LeapFrog Interactive Learning Easel User manual

Instruction Manual
This manual contains important information. Please save it for future reference.
Interactive Learning Easel
Interactive Learning EaselInteractive Learning Easel Interactive Learning Easel

2
INTRODUCTION
Thank you for purchasing the Interactive Learning Easel!
This 2-in-1 blackboard/whiteboard easel comes with 26
letter tiles, six shape tiles, chalk and an erasable marker. The
interactive learning panel teaches letters and encourages
creative play through drawing. The touch-sensitive pictures in
the book describe how to use the magnetic shape tiles to draw
pictures. The letter tile reader helps kids explore letter sounds,
letter writing and new words.
Board Clip
Release
Activity
Buttons
Music Button
Letter Tile Reader
Letter Tiles
Shape Tiles
Storage Tray
Off/Low/High
Volume Selector
Board Clip
Artwork Clip
Whiteboard
/Blackboard
Touch Book
Chalk
Erasable Marker

3
Connector (1)
Learning Panel (3)
A-Frame (1/2)
Connector (2) Upper Rear Leg (4)
Storage Tray (1/2)
Brace (5)
INCLUDED IN THE PACKAGE

4
Lower Rear Leg
Rear Leg Base (8)
Lower Front Leg (7)
Lower Front Leg (6)
6 Nuts
10 Screws 6 Bolts

5
• Quick Start Guide
Whiteboard/
Blackboard
26 Magnetic
Letter Tiles
6 Magnetic Shape
Tiles
3 Chalk Pieces 1 Erasable Marker

6
WARNING
All packing materials such as tape, plastic sheets, packaging
locks, removable tags, cable ties and packaging screws are not
part of this toy, and should be discarded for your child’s safety.
NOTE
Please save this Instruction Manual as it contains important
information.
ATTENTION
Pour la sécurité de votre enfant, débarrassez-vous de tous
les produits d’emballage tels que rubans adhésifs, feuilles de
plastique, attaches, étiquettes, cordons et vis d’emballage. Ils
ne font pas partie du jouet.
NOTE
Il est conseillé de sauvegarder ce manuel d’instructions car il
comporte des informations importantes.
NOTE
Please ask us about the availability of FSC Products.
NOTE
Merci de nous consulter pour connaître la disponibilité des
produits FSC.
Pull out the packaging locks and
discard.
Rotate the packaging locks 90
degrees counterclockwise.
Unlock the Packaging Locks

7
CAUTION:
Adult assembly required.
Small fasteners included.
CHOKING HAZARD—small parts.
Not for children under 3 yrs.
ATTENTION :
Ce jouet doit être assemblé par un adulte.
Petites attaches incluses.
RISQUE D’ÉTOUFFEMENT—Petites pièces.
Ne convient pas aux enfants de moins de 3 ans.
NOTE
Please cut and discard the cords before
playing with the unit. The cords are
not part of the product and should be
discarded for your child’s safety.

ASSEMBLY
With the Interactive Learning Easel, safety comes first. To
ensure your child’s safety, adult assembly is required.
ADULT ASSEMBLY REQUIRED:
Tool needed: Phillips-head screwdriver (not included)
Note: Numbers referenced below refer to the molded
plastic numbers on assembly parts. See INCLUDED IN THE
PACKAGE pages for reference.
1. Locate the marking of numbers 1 and
2 on the A-Frame and on the Storage
Tray separately. Align A-Frame 1 with
Storage Tray 1 and A-Frame 2 with
Storage Tray 2. The legs will rest in
the slots until they are secured.
2. Lay the pieces face down on a flat
surface so that the back of the
Storage Tray 1/2 and the back of the
A-Frame 1/2 are facing up.
8

3. Slide Connector 1 into the slot formed
by the aligned pieces A-Frame 1 and
Storage Tray 1 with the number 1 on
Connector 1 facing up.
4. Use three Screws and your Phillips-
head screwdriver to secure.
5. Slide Connector 2 into the slot
formed by the aligned pieces
A-Frame 2 and Storage Tray 2 with
the number 2 on Connector 2 facing
up.
6. Use three Screws and your Phillips-
head screwdriver to secure.
9

7. Slide the four knobs on the back of
the Learning Panel 3 into the slots on
the A-Frame 1/2. The Learning Panel 3
will rest in the slots until it is secured.
8. Secure Learning Panel 3 to A-Frame
1/2 with two Screws on each side as
shown.
9. Snap Upper Rear Leg 4 into the top
of A-Frame 1/2 as shown with the
number 4 facing out.
10. Snap Brace 5 into the back of Learning
Panel 3 as shown with the number 5
facing up.
10

11
11. Firmly snap the other end of Brace
5into the yellow slot in the back of
Upper Rear Leg 4 as shown. (Note:
Once inserted, this piece cannot be
removed.) You have now assembled
the upper easel.
12. Lay the assembled upper easel face
down on a flat surface.
13. Fit Lower Front Leg 6 into Connector
1 with the curved side of the leg
facing down and the number 6 facing
up. Secure with two Nuts and two
Bolts, inserting the Nuts from the
bottom.
14. Fit Lower Front Leg 7 into Connector
2with the curved side of the leg
facing down and the number 7 facing
up. Secure with two Nuts and two
Bolts, inserting the Nuts from the
bottom.

12
15. Fit Lower Rear Leg into the top of
A-Frame 1/2 with the curved side of
the leg facing up. Secure with two
Nuts and two Bolts, inserting the Nuts
from the top.
16. Secure the Lower Rear Leg to the
Upper Rear Leg 4 with two Nuts and
two Bolts.
17. Insert Lower Rear Leg into Rear Leg
Base 8.
18. Slot the Whiteboard/Blackboard
onto the top of the Learning Panel.
Lower the Board Clip over the
Whiteboard/Blackboard.

