Blaupunkt SF02 User manual

User manual
Mobile phone SF02

EN
2
Table of Contents
1. Safety instructions ................................................................................................................................. 4
2. Technical Specifications......................................................................................................................... 5
3. Getting started....................................................................................................................................... 6
3.1 Insert the memory card and SIM card............................................................................................ 6
3.2 Switch the device on and off........................................................................................................... 7
3.3 Unlock the device ............................................................................................................................ 7
4. Charging the battery.............................................................................................................................. 7
5. Using the Touch screen ......................................................................................................................... 8
6. Using the Phone’s Buttons .................................................................................................................... 8
6.1 Virtual buttons ................................................................................................................................. 8
6.2 Menu icons....................................................................................................................................... 8
7. Manage calls........................................................................................................................................... 9
7.1 Make calls......................................................................................................................................... 9
7.2 Flight mode ...................................................................................................................................... 9
7.3 Receive a call.................................................................................................................................... 9
7.4 Emergency calls................................................................................................................................ 9
8. The Home screen................................................................................................................................... 9
8.1 Notification bar ................................................................................................................................ 9
8.2 Customize the idle screen ............................................................................................................. 10
9. Connecting to the Internet.................................................................................................................. 10
9.1 Configure the Internet................................................................................................................... 10
9.2 Access Internet via Wi-Fi ............................................................................................................... 10
10. Messages............................................................................................................................................ 10
10.1 Send Message .............................................................................................................................. 10
10.2 Input methods.............................................................................................................................. 11
11. Multimedia......................................................................................................................................... 11
11.1 Camera ......................................................................................................................................... 11
11.2 Photos........................................................................................................................................... 11
11.3 FM Radio ...................................................................................................................................... 11
12. Contacts.............................................................................................................................................. 12
13. Phone.................................................................................................................................................. 13
14. Search................................................................................................................................................. 13
15. Google Play Store............................................................................................................................... 13
16. More applications.............................................................................................................................. 14
16.1 Clock ............................................................................................................................................. 14
16.2 E-mail............................................................................................................................................ 14
16.3 File manager / Files...................................................................................................................... 14
17. Settings............................................................................................................................................... 14
17.1 Network & Internet ..................................................................................................................... 14
17.2 Connected devices....................................................................................................................... 15

EN
3
17.3 Apps & notifications .................................................................................................................... 15
17.4 Battery.......................................................................................................................................... 15
17.5 Display .......................................................................................................................................... 15
17.6 Scheduled power on/off.............................................................................................................. 15
17.7 Sound............................................................................................................................................ 15
17.8 Storage ......................................................................................................................................... 16
17.9 Privacy .......................................................................................................................................... 16
17.10 Location...................................................................................................................................... 16
17.11 Security....................................................................................................................................... 16
17.12 Accessibility................................................................................................................................ 16
17.13 Accounts..................................................................................................................................... 16
17.14 Digital Wellbeing & parental controls ...................................................................................... 16
17.15 Google ........................................................................................................................................ 16
17.16 System........................................................................................................................................ 16
17.17 About phone .............................................................................................................................. 16
18. Handling and maintenance ............................................................................................................... 17
18.1 Battery.......................................................................................................................................... 17
18.2 Maintain the appliance................................................................................................................ 17
19. Recycling your device ........................................................................................................................ 17
20. Declaration of Conformity................................................................................................................. 18

