Blaupunkt SL 01 Instruction manual

Quick User Guide
Mobile phone SL 01

Table of Contents
1. Safety instructions...............................................................................2
2. Technical Specifications ......................................................................4
3. Insert the memory card and SIM card ...............................................5
4. Switch the device on and off ..............................................................6
5. Using the Phone’s Buttons..................................................................6
6. Manage calls........................................................................................6
6.1 Make calls.................................................................................6
6.2 Disable Phone Calls (Airplane mode)......................................7
6.3 Receive a call............................................................................7
6.4 Emergency calls .......................................................................7
7. The Home screen ................................................................................7
7.1 Notification bar ........................................................................8
7.2 Application Launcher ...............................................................9
8. Handling and maintenance.............................................................. 10
9. SIM cards .......................................................................................... 11
10. Recycling your device..................................................................... 11
11. Declaration of Compliance ............................................................ 12

2
1. Safety instructions
ATTENTION: Please read this guide carefully. Failure to comply with
the safety regulations may be dangerous or illegal, and the
manufacturer can not be held liable for any malfunction resulting
from improper use.
Safe switch-on
The owner of the device is responsible for the use of the device.
Never switch the device on in areas where wireless devices are
prohibited or radio interference may be dangerous.
Road safety
Observe the local laws and regulations regarding smartphone usage
while driving. If you make a phone call while driving, observe the
following rules: Focus on driving to become aware of traffic
conditions; If the device has a hands-free function, use handsfree. If
the traffic situation requires, stop the car before you pick up the
phone.
Interference
Wireless devices may be sensitive to interference that affects
performance.
Electronic devices
To avoid demagnetisation, do not leave your device for a long time
close to electronic devices.
Use in hospitals
Hospitals and other healthcare facilities can use devices that are
particularly sensitive to RF signals. Switch off your phone if
prohibited signals are instructed to do so, or hospital staff ask for it.
Electrical medical devices
Your phone is a radio transmitter that can interfere with electronic
medical devices or implants such as hearing aids, pacemakers, insulin
pumps, and so on. operation. We recommend that you keep a
distance of at least 15 cm between the implant and the device, never
wear your phone in the breast pocket. Follow the instructions of the

3
manufacturer of the medical device. If you have a medical implant
and have any other questions about using mobile or wireless devices,
ask your doctor.
Use on the airplane
Your device supports flying mode, please use this feature on the
airplane. Follow the instructions on the airplane.
Explosion hazards and restricted areas
Turn off the device in explosion hazardous areas. Sparks in such
places may lead to an explosion or fire that may result in serious
injury or death. Turn off the devicce at gasoline or gas filling stations,
especially near the fuel pumps. Follow the instructions strictly in
locations such as fuel tanks, chemical plants, and explosive
substances.
Use environment
The device complies with the recommended emission values for
radio waves when kept at a minimum distance of 1.5 cm from the ear.
When carrying the phone in a case, belt clip or holder, make sure
that it does not contain metal and that the phone is slightly
distracted from the body. When using other accessories, it is not
possible to operate in accordance with radio frequency guidelines. If
you do not use a case and do not hold the phone on your ear, keep it
at least 2.5 cm away from your body, especially during data transfer.
Proper use
Please do not attempt to disassemble the device. If the product is
defective, contact your distributor.
Battery and other accessories
Only use parts and accessories approved by the manufacturer. Using
non-factory accessories and spare parts may result in warranty loss.
Please do not charge the device before inserting the battery. Do not
short-circuit the battery.
Charge the appliance in a well-ventilated and suitable temperature
environment away from flammable and explosive materials. Handle

4
the used battery according to local regulations and do not throw it
into household trash.
Water resistance
The appliance is not waterproof and dry. Precipitation, fog, and other
liquids can corrode electronic circuits. If moisture has reached the
phone, remove the battery and contact the dealer.
Backup
Make a backup of all the data stored on your device.
Connect to another device
Before connecting an external device, read the safety instructions in
this manual. Do not connect an incompatible device.
2. Technical Specifications
Basic Features
•AndroidTM 7.0 Nougat
•5” FWVGA display, 854x480 pixel
•2 MP front camera
•8 MP back camera
•1.3 GHz Quad Core processor
•1 GB RAM + 8 GB ROM memory
•microSD card up to 32 GB
•Dual SIM / Single SIM + SD card
•Multimedia functions
•Wi-fi
•Bluetooth
•2200 mAh battery
•GSM 900 / 1800 MHz
•WCDMA 900 / 2100 MHz
Android is a trademark of GoogleTM Inc.

