Blaupunkt IVTV-01 Specification sheet

In Car Video
IVTV-01
Bedienungs- und Einbauanleitung
Operating and installation instructions
Notice d’emploi et de montage
Istruzioni d’uso e di installazione
Gebruiksaanwijzing en inbouwhandleiding
Bruks- och monteringsanvisning
Instrucciones de manejo e instalación
Instruções de serviço e de montagem
Betjenings- og monteringsvejledning
http://www.blaupunkt.com

14
CONTENTS
Safety notices ........................ 15
Notes on installation and
operation ................................ 16
Tuner connection ........................... 16
Remote control .............................. 18
Functions ............................... 19
Switching on the TV tuner ............. 19
Switching off the TV tuner ............. 19
Selecting TV/CATV/AV1/
AV2 mode ..................................... 19
Programming the
TV/CATV channel .......................... 20
Detecting the input signal .............. 20
Channel selection .......................... 20
AV output ...................................... 21
Connection options ....................... 21
Installation.............................. 22
Diversity antenna system ............... 22
Safety circuit ................................. 24
Accessories............................ 25
Specifications ........................ 25

15
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
Thank you for choosing a Blaupunkt
product. We hope you enjoy using this
new piece of equipment.
Please read these operating instruc-
tionsbeforeusingtheequipmentfor
the first time.
The Blaupunkt editors are constantly
working on making the operating in-
structions clearer and easier to under-
stand. However, if you still have any
questions on how to operate the equip-
ment, please contact your dealer or the
telephone hotline for your country. You
will find the telephone numbers printed
at the back of this booklet.
We provide a manufacturer guarantee
for our products bought within the Eu-
ropean Union. You can view the guar-
antee conditions at www.blaupunkt.de
or ask for them directly at:
Blaupunkt GmbH
Hotline
Robert-Bosch-Str. 200
D-31139 Hildesheim
SAFETY NOTICES
Safety notices
Please observe the following safety
noticesduringinstallationandwhilst
making the connections.
-Disconnect the negative and positi-
ve terminals of the battery.
-When doing so, please observe the
safetynoticesprovidedbythevehicle
manufacturer.
-Before drilling the holes necessary
for mounting the equipment and for
layingcables,pleasemakesurethat
concealed cables, the fuel tank and
fuel lines cannot be damaged in the
process!

16
NOTES ON INSTALLATION AND OPERATION
Notes on installation and
operation
Tuner connection
-The tuner must first be installed in a
suitable location. You must make
surethat thedevice isfixed securely
in place and that it is not subjected
to moisture or dirt. You must not lay
the connecting cables in a way that
could cause the vehicle passengers
togetinadvertentlycaughtupinthem
and rip them out.
-Please note that the tuner must not
bepositionednearheatsources(e.g.
heating, direct sunlight) since this
could result in faulty behaviour as a
result of excess temperature.
-Connect all of the tuner’s audio,
videoandpowersupplyconnections
(see connection diagram in the
following picture) that you need for
your system installation. When
positioningtheinfraredsensor,make
sure there are no objects positioned
between the sensor and the place
whereyouusuallykeepyourremote
control, since they could interfere
with the transmission of the infrared
signal.
Note:
The following diagram shows all of the
tuner’s connection options. Your car
system’s connections do not necessar-
ily have to be exactly the same as this.

17
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
SAFETY
EXTERNAL
ANT. IN AV2 AV1
LRVIDEOLRVIDEO
ANT.1 ANT.2 ANT.3 ANT.4
EXT.IR
VIDEO R L
AV OUT
1
23
4
Video output
Audio output (R)
Audio output (L)
To the SAFETY
CIRCUIT (refer to the
notes on correct and
safe system operation,
page 24)
4 cables:
1. Ground/GND
2. N.C.
3. + 12V permanent
4. + 12V
A/V SOURCE 1
(VIDEO GAMES CONSOLE,
VCR or DVD PLAYER)
A/V SOURCE 2
(VIDEO GAMES CONSOLE,
VCR or DVD PLAYER)
IR sensor for the
remote control option
LEFT
DIVERSITY ANTENNA
RIGHT
DIVERSITY ANTENNA
NOTES ON INSTALLATION AND OPERATION
Tuner connection