EN
4
1. Safety instructions
ATTENTION: Please read this guide carefully. Failure to comply with the safety regulations may be
dangerous or illegal, and the manufacturer can not be held liable for any malfunction resulting from
improper use.
Safe switch-on
The owner of the device is responsible for the use of the device. Never switch the device on in areas
where wireless devices are prohibited or radio interference may be dangerous.
Road safety
Observe the local laws and regulations regarding smartphone usage while driving. If you make a
phone call while driving, observe the following rules: Focus on driving to become aware of traffic
conditions; If the device has a hands-free function, use handsfree. If the traffic situation requires,
stop the car before you pick up the phone.
Interference
Wireless devices may be sensitive to interference that affects performance.
Electronic devices
To avoid demagnetisation, do not leave your device for a long time close to electronic devices.
Use in hospitals
Hospitals and other healthcare facilities can use devices that are particularly sensitive to RF signals.
Switch off your phone if prohibited signals are instructed to do so, or hospital staff ask for it.
Electrical medical devices
Your phone is a radio transmitter that can interfere with electronic medical devices or implants such
as hearing aids, pacemakers, insulin pumps, and so on. We recommend that you keep a distance of
at least 15 cm between the implant and the device, never wear your phone in the breast pocket.
Follow the instructions of the manufacturer of the medical device. If you have a medical implant and
have any other questions about using mobile or wireless devices, ask your doctor.
Use on the airplane
Your device supports flying mode, please use this feature on the airplane. Follow the instructions on
the airplane.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in such places may lead to an explosion or
fire that may result in serious injury or death. Turn off the device at gasoline or gas filling stations,
especially near the fuel pumps. Follow the instructions strictly in locations such as fuel tanks,
chemical plants, and explosive substances.
Use environment
The device complies with the recommended emission values for radio waves when kept at a
minimum distance of 1.5 cm from the ear. When carrying the phone in a case, belt clip or holder,
make sure that it does not contain metal and that the phone is slightly distracted from the body.

EN
5
When using other accessories, it is not possible to operate in accordance with radio frequency
guidelines. If you do not use a case and do not hold the phone on your ear, keep it at least 2.5 cm
away from your body, especially during data transfer.
Proper use
Please do not attempt to disassemble the device. If the product is defective, contact your distributor.
Battery and other accessories
Only use parts and accessories approved by the manufacturer. Using non-factory accessories and
spare parts may result in warranty loss. Do not short-circuit the battery.
Charge the appliance in a well-ventilated and suitable temperature environment away from
flammable and explosive materials. Handle the used battery according to local regulations and do
not throw it into household trash.
The mains power socket used must be close to the charger/holder and easily accessible, so that it
can be used as an 'on/off' facility.
Water resistance
The appliance is not waterproof. Precipitation, fog, and other liquids can corrode electronic circuits.
If moisture has reached the phone, power of the phone, if it’s possible.
Backup
Make a backup of all the data stored on your device.
Connect to another device
Before connecting an external device, read the safety instructions in this manual. Do not connect an
incompatible device.
2. Technical Specifications
Basic features:
Display 4.0” WVGA (480 * 800 px)
Operating system Android 10TM GO
CPU 1.3 GHz Quad Core
RAM 1GB
ROM 8GB
Wifi 802.11 b/g
Battery 1400mAh
Back Camera 5MP
Front Camera 2MP
Bluetooth
Network:
GSM: 900 / 1800 MHz
WCDMA: 900 / 2100 MHz
SAR value: 0.37 W/Kg (Head), 0.85 W/Kg (Body)

EN
6
Power Supply Features:
Manufacturer
Shenzhen YiHuiDa Electronic Co.,
Limited
Model
YZD-DM051000
Input voltage
100-240 V
Input AC frequency
50/60 Hz
Output voltage
5.0 V
Output current
1 A
Output power
5W
Average active efficiency
68%
Efficiency at low load(10%)
55%
No-load power consumption
0.1W
Phone layout
The following illustration of the phone is for informational purposes only; your device may be
different.
3. Getting started
3.1 Insert the memory card and SIM card
Turn off the power and remove the back cover and battery. Insert the SIM card according to the
mark on the device. Make sure that the chip contact and the cut edge of the card are aligned in the
correct direction. Slide the card into the slot until it stops. The device handles Micro SIM + Micro SIM
+ Micro SD cards.

