensors for Vento Expert Duo only the affected ventilator goes to the maximum speed according to the
humidity control scenario. The rest of the ventilators continue to run with the same speed.
WIFI PARAMETER SETUP
Setup of the Wi-Fi parameters is only possible on Master units. To set up ventilator Wi-Fi parameters via the
mobile app go to Menu - Connection - WI-FI setup.
Press the Receive button to display the current Wi-Fi settings.
Select one of the Wi-Fi operation modes:
Access point: access point mode without a home router.
Select the desired security level for the Access point mode:
• Open: open network, not password-protected.
• WPA PSK: password-protected. The encryption technology based on the WPA protocol does not
ensure full security.
• WPA2 PSK: password-protected. The encryption technology is for modern networks.
• WPA/WPA2 PSK: password-protected (recommended). This combined technology activates WPA
and WPA2 and provides compatibility with any electronic devices.
Enter your access point password and press the Apply button.
Client: client mode. The ventilator operates in the home router network.
Enter the home router details and the IP address type for the Client mode.
• Enter the name of the Wi-Fi home router access point.
• Enter the password for the Wi-Fi home router access point.
Select IP address type:
DHCP: the IP address is set up automatically upon connection to the home router (recommended).
Static: enables manual entry of the IP address, subnet mask and default gateway. These settings are
recommended for expert users only. Select this IP address type at your own risk.
Then press the Apply button.
