BODY BIKE Smart Programming manual

GENERAL INFO
TROUBLE
SHOOTING
Version 1.1

Before beginning any exercise, please consult your physician
Wipe off the cycle after EVERY use. If necessary, use water in a spray bottle and a tissue with some washing-
up liquid.
NEVER use alcohol or chemicals to clean the cycle
ALWAYS release tension after use and unlock ALL handles
The rubber feet should always be adjusted to ensure that the cycle is in level
DO NOT perform stretch exercises on the cycle, pedals or up against the cycle
DO NOT switch the front or seat post from one cycle to another
DO NOT lift the cycle by the saddle or the handles – use the handlebar in locked position and wheel the cycle.
Avoid bumps, uneven surfaces and set down the cycle with care. Only for indoor use
DO NOT pedal fast in an attempt to set a record if you do not have the bike under control
DO NOT add more tension than necessary. Over-tightening the tension knob to the extent that pedalling is not
possible may cause harm to the brake unit
To make the cycle look its best, use a cloth with a little Vaseline oil on all parts except the phone holder,
handlebar and saddle.
Use a cloth with Vaseline oil to clean between the top of the posts and the sliders.
Every other week pull out the seat post and the front post and wipe them clean with an oily cloth
Tighten the pedals every 14 days to avoid them getting loose or breaking off.
Tighten both screws in adjustment handles once a month (8 in total).
Inspect the brake pad after the first month and hereafter every three months to make sure it is not
worn through. The pad has an expected durability of 1500 hours. How to replace the brake, see figure 1.
GENERAL INFO
Loosen
Replace entire brake unit
8 mm wrench
REPLACE BRAKE UNIT
Figure 1

Once a month, inspect that the flywheel edge is absolutely smooth. If dirt has gathered on the flywheel edge,
clean it with 3M Scotch-Brite™ pad.
Pedals should be changed once a year or at least after 1500 hours.
At an annual service check vacuum clean inside the cycle and check that the ribs on the Poly-V belt and pulley are
clean.
Every second year the rubber feet should be replaced as the rubber hardens and becomes unable to absorb the
impact.
GENERAL INFO

Position K
Loosen
Tighten
Handle
unlocked
6mm Allen
ADJUST HORISONTAL HANDLES
Adjust only a quarter of a turn
at the time.
How to keep the cycles in good condition?
It is a good idea to place a board at the exit of the room displaying all cycle numbers. Here people can write
possible problems or concerns arisen during the workout. In this way, the people who are servicing the cycles
can get up-dated regularly on how the cycles are performing, and problems can be identified before they turn
critical.
SMART Release handles are not locking
Adjust the handles by tightening the M8 bolt. For more information, see figure 2a and 2b.
TROUBLE SHOOTING
Figure 2a

TROUBLE SHOOTING
The belt does not catch hold of the flywheel
If the belt does not catch hold of the flywheel, it is time to tighten the belt, see figure 3.
TIGHTEN POLY-V BELT
Tighten belt equally on both sides.
Tighten to 125 kg/229Hz.
19 mm wrench
10 mm wrench
Belt tension
frequency meter
1. Loosen 2. Loosen
3. Tighten
Figure 3
Loosen Loosen
Tighten
Tighten
6mm Allen
ADJUST VERTICAL HANDLES
Adjust only a quarter of a turn
at the time.
Handle
unlocked
Handle
unlocked
Figure 2b

Removal of side cover
In the event that it is necessary to remove the side covers, please follow the instructions on figure 4 below
Loosen
Loosen
17 mm Wrench
3 mm Allen
8 mm Allen Hold top nut with
wrench
Turn handle
counter-clockwise
until top nut comes
off
Carefully lift topcover.
Remove 10 screws.
Dismount pedalarm
REMOVE LEFT SIDECOVER
Figure 4