EN
7
3.2 Switch the device on and off
Press and hold the Power button to turn on the power.
Press and hold the power button and select “Power off” from the Options menu.
3.3 Unlock the device
To unlock the device, you may need the PIN (not the SIM card PIN), password, or pattern drawing.
Unlock the screen:
1. Press the power key to wake up the phone.
2. Place and hold your finger to the lock icon, then pull down
it.
Please, note: the process of unlocking depends on the
pre-configured unlock method.
To set the unlock method:
▪In the idle screen, touch Settings > Security
▪Touch Screen lock.
▪Choose the type of locking as desired. You can set your
screen lock on the basis of Pattern, PIN, Password, Swipe
or None.
4. Charging the battery
•Connect one end of the charger to the device.
•Connect the charger to the power outlet.
•Charging will start regardless of whether the device is turned on or not.
•When the phone is turned on, the movement of the battery icon in the upper right corner
indicates charging. When the motion stops, the phone is charged.
•When the phone is turned off, the movement of the battery icon on the screen indicates
charging. When the motion stops, the phone is charged.
•Disconnect the charger from the power outlet.
•Disconnect the charger from the phone.

EN
8
5. Using the Touch screen
You can use the touch screen in the following ways:
•Touch: Acts on items on the screen, such as application and settings icons, to type letters and
symbols using the onscreen keyboard, or to press onscreen buttons.
•Touch and hold: Touch and hold an item on the screen until an action occurs.
•Drag: Touch and hold an item and move your finger on the screen until you reach the target
position.
•Swipe or slide: Quickly slide your finger across the surface of the screen, (without dragging an
item). For example, slide the screen up or down to scroll a list.
•Double-tap: You can tap twice quickly to control the zoom in Maps.
•Pinch: In some applications (Such as Maps, Browser, and Gallery) you can zoom in and out by
placing two fingers on the screen at once and pinching them together (to zoom out) or
spreading them apart (to zoom in).
•Rotate the screen: On most screens, the orientation of the screen changes as you rotate it. You
can turn this feature on and off.
6. Using the Phone’s Buttons
6.1 Virtual buttons
Button
Description
Apps: Opens the list of recent
applications.
Home: returns to Home screen.
Pressed long opens the Google
AssistantTM
Back: returns to the previous screen
you were working in
6.2 Menu icons
Dialer
Messaging
Browser (Chrome)
Camera

EN
9
7. Manage calls
7.1 Make calls
▪Tap the icon on main menu or the home screen to dial the desired number.
▪To dial an international number, touch and hold the 0 key to enter the Plus (+) symbol, and then
enter the international country prefix, followed by the phone number.
▪Press the icon to dial.
▪You can control the volume using the Volume up / down buttons on the left side of the
unit.
▪Dialer can also open Call log and Contacts.
▪While during a call, touch the icon to end a call.
7.2 Flight mode
Some locations like airplanes may require you to turn off your mobile, Wi-Fi, and Bluetooth wireless
connections.
▪Swipe you finger in the idle screen from top to bottom to open the drop down menu.
▪Touch the Flight mode.
7.3 Receive a call
In an incoming call, you can choose from the following options:
▪Tap the Answer option to receive the call.
▪Tap the Decline option to reject the call.
7.4 Emergency calls
You can also make emergency calls without a SIM card. For more information, contact your network
service provider.
8. The Home screen
When you sign in, the home screen opens.
The Home screen is your starting point to access all the features on your
phone. Swipe on the screen to left or right to view all installed
applications.
8.1 Notification bar
The notification bar shows your device status and notifications.
Notification icons indicate new messages and events. When a new
notification arrives, its icon appears in the Notification Bar.
Notification Icons Status Icons