5
Power Supply Features:
•Input: AC 100-240V~50/60Hz 0.25 A
•Output: DC 5.0V –1.0 A
SAR value:
•0,257 W/Kg (Head)
•0,761 W/Kg (Body)
3. Insert the memory card and SIM card
When subscribing to a service provider, they provides a SIM card to
use the network. Your SIM card has a phone number and various
services, but you can store data on it, for example. phone numbers.
The two SIM sockets allow you to connect to two types of network.
Remove the back cover and insert the SIM cards according to the
mark on the device, as shown in the illustration.
The label on the phone indicates the direction of insertion of the SD
card:
Then insert the battery and reconnect the back cover.

6
4. Switch the device on and off
Press and hold the Power button to turn on the power.
Press and hold the power button and select “Power off” from the
Options menu.
5. Using the Phone’s Buttons
Button
Description
Menu: Opens the related menu with
additional options and actions, depending on
the application. Press and hold to open a list
of recent applications.
Home: returns to Home screen.
Back: returns to the previous screen you were
working in
6. Manage calls
6.1 Make calls
•Tap the icon on main menu or the home screen to dial the
desired number.
•Touch the icon on main menu or the home screen to
make a call from contact, groups or favorites.
•To dial an international number, touch and hold the 0 key to
enter the Plus (+) symbol, and then enter the international
country prefix, followed by the phone number
•Touch the icon to call with SIM 1 or SIM 2.

7
•Press the Volume Up/ Down keys to adjust the call volume.
•You can access Call Logs, Contacts from the dialer screen.
•While during a call, touch the icon to end a call.
6.2 Disable Phone Calls (Airplane mode)
Some locations like airplanes may require you to turn off your mobile,
Wi-Fi, and Bluetooth wireless connections.
•Press and hold the Power button.
•Touch the Airplane mode.
6.3 Receive a call
In an incoming call, you can choose from the following options:
•Drag the phone icon to the right to receive the call.
•Drag the phone icon to the left to reject the call.
•Drag the phone icon upwards to reject with SMS.
6.4 Emergency calls
You can also make emergency calls without a SIM card. For more
information, contact your network service provider.
7. The Home screen
When you sign in, the home screen
opens.
The Home screen is your starting point
to access all the features on your phone.
Touch the main menu icon at the
bottom of the screen to view all
installed applications.
The status bar shows the time,
signal strength, battery
satus and notification
Touch and hold an empty
spot to change wallpaper.

8
7.1 Notification bar
The notification bar shows your device status and notifications.
Notification icons indicate new messages and events. When a new
notification arrives, its icon appears in the Notification Bar.
Notification Icons Status Icons
To see more information about notifications, open the notification
panel by swiping your finger over the top of the screen.
Status icons:
Icon
Description
Icon
Description
Signal strength
indicator
Alarm has
been set
New missed calls
Wi-Fi is
activated
USB is connected
Bluetooth is
on
The headphone is
being used
Battery
charging
symbol
New message from
SIM 1
Airplane mode
is activated

9
Close the notification bar:
Drag the bottom of the notification panel to the top of the screen or
simply press the back button. The notification panel will also close
when responding to a notification.
7.2 Application Launcher
Press the Launcher icon to enter the
Main Menu. From here you can access all
installed applications and widgets.
Touch the app to start.
To add an application shortcut to the
desktop screen, press and hold it until it
vibrates and enters Home screen. Place it
and release your finger.
Slide the Launcher left or right to bring
more icons into view.
As soon as you install a new application, it comes in this list.
To access widgets, press the menu button
on the Home screen, then tap the widget
icon at the bottom of the screen. Widgets
can not be started as an application.
Press and hold the selected widget until it
vibrates and the Home screen open. Place
and release your finger from the screen.
The app may request further action to
activate the widget.
You can configure the widget in the
submenu, for example, size. The options
displayed, depend on the given widget. If
there is not enough space on the Home

