Blue Thumb IllumiGlow PB2897 User manual

DESCRIPTION AND FEATURES
Your Blue Thumb IllumiGlow®Fountain & Pond
3 Light Kit, containing a set of 3 warm white LED
pond/garden lights, has been manufactured with
quality materials to ideally integrate into any pond
and garden scene, thanks to their compact design.
• Our lights have a glass lens and are suitable
for use in or out of water.
• ThehighpowerenergyecientLEDemits
a natural warm light providing years of
maintenance free satisfaction.
• The 110-120V AC transformer converts the
power supply to a safe 12 volts for peace of
mind in your pond or garden.
Included:
• 3 Corded LED Lights
• 120V Transformer
• Photocell Light Sensor
• 3-way, 2-pin Splitter
• 3 Tripod Bases
• 3 Garden Spikes
• All Connection Cords
IllumiGlow®Fountain & Pond 3 Light Kit
Featuring Item# PB2897
Installation Instructions

INSTALLATION
• Ifrequired,haveaqualiedelectricianinstallaweatherproofpowerpointneartothe
pond or garden, within reach of the transformer and light.
• Mount the Transformer (4) in a dry and protected location making sure that it can’t be
wet by either rain or reticulation.
• For pond installation slide the Weighted Base (2) into the circular recess on the
underside of the Light Body (1). Position the light(s) in the desired location taking
care not to wet the Bi-pin Plug (5) at the end of the 16 ft. light cord(s).
• For garden installation slide the Garden Spike (3) into the circular recess on the
undersideoftheLightBody(1).Holdingthelightbodyrmly,pushthelight(s)with
attached spike into the desired location(s) taking care not to penetrate any hidden
services.
• Adjust the light(s) until facing in the general direction of the feature you wish to
illuminate.Werecommendnaladjustmentsbecarriedoutatnight.
• Insert the bi-pin male plug (5) on the end of the light cord into the 3-way Splitter
(6)andtightenthelockingcollarrmly.Dothisfortheother2lights.Connectthe
splitter to the output end of the Photocell (7) with the included 6 in. cord and tighten
thelockingcollarsrmly.Connectthetransformer6ft.cordtotheinputendofthe
photocellandtightenthelockingcollarrmly.Thetransformercannowbeturnedon.
• Once in the correct position lock the light by tightening the Thumb Screws (8), taking
care not to over tighten.
IllumiGlow®
Fountain & Pond 3 Light Kit
Connection Diagram
1Light Body
2Weighted Base
3Garden Spikes
4Transformer
5Bi-pin Plug
6 3-way Splitter
7 Photocell
8Thumb Screw
1
2
6 ft. cord
3
5
4
1
2
6 in. cord
16 ft. cords
6
7
8

MAINTENANCE
There is minimal maintenance required on your Blue Thumb IllumiGlow®
Fountain & Pond 3 Light Kit. The light should be inspected on a regular basis
to ensure the light or cable is not damaged in any way. Clean the lens on the
lightregularlyformaximumeciency.
IMPORTANT SAFEGUARDS
To guard against injury, basic safety precautions should be observed including
but not limited to the following;
• The light should only be used in clean water. Do not use the light in any
solventorammableliquids.Donotuseinchlorinatedorsaltwater.
• Do not operate the light if the light or any of the components of the light
such as the power cable or transformer have been damaged.
• If the 110V plug supplying the transformer gets wet, do not unplug the
cord. Disconnect the circuit breaker that supplies power to the power
outlet. Then unplug and examine the plug and power outlet for presence
of water. If the power outlet has become wet, you should consult an
electrician before using the again.
• Always use a properly grounded power supply.
• Always unplug the light from the power supply when not in use or
before performing any maintenance. Never pull the transformer cord to
disconnect the plug from the power supply. Grasp the plug and pull to
disconnect.
• Do not install or store the light where it will be exposed to extreme hot or
cold temperatures.
• Keep out of reach of children or pets.
• Do not cut the cord as this will result in voiding your warranty.
• Care should be taken to arrange the power cord so that it cannot be
accidentally tripped over or pulled.
• Do not attempt to repair the light yourself. Return to an authorized service
center or place of purchase if a fault occurs.
• Do not use in water above 95°F.
www.shopbluethumb.com

WARRANTY AGAINST DEFECTS
This product comes with a warranty against defects (Warranty). The Warranty is provided
to the original purchaser of the product on the following terms:
• To make a claim under the Warranty you must return the faulty product to the place
of purchase with a valid receipt or proof of purchase.
• A Warranty claim must be made within 3 years of the date of purchase.
• If your claim complies with the above terms and the product is not an Exhaustible
Item and no Voiding Events have occurred, we will (at our sole discretion):
- repair the product, if possible; or
- provide a replacement product; or
- if a replacement product is not available, provide a refund for
the purchase price paid.
• You will bear the cost associated with claiming under the Warranty such as the cost
of transportation and delivery of the product to and from the place of purchase.
• The Warranty will be void if any of the following events occur, as determined by us,
at our sole discretion (Voiding Events):
-anytampering/removalofwarranty/identicationlabelsorelectrical
components is evident;
- the defect has arisen due to: an accident, incorrect or inadequate installation,
misuse or abuse of the product (including improper maintenance and service),
excessive wear and tear, not following manufacturer’s guidelines/instructions, or
the product has been used in a manner contrary to the purpose or suitability of
the product;
-theproducthasbeenmodiedwithoutourauthorityincludingbutnotlimitedto
cutting, modifying or extending any of the wiring;
- the defect is caused by power surges/spikes/brownouts.
• Damage to property or personal injury caused by the improper use or abuse of
the product will not be covered and the manufacturer excludes all liability for such
events, to the extent permitted by law.
www.shopbluethumb.com
