Body Craft EXP Series User manual

Owner’s Manual
(E1K1-V4) ver. 1.5
1
Base Serial Number: E ____________________
Console Serial Number:____________________
Purchased Date: ___ / ___ / ______
Dealer’s Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
E1000 Elliptical
Open your Camera
App and point it at
the QR Code
Base Serial Number
Serial Number
To see in
FULL COLOR
& additional information,
scan this QR code.

Congratulations and Welcome to the BODYCRAFT Family
Thank you for selecting BODYCRAFT. Your choice reflects a wise investment in you and your
facility. We hope you use it for many healthy years!
BODYCRAFT offers a complete array of high-quality fitness equipment. Please refer to our website at
www.bodycraft.com to view more ways to enhance your lifestyle.
Your BODYCRAFT machine has all the quality and design elements to make your workout extremely efficient
and comfortable. Your new unit is a serious cardio machine that will keep you motivated, challenged and
within reach of your fitness goals. Strength & cardiovascular training is vital for all ages which will provide an
effective workout, producing results that will encourage you to reach your fitness goals and maintain the
body you have always wanted.
Spending 15 to 30 minutes a day, three times a week, is all you need to start seeing the benefits of
a regular exercise program.
As a premium exercise equipment manufacturer, we are committed to your complete satisfaction. If you
have questions, suggestions or find missing or damaged parts, we guarantee your complete satisfaction
through our authorized dealer network or by contacting us directly. Please call your local dealer or
BODYCRAFT.
BODYCRAFT (a division of Recreation Supply, Inc.)
7699 Green Meadows Dr.
Lewis Center, OH 43035
Phone: [phone] am - 5 pm EST Email: [e-mail]
Proof of purchase must be supplied to validate warranty and the product must have been
registered with BODYCRAFT via online at www.bodycraft.com or by calling 800-990-5556
or 740-965-2442 M-F 9 a.m. - 5 p.m. EST.
For parts orders, owner’s manuals, software
update files, exercise guides and contact
information scan this QR code.
Or go to:
https://www.bodycraft.com/customer-support

Page
Product Safety Information
FCC Information ……………………………………………………………… 5
Product Safety ……………………………………………………………. 6 - 7
Product Overview
Product Overview Components & Tools for Assembly .…………………... 8
Hardware Identification Chart ..................................................….………..9
Assembly Parts ………………………………………………………………. 10
Shipping Boxes and What’s Inside Each One ………………………….. 11
How Assemble the Elliptical
Pre Assembly Tips ………….. ..........................................…………. 12
Product Assembly Instructions ..........................................…………. 12- 28
Operation Instructions
Operating Instruction ……………………………………………………….. 29
Cleaning your Elliptical..…………………………………………………… 30
Heart Rate Monitoring Grips & Wireless Receiver …………………….... 31
Erratic Heart Rate Readings & Exercise Tips ……………………………. 32
Installation Checklist ………………………………………………………. 33
Energy Saving function: These consoles are equipped with power saving function.
This means after 10 minutes of inactivity it will automatically power off. Press any
key on the console for X-9LCD or touch the screen for X-10TS/X-16TS to wake up
the console from power save mode.
3
Table of Contents
4
5 - 6
7
8
9
10
11
12 - 29
30 - 31
32
33
34
35

Caution: Please note that changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
Page
Maintenance & Repairs
Information Needed Prior to Contacting Customer Support ……………… 34
Circuit Diagram ………………………………………………………………... 35
Parts Lists ………..………….………………………………………….…. 36 - 37
Parts Exploded Views………………………………….…………….……38 - 39
Warranty
Product Warranty ..........................................................….……..….……... 40
Product Warranty Registration ............................................….…..……… 41
Contact Us Information ……………………………………………………….. 42
Table of Contents
FCC Information
36
37
38 - 39
40 - 41
42
43
44
4

Safety and Warnings - Elliptical
There is a risk assumed by individuals who use this type of equipment.
A moment’s lack of attention can result in an accident, as can failure to
observe certain simple safety precautions.
Read, study and understand the Assembly Instructions and all the warning labels on this
product. Furthermore, it is recommended to familiarize yourself and others with the proper
operation and workout recommendations for this BODYCRAFT product prior to use.
● We recommend that two people be available for moving and assembly of this product.
● Keep children away from the Elliptical. Do not allow children to use or play on the Elliptical.
● Keep children and pets away from the Elliptical when it is in use.
● It is recommended that you place this exercise equipment on an equipment mat.
● Set up and operate the Elliptical on a solid level surface. Do not position the Elliptical on
loose rugs or uneven surfaces.
● Inspect the Elliptical for worn or loose components prior to use.
● Tighten/replace any loose or worn components prior to using the Elliptical.
● Always choose the workout which best fits your physical strength and flexibility level. Know
your limits and train within them.
● Always use common sense when exercising.
● Keep hands, limbs, loose clothing and long hair well out of the way of moving parts.
● Do not wear loose or dangling clothing while using the Elliptical.
● Never exercise in bare feet or socks; always wear correct footwear, such as running,
walking, or cross-training shoes.
● Be careful to maintain your balance while using, mounting, dismounting, or assembling the
Elliptical. Loss of balance may result in a fall and serious bodily injury.
5