10
screen, the widget will not be added.
To close the launcher, press the Home button or the Back button.
8. Handling and maintenance
Battery
The device has a rechargeable battery. When the power supply is low,
charge the battery.
Disconnect the charger from the power outlet and the appliance
when not in use. Do not allow the battery to charge for more than a
week, as it may reduce the battery life.
Extreme temperatures may also affect the battery. If the ambient
temperature exceeds 40 ° C, do not charge the battery.
Do not use a damaged battery or charger.
Do not short-circuit the battery. For example, a metallic object such
as a coin, clip or pen may cause a short circuit.
Do not leave the battery too hot (such as in a car in summer) or too
cold (such as freezing), as it may reduce its service life. Try to store
the battery between 15 ° C and 25 ° C. A too cold or too hot battery
may temporarily not work, even if it is fully charged.
Do not throw the battery in a fire. Dispose of the used battery
according to local regulations and recycle if possible.
Maintain the appliance
Keep the appliance dry. Precipitation, mist and all other liquids can
cause corrosion in the circuit boards. If it is still wet, remove the
battery. Do not put it back until the product is completely dry.
Do not store the product in dusty places, as moving parts and
electrical accessories may be damaged.
Do not store the device in hot places. High temperatures can shorten
the life of the electrical devices, damage the battery and melt the
plastic parts.

11
Do not store the device in a cold place. When the device returns to
normal temperature, the inside moisture can damage the electrical
circuits.
Open the appliance only as instructed in this manual.
Do not drop, shake the appliance as small parts break.
Do not use strong chemicals or solvents to clean the appliance.
Do not paint the appliance. Paint can clog the moving parts and
hinder proper operation.
Use only approved parts, improper parts may damage the unit and
may result in warranty loss. If the product does not work properly,
consult the service provided on the warranty card.
The manufacturer is not liable for any malfunction resulting from
improper use.
9. SIM cards
From the Menu / Settings / SIM Cards menu, you can choose a
preferred SIM card for the following:
•Mobile Data Connection
•Calls
•SMS messages
In this menu you can also deactivate any of the cards.
10. Recycling your device
The logo on the left indicates that the product should
not be disposed of in household garbage. Dispose of
such devices at a collection point for hazardous waste
(electronic waste).

12
11. Declaration of Compliance
The Blaupunkt SL 01 model complies with the essential requirements
and relevant provisions of the 2014/53 / EU Directive and RoHS
Directive 2011/65 / EU.
To view the Declaration of Compliance, please contact us at the
following e-mail address: [email protected]
Import: HTM Mobile Ltd. Address: 1118. Budapest, Dayka Gábor
street 3.
For more information on this product, visit our website at
www.htmmobile.hu or www.blaupunkt.com.
Google, Android, and Google Play, is a trademark of GoogleTM Inc.

Erste Schritte
Mobiltelefon SL 01

Inhaltsverzeichnis
1. Sicherheitsvorschriften .......................................................................2
2. Beschreibung des Geräts....................................................................3
2.1 Technische Spezifikationen..........................................................3
2.2 Technische Daten .........................................................................4
3. Speicherkarte und SIM -Karte einlegen .............................................4
4. Ein- und Ausschalten des Geräts........................................................5
5. Tastatur des Geräts .............................................................................5
6. Anrufe ..................................................................................................6
6.1 Anruf tätigen.................................................................................6
6.2 Anruf annehmen ..........................................................................6
6.3 Notrufe..........................................................................................6
7. Startbildschirm ....................................................................................7
7.1 Statusleiste ...................................................................................7
7.2 Anwendungssymbole...................................................................8
8. SIM Karten ...........................................................................................9
9. Pflege und Wartung ............................................................................9
10. Recycling Ihres Geräts.................................................................... 10
11. Konformitätserklärung................................................................... 10

2
1. Sicherheitsvorschriften
Bitte lesen Sie die Sicherheitsanweisungen sorgfältig durch, da das
Ignorieren gefährlich oder illegal sein kann.
Der Besitzer des Geräts ist für die Verwendung dieses Geräts
verantwortlich.
Sperrgebiete
Schalten Sie das Gerät aus, wenn die Verwendung eines
Mobiltelefons nicht autorisiert ist oder Störungen oder Gefahren
verursachen kann, z. B. in Flugzeugen, Krankenhäusern oder
medizinischen Geräten, Kraftstoffen, Chemikalien oder
Sprenggebieten. Beachten Sie die Anweisungen in eingeschränkten
Bereichen.
Verkehrssicherheit
Beachten Sie die örtlichen Gesetze und Vorschriften. Verwenden Sie
das Telefon nicht während der Fahrt, erste Verkehrssicherheit.
Interferenz
Alle drahtlosen Geräte sind möglicherweise anfällig für Störungen,
die die Leistung beeinträchtigen können.
Qualifizierter Service
Das Produkt kann nur von einer qualifizierten Person repariert
werden.
Ladegerät, Batterie und anderes Zubehör
Verwenden Sie nur eine vom Hersteller zugelassene Batterie,
Ladegerät und anderes Zubehör. Verbinden Sie keine inkompatiblen
Produkte.
Wasserbeständigkeit
Das Gerät ist nicht wasserdicht, also halten Sie es trocken.

