Blodgett ZEPHAIRE-G Application guide

ZEPHAIRE G
MECHANICAL & SOLID STATE CONTROLS
GAS CONVECTION OVENS
REPLACEMENT PARTS LIST
EFFECTIVE JULY 26, 2007
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items specified are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
www.blodgett.com
BLODGETT OVEN COMPANY, 44 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: [phone] [phone] Fax: [phone]
www.blodgett.com

ZEPHAIRE G
JULY 26, 2007
;ASAP Distributor Required Stocking Parts
Doors Are Not Returnable
* Item Is Too Large For UPS
IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven. The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge.
2
ELECTRICAL COMPONENTS
(SOLID STATE CONTROLS)
(AFTER 07/12/93)
Ref. Part
No. No. Description
8 32232 Motor, 115V, 1 PH, 1/3 HP, 1 SP
32291 Motor, 115V, 1 PH, 1/3 HP, 2 SP
23077 Capacitor, Motor 2 SP
20362 Conduit Assy., Motor 1 SP
20065 Conduit Assy., Motor 2 SP
1 20349 Buzzer, 120V
9 18225 Timer, 60 Minute, 120V, 60 HZ
6 16686 Knob, Timer
33152 Temperature Controller w/ Potentiometer
13 18588 Probe, Temperature
16686 Knob, Thermostat
3 20355 Transformer, 115V to 24V
10 20348 Spark Box Assy, LP & Nat (G770MGC-Blue)
7 21134 Axial Fan, Low Velocity, 115 V, 60HZ (Qty 2)
14 35702 Microswitch Kit (Replaces 19978)
35419 Bracket Assy., Microswitch
(Replaces 21081)
5091 Cord Set Assy
4 6502 Cool Down Switch, Rocker DPDT Red
4 6500 Blower Switch, Rocker DPST Blue 1 SP
7636 Blower Switch, Rocker 3PDT Black 2 SP
4 6497 Light Switch, Rocker SPST Matte Black
2 18265 Indicator Light, 28V, Red, Round
4342 Lamp
4922 Socket, Lamp
15891 Tube Assy, for lamp
ELECTRICAL COMPONENTS
(MECHANICAL CONTROLS)
(PRIOR TO 07/12/93)
Ref. Part
No. No. Description
8 32232 Motor, 115V, 1 PH, 1/3 HP, 1 SP
8 32291 Motor, 115V, 1 PH, 1/3 HP, 2 SP
20362 Conduit Assy., Motor 1 SP
20349 Buzzer, 120V
19 5147 Timer, 60 Minute Mechnical, w/bell
15956 Timer, for Buzzer
16030 Knob, Timer
23 16536 Thermostat, KX-234-36
16393 Dial, Thermostat
21082 Bracket Assy., Thermostat
20195 Gauge, Spark Gap
35702 Microswitch Kit (Replaces 19978)
35419 Bracket Assy., Microswitch
(Replaces 21081)
5091 Cord Set Assembly
6502 Cool Down Switch, Rocker DPDT Red
6500 Blower Switch, Rocker DPST Blue
6497 Light Switch, Rocker SPST White
15673 Indicator Light, 125V, Red, Round
4342 Lamp
4922 Socket, Lamp
15891 Tube Assy, for lamp
20361 Wiring Harness, 115V, 1 SP
21593 Wiring Harness, 115V, 2SP

3 ZEPHAIRE G
MECHANICAL CONTROLS
5147
Timer, 60
Min. Mech
19 18265
Indicator
Light
2
6502
6500
M5132
Rocker
Switch
435702
Microswitch
14
32232
32291
Motor
8
21080
Spark
Module,
White
19
21069
Thermal
Switch
15
12
21071
21072
Pilot Assy
20
21100
Striker
Plate
17 21098
Roller
Catch
Assy
16
15853
Blower
Wheel
18
23
16536
Thermostat, Mech
30218
30219
Dual Solenoid/
Press. Reg.

