BLOTZ B28-STA-104 User manual

28mm Starship Corridor (T-Junction)
B28-STA-104
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due care and remember
to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold pieces in place while
you allow glue to dry.
A full-colour copy of these instructions can be found on our website: www.blotz.co.uk
Starting with one of the external corner supports
remove the pieces shown above from the sprue.
Apply a little glue to thinner of the support pieces
and glue it to the wider one as shown above.
Glue the support to the corner of the base using
the lugs provided then stick the two bottom walls
into position. At this point it’s useful (but not
essential) to allow this to dry before proceeding.
Next glue the middle and upper portions of the wall
to the support.
Finally glue the decorative pieces into position.
Note that these are flush to the outer edge of the
wall pieces.
Now repeat this process with the other corner
column.

Each of the corridor walls is formed from a set of
the pieces shown above.
Apply a little glue to the supports and attach the
pieces as shown above. Note the two lugs on each
support should be at the bottom of the wall (i.e.
the section with the four sets of horizontal lines
marked on it. Leave to dry.
Once the wall is dry remove the pieces shown
above from the sprue.
Glue these into position on the wall (NB: There are
lines inscribed on the wall to help you position
these). Leave to dry. Ensure the decorative pieces
do not extend over the ends of the wall as this will
make linking corridor sections together quite tricky.
Finally glue the long wall into position using the
lugs provided.