3
Gehörschutz
Um Hörschäden zu vermeiden, sollten Sie bei hoher Lautstärke nicht
lange Musik oder Radio hören.
Verwenden Sie die Umgebung
Das Gerät entspricht den empfohlenen Emissionswerten für
Radiowellen, wenn es mindestens 1,5 cm von der Mündung entfernt
gehalten wird. Wenn Sie das Telefon in einem Etui, Gürtelclip oder
Halter tragen, stellen Sie sicher, dass es kein Metall enthält und dass
das Telefon leicht vom Körper abgelenkt ist. Bei Verwendung anderer
Zubehörteile ist es nicht möglich, mit Funkfrequenzrichtlinien zu
arbeiten. Wenn Sie keinen Koffer benutzen und das Telefon nicht an
Ihrem Ohr halten, halten Sie es mindestens 2,5 cm von Ihrem Körper
entfernt, insbesondere während der Datenübertragung.
2. Beschreibung des Geräts
2.1 Technische Spezifikationen
•AndroidTM 7.0 Nougat
•5” HD IPS Bildschirm, 854x 480 Pixel
•2 MP Kamera vorne
•8 MP Kamera hinten
•1.3 GHz Quad Core Prozessor
•1 GB RAM + 8 GB ROM zum Speichern
•durch microSD Karte erweitbar bis 32 GB
•Zwei SIM Steckplätze, 1 SIM Steckplatz + SD Karte
•Multimedia Funktionen
•Wifi
•Bluetooth

4
•2200 mAh Akkumulator
•GSM 900 / 1800 MHz
•WCDMA 900 / 2100 MHz
Android is a trademark of GoogleTM Inc.
2.2 Technische Daten
Netzteil:
•Eingang: AC 100-240V~50/60Hz 0.25 A
•Ausgang: DC 5.0V –1.0 A
Akkumulator und Spannung: 2200 mAh
SAR Werte:
•0,257 W/Kg (Kopf)
•0,761 W/Kg (Körper)
3. Speicherkarte und SIM -Karte einlegen
Mit den zwei SIM-Sockeln können Sie sich mit zwei Arten von
Netzwerken verbinden. Entfernen Sie die hintere Abdeckung und
legen Sie die SIM-Karten entsprechend der Markierung auf dem
Gerät wie folgt ein:
Das Etikett auf dem Telefon zeigt die Einsetzrichtung der SD-Karte an

5
Setzen Sie dann die Batterie ein und befestigen Sie die hintere
Abdeckung wieder.
4. Ein- und Ausschalten des Geräts
Drücken Sie die Ein-Austaste –auf der Seite des Geräts –zum
Einschalten des Geräts.
Drücken Sie lang die Ein-Austaste, dann wählen Sie die Option
Ausschalten.
5. Tastatur des Geräts
Taste
Bedeutung
Menü: das anknüpfende Menü mit weiteren Optionen
und Operationen wird geöffnet, der Inhalt hängt von
der bestimmten Applikation ab. Lang gedrückt wird die
Liste der letzten Applikationen geöffnet.
Homescreen: es geht zurück zum Homescreen. Lang
gedrückt wird Google Assistant geöffnet.
Zurück: zurück zum vorigen Bildschirm, der geöffnet
war.

6
6. Anrufe
6.1 Anruf tätigen
➢Berühren Sie im Hauptmenü das Symbol oder auf dem
Homescreen zum Wählen der gewünschten Rufnummer.
➢Berühren Sie im Hauptmenü oder auf dem Homescreen das
Symbol zum Wählen von den Partnern, Gruppen oder
Lieblings.
➢Die Lautstärke kann man auf der Seite des Geräts mit der Taste
auf/ab regeln.
➢Beim Wählen kann man die Anrufliste und Partner öffnen.
➢Während dem Anruf berühren Sie zum Abbrechen des
Anrufs.
6.2 Anruf annehmen
Bei einem eingehenden Anruf haben Sie folgende Möglichkeiten:
▪Ziehen Sie das Symbol nach rechts zum Annehmen.
▪Ziehen Sie das Symbol nach links zum Ablehnen.
▪Ziehen Sie das Symbol nach oben zum Ablehnen durch SMS.
6.3 Notrufe
Notrufe können Sie auch ohne SIM –Karte tätigen. Für weitere
Information kontaktieren Sie bitte den Netzwerkanbieter.
