Blu STUDIO 7.0 LTE User manual

1
STUDIO 7.0 LTE
Quick Guide/Guía Rápida/Guia Rápido/ Guide Rapide

2
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiated radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no

3
guarantee that interference will not occur in a particular installation If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Note:

4
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
RF Exposure Information (SAR)
This device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the United
States.
During SAR testing, this device was set to transmit at its highest certified power level in all
tested frequency bands, and placed in positions that simulate RF exposure in usage against the
head with no separation, and near the body with the separation of 12 mm. Although the SAR is
determined at the highest certified power level, the actual SAR level of the device while operating

5
can be well below the maximum value. This is because the device is designed to operate at
multiple power levels so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower the power output.
The exposure standard for wireless devices employing a unit of measurement is known as the
Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg.
This device is complied with SAR for general population /uncontrolled exposure limits in
ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods and
procedures specified in IEEE1528. This device has been tested and meets the FCC RF exposure
guidelines when tested with the device directly contacted to the body.

6
The FCC has granted an Equipment Authorization for this model device with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this
model device is on file with the FCC and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: YHLBLUST70LTE.
For this device, the highest reported SAR value for usage against the head is 0.19 W/kg, for
usage near the body is 1.20 W/kg.
While there may be differences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation distance of 12 mm
between the unit and the human body. Carry this device at least 12 mm away from your body to

7
ensure RF exposure level compliant or lower to the reported level. To support body-worn operation,
choose the belt clips or holsters, which do not contain metallic components, to maintain a
separation of 12 mm between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not tested
and certified, and use such body-worn accessory should be avoided.
IC Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and

8
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada
IC: 11492A-ST70LTE

9
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled exposure
limits in IC RSS-102 and had been tested in accordance with the measurement
methods and procedures specified in IEEE 1528 and IEC 62209. This equipment
should be installed and operated with minimum distance 1.2 cm between the
radiator and your body. This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or transmitter.
Cet appareil est conforme aux limites d'exposition DAS incontrôlée pour la population
générale de la norme CNR-102 d'Industrie Canada et a été testé en conformité avec
les méthodes de mesure et procédures spécifiées dans IEEE 1528 et IEC 62209.

10
Cet appareil doit être installé et utilisé avec une distance minimale de 1.2 cm entre
l’émetteur et votre corps. Cet appareil et sa ou ses antennes ne doivent pas être
co-localisés ou fonctionner en conjonction avec tout autre antenne ou transmetteur.

11
For instructions or any questions pertaining to phablet usage, please click on the BLU Help icon
on the home screen of the phablet. Also included in BLU Help is a product registration link and
technical support. You may also access the BLU help page by visiting the following address:
manuals.bluproducts.com
Para obtener instrucciones o preguntas relacionadas con el uso de la phableta, por favor haga
clic en el icono de BLU Help en la pantalla principal de la phableta. También se incluye en BLU
Help un enlace para registro del producto y soporte técnico. Usted también puede acceder la
página de BLU Help visitando la siguiente dirección: manuals.bluproducts.com
Para obter instruções ou perguntas relacionadas ao uso do phableta, por favor, clique no ícone
BLU Help na tela principal do phableta. Também incluído no BLU Help um link para registrar o
produto e suporte técnico. Você também pode acessar a página de BLU Help visitando o
seguinte endereço: manuals.bluproducts.com
Pour des instructions ou pour toutes questions sur l'utilisation du phablette veuillez cliquer sur
l'icôneAide BLU sur l'écran d'accueil du phablette. L'Aide BLU comprend un lien pour
enregistrer le produit et pour le soutien technique. Vous pouvez aussi accéder à la page aide
BLU en visitant l'adresse suivante: manuals.bluproducts.com
ATTENTION

12
SAFETY INFORMATION
Transportation Safety
Please observe all transportation laws and regulations.
PLEASE DRIVE RESPONSIBLY - DO NOT TEXT & DRIVE
Hospital Safety
Please follow hospital rules and limitations.
Please turn off your phablet when near medical instruments.
Airport Safety
Remember to follow all airport and flight safety regulations.
Water Hazard
Your phablet is not waterproof. Keep your phablet away from water or liquid to avoid damage.
Emergency Calls
Make sure your phablet is switched on and in a service area. In home screen, tap the dial key and dial the
emergency number.
Battery Usage
For better performance and longer battery life, it is recommended that you charge the battery fully before
using the phablet for the first time and that you initially complete two to three charge cycles.
BLU_S0010UU_V03

