USER’S MANUAL
INLINE AXIAL FAN
EN
BLABDUCTO

2
WARNING
!
Disconnect the fan from power supply prior to any connection, servicing
and repair operations.
Only duly qualified electricians with valid electrical permit for electric
operations at the units with operating voltage up to 1000 V are allowed
for mounting and maintenance after careful study of the present
user's manual.
The single-phase power mains must comply with the acting local electrical
norms and standards.
Check the fan for any visible damages of the impeller and the casing before
starting installation. The casing internals must be free of any foreign objects
which can damage the impeller blades.
Due to constant improvements the design of some models may slightly
differ from those ones described herein.
While mounting the fan do not compress the casing!
Deformation of the casing may result in the motor jam and noisy operation.
Misuse of the fan and any unauthorised modifications are not allowed.
Take steps to prevent ingress of smoke, carbon monoxide and other
combustion products into the room through open chimney flues or other
fire-protection devices. Sufficient air supply must be provided for proper
combustion and exhaust of gases through the chimney of fuel burning
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
3
WARNING
!
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
equipment to prevent back drafting.
Transported air must not contain any dust or other solid impurities, sticky
substances or fibrous materials.
Do not use the fan in a hazardous or explosive environment containing
spirits, gasoline, insecticides, etc.
Do not close or block the fan intake or extract vents in order to ensure the
efficient stream.
Do not sit on the fan and do not put objects on it.
The timer circuit is live.
Disconnect the fan from power supply prior to any adjustment operations.
The fan delivery set includes a specially designed plastic screwdriver for
adjustment of the fan parameters.
Use the plastic screwdriver to change the turn-off delay time.
This appliance is not intended to be used by persons(include children).
If the supply cord is damaged, it must be replaced by a special cord or
assembly available from the manufacturer or its service agent.
Precautions must be taken to avoid the back-flow of gases into the room
from the open flue of gas or other fuel-burning appliances with reduced
physical, sensory or mental capabilities or lack of experience and

2
WARNING
!
Disconnect the fan from power supply prior to any connection, servicing
and repair operations.
Only duly qualified electricians with valid electrical permit for electric
operations at the units with operating voltage up to 1000 V are allowed
for mounting and maintenance after careful study of the present
user's manual.
The single-phase power mains must comply with the acting local electrical
norms and standards.
Check the fan for any visible damages of the impeller and the casing before
starting installation. The casing internals must be free of any foreign objects
which can damage the impeller blades.
Due to constant improvements the design of some models may slightly
differ from those ones described herein.
While mounting the fan do not compress the casing!
Deformation of the casing may result in the motor jam and noisy operation.
Misuse of the fan and any unauthorised modifications are not allowed.
Take steps to prevent ingress of smoke, carbon monoxide and other
combustion products into the room through open chimney flues or other
fire-protection devices. Sufficient air supply must be provided for proper
combustion and exhaust of gases through the chimney of fuel burning
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
3
WARNING
!
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
equipment to prevent back drafting.
Transported air must not contain any dust or other solid impurities, sticky
substances or fibrous materials.
Do not use the fan in a hazardous or explosive environment containing
spirits, gasoline, insecticides, etc.
Do not close or block the fan intake or extract vents in order to ensure the
efficient stream.
Do not sit on the fan and do not put objects on it.
The timer circuit is live.
Disconnect the fan from power supply prior to any adjustment operations.
The fan delivery set includes a specially designed plastic screwdriver for
adjustment of the fan parameters.
Use the plastic screwdriver to change the turn-off delay time.
This appliance is not intended to be used by persons(include children).
If the supply cord is damaged, it must be replaced by a special cord or
assembly available from the manufacturer or its service agent.
Precautions must be taken to avoid the back-flow of gases into the room
from the open flue of gas or other fuel-burning appliances with reduced
physical, sensory or mental capabilities or lack of experience and