SOLID STATE CONTROLS
20349
Buzzer
1
18265
Indicator
Light
2
20355
Transformer
3
6502
6500
M5132
Rocker
Switch
4
16686
Knob
6
21134
Axial Fan
7
32232
32291
Motor
8
18225
Timer
9
20348
Spark
Box, Blue
10
18584
18585
Pilot Burner
Assy, Complete
11 18588
Probe
13
35702
Microswitch
14
521098
Roller Catch
Assy
16
21100
Striker Plate
17
15853
Blower
Wheel
18
4 ZEPHAIRE G
30005 NAT
30006 LP
Dual
Solenoid/
Pressure
Reg.

BURNER & PIPING ASSEMBLY
(SOLID STATE CONTROLS)
Ref. Part
No. No. Description
18799 Steel Tube Burner Assy. (Set of 2)
8717 Orifice, Main Burner (Specify Model & Gas
Type) (Set of 2)
90063 Air Shutter Only
3001 Locknut, Air Shutter
15871 Manifold Assy.
21070 Tubing, Manifold Assy.
4872 Manifold Plug
15963 Coupling, Reducer 3/4" to 1/2"
11 18584 Pilot Burner Assy., Complete Nat
11 18585 Pilot Burner Assy., Complete LP
18263 Orifice, Pilot Burner, Nat
18257 Orifice, Pilot Burner, LP
18586 Pilot Tubing Assy.
5 30005 Dual Solenoid/Pressure Reg, Nat 24V
5 30006 Dual Solenoid/Pressure Reg, LP 24V
30514 Conv. Kit, LP to Nat (Johnson Control
Ignition & Honeywell Valve)
30399 Conv. Kit, Nat to LP (Johnson Control
Ignition & Honeywell Valve)
21079 Air Duct Assy. (Set of 2)
17364 Deflector Assy.
18256 Flame Sensor Probe
19677 Wire, Flame Sensor
INTERIOR COMPONENTS
Ref. Part
No. No. Description
20864 Liner Baffle, Stainless Steel
20758 Liner Baffle, Porcelain
21085 Liner Bottom, Aluminized
21560 Liner Bottom, Porcelain
18 15853 Blower Wheel Assy. 10 3/4"
20376 Collector Assy., Heat Lower
20353 Clip, Thermostat Bulb
20246 Rack, Oven (27-7/8" x 28-3/16")
21422 Rack Support (Set of 2)
21086 Rack Stop (Set of 2)
8646 Support Assy., Baffle (Set of 4)
90027 Motor Mount & Panel Assy.
19640 Baffle Screen Assy.
BURNER & PIPING ASSEMBLY
(MECHANICAL CONTROLS)
Ref. Part
No. No. Description
18799 Steel Tube Burner Assy. (Set of 2)
8717 Orifice, Main Burner (Specify Model & Gas
Type) (Set of 2)
90063 Air Shutter Only
3001 Locknut, Air Shutter
15871 Manifold Assy.
21070 Tubing, Manifold Assy.
4872 Manifold Plug
15963 Coupling, Reducer 3/4" to 1/2"
19 21080 Spark Module Assy (White)
15 21069 Switch, Thermal SPDT
21076 Thermal Switch Bracket
20 21071 Pilot Burner Assy., Nat
20 21072 Pilot Burner Assy., LP
20589 Orifice, Pilot Burner, Nat
20193 Orifice, Pilot Burner, LP
18586 Pilot Tubing Assy.
21075 Bracket Assy., Pilot, Nat
12 30218 Dual Solenoid/Pressure Reg, Nat. 120V
12 30219 Dual Solenoid/Pressure Reg, LP 120V
21084 Conv. Kit, LP to Nat (Before 7/12/93)
(Robert Shaw Ignition & Johnson Gas Valve)
21083 Conv. Kit, Nat to LP (Before 7/12/93)
(Robert Shaw Ignition & Johnson Gas Valve)
30402 Conv. Kit, LP to Nat (7/12/93 thru 9/29/93)
(Robert Shaw Ignition & Honeywell Valve)
30398 Conv. Kit, Nat to LP (7/12/93 thru 9/29/93)
(Robert Shaw Ignition & Honeywell Valve)
20373 Thru Pipe Assy.
21078 Secondary Air Duct Assy.
21079 Air Duct Assy. (Set of 2)
17861 Deflector Assy.
5 ZEPHAIRE G