13
KEY FUNCTIONS
Power
Back
Home
Recent Apps
Front Camera
Speaker
Volume

14
Rear Camera

15
INTRODUCTION
Installation of the SIM Card
Warning: Please keep the SIM card out of the reach of children. The SIM card and its contact are easily
damaged due to scratching or bending. Please use caution when carrying, installing, or taking out the SIM
card. Note: Please contact your cellular phablet service provider directly to obtain your SIM card.
To insert SIM card:
1. Remove the SIM tray. Insert the SIM card.
2. Insert the SD card (For additional storage capacity).
3. Insert the SIM tray and power on the phablet.
SIM Slot
Memory Card
Slot

16
When you initially power on your phablet, there will be a series of steps to set up basic features.
INSERT SIM
Insert your SIM card so the phablet can register to the network.
SELECT LANGUAGE
While on the Welcome screen, please scroll to select your language.
SELECT WI-FI
This process allows the device to connect to the internet. Click on the desired Wi-Fi network that the device
will be connecting to. Please note that any unsecured Wi-Fi networks can be connected to directly and any
secured Wi-Fi networks require a password for credentials prior to connection. It is recommended that you
connect to a Wi-Fi network to check for software updates prior to startup.
ADD YOUR ACCOUNT
Sign in to your GoogleTM account in order to keep accounts streamlined with Google services. Your Gmail
account will be used for some Google programs which include: Google PlayTM Store, Google DriveTM,
Google+TM and Google WalletTM. If you do not have a Google account, click to create a new account. In this
step you can also setup payment info if desired. Click next to continue.
RESTORE APPS & DATA
You can restore your previous applications and data that have been backed up from another device. You
may also setup the phablet as a new device. Click next to continue.
GOOGLE SERVICES
Click to add or remove Google services which include Backup, Location Service, and Google NowTM.
DISCLAIMER: Android, Google, Google Play and other marks are trademarks of Google Inc.

17
INFORMACIÓ N DE SEGURIDAD
Seguridad de Transporte
Por favor siga todas las leyes y regulaciones de transporte.
MANEJE RESPONSABLEMENTE - NO USE MENSAJERIA DE TEXTO CUANDO CONDUCIENDO
Seguridad de Hospitales
Por favor siga todas las leyes y regulaciones de hospital
Por favor, apague su phableta cuando cerca de instrumentos médicos.
Seguridad de Aeropuertos
Por favor, siga todas las normas de seguridad de vuelo
Prueba de Agua
La phableta no es impermeable. Manténgalo alejado de agua o líquidos para evitar daño.
Llamadas de Emergencia SOS
Asegúrese de que su phableta está encendido y en un área de servicio. En la pantalla de inicio, pulse la
tecla de marcación y marque el número de emergencia.
Uso de batería
Para mejorar el rendimiento y la vida útil de la batería, se recomienda que cargue la batería totalmente
antes de utilizar la phableta por primera vez.
El rendimiento óptimo de una batería nueva se obtiene generalmente después de dos o tres ciclos de
carga completos.

18
FUNCIONES
Volumen
Retroceder
Inicio
Apps Recientes
Encender
Cámara Frontal
Altoparlante

19
Cámara Trasera

20
INDRODUCCIÓ N
Instalación de la Tarjeta SIM
Advertencia: Mantenga la tarjeta SIM fuera del alcance de los niños. El contacto de la tarjeta SIM se daña
fácilmente debido al roce o flexión. Por favor tenga cuidado al transportar o instalar la tarjeta SIM.
Nota: Por favor comuníquense con el proveedor de servicio directamente para obtener su tarjeta SIM.
Para insertar la tarjeta SIM:
1. Retire la bandeja de SIM. Inserte la tarjeta SIM.
2. Inserte la tarjeta de memoria (Para capacidad adicional).
3. Inserte la bandeja de SIM y encienda el phablet.
Ranura de Tarjeta
de Memoria
Ranura de
Tarjeta SIM