The product must be collected separately at the end
of service life.
Do not dispose of as unsorted municipal waste.
4
WARNING
!
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
knowledge provided that they have been given supervision or instruction
regarding a safe use of the product and understand the risks involved.
Do not allow children play with the product.
5
DELIVERY SET
1. Fan – 1 item
2. Screws and dowels – 4 items
3. Fixing bracket – 1 item
4. User's manual – 1 item
5. Packing box
BRIEF DESCRIPTION
The products is an axial fan for exhaust or supply ventilation of small to medium-sized premises.
The fan is designed for connection to 100, 125 and 150 mm air ducts.
OPERATION GUIDELINES
The fan is rated for connection to AC single-phase 220…240 V/50 Hz or 220…240 V/60 Hz power supply, depending
on the fan model type. For details, please refer to the sticker on the fan casing. The fan is rated for operation at the ambient
air temperature from +1 °C up to +45 °C. Ingress protection rating against access to hazardous parts and water ingress is
IPX4. The fan requires no grounding.
MOUNTING
The fan is designed for vertical or horizontal installation and connection to a round air duct of a matching diameter, Fig. 1–3.
ATTENTION!
In case of vertical mounting the fan must be protected against ingress of rainfalls and condensate inside the fan.
Fan installation with direct air discharge upwards is not allowed, Fig. 3.
Read the user's manual carefully before proceeding with installation works.
Compliance with the manual requirements ensures reliable operation and long service
life of the product. Keep the user's manual available as long as you use the product.
You may need to re-read the information on the product servicing.
EN
Use the supplied fixing bracket for mounting. Attachment of the fixing bracket to the fan is shown in Fig. 4.
Fan mounting steps are shown in Fig. 5–12. Wiring options are shown in Fig. 13–16.
MAINTENANCE
Cut off power supply to the fan and take steps to prevent unintentional power supply activation before completion of the
maintenance operations.
The fan maintenance periodicity is at least once per 6 months, depending on operation conditions.
Maintenance works include regular cleaning of the fan surfaces of dust and dirt and checking reliability of electrical
connections.
Follow the applicable local maintenance safety requirements.

The product must be collected separately at the end
of service life.
Do not dispose of as unsorted municipal waste.
4
WARNING
!
Follow the user's manual requirements to ensure durable
and trouble-free operation of the fan.
knowledge provided that they have been given supervision or instruction
regarding a safe use of the product and understand the risks involved.
Do not allow children play with the product.
5
DELIVERY SET
1. Fan – 1 item
2. Screws and dowels – 4 items
3. Fixing bracket – 1 item
4. User's manual – 1 item
5. Packing box
BRIEF DESCRIPTION
The products is an axial fan for exhaust or supply ventilation of small to medium-sized premises.
The fan is designed for connection to 100, 125 and 150 mm air ducts.
OPERATION GUIDELINES
The fan is rated for connection to AC single-phase 220…240 V/50 Hz or 220…240 V/60 Hz power supply, depending
on the fan model type. For details, please refer to the sticker on the fan casing. The fan is rated for operation at the ambient
air temperature from +1 °C up to +45 °C. Ingress protection rating against access to hazardous parts and water ingress is
IPX4. The fan requires no grounding.
MOUNTING
The fan is designed for vertical or horizontal installation and connection to a round air duct of a matching diameter, Fig. 1–3.
ATTENTION!
In case of vertical mounting the fan must be protected against ingress of rainfalls and condensate inside the fan.
Fan installation with direct air discharge upwards is not allowed, Fig. 3.
Read the user's manual carefully before proceeding with installation works.
Compliance with the manual requirements ensures reliable operation and long service
life of the product. Keep the user's manual available as long as you use the product.
You may need to re-read the information on the product servicing.
EN
Use the supplied fixing bracket for mounting. Attachment of the fixing bracket to the fan is shown in Fig. 4.
Fan mounting steps are shown in Fig. 5–12. Wiring options are shown in Fig. 13–16.
MAINTENANCE
Cut off power supply to the fan and take steps to prevent unintentional power supply activation before completion of the
maintenance operations.
The fan maintenance periodicity is at least once per 6 months, depending on operation conditions.
Maintenance works include regular cleaning of the fan surfaces of dust and dirt and checking reliability of electrical
connections.
Follow the applicable local maintenance safety requirements.

6
DIMENSIONS
øD L
H
K
Model
øD
L
H
K
N
BLABDUCTO 100
99
138
109
160
54
BLABDUCTO 125
124
162
138
160
54
BLABDUCTO 150
149
182
166
190
54
N
7
EN
3
1
4
2

6
DIMENSIONS
øD L
H
K
Model
øD
L
H
K
N
BLABDUCTO 100
99
138
109
160
54
BLABDUCTO 125
124
162
138
160
54
BLABDUCTO 150
149
182
166
190
54
N
7
EN
3
1
4
2