19. Slide the Board Clip Release switch
to the right and while holding it, lift
the Board Clip.
20 . Position the Whiteboard/Blackboard
under the Board Clip. Release the
clip to secure the Whiteboard/
Blackboard in place. Repeat
these steps when switching from
whiteboard to blackboard.
SET-UP
1) After assembling the easel, place the Erasable Marker and
Chalk pieces in the left cups of the Storage Tray.
2) Place the 26 magnetic Letter Tiles in the center cup of
the Storage Tray.
3) Place the 6 magnetic Shape Tiles in the right cup of the
Storage Tray.
Now, let’s create and draw together!
13

14
GETTING STARTED
BATTERY REMOVAL AND INSTALLATION
1. Make sure the unit is turned Off.
2. Find the battery cover located on the back of the unit, use a
screwdriver to loosen the screw, and then open the battery
cover.
3. Remove old batteries by pulling up on one end of each battery.
4. Install 2 new AA (AM-3/LR6) batteries following the diagram
inside the battery box. (For best performance, alkaline
batteries or fully charged Ni-MH rechargeable batteries are
recommended.)
5. Replace the battery cover and tighten the screw to secure.

15
IMPORTANT: BATTERY INFORMATION
• Insert batteries with the correct polarity (+ and -).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable
batteries.
• Only batteries of the same or equivalent type as
recommended are to be used.
• Do not short-circuit the supply terminals.
• Remove batteries during long periods of non-use.
• Remove exhausted batteries from the toy.
• Dispose of batteries safely. Do not dispose of batteries in
fire.
RECHARGEABLE BATTERIES
• Remove rechargeable batteries (if removable) from the toy
before charging.
• Rechargeable batteries are only to be charged under adult
supervision.
• Do not charge non-rechargeable batteries.
WARNING:
Adult assembly required for battery installation.
Keep batteries out of reach of children.
ATTENTION :
Les piles ou accumulateurs doivent être installés par un
adulte. Tenir les piles ou accumulateurs hors de portée des
enfants.

PRODUCT FEATURES
1. Off/Low/High Volume Selector
To turn the unit On, slide the Off/Low/
High Volume Selector to the Low or
High position. To turn the unit Off, slide
the Off/Low/High Volume Selector to
the Off position.
2. Double-sided Whiteboard/Blackboard
Select either the whiteboard or blackboard side of the
easel to explore a variety of activities. (See Assembly
Instructions above for details on flipping and securing the
board.)
Whiteboard side:
Use the erasable marker to draw and
create pictures by drawing directly on
and around the six magnetic Shape
Tiles. Practice writing letters and spelling
words using the erasable marker and the
26 magnetic Letter Tiles.
Blackboard side:
Use the three colored chalk pieces to
draw and create pictures by tracing
around the six magnetic Shape Tiles.
Then fill them in with different colors
or add fun details. Practice writing and
spelling skills with the Chalk and 26
magnetic Letter Tiles.
16

3. 26 Magnetic Letter Tiles and Letter Tile Reader
Insert any of the 26 magnetic Letter
Tiles into the Letter Tile Reader to hear
letter names, sounds and a word starting
with that letter. Press to explore colors
and vocabulary. Then remove the tiles
to hear drawing and writing prompts.
4. Touch Book and 6 Magnetic Shape Tiles
Flip the pages and touch the pictures in
the Touch Book to explore drawing and
spelling. Then use the Shape or Letter
Tiles to follow along.
5. Four Activity Buttons
Press the buttons for music or art activities:
Drawing Music - Fun tunes to accompany creative
activities.
Shape Art Activity - Use tiles and
draw shapes to make patterns and
pictures.
Rhythm Art Activity - A game to draw
lines and dots as you hear silly sounds.
Dot Art & Line Art Activities - Explore
how pictures are composed of simple
dots and lines.
17

6. Light-Up Music Button
Press to hear four learning songs
about the alphabet, colors, shapes and
creativity while the light blinks along.
7. Erasable Marker and Three Chalk Pieces
Use the included Erasable Marker for
activities on the whiteboard side and
to draw directly onto the Six Magnetic
Shape Tiles. Wipe the whiteboard with
a damp cloth, dry with a dry cloth, and
do it all over again! Use the included
Chalk to write, draw or create art with,
or trace around the Shape Tiles on the
Blackboard side.
8. Storage Tray
Store all 26 magnetic Letter Tiles, six
magnetic Shape Tiles, Erasable Marker
and three Pieces of Chalk.
18

9. Paper Clip
On the whiteboard side, place paper
under the Clip to attach it to the board
surface to create art or to display your
child’s artwork.
10. Automatic Shut-Off
To preserve battery life, the Interactive Learning Easel
will automatically shut off after approximately 90 seconds
without input. The unit can be turned on again by turning
a book page, pressing any of the five buttons, or flipping
the board over.
19

SONG LYRICS
Song 1
Grab your chalk and marker,
And let’s go!
Use your imagination,
And let the art flow!
Song 2
Express yourself,
Create and play!
Make it silly or smart,
You can do it your way.
Draw a line,
Up and down.
Make it square,
Make it round.
Shapes and colors
are everywhere!
Song 3
Pictures are made,
With colors and shapes -
Red, green and blue.
Come on, let’s make,
Circles and squares,
Rectangles, too.
It’s fun to draw;
Yes, it’s fun to do.
