BMB MEDICAL I-MOVE User manual

BMB MEDICAL –I-MOVE –2VTRS062022
-
USER MANUAL
Supplied By:

BMB MEDICAL –I-MOVE –2VTRS062022
1
The purpose of this manual is to familiarize you with the use, maintenance, and safety procedures
for your new medical equipment. We strongly advise you to read this document carefully and
apply the recommendations it gives, for optimum and safe use.
BMB MEDICAL offers a wide range of options for the models covered by this handbook. Some
of the features described in this manual might therefore not apply to your care chair.
Some illustrations are provided for information purposes and do not accurately represent the
device in your possession.
The information in this document may be modified without notice and does not imply any responsibility of any sort
of BMB MEDICAL. Any representation or copying, whether complete or partial, without authorization from BMB
MEDICAL is illegal. This illegal representation or copying, by any method at all, would constitute an infringement of
rights. The illustrations in this document are not contractual.
JD Healthcare Group Pty Ltd
3/22 Beaumont Rd
Mt. Kuring-Gai 2080
p: 1300 791 404
e: [email protected]
w: www.jdhealthcaregroup.com.au

BMB MEDICAL –I-MOVE –2VTRS062022
2
CONTENTS
1INTRODUCTION................................................................................................................................4
1.1 PRODUCT PRESENTATION .....................................................................................................4
1.1.1 I-MOVE TRANSFER CHAIR..............................................................................................5
1.1.2 I-MOVE TRANSFER CHAIR FOR OVERWEIGHT PATIENTS.......................................6
1.1.3 MOTORIZED I-MOVE EZ-GO TRANSFER CHAIR........................................................7
1.1.4 1.1.4 MOTORIZED I-MOVE EZ-GO TRANSFER CHAIR FOR OVERWEIGHT
PATIENTS............................................................................................................................................8
1.1.5 OUTDOOR I-MOVE.........................................................................................................9
1.2 APPLICATION FIELD .................................................................................................................10
1.3 PURPOSE OF THE USER MANUAL.........................................................................................10
1.4 USERS .........................................................................................................................................10
1.5 STORAGE...................................................................................................................................10
1.6 APPLIED PARTS .........................................................................................................................10
1.7 SYMBOLS AND STANDARDS USED ......................................................................................11
2INSTRUCTION FOR USE..........................................................................................................................13
2.1 OPERATING CONDITIONS..............................................................................................................13
2.2 INSTALLATIONPROCEDURE ..........................................................................................................13
2.3 MOTORIZED WHEEL.......................................................................................................................13
2.3.1 START-UP .............................................................................................................................13
2.3.2 BATTERY ..............................................................................................................................13
2.4 PRODUCT POWER SUPPLY .............................................................................................................15
2.4.1 MOTORISED DRIVE ...............................................................................................................16
2.4.2 STANDARD I-MOVE.........................................................................................................17
2.5 ARMREST....................................................................................................................................17
2.6 FOOTREST..................................................................................................................................18
2.7 OPTIONS ...................................................................................................................................18
2.7.1 LEGREST.............................................................................................................................18
2.7.2 ANTISTATIC SYSTEM .......................................................................................................19
2.7.3 REMOVABLE IV POLE / ANTI-THEFT BAR....................................................................20
2.7.4 HOLDER FOR OXYGEN CYLINDER ...............................................................................20
2.7.5 ACCESSORY BASKET.......................................................................................................21
2.7.6 COIN ACCEPTOR AND WALL FIXATION ....................................................................22
2.7.7 HOOKS TO HOLD BAG..................................................................................................22

BMB MEDICAL –I-MOVE –2VTRS062022
3
3CLEANING AND DISINFECTION ....................................................................................................23
3.1 INTRODUCTION .......................................................................................................................23
3.2 FREQUENCY ..............................................................................................................................23
3.3 CLEANING AND DISINFECTION ADVICE.............................................................................23
3.3.1 CLEANING OPERATION .................................................................................................23
3.4 RECOMMENDED EQUIPMENT AND PRODUCTS ................................................................24
3.4.1 CLEANING OF THE OUTDOOR CHAIR........................................................................25
4PRECAUTIONS...................................................................................................................................26
4.1 PRECAUTIONS REGARDING THIS DEVICE.............................................................................26
4.1.1 WARNING.........................................................................................................................26
4.1.2 CONTRAINDICATIONS...............................................................................................................27
4.1.3 PRECAUTION ASSOCIATED WITH EQUIPMENT CARE AND MAINTENANCE ......28
4.1.4 MC-RELATED INFORMATION.........................................................................................28
4.2 TRANSPORT AND STORAGE .................................................................................................30
4.2.1 TRANSPORT ......................................................................................................................30
4.2.2 STORAGE ..........................................................................................................................30
4.3 WARRANTY...............................................................................................................................30
4.4 AFTER SALES SERVICE .............................................................................................................31
4.5 ENVIRONMENT.........................................................................................................................32
4.5.1 SPENT EQUIPMENT..........................................................................................................32