DEPENDENT DOOR COMPONENTS
(1 DOOR HANDLE, WITH LOWER DOOR SUPPORT)
Ref. Part
No. No. Description
20806 Door Assy, Solid LH
20805 Door Assy, Solid RH
20804 Door Assy, Glass LH
20803 Door Assy, Glass RH
35580 Door Conversion Kit, Independent to
Dependent, Glass
35579 Door Conversion Kit, Independent to
Dependent, Solid
9036 Window Assy, Drop In (10-1/8" x 17-1/8")
17558 Handle, Porcelain Door
18081 Top Plate, Door Handle
4887 Chain & Turnbuckles, Door Operating
90074 Sprocket Assy
90017 Washers, Door (Set of 2)
90004 Bushings, Door Hinge (Set of 2)
16657 Sleeve, Upper Door Bushing
17557 Hinge Pin, Upper Door
14 35702 Microswitch Kit (Replaces 19978)
35419 Bracket Assy, Microswitch (Replaces 21081)
90077 Cam Assy, Door Switch
17311 Trim, Center Door
16448 Pressure Lock
17519 Gasket Assy., Perimeter (Before 12/01/2005)
36876 Gasket Assy., Perimeter (After 12/01/2005)
20359 Arm Assy, LH Door
90076 Arm Assy, RH Door
20659 Support Assy, Lower Door
INDEPENDENT DOOR COMPONENTS
(2 DOOR HANDLES, NO LOWER DOOR SUPPORT)
Ref. Part
No. No. Description
21090 Door Assy, Solid LH
21091 Door Assy, Solid RH
21557 Door Assy, Glass LH
21558 Door Assy, Glass RH
35580 Door Conversion Kit, Independent to
Dependent, Glass
35579 Door Conversion Kit, Independent to
Dependent, Solid
NOTE: Lower door pins no longer come with the
door assemblies. The pins must be
ordered separately.
9036 Glass Assy (10-1/8" x 17-1/8")
21097 Door Handle Assy
21099 Handle Bracket, Bottom
16 21098 Catch Assy, Roller (On Top of Door)
17 21100 Striker Plate (On Oven)
17519 Gasket, Perimeter Door
23120 Gasket, Center Door (3 Piece)
21092 Door Stop Bushing w/ Pin
21093 Door Stop Bracket & Nut Assy.
16657 Upper Bushing Sleeve
15932 Bearing, Flanged
21094 Door Pin, Upper Assy
21095 Door Pin, Lower Assy (Before 12/02/93)
30654 Door Pin, Lower Assy (After 12/02/93)
21096 Door Pins, Upper & Lower (Set of 4)
(Before 12/02/93)
30653 Door Pins, Upper & Lower (Set of 4)
(After 12/02/93)
30655 Bearing, Door Hinge (Set of 2)
(After 12/02/93)
90053 Door Switch Cam Assy (Before 12/02/93)
30652 Door Switch Cam Assy (After 12/02/93)
36307 Support Assy w/Microswitch, Lower Door
6 ZEPHAIRE G

