Blaupunkt CDC A01 User manual

Changer
CDC A01
Operating and Installation Instructions
http://www.blaupunkt.com

2
Thank you for choosing this Blaupunkt
product. We hope that you will enjoy it
for a long time to come.
PleasereadtheseOperatingInstruc-
tionsbeforeusingtheproduct forthe
first time.
Oureditorsconstantlystrivetomakeour
Operating Instructions clear and easy-
to-understand.Ifyoustillhavequestions
about how to use or install this product,
please contact your dealer or call the
telephone hotline for your country. The
hotline number is listed on the inside
back cover of this booklet.
We grant a manufacturer’s guarantee
on all of our products purchased within
the European Union. You can read the
terms and conditions of guarantee on
the Internet at www.blaupunkt.de or
request them directly by writing to:
Blaupunkt GmbH
Hotline CM/PSS 6
Robert Bosch Str. 200
D-31139 Hildesheim, Germany
CONTENTS GENERAL INFO
General Info ............................. 2
Safety Instructions ................... 3
Tips for Safe Operation ............ 3
Condensation .................................. 3
Before Installing
the Equipment ......................... 4
Transport Locking Screws ............... 4
Precautions for Installation
and Wiring ...................................... 4
Position of the Built-in
Anti-Vibration Armature .................... 5
Using the Changer ................... 6
Loading a CD .................................. 6
Installing the Magazine .................... 7
Handling CDs ........................... 8
New CDs ........................................ 8
Parts Used in Installation ......... 9
Wiring ........................................... 10
Reset Function .............................. 10
Installation.............................. 11
Installation Procedure for
Installation on Carpet
(Horizontal Position) ...................... 11
Installation Procedure for
Installation on Carpet
(Vertical Position) ........................... 12
Installation Procedure for
Installation on Carpet
(at a 45°Angle) ............................. 14
Installation Procedure
(Suspended Installation) ................ 15

3
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
SAFETY INSTRUCTIONS
Safety Instructions
When carrying out installation work
and making connections please
observe the following safety
instructions:
- Electronic vehicle systems may fail
iftheyareincorrectlyinstalledorser-
viced.
- Disconnect the negative terminal of
the battery! When doing so, please
observe the vehicle manufacturer’s
safety instructions.
- Make sure you do not damage ve-
hicle components when drilling any
holes.
- Depending on the model, your ve-
hicle may differ from the description
providedhere.Weacceptnorespon-
sibility for any damages due to in-
correct installation or connection or
for any consequential damages.
If the information provided here is not
suitable for your specific installation re-
quirements, please contact your
Blaupunkt dealer, your vehicle manu-
facturer or our telephone hotline.
Tips for Safe Operation
- ThisCDchangerisdesignedonlyfor
operation in negatively grounded,
+12VDCsystems.Thisdevicecan-
not be used in +24 V or positively
grounded systems.
- This equipment may not function
properly at extremely high or low
temperatures. This device is
equipped with a built-in automatic
protection circuit. If the temperature
reaches a pre-set value, the auto-
maticprotectioncircuitwillshutdown
the entire device. If this happens,
open a window and let the car cool
down.
Condensation
Onrainy,dampdaysorjustafterturning
on the car heater, water vapour may
condense on the laser lens of the CD
changer.Ifthishappens,theequipment
will not function properly. To counteract
this, remove the magazine from the
device and wait for approximately one
hour.Duringthistime,thewater vapour
will evaporate, after which the
equipment will function normally again.
Remove the magazine from the CD
changer at temperatures above 60°C
if it is not in use, or before long periods
of disuse at any temperature.

4
Before Installing the
Equipment
Transport Locking Screws
The mechanism in the CD changer is
“locked” by the transport screws during
shipping. Make
certain to remove these screws before
installing the changer.
Note:
After removing the transport locking
screws, place the enclosed seals over
the screw holes. These seals prevent
dust from entering the device, which
could lead to malfunctions.
Precautions for Installation and
Wiring
1. Do not install the equipment in the
following locations:
- Locations that are exposed to di-
rect sunlight.
- Locations at which warm air exits
the car heating system.
- Locations in which proper instal-
lation is impossible and locations
in which many vibrations are pro-
duced.
2. - Make certain to use the brackets
and screws supplied.
- Wheninstallingtheequipment,do
not use any screws that are part
ofthebrakingorsteeringsystems.
3. The device may only be installed in
the approved manner (on one of its
sides,onone ofitsends,atanangle
of 45°, or suspended. If it is installed
upside-down or with the front facing
down, malfunctions may occur.
BEFORE INSTALLING THE EQUIPMENT

5
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
Position of the Built-in Anti-
Vibration Armature
Thisdevicecanbeinstalledhorizontally
(suspended),vertically,orat a 45°ang-
le.Onceyouhavechosenaninstallation
procedure, you have to set the position
of the built-in anti-vibration armature
accordingly. Please do this before
carrying out the procedures explained
below.VibrationmaycauseCDstoskip
iftheequipmentisusedbeforetheanti-
vibration system has been configured
correctly.
- The anti-vibration armature is set to
“0” (for horizontal installation) at the
factory before shipping.
- The built-in anti-vibration armature
adjusts on both the left and right
sides.
- Beforeattaching the brackets, usea
screwdriver to set the position of the
anti-vibration armature.
For horizontal or suspended instal-
lation:
Make certain that the built-in anti-vibra-
tion armature is set to the “0” position.
BEFORE INSTALLING THE EQUIPMENT