BMB MEDICAL –I-MOVE –2VTRS062022
4
1INTRODUCTION
1.1 PRODUCT PRESENTATION
Patient support device. The frame of the chair is mounted on casters to allow patient transfer,
and it can be equipped with an electric wheel to assist movement. The MD is equipped with a
mechanical braking system.
The device allows an operator to convey the patient within a healthcare establishment.
The products are designed to ensure that there are no unacceptable risks (essential performance)
associated with patient support or caused by accidental movements.
List of I-Move references:
oI-MOVE –Stackable transfer chair I-MOVE
oI-MOVE BARIATRIC –Bariatric transfer chair I-MOVE
oI-MOVE EZ-GO –motorized transfer chair I-MOVE
oI-MOVE EZ-GO BARIATRIC –Motorized bariatric transfer chair I-MOVE
oI-MOVE OUTDOOR –Outdoor transfer chair I-MOVE

BMB MEDICAL –I-MOVE –2VTRS062022
5
1.1.1 I-MOVE TRANSFER CHAIR
TECHNICAL CHARACTERISTICS
REFERENCE
I-MOVE
DESCRIPTION
PATIENT TRANSFER CHAIR
SAFE WORKING LOAD
200 kg (maximum acceptable weight comprising the weight of the
patient, the mattress and the accessories)
WEIGHT
35 kg
OVERALL DIMENSION
105 x 75 x 100 cm
CUSHION AND BACK SIZE
46 x 46 cm
BACK HEIGHT
55 cm
EQUIPMENT
* Overall dimensions : 105 (length) x 75 (width) x 100 (height) cm
* Dimensions seat and back: 46 x 46 cm
* Seat height : 55 cm
* Steel frame epoxy coated, white RAL 9003
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be
operated in stand position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking foot rest
* Polyurethan armrests, can be folded up
* Anti-shock protection
* Cushion in foam - Thickness 5 cm
* Seamless finish, vinyl coating
* Colour range : fuchsia, green, blue
OPTIONS
Removable IV pole, 2-stage, 2 hooks.
Fixed IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
Anti-static system.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Accessory basket.
Holder for oxygen cylinder.
Equipment for leg rest (pair).
Adjustable leg rest (1 piece).
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Hooks to hold bags.

BMB MEDICAL –I-MOVE –2VTRS062022
6
1.1.2 I-MOVE TRANSFER CHAIR FOR OVERWEIGHT PATIENTS
TECHNICAL CHARACTERISTICS
REFERENCE
I-MOVE -Transfer chair for overweight patient
DESCRIPTION
OVERWEIGHT PATIENT TRANSFER CHAIR
SAFE WORKING LOAD
250 kg (shows the maximum acceptable weight comprising the
weight of the patient, the mattress and the accessories)
WEIGHT
50 kg
OVERALL DIMENSION
105 x 90 x 102 cm
CUSHION AND BACK SIZE
46 x 65 cm
BACK HEIGHT
55 cm
EQUIPMENT
* Overall dimensions : 105 (length) x 90 (width) x 102 (height) cm
* Dimensions seat and back: 46 x 65 cm
* Seat height : 55 cm
* Steel frame epoxy coated, white RAL 9003
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be
operated in stand position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking foot rest
* Polyurethan armrests, can be folded up
*Anti-shock protection
* Cushion in foam - Thickness 8 cm
* PVC coated Jersey
* Colour range : lavender, green, squirrel
OPTIONS
Removable IV pole, 2-stage, 2 hooks.
Fixed IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
Anti-static system.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Accessory basket.
Holder for oxygen cylinder.
Equipment for leg rest (pair).
Adjustable leg rest (1 piece).
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Hooks to hold bags.