BLODGETT OVEN COMPANY, 44 Lakeside Avenue, Burlington, Vermont 05401 USA
Telephone: [phone] [phone] Fax: [phone]
A division of G.S. Blodgett Corporation
7 ZEPHAIRE G
ROLL-IN UNITS
Ref. Part
No. No. Description
20517 Docking Plate Assy.
8355 Docking Pins, Transport Cart
8356 5" Casters, Transport Cart
9052 Handle, Transport Cart (Sgl Oven)
8359 Catch Mechanism, Transport Cart
8357 Locking Bar, Transport Cart
8358 Tracks & Shelf Assy., Transport Cart
9015 Handle, Transport Cart (Dbl Oven)
7931 Vertical Posts (Each)
6902 Track, LH
6903 Track, RH
21089 Rack Stop, S/S
7689 Transport Cart, CTRG
8626 Transport Cart, CTRG-2
7365 Roll-In Basket Dolly, DBRI-L
11206 Roll-In Pan Rack, RPR-L9 (w/ 5 Racks)
7590 Racks for Pan Rack, L9 (26" x 26")
EXCLUSIVE TO EXPORT
Ref. Part
No. No. Description
21430 Axial Fan, 3", 230V Qty 2 per oven CE
32648 Harness, Wiring CE
33094 Block, Terminal 4 Pole CE
32529 Thru Pipe Assy. CE
34906 Manifold Assy (w/pressure tap) CE
34974 Conversion Kit, Air Pressure Differential
Switch (Replaces M3330) CE
Before 03/26/99 or S.N. 032699YA019S
M9422 Air Pressure Differential Switch, switch only
CE
M9705 Polyurethane Tubing (Per Foot, Total 3 FT)
used w/pressure switch CE
M6449 Noise Filter
M3172 Timer, Fixed, 2 Second
16539 Indicator Light, 250V, Amber, Round
30517 Switch, Rocker DPST, Black
36066 Thermostat, High Limit Kit (Manual Reset) CE
Replaces M3295
16037 Indicator Light, 250V, Red, Round
M9182 Dual Solenoid/Pres Reg, 240V
20084 Timer, 60 Min.
34748 Control Panel & Decal, w/Lights CE
31023 Control Panel & Decal w/o Lights (S.S.)
31024 Control Panel & Decal w/Lights (S.S.)
34744 Control Panel & Decal
w/Lights & w/Steam (S.S)
34746 Control Panel & Decal
w/o Lights & w/Steam (S.S)
34747 Control Panel & Decal w/o Lights (S.S)
34530 Pilot Burner & Ignitor Assy, Nat CE
34531 Pilot Burner & Ignitor Assy, LP/But CE
EXTERIOR COMPONENTS
Ref. Part
No. No. Description
20333 Crown Assy. (Before 12/02/93)
23190 Crown Assy. (After 12/02/93)
21101 Control Panel Assy.w/o Lights (Mech)
31023 Control Panel & Decal w/o Lights (S.S)
22654 Decal, Control, For 31023
31025 Control Panel & Decal w/Lights (S.S)
34744 Control Panel & Decal w/Lights & w/Steam
(S.S)
34746 Control Panel & Decal w/o Lights & w/Steam
(S.S.)
34747 Control Panel & Decal w/o Lights (S.S)
20757 Access Panel Assy., 4"x4" (Gas Valve)
21102 Combustion Cover Assy. (Before 12/02/93)
20738 Combustion Cover Assy. (After 12/02/93)
21103 Nameplate, Zephaire 4-5/8"
(Before 12/89)
23295 Nameplate, Blodgett/Zephaire 7-15/16"
(After 12/89)
21104 Flue Box (Sgl Oven)
21107 Flue Assy., Stacking (3 Piece)
35048 Backpipe Assy. (Dbl Oven)
(Replaces number 17880)
7839 Drafthood, Direct Venting, S/S (Sgl Oven)
21108 Drafthood, Direct Venting, S/S (Dbl Oven)
7840 Draft Diverter, Canopy Vent, S/S (Sgl Oven)
20447 Draft Diverter, Canopy Vent, S/S (Dbl Oven)
21835 Back Panel, S/S
(Before 02/23/99, S.N. 022399YA005S)
34761 Back Panel, S/S
(After 02/23/99, S.N. 022399YA005S)
34570 Bodyside, RH S/S (Prior to 11-21-05)
34571 Bodyside, LH S/S (Prior to 11-21-05)
NOTE: The bodysides 34570 & 34571 replace part
#17363 & #15994.
36407 Bodyside, RH S/S (11-21-05 and after)
37205 Bodyside, LH S/S (11-21-05 and after)
20223 Bodytop, S/S
8600 Legs, 6" w/ Bolts, S/S (Set of 4)
8598 Legs, 25" w/ Bolts, S/S (Set of 4)
7847 Leg Bolts (Set of 8)
92000 Leg Studs (Set of 4)
21053 Open Stand 25" w/ Feet, S/S
20878 Open Stand 25" w/ Casters, S/S
16002 Caster Kit, Sgl Oven (Set of 4)
5779 Caster Kit, Dbl Oven (Set of 4)
19528 Caster Kit, Low Profile (Set of 4)
31013 Caster Kit, Heavy Duty Low Profile (Set of 4)
31803 Clips, Dbl Stacking (Set of 2)