EN
10
To see more information about notifications, open the notification
panel by swiping your finger over the top of the screen.
Close the notification bar:
Drag the bottom of the notification panel to the top of the screen or
simply press the back button. The notification panel will also close
when responding to a notification.
8.2 Customize the idle screen
Press and hold your finger this empty area of the screen for reaching
the following menus:
Wallpapers:
you can add a wallpaper from the Gallery Go or the Wallpapers, which
contains a pre-installed wallpaper. Here you can select the My photos
option which opens the Files, and you can choose a picture.
Select the photo you want to set up and confirm it by pressing the Set
wallpaper at the top of the screen. You can set the selected image to the background of the Home
screen, the Background screen of the Lock screen, or both.
9. Connecting to the Internet
Your device has pre-installed browser to access websites through your mobile device. Open your
browser (Chrome) and enter the URL of the page you want to access in the address bar. You must
have a subscription to access the web pages, and you must complete the appropriate configuration
settings on your device.
9.1 Configure the Internet
Go to Settings > Network & Internet > Data usage > Tap Mobile data.
By default, your network provider sends the Access Point Name settings via SMS, or it comes
automatically with your SIM card. You may need to install these settings. After this, you can choose
from the listed access point names. If the access point names are not listed by default, please
contact your network provider for the same.
To add any operator Access point Name, go to Settings Network & Internet > Mobile network >
Advanced > Access Point Name.
9.2 Access Internet via Wi-Fi
Go to Settings > Network & Internet > Wi-Fi, then enable Wi-Fi. Next, select the Wi-Fi connection
listed under Wi-Fi networks.
10. Messages
Select Messages in the Standby screen.
10.1 Send Message
To send a new message, tap the Start chat button in the right corner of the screen.
Enter the recipient's phone number or select from the Contacts list.

EN
11
If you have selected the recipients, confirm by tapping the Send to option.
Enter the text of the message and press the send key.
To add an attachment, press the +icon on the left.
When you edit a message, the default message type is SMS. As soon as you add an attachment or
reach 10 SMS messages, the phone automatically switches to MMS.
10.2 Input methods
The device contains various input modes. In Editing mode, press and hold [,] to display Input Options
and to set the keyboard.
Writing numbers and symbols
Press the 123? button for reaching the numbers and the symbols.
For the numbers: you can also enter them with the letters containing the numbers: press and hold,
then swipe to the desired character.
For the symbols: press and hold [. ] to display the list of symbols, slide your finger to the symbol you
want to enter.
11. Multimedia
11.1 Camera
Use the camera to take photos and video clips. To open the camera, press the Camera icon in the
idle screen. To take a photo or video, press the recording icon: . To set the camera parameters,
press the Settings icon at the left corner of the top of the screen.
11.2 Photos
In the Gallery Go app, you can view pictures and videos taken with your camera, or those stored on
your SD card.
11.3 FM Radio
Connect the headset, then press the FM Radio icon in the main menu. By opening the channel list,
the machine automatically searches for and stores available stations.
FM Radio Radio on Radio off
You can move forward or backward through the channels and add the currently listened channel to
Favorites:

EN
12
12. Contacts
On the Main Menu, select the Contacts icon.
1. To create a new contact, press the New contact icon or enter your Google Account to
synchronize your contacts.
2. Fill the desired fields.
3. Save the contact.
By opening the contact, the following functions are available:
Add a contact to Favorites.
Additional options: Delete, Share, Set ringtone, Route to voicemail, Move to another
account, Block numbers, Help & feedback.
Dial the number.
Send a message to the phone number.
Make video call with Google Duo (Google-account is needed)
Edit the contact.
Additional features available on contacts:
•Search: search between contacts.
•Your info: you can add here you own contact information.
•Accounts: managing Accounts.
•Contact sync settings: changing Google synchronization settings. (This menu can be seen,
when you are signed in a Google-account)
•Display: Setting the appearing of the contacts and the theme of the application.
•Edit contacts: Settings default account for new contacts and phonetic names.
•Manage contacts: Import, export, restore contacts; undo changes and blocked numbers.