6
USING THE CHANGER
For vertical installation:
The built-in anti-vibration armature
should be set to the “90” position.
For installation at a 45°angle:
The built-in anti-vibration armature
should be set to the “45” position.
Using the Changer
Loading a CD
1. Press the button on the CD drawer
of the magazine and slide out only
onedrawer
.
2. Insert the CD in the drawer with the
playable side down (in other words,
withthelabelfacingup).Eachdrawer
can only hold one CD.
3. Press the button on the CD drawer
so that it closes by sliding inside the
magazine.
Printed side
faces up
Playable side
faces down
BEFORE INSTALLING
THE EQUIPMENT

7
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
You can load up to ten CDs.
Installing the Magazine
1. Slide the cover to the right.
2. Firstmakecertainthatthemagazine
isorientedsothattheCDlabelsface
up and so that the magazine faces
intheproperdirectionforinstallation.
Insert the magazine until it engages
and thus is locked. When the maga-
zine is used for the very first time, it
will not engage until the changer is
connected to electrical power.
To eject the magazine:
To eject the magazine, press the
Eject button ( ).
Note:
Always close the cover after loading a
CD or removing the magazine.
In order to prevent equipment malfunc-
tions, always close the cover.That way
theequipmentisimpervioustodust,dirt,
and other foreign bodies.
USING THE CHANGER
Eject button

8
Handling CDs
New CDs
The following symptoms often occur
when using new CDs:
- The CD does not play evenly after
being inserted
.
- ThechangerchangestothenextCD
beforeithasfinishedplayingthefirst
CD.
- ThechangerplaysthesameCDover
and over again.
- The system will not play a specific
CD.
Remove from the CD surface all plastic
particles from burs before inserting the
CD in the magazine.
Thesesymptoms occurwhen thereare
burs on the CD in the centre hole or
alongtheoutercircumferenceoftheCD
and, as a result, the CD is not drawn
into the changer properly or sticks
somewhatinsidethemagazine.Ifthese
things happen, use a pen or a similar
object to remove the burs as shown in
the figure at right.
Note:
Althoughthereareprotectivefilmsmar-
keted as CD accessories, use of these
products leads to malfunctions and
should be strictly avoided.
Dirt, dust, scratches, and deformations
cause skipping and diminished sound
qualityduringplayback.Hereare some
tips on how to take care of your CDs:
1. UseCDsthatbearthefollowingsym-
bol.
2. Use a soft cloth to wipe away finger-
prints and dust from the playable
(shiny) side of the CD. Unlike pho-
nograph records, CDs have no
grooves to collect dust and small
particles. Thus gentle wiping is usu-
ally sufficient to remove most par-
ticles. Wipe from the centre of the
CD straight outwards. Small dust
particlesandspotsdonotaffectplay-
back quality.
3. Neverusechemicalssuchasrecord
cleaner,anti-staticsprayorfluid,ben-
zene or paint thinner to clean your
CDs.Useofthesechemicalswilllead
to irreparable damage to the plastic
surface of the CD.
HANDLING CDS
Bur Centre
hole
Bur
Outer
circum-
ference

9
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
4. Afteruse,returntheCDstotheirpro-
tective cases to avoid major
scratches that can lead to skipping
on playback.
5. Never store CDs where they are ex-
posedtodirectsunlight,high humid-
ity, or high temperatures over long
periods. CDs may warp if exposed
to high temperatures over long peri-
ods.
6. The playable side of the CD should
not be pasted with paper or marked
with a ballpoint pen.
Parts Used in Installation
Bracket (A)
2 x
Bracke (B)
2 x
Hex bolt (M6 x 12)
4 x
Console bolt (M4 x 5)
4 x
Tap screw (M5 x 12)
4 x
HANDLING CDS PARTS USED IN
INSTALLATION

10
8-pin DIN cable
1 x
Seals
1 x
Double-sided adhesive tape
2 x
PARTS USED IN INSTALLATION
Wiring
Reset Function
You must use a ballpoint pen or a thin
piece of metal to press the reset but-
ton. It should be pressed in the follow-
ing situations:
- During initial installation of the unit,
after wiring has been completed.
- If some functions do not work.
Connect this cable
to the main unit
Reset button

11
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
Installation Procedure for
Installation on Carpet
(Horizontal Position)
1.
- Make certain that the built-in anti-vi-
brationarmaturehas beensettothe
“0” position on both the right and left
sides.
- Using the hex bolts (M4 x 5), fasten
the left and right brackets (A).
- Fastentheleftandright brackets(A)
to the corresponding brackets (B).
Dothis usingthe hexbolts (M6x12)
and hex nuts (M6).
2.
- Lift up the carpet and decide where
you want to mount the unit.
- Fasten the double-stick tape sup-
plied to the bottoms of the brackets
(B) and remove the protective back-
ing from the tape.
- Fasten the unit to the floor by press-
ing it down firmly.
3.
- Unscrew the hex nuts and remove
the CD changer.
INSTALLATION
Position of the built-in anti-
vibration armature
Hex bolts
(M6x12)
Hex bolts
(M4x5)