BMB MEDICAL –I-MOVE –2VTRS062022
7
1.1.3 MOTORIZED I-MOVE EZ-GO TRANSFER CHAIR
TECHNICAL CHARACTERISTICS
REFERENCE
I-MOVE EZ-GO - Motorized
DESCRIPTION
MOTORIZED PATIENT TRANSFER CHAIR
SAFE WORKING LOAD
200 kg (shows the maximum acceptable weight comprising the weight
of the patient, the mattress and the accessories)
WEIGHT
52 kg
OVERALL DIMENSION
105 x 70 x 102 cm
CUSHION AND BACK SIZE
46 x 46 cm
BACK HEIGHT
55 cm
EQUIPMENT
* Overall dimensions: 105 (length) x 70 (width) x 102 (height) cm
* Dimensions seat and back: 46 x 46 cm
* Seat height: 55 cm
* Motorized drive system with autonomous wheel
* Switchable battery - 5 km autonomy per battery - Charge time : 5
hours
* Lithium battery without memory effect
* Forward/Backward twist grip with progressive speed acceleration
* Steel frame epoxy coated
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be operated
in stand position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking footrest
* Polyurethan armrests, can be folded up
* Accessory basket
* Anti-shock protection
* Supplied with 2 batteries and external charger
* Cushion in foam - Thickness 5 cm
* Seamless finish, vinyl coating
* Color range: fuchsia, green, blue
OPTIONS
Removable IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Holder for oxygen cylinder.
Hooks to hold bags.
Equipment for leg rest (pair).
Adjustable leg rest (1 piece).
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Without battery (depreciation).
Additional battery.
External wall charger
External charger mobile version
Charging station 1 charger
Charging station 2 chargers (one multi-socket included)
Charging station 3 chargers (one multi-socket included)
Charging station 4 chargers (one multi-socket included)

BMB MEDICAL –I-MOVE –2VTRS062022
8
1.1.4 1.1.4 MOTORIZED I-MOVE EZ-GO TRANSFER CHAIR FOR OVERWEIGHT PATIENTS
CARACTERISTIQUES TECHNIQUES
REFERENCE
I-MOVE EZ-GO BARIATRIC - Transfer chair for overweight patient
DESCRIPTION
OVERWEIGHT PATIENT TRANSFER CHAIR
SAFE WORKING LOAD
250 kg (shows the maximum acceptable weight comprising the weight of the
patient, the mattress and the accessories)
WEIGHT
65 kg
OVERALL DIMENSION
105 x 90 x 102 cm
CUSHION AND BACK SIZE
46 x 65 cm
BACK HEIGHT
55 cm
EQUIPMENT
* Overall dimensions: 105 (length) x 90 (width) x 102 (height) cm
* Dimensions seat and back: 46 x 65 cm
* Seat height : 55 cm
* Motorized drive system with autonomous wheel
* Switchable battery - 5 km autonomy per battery - Charge time : 5 hours
* Lithium battery without memory effect.
* Forward/Backward twist grip with progressive speed acceleration
* Steel frame epoxy coated RAL 9010
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be operated in stand
position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking foot rest
* Polyurethan armrests, can be folded up
* Accessory basket
* Supplied with 2 batteris and external charger
* Anti-shock protection
* Cushion in foam HR 35kg/m3 - Thickness 8 cm
*Seamless finish, vinyl coating
* Colour range : lavender, green, squirrel
OPTIONS
Removable IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Holder for oxygen cylinder.
Hooks to hold bags.
Equipment for leg rest (pair).
Adjustable leg rest (1 piece).
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Without battery (depreciation).
Additional battery.
External wall charger
External charger mobile version
Charging station 1 charger
Charging station 2 chargers (one multi-socket included)
Charging station 3 chargers (one multi-socket included)
Charging station 4 chargers (one multi-socket included)

BMB MEDICAL –I-MOVE –2VTRS062022
9
1.1.5 OUTDOOR I-MOVE
CARACTERISTIQUES TECHNIQUES
REFERENCE
I-MOVE OUTDOOR –Outdoor transfer chair
DESCRIPTION
TRANSFER CHAIR
SAFE WORKING LOAD
200 kg (shows the maximum acceptable weight comprising the weight of the
patient, the mattress and the accessories)
WEIGHT
35 kg
OVERALL DIMENSION
105 x 75 x 100 cm
CUSHION AND BACK
SIZE
46 x 46 cm
BACK HEIGHT
55 cm
EQUIPMENT
* Overall dimensions : 105 (length) x 75 (width) x 100 (height) cm
* Dimensions seat and back : 46 x 46 cm
*Seat height : 55 cm
* Steel frame epoxy coated, white RAL 9003
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be operated in
stand position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking foot rest
* Polyurethan armrests, can be folded up
* Anti-shock protection
* Polypropylene plastic fitting
* Color : blue
OPTIONS
Removable IV pole, 2-stage, 2 hooks.
Fixed IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
Anti-static system.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Accessory basket.
Holder for oxygen cylinder.
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Hooks to hold bags.