EN
13
13. Phone
From the Standby screen, open the Phone icon to dial or make call settings.
To enter the number to dial, open the dialer.
You can also choose from the following options:
Search for a contact:
Dial from Favorites.
View call logs, dialing from call logs.
Open Contacts.
To access the settings, select the options icon:
In this menu, you can find the following menus: Display options, Sounds and vibration, Quick
responses, Calls (Calls settings: Fixed Dialling Numbers, Call forwarding, Call barring, Caller ID, Call
waiting), Blocked numbers, Voicemail, Accessibility, Assisted dialling, Caller ID & spam, Nearby
places, About, terms & privacy, Advanced (Flip to silence).
14. Search
Your device uses Google search on the Ready screen. Enter the search term in the search queue and
press the search button:
15. Google Play Store
Play Store lets you download music, movies, android apps and games. Open the application from
the Standby screen:
Enter your Google Account information to use this app.

EN
14
16. More applications
16.1 Clock
You can check the date and time on the clock surface. By pressing the alarm icon, you can set a new
alarm, or turn the current alarm on or off. You can set a countdown, stopwatch, city or change the
settings of the Clock application.
16.2 E-mail
To set up an email account, go to Google app drawer > Gmail, select the type of account you want to
set up (Google, Outlook, Hotmail, and Live, Yahoo, Exchange and Office 365, Other).
Enter the email address and password, then follow the on-screen instructions.
16.3 File manager / Files
In this menu, you can view, edit, or delete data stored on your device and SD card.
17. Settings
17.1 Network & Internet
Navigate from the Standby screen or from the Main Menu to Settings. Under Network & Internet,
you can do the following:
⚫Wi-Fi
Turn on the feature to access Wi-Fi networks. The device automatically displays available networks.
Select the network you want to connect to. Enter the password if it’s necessary.
⚫Mobile network
oYou can turn on or off the mobile data or the roaming data;
oCheck the app data usage;
oChoose from the following network types: 2G only, 3G only, 3G/2G Auto;
oCheck and edit access points;
oManually search and choose a network.
⚫Data saver
To help reduce data usage, Data saver prevents some apps from sending or receiving data in the
background. An app you’re currently using can access data but may do so less frequently. This may
mean, for example, that images don’t display until you tap them.

EN
15
⚫Hotspot & tethering
You can share your device's Internet connection via USB, via Bluetooth or by setting a Wi-Fi hotspot.
⚫SIM cards
You can enable/disable SIM cards and set the preferred SIM for Mobil Data, Calls and SMS use.
⚫Airplane mode
You can turn Flight mode on or off in Menu / Settings / Network & Internet. By activating it, the
device turns off the wireless features (mobile network, Wi-Fi, Bluetooth, FM radio, GPS), but the
multimedia features (Music, Video, Games) can still be used.
⚫VPN:
Virtual private networks can be configured in this menu item.
⚫Private DNS:
Setting of Private DNS.
17.2 Connected devices
⚫Bluetooth
Your device supports Bluetooth, which allows you to send data wirelessly.
oTurn on the function.
oFrom the Available Devices list, select the device you want to exchange data with. Before
sending data, you need to pair your device with another device.
oTo pair, make sure the code on the screen matches the code of the other device.
oIf the code matches, confirm.
17.3 Apps & notifications
In this menu you can view apps installed on your device, customize their notifications and
permissions.
17.4 Battery
We get information about the battery (current charge, last full upload time, screen and device usage
since full charge), and check if there is an app which drains the battery. Here you can turn on off the
Battery saver option.
17.5 Display
You can set here the brightness level, night light, wallpaper, dark theme, screen timeout,
auto-rotate screen, font size and lock screen display.
17.6 Scheduled power on/off
Use the Schedule power on/off feature to power your device on and off at set times in order to save
power and prevent interruptions while resting.
17.7 Sound
It is possible to set the device's ringtone, volume, and other tones.

