BLOTZ B10-MW-114 User manual

10mm Monorail Station
(Single Platform)
B10-MW-114
Please read these instructions fully before starting construction.
PVA or equivalent glue will be required to stick sections together.
Sand paper can be used to gently clean any joints.
A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due
care and remember to cut away from yourself at all times.
During the construction of this model you may find it convenient to use pegs / elastic bands to hold
pieces in place while you allow glue to dry.
Start by removing the support pillar pieces from
the sprue. The image shown above is for a single
support pillar.
Glue the pieces together as shown above with the
slots being opposite each other. Repeat for the other
pillar.
Glue the lugs at the bottom of each pillar into its
base. Allow glue to dry.
Now take the platform piece and the seven stanchions
from the sprue.
Turn the platform piece upside down and glue
the stanchions in place as shown. Allow to dry.
Each of the roof supports is formed from four pieces
(shown above). Glue them together as shown with the
slots opposite each other. Allow to dry.

The roof is formed from the two large pieces and
four beams (see above).
Turn the main roof piece over and glue the beams into
place using the holes/lugs provided.
Once you’re happy that the glue has set
sufficiently turn the roof over and glue the side
piece into place as shown. Leave to dry fully.
The lift is formed from the pieces shown above.
Glue the pieces
together as shown
with the square
holes in the side
pieces nearest to
the back piece (i.e
the one with the
slot).
Slot the platform section on top of the support pillars
(glueing them in place if you so wish). Push the lift into
position aligning the ends of the central stanchion
into the slot on the lift.
Add the two roof supports (note the direction of
the slots on the top of the support) into the holes
provided.
The railings are added to the edges of the platform
and will slot into the holes provided.

Finally sit the roof on top with the roof beams resting in the slots on top of the roof supports.