BMB MEDICAL –I-MOVE –2VTRS062022
10
1.2 APPLICATION FIELD
This chair is intended for the reception and transfer of the patient in sitting position. Its technical
characteristics also allow an outdoor use.
1.3 PURPOSE OF THE USER MANUAL
Healthcare professionals, this user manual was created for you to provide you with the necessary
information and precautions to observe for autonomous and safe use.
The product’s service life is dependent upon observance of the maintenance and tracking
instructions.
It is thus essential that all staff has access to and be informed of the handling procedures and
risks associated with the use of this chair. This latter should be handled by a qualified person
who is aware of the risks inherent to improper use. Additional training is not required as we
consider that knowledge of the user manual is sufficient.
1.4 USERS
Healthcare professionals: physicians, caregivers and agents approved by Technical Services who
are accustomed to working with similar equipment can operate all functions.
1.5 STORAGE
This user manual should be kept near the product, in a place provided for this purpose. It must
be shielded from all elements and substance that could compromise its perfect legibility.
1.6 APPLIED PARTS
The applied parts are as follows:
-Upholstery
-Armrests
-Footrest

BMB MEDICAL –I-MOVE –2VTRS062022
11
1.7 SYMBOLS AND STANDARDS USED
I-MOVE and I-MOVE transfer chairs for overweight patients are Class I, non-invasive and non-
active medical devices.
The I-MOVE EZ-GO transfer chair is a Class I, non-invasive and active medical device.
Type B appliance
Electrical class II equipment
Electrical hazard, do not open
Duty cycle (motor cycle)
1 min. operation / 19 min. stop
IPX5
Splash-resistant
See the manual / instruction brochure
Indicates the maximum patient weight and safe working load
Complies with the requirements of Regulation (EU) 2017/745 of the European
Parliament and of the Council
Serial number
Manufacture date
Manufacturer
Alternating current
Maximum patient weight
Electronic waste: this symbol indicates that the product must not be discarded with
unsorted municipal waste, but rather to a selective waste collection channel. Contact
the local distributor for information concerning the return and/or collection systems
available in the country.
Protéger de l’humidité / keep dry
Haut, tenir debout / stand up
Fragile / fragile
Recyclable / recycling
Temperature range

BMB MEDICAL –I-MOVE –2VTRS062022
12
Humidity limit
General safety sign:
-Information highlighted by this symbol must be read and scrupulously observed.
-Indicates that failure to observe the guideline could endanger the patient or user, or
damage the equipment.
“WARNING: This appliance must not be altered without the manufacturer’s written consent.”
“Caution: only purpose-built accessories provided for this MD by BMB MEDICAL may be
used.”
Sitting on the armrests is prohibited
Leaning against the chair is prohibited

BMB MEDICAL –I-MOVE –2VTRS062022
13
2INSTRUCTION FOR USE
2.1 OPERATING CONDITIONS
2.2 INSTALLATION PROCEDURE
Before putting the chair into service, depending on the model, check the operation of:
-Motorized drive
-Braking
-Armrests
-Footrest
Clean the product according to your establishment's internal protocol.
2.3 MOTORIZED WHEEL
The motorized traction by the wheel facilitates the movement of the chair.
2.3.1 START-UP
Storing and/or carrying motorized chairs in very low temperature conditions (below 5 ° C) may
alter the operation of the product. This is why it is recommended to leave the products for 24
hours in a temperate environment before putting them into service following the conditions
described above.
2.3.2 BATTERY
The battery box comes with its own external charger.
Before first use, leave the product in a warm environment for 24 hours and then
charge the battery for 6 to 8 hours on a mains socket.
In order to maintain an acceptable level of charge, it is recommended to charge
the motorized chairs as soon as possible. It is not necessary to wait until the
battery is completely discharged.
AMBIENT CONDITIONS
FUNCTIONING
Ambient temperature
+ 5 C° à + 30°C
Relative humidity
20 à 90% à 30° C –non-condensing
Atmospheric pressure
700 à 1060 ha