12
INSTALLATION
4.
- Using a knife, cut through the carpet
directlyabovetheboltsofthemount-
ing bracket (B).
- Replace the carpet in its original po-
sition, so that the bolts poke through
the carpet.
5.
- Using the hex bolts again, refasten
the changer on top of the carpet.
Installation Procedure for
Installation on Carpet
(Vertical Position)
1.
- Make certain that the built-in anti-vi-
brationarmaturehas beensettothe
“90” vertical installation position on
both the right and left sides.
- Using the hex bolts (M4 x 5), fasten
the left and right brackets (A).
- Fastentheleftandright brackets(A)
to the corresponding brackets (B).
Dothis usingthe hexbolts (M6x12)
and hex nuts (M6).
Hex bolts
(M6x12)
Hex bolts
(M4x5)
Position of the built-in anti-
vibration armature

13
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
INSTALLATION
2.
- Lift up the carpet and decide where
you want to mount the unit.
- Fasten the double-stick tape sup-
plied to the bottoms of the brackets
(B) and remove the protective back-
ing from the tape.
- Fasten the unit to the floor by press-
ing it down firmly.
3.
- Unscrew the hex nuts and remove
the CD changer.
4.
- Using a knife, cut through the carpet
directlyabovetheboltsofthemount-
ing bracket (B).
- Replace the carpet in its original po-
sition, so that the bolts poke through
the carpet.
5.
- Using the hex bolts again, refasten
the changer on top of the carpet.

14
INSTALLATION
Installation Procedure for
Installation on Carpet
(at a 45°Angle)
1.
- Set the built-in anti-vibration arma-
ture to the 45°position “45” on both
the right and left sides.
- Using the hex bolts (M4 x 5), fasten
the left and right brackets (A).
- Fastentheleftandright brackets(A)
to the corresponding brackets (B).
Dothis usingthe hexbolts (M6x12)
and the hex nuts (M6).
2.
- Lift up the carpet and decide where
you want to mount the unit.
- Fasten the double-stick tape sup-
plied to the bottoms of the brackets
(B) and remove the protective back-
ing from the tape.
- Fasten the unit to the floor by press-
ing it down firmly.
3.
- Unscrew the hex nuts and remove
the CD changer.
Hex bolts (M6x12)
Hex bolts
(M4x5)
Position of the built-in
anti-vibration armature

15
FRANÇAIS ENGLISHESPAÑOL
PORTUGUÊS
INSTALLATION
4.
- Using a knife, cut through the carpet
directly above the screws of the
mounting bracket (B).
- Replace the carpet in its original po-
sition, so that the screws poke
through the carpet.
5.
- Using the hex bolts again, refasten
the changer on top of the carpet.
Installation Procedure
(Suspended Installation)
1.
- Make certain that the built in anti-vi-
brationarmaturehas beensettothe
“0” position on both the left and right
sides.
- Using the hex bolts (M4 x 5), fasten
the left and right brackets (A).
Hex bolts
Hex bolts
Position of the built-in
anti-vibration armature

16
2.
-Determine where you want to install
theunitanddrillfourmountingholes.
3.
- FastentheCDchangerusingthetap
screws (M5 x 12).
3,6 ø
INSTALLATION

Service numbers / Numéros du service après-vente / Números de
servicio / Números de serviço␣
Country: Phone: Fax: WWW:
Germany (D) 0180-5000225 05121-49 4002 http://www.blaupunkt.com
Austria (A) 01-610 390 01-610 393 91
Belgium (B) 02-525 5454 02-525 5263
Denmark (DK) 44 898 360 44-898 644
Finland (FIN) 09-435 991 09-435 99236
France (F) 01-4010 7007 01-4010 7320
Great Britain (GB) 01-89583 8880 01-89583 8394
Greece (GR) 0800-550 6550 01-576 9473
Ireland (IRL) 01-4149400 01-4598830
Italy (I) 02-369 6331 02-369 6464
Luxembourg (L) 40 4078 40 2085
Netherland (NL) 023-565 6348 023-565 6331
Norway (N) 66-817 000 66-817 157
Portugal (P) 01-2185 00144 01-2185 11111
Spain (E) 902-120234 916-467952
Sweden (S) 08-7501500 08-7501810
Switzerland (CH) 01-8471644 01-8471650
Czech. Rep. (CZ) 02-6130 0441 02-6130 0514
Hungary (H) 01-333 9575 01-324 8756
Poland (PL) 0800-118922 022-8771260
Turkey (TR) 0212-3350677 0212-3460040
USA (USA) 800-2662528 708-6817188
Brasil
(Mercosur) (BR) [phone] [phone]
Malaysia
(Asia Pacific) (MAL) [phone] [phone]
02/02 CM/PSS 8 622 403 245
Blaupunkt GmbH