18
NOTES ON INSTALLATION AND OPERATION
MUTE
Pressing this button switches off
the sound of the monitor system.
MON ON/OFF
For switching on the monitor.
AV/TV
You can use this switch to
select the available video
and audio inputs and/or TV
channels.
Group of TV related
buttons.
Auto Program
Pressing this button
causes the tuner to scan
and store all the available
stations.
UP/DOWN
For selecting items in the
OSD menu.
Channel selection
buttons
If you press one of
these buttons, the tuner
changes TV channels.
TV ON/OFF
For switching on the
television. -/+
Volume control for the
monitor loudspeaker.
Remote control
MENU MUTE
ADJUST
TV ON/OFF
RC-MOTV
MENU
MON ON/OFF
TV/AV
PROG
CHAN

19
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
FUNCTIONS
Functions
The supplied remote control is suitable
for operating the TV tuner IVTV-01 as
well as the ceiling mounted monitor
IVMR-7001.
The area on the remote control that is
surrounded by a border contains
controls that apply to the TV tuner.
Switching on the TV tuner
To switch on the TV tuner, press the TV
ON/OFF button.
Switching off the TV tuner
To switch off the TV tuner, press theTV
ON/OFF button again.
Selecting TV/CATV/AV1/AV2
mode
You canuse theTV/AV buttonto switch
between the channel/input options TV,
CATV, AV1 and AV2.
Input source Description
AV1 External audio/video input 1
AV2 External audio/video input 2
System TV Cable TV (CATV)
PAL/BG Cable TV channels 2 ~ 69 Cable TV channels 1 ~ 57

20
FUNCTIONS
Programming the TV/CATV
channel
You can use the PROG button to store
the channels that you want for CATV or
fortheVHF/UHFrange.Ifyoupressthe
PROGbutton,thetunerstartssearching
forchannels andstores allthereceived
channels. The “AUTO” status is
indicatedinthebottomleftofthemonitor
whilst automatic programming is being
carried out.
The system stores TV and CATV
channelsindifferentmemorylocations.
This function is only available in TV or
CATV operating modes.
Note:
If you want to cancel automatic pro-
gramming,presstheCHANNELbutton.
Generally, however, you should NOT
interruptautomaticprogrammingorelse
not all of the channels can be stored.
Detecting the input signal
Thetunersystemautomaticallydetects
whether a signal is being received and/
or whether a signal can be received in
everysignalinputmodeornot.Ifitdoes
not detect a signal, the “No Signal” sta-
tusisindicated.If asignalisreceived,a
corresponding display appears imme-
diately.
Channel selection
You can select the channel you require
using the two and CHANNEL but-
tons. If the channels were stored using
theautomaticprogrammingfeature,you
can switch between the programmed
channels using these buttons. If you
keep one of the buttons pressed down,
youcanmovethroughtheprogrammed
channels one by one.

21
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
AV output
Thisconnectionoptionisusedforsend-
ing the audio signal directly to the car
sound system. In order to use this op-
tion, the car sound system must be
equipped with anAUX input. The video
output is used to connect additional
video screens and it only outputs the
video signal.
Connection options
FUNCTIONS
IVSC
AV output
IVTV
01
Monitor
Monitor
Audio R/L
Cable adapter 7 607 001 603
IVTV
01 IVMR
7001
RCA-Y adapter
7 607 001 507
Radio
or
amplifier
RCA / ISO (10 pin)
7 607 001 508
RCA / ISO-C3 (8 pin)
7 607 001 509

22
Installation
Diversity antenna system
The Diversity antenna system that is integrated in the tuner has been specially
developed for mobile applications and ensures optimum signal reception.
a. Installation
Remove the protective covering from the antenna foot and secure the adhe-
sive foot to the required position (the surface to which it is stuck must be free
from dust and grease).
b. Adjusting the angle
In order to achieve optimum reception quality, adjust the position of the an-
tennasothat (ifpossible)one rodisaligned horizontallyandone rodvertically.
c. Installation notes
-Installation on the rear window
INSTALLATION
-Installation on the windscreen