BMB MEDICAL –I-MOVE –2VTRS062022
14
« Warning: Do not short-circuit the batteries and do not leave the system unused and without
charging for extensive periods of time as this could cause self-discharge, leading to medium-
term damage. This will also have an environmental impact. »
In case of prolonged interruption of use of your equipment, it is recommended to recharge
the battery once a month. Beyond 50 days of storage without recharging, the performance
of the battery may be impaired or even irreversibly damaged.
Battery specifications
Battery safety symbols
Battery type:
Lithium-
Ion
IPX4 ald IPX5
Protection rating
Capacity:
4.50 Ah
CE marking
Input supply voltage:
29~45V
CC
Indoor use
Label with information on the operation of the batteries.
Rechargeable battery
(Option : EZSBA Without battery (depreciation))
Product power battery

BMB MEDICAL –I-MOVE –2VTRS062022
15
2.4 PRODUCT POWER SUPPLY
Power grid connection conditions and electromagnetic compatibility:
This medical device’s power cord may represent an obstacle that could cause a fall. Be
mindful of its presence when moving around the appliance, when the latter is connected to
the mains.
Position the product such that it can be easily unplugged.
Unplug the product before moving it.
Do not leave the cables in contact with the floor or the casters,
Do not knot the cables,
Periodically check the condition of the cables.
Mains connection:
100~240V depending on the country.
Frequency:
50 /60 Hz
Rated current:
3.3 A
Protection rating / degree of electric shock
protection:
Class 2 appliance
Power input:
525 W
Intermittent operating mode:
5% i.e., 1 minute of continuous operation followed
by 19 minutes of rest.

BMB MEDICAL –I-MOVE –2VTRS062022
16
The mains plug is the electrical grid insulation device.
Work on electrical parts should only be performed by qualified and authorized staff.
Electromagnetic interference caused by the chair cannot be excluded. In this case, the chair’s
functions should be inhibited and those instruments subject to interference should be moved
away. You can view the EMC information here.
2.4.1 MOTORISED DRIVE
DEMARRAGE
-Press the start button (F)
oThe battery charge level indicator lights up (E)
-Fully press the brake control (A) and then release it.
When a green or red arrow is displayed (D), the
chair is started and ready for use.
SHIFTING
Forward:
Select the drive direction (B).
Select speed (C).
Turn the control handle forward (G). The speed is controlled by this handle.
A B C D E F G
In forward motion there are two speeds:
"turtle" being slow and "rabbit" being fast.
In reverse there is only one speed.

BMB MEDICAL –I-MOVE –2VTRS062022
17
Reverse:
Select the drive direction (B).
Turn the control handle forward (G). The speed is controlled by this handle. The
selected speed (C) has no impact in reverse.
For safety reasons, the command reaction time is 0.5 seconds
Check regularly that nothing on the ground is hindering the rotation of the wheel.
BRAKING
-Fully press the brake control (A) to activate the brake.
For safety reasons, the command reaction time is 0.5 seconds.
2.4.2 STANDARD I-MOVE
- Push with your foot the green pedal to unblock the chair.
- Push with your foot the red pedal to immobilize the chair.
2.5 ARMREST
To raise or lower the armrests, simply raise them or lover them manually.

BMB MEDICAL –I-MOVE –2VTRS062022
18
2.6 FOOTREST
The opening at the front of the tray allows a foot to be inserted to advance or push back the
footrest.
To deploy the footrest, extended as far as the stop to lock it. To retract the footrest, lift it and
push it.
-When moving a patient make sure that the footrest is deployed.
-Do not step on the foot rest to sit in the transfer chair.
-Do not stand up on the footrest.
2.7 OPTIONS
2.7.1 LEGREST
To install the leg rest, insert the bar in the jaws provided for the purpose under the chair.
It is possible to incline the leg rest by placing its bar in the 2nd notch.

BMB MEDICAL –I-MOVE –2VTRS062022
19
For storage, place the leg rest upside down as shown below
- Do not sit on the leg rest
- Do not apply a load greater than 20kg on the leg rest.
2.7.2 ANTISTATIC SYSTEM
The I-MOVE EZ-GO is equipped with antistatic wheel (optional for I-MOVE standard version)
In order to maintain the antistatic functions of the wheels, you must clean it regularly (no
dust )
Leg rest fitting
Inclined position
Straight position