EN
16
17.8 Storage
You can check here the device and the SD-card storage.
17.9 Privacy
Here can be checked the followings: application permissions, turning on or off showing password
when the user types it, the lock screen settings, autofill, Google location history, activity controls,
ads and usage & diagnostic.
17.10 Location
You can turn on or off using Location and manage its settings.
17.11 Security
We get a general overview of the security status of your device, set different device security and
privacy rules.
⚫Screen lock
In this menu, you can set screen lock on your device to prevent unauthorized access. (None,
Swipe, Pattern, PIN, Password)
⚫SIM card lock
You can turn the PIN code on or off and change the SIM card PIN.
17.12 Accessibility
You can customize your phone using accessibility settings and apps.
17.13 Accounts
You can add a new account (corporate, personal, other) to this device in this menu item. Select the
account type from the list and follow the on-screen instructions.
17.14 Digital Wellbeing & parental controls
It can help you manage the screen time and set parental control.
17.15 Google
You can check and manage your Google accounts here.
17.16 System
This menu option allows you to perform language & input settings, adjust gestures, set date and
time, backup, do more reset methodes on the phone and check system update.
17.17 About phone
You can check information about the device, the software, the phone number (if it’s set) and
emergency information about the owner.

EN
17
18. Handling and maintenance
18.1 Battery
•The device has a rechargeable battery. When the power supply is low, charge the battery.
•Disconnect the charger from the power outlet and the appliance when not in use. Do not
allow the battery to charge for more than a week, as it may reduce the battery life.
•Extreme temperatures may also affect the battery. If the ambient temperature exceeds 40 °C,
do not charge the battery.
•Do not use a damaged battery or charger.
•Do not short-circuit the battery. For example, a metallic object such as a coin, clip or pen may
cause a short circuit.
•Do not leave the battery too hot (such as in a car in summer) or too cold (such as freezing), as
it may reduce its service life. Try to store the battery between 15 °C and 25 °C. A too cold or
too hot battery may temporarily not work, even if it is fully charged.
•Do not throw the battery in a fire. Dispose of the used battery according to local regulations
and recycle if possible.
18.2 Maintain the appliance
•Keep the appliance dry. Precipitation, mist and all other liquids can cause corrosion in the
circuit boards.
•Do not store the product in dusty places, as moving parts and electrical accessories may be
damaged.
•Do not store the device in hot places. High temperatures can shorten the life of the electrical
devices, damage the battery and melt the plastic parts.
•Do not store the device in a cold place. When the device returns to normal temperature, the
inside moisture can damage the electrical circuits.
•Open the appliance only as instructed in this manual.
•Do not drop, shake the appliance as small parts break.
•Do not use strong chemicals or solvents to clean the appliance.
•Do not paint the appliance. Paint can clog the moving parts and hinder proper operation.
•Use only approved parts, improper parts may damage the unit and may result in warranty loss.
If the product does not work properly, consult the service provided on the warranty card.
•The manufacturer is not liable for any malfunction resulting from improper use.
19. Recycling your device
The logo on the left indicates that the product should not be disposed of in household
waste. Dispose of such devices at a collection point for hazardous waste (electronic waste).

EN
18
20. Declaration of Conformity
The Blaupunkt SF 02 model complies with the essential requirements and relevant provisions of the
2014/53/EU Directive and RoHS Directive 2011/65/EU. The Declaration of Conformity is available on
our website.
Designed and Engineered by
Blaupunkt Competence Center Mobile Europe
HTM Mobile Kft.
1118 Budapest, Dayka Gábor utca 3. Hungary
Assembled in P.R.C by
ESTONEHK TECHNOLOGY LTD.
Flat/RM B 5/F Gaylord Commercial Building 114-118 Lockhart Road, Hong Kong
For more information on this product, visit our website at www.htmmobile.hu or
www.blaupunkt.com.
Google, Android and other marks are trademarks of Google LLC.