23
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
-Installation on the side window
INSTALLATION
Tuner Box
ANT.1ANT.2ANT.3ANT.4
-Antenna attachment
-Connection of the antenna to the tuner box
The supplied adhesive strips for
the antenna achieve optimum
adhesion after approx. 24 hours.
You must not re-use adhesive
stripsonceyouremovethemfrom
the window. If you want to re-in-
stalltheantenna,youcanusethe
supplied replacement adhesive
strip,whichcanbecuttosizewith
scissors.

24
TV/AV selection Function of the safety circuit
Vehicle is moving Vehicle is stationary
TV IN Monitor off Monitor on
AV IN Monitor off Monitor on
INSTALLATION
Safety circuit
Thetunermodulehasbeen fittedwith asafetycircuit toensure safeTVoperation.
The supplied accessory components include a special safety cable. If the safety
system is installed correctly, you can only activate TV operating mode if the
vehicle handbrake is on.The schematic diagrams below provide information on
howto install the system. Ifyou require additional assistance,please contact your
dealer.
Handbrake
Battery (-)
Hand-
brake (+)
Tuner
Safety cable
Safety
Parking lamp
Tuner
Safety cable
Safety

25
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKAESPAÑOL
PORTUGUÊS
DANSK
ACCESSORIES AND SPECIFICATIONS
IR cable
AV cable
Electrical cable
Safety cable
Remote control with battery
Operating instructions
Subject to changes!
1
AV input 2 xAV RCA
AV output 1 xAV RCA
TV channels see page 19
Dimensions (W x H x D) 182 x 27.4 x 134 mm
Weight 640 g
Supported system PAL/BG
Visible-type fuse 3 amps
Operating temperature 0°C to +60°C
Storing temperature -20°C to +70°C
Operating voltage 10 V to 16 V
Current consumption approx. 1A (TV mode), 0.76 AAV mode
Quiescent current consumption < 1 mA
Video input/output impedance 75 ohms
Audio input/output impedance 620 ohms
Video in/out amplification 0 dB / 75 ohms
Audio in/out amplification 0 dB / without load
Specifications
Accessories

05/03 CM/PSS 8 622 403 179
Blaupunkt GmbH
Service-Nummern / Service numbers / Numéros du service après-
vente / Numeri del servizio di assistenza / Servicenummers /
Telefonnummer för service / Números de servicio / Números de
serviço / Servicenumre
Country: Phone: Fax: WWW:
Germany (D) 0180-5000225 05121-49 4002 http://www.blaupunkt.com
Austria (A) 01-610 390 01-610 393 91
Belgium (B) 02-525 5454 02-525 5263
Denmark (DK) 44 898 360 44-898 644
Finland (FIN) 09-435 991 09-435 99236
France (F) 01-4010 7007 01-4010 7320
Great Britain (GB) 01-89583 8880 01-89583 8394
Greece (GR) 210 57 85 350 210 57 69 473
Ireland (IRL) 01-4149400 01-4598830
Italy (I) 02-369 6331 02-369 6464
Luxembourg (L) 40 4078 40 2085
Netherlands (NL) 023-565 6348 023-565 6331
Norway (N) 66-817 000 66-817 157
Portugal (P) 01-2185 00144 01-2185 11111
Spain (E) 902-120234 916-467952
Sweden (S) 08-7501500 08-7501810
Switzerland (CH) 01-8471644 01-8471650
Czech. Rep. (CZ) 02-6130 0441 02-6130 0514
Hungary (H) 01-333 9575 01-324 8756
Poland (PL) 0800-118922 022-8771260
Turkey (TR) 0212-3350677 0212-3460040
USA (USA) 800-2662528 708-6817188
Brasil
(Mercosur) (BR) [phone] [phone]
Malaysia
(Asia Pacific) (MAL) [phone] [phone]