8
EN
QF
L N
56
7 8
910
9
11 12
13
Wiring diagrams
2
1
S
QF
L
N
BLABDUCTO 100/125/150

8
EN
QF
L N
56
7 8
910
9
11 12
13
Wiring diagrams
2
1
S
QF
L
N
BLABDUCTO 100/125/150

10
TRANSPORTATION AND STORAGE RULES
Transportation is allowed by any transportation vehicle provided that the product is in the manufacturer's original
package.
Store the delivered product in the manufacturer's original packing box in a dry ventilated premise with the
ambient temperature from +5 °C up to + 40 °C and relative humidity less than 80 %.
The storage environment must be free of dust, acid or alkali vapours to prevent corrosion.
DISPOSAL
Do not dispose in domestic waste. The unit contains in part material that can be recycled and in part substances
that should not end up as domestic waste.
Dispose of the unit once it has reached the end of its working life according to the regulations valid where you
are.
AUSTRALASIA BLAUBERG WARRANTY:
 This warranty is given by Blauberg Australasia Pty Ltd, with an office at U5, 45 Eastern Creek Drive, Eastern
Creek, NSW 2766, Australia. Phone [phone]
 From the date of purchase, the original purchaser is entitled to free replacement parts, or a new unit for a
period of five years from the date of purchase
 The defective parts or unit must be returned to Blauberg Australasia Pty Ltd at your own cost before an
exchange or parts or unit will be given
 A proof of purchase will be required before a warranty clam is accepted
 The warranty will also not cover damage caused by misuse, neglect, shipping accident, incorrect or
improper installation, voltage supply problems, unauthorised modification or repairs of any kind, exposure to
corrosive conditions, exposure to weather and where no fault is found with the product
 We will not cover any loss incurred by you in relation to the product or making the claim under this warranty
including without limitation any costs associated with installation, reinstallation, or transporting the product.
 Protection degree index according to IP rating against access to hazardous parts and water ingress – IP24.
Additional information:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement of the purchased product for a major failure of the product. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. Our ventilation products also come with a five years limited warranty given by the
distributor Blauberg Australasia Pty Ltd, with an office at U5, 45 Eastern Creek Drive, Eastern Creek, NSW
2766, Australia, as set out in the instruction manual in the box. If your product does not provide the general
features and functions described in the user documentation in the five year period after delivery to you,
please call Blauberg Australasia Pty Ltd, (ABN 85 637 003 582) on 1300 475 504 with details of your product,
serial number and proof of purchase. You maybe required to return the ventilation product to the address
listed, in which case such a return will be at your own cost.
The benefits under this warranty are in addition to other rights and remedies that you may have at law.
11
BLABDUCTO
100
125
150
BLABDUCTO
Approval mark
Manufacturing date
Sales date
Sold
(name and stamp of the seller)
Acceptance certificate
The fan is recognized as serviceable.

10
TRANSPORTATION AND STORAGE RULES
Transportation is allowed by any transportation vehicle provided that the product is in the manufacturer's original
package.
Store the delivered product in the manufacturer's original packing box in a dry ventilated premise with the
ambient temperature from +5 °C up to + 40 °C and relative humidity less than 80 %.
The storage environment must be free of dust, acid or alkali vapours to prevent corrosion.
DISPOSAL
Do not dispose in domestic waste. The unit contains in part material that can be recycled and in part substances
that should not end up as domestic waste.
Dispose of the unit once it has reached the end of its working life according to the regulations valid where you
are.
AUSTRALASIA BLAUBERG WARRANTY:
 This warranty is given by Blauberg Australasia Pty Ltd, with an office at U5, 45 Eastern Creek Drive, Eastern
Creek, NSW 2766, Australia. Phone [phone]
 From the date of purchase, the original purchaser is entitled to free replacement parts, or a new unit for a
period of five years from the date of purchase
 The defective parts or unit must be returned to Blauberg Australasia Pty Ltd at your own cost before an
exchange or parts or unit will be given
 A proof of purchase will be required before a warranty clam is accepted
 The warranty will also not cover damage caused by misuse, neglect, shipping accident, incorrect or
improper installation, voltage supply problems, unauthorised modification or repairs of any kind, exposure to
corrosive conditions, exposure to weather and where no fault is found with the product
 We will not cover any loss incurred by you in relation to the product or making the claim under this warranty
including without limitation any costs associated with installation, reinstallation, or transporting the product.
 Protection degree index according to IP rating against access to hazardous parts and water ingress – IP24.
Additional information:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement of the purchased product for a major failure of the product. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. Our ventilation products also come with a five years limited warranty given by the
distributor Blauberg Australasia Pty Ltd, with an office at U5, 45 Eastern Creek Drive, Eastern Creek, NSW
2766, Australia, as set out in the instruction manual in the box. If your product does not provide the general
features and functions described in the user documentation in the five year period after delivery to you,
please call Blauberg Australasia Pty Ltd, (ABN 85 637 003 582) on 1300 475 504 with details of your product,
serial number and proof of purchase. You maybe required to return the ventilation product to the address
listed, in which case such a return will be at your own cost.
The benefits under this warranty are in addition to other rights and remedies that you may have at law.
11
BLABDUCTO
100
125
150
BLABDUCTO
Approval mark
Manufacturing date
Sales date
Sold
(name and stamp of the seller)
Acceptance certificate
The fan is recognized as serviceable.

Blauberg_Australasia_B01-(BLABDUCTO)EN-02www.blaubergventilation.com.au
BLABDUCTO