Safety and Warnings - Elliptical
● Keep both feet firmly and securely on the Foot Pedals while exercising.
● This Elliptical should not be used by persons weighing over 400 pounds /181 kgs.
● The Elliptical should be used by only one person at a time.
● Make sure that adequate space is available for access to and passage around the
Elliptical; keep at least a distance of 3 feet from any object while using the machine.
● This Elliptical is designed for commercial and home usage.
●Maintenance:
○ Replace any defective components immediately and/or keep the equipment out of use
until the equipment is completely repaired.
○ Clean seat, plastic and frame on a regular basis. We recommend warm, soapy water.
Do not use harsh or abrasive chemicals.
WARNING: Before using this product or any exercise or conditioning program, you should consult
with your personal physician to see if you require a complete physical exam. This is especially
important if you have never exercised before, are pregnant, or suffer from any illness. Follow your
physician's recommendations in developing your own personal fitness program.
READ AND FOLLOW THE SAFETY PRECAUTIONS. FAILURE TO FOLLOW THESE
INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY.
6

Product Overview Components and Tools for Assembly
PHILLIPS SCREWDRIVER #2
w/ Magnetic TIP
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY:
THE FOLLOWING TOOLS ARE RECOMMENDED FOR EASIER ASSEMBLY:
SOCKET SET ⅜ drive w/ 3“ & 6”
EXTENSION for 13mm & 17mm
OPEN & CLOSED WRENCHES
for 13mm & 17mm
ALLEN WRENCHES SET
4mm to 10mm)
PHILLIPS SCREWDRIVERS
#2 w/ Magnetic TIP
TORQUE WRENCH ⅜ DRIVE
7

Unpack the box in a clear area. Use the List of Hardware below to check the contents of the hardware kit. This
chart is provided to help identify the hardware used in the assembly process. Place the washers, the end of bolts,
or screws on the circles to check for the correct diameter. Use the ruler to check the length of the bolts and
screws.
NOTICE: The length of all bolts and screws except those with flat heads is
measured from below the head to the end of the bolt or screw. Flat
head bolts and screws are measured from the top of the head to the
end of the bolt or screw.
Please review below to know the content of the hardware kit.
If a part is not in the hardware bag, check to see if it has been preassembled.
Hardware Identification Chart
8

Unpack the box in a clear area. Follow the List of Assembly Parts below to check and make sure all assembly parts are
present and in good condition. Do not dispose of the packing material until the assembly process is completed. Assembly
tools and hardware kit have included for you to use when assembling the product
Assembly Parts
(12DC / 3A)
NOTE: 9” LCD Console will NOT NEED the Power Adaptor (107) & Power Cord (108) for use. The Power
Adaptor (107) & Power Cord (108) are REQUIRED for the 16” & 10” Touch Screen Consoles or charging the
battery, if needed, for the 9” LCD console.
Adaptor (107) & Power Cord
(108)
9
(5 each)

Shipping Boxes and What’s Inside Each One
Large Box 2 of 2
1 each @ 331 lbs
33” x 29” x 58.3”
Small Box 1 of 2
1 each @ 9 lbs
19” x 6.25” x 5”
(Includes the console
model that was ordered)
BODYCRAFT reserves the right to make improvements at any time which may affect
color, parts, materials, size, weight, or any other aspect.
TIP: Place all parts from the boxes in a cleared area and position them on the floor in front of you.
Remove all packing materials from your area and place them back into the box. Do not dispose of the
packing materials until assembly is completed.
Read each step carefully before beginning.
10

Product Assembly - Pre Assembly Tips
PRE ASSEMBLY TIP #1 – UnPacking “The Monster” (E1200 & E1000).
Once you have taken all the parts and main frame out of the shipping box, place the main
frame forward on packaging foam. ONLY REST ON METAL FRAME NOT PLASTIC.
Very stable and safe to start the Assembly STEPS.
This will ensure a happier and longer life or at least
during the rest of the assembly process!
Not stable and can easily fall
over. DO NOT attempt till
after lower frame is attached.
PRE ASSEMBLY TIP #2 – Wrapping the moving arms ends.
The bottom of both moving arms WILL swing back and forth during
the assembly STEPS, potentially causing damage to machine or the
assembly tech. Take some of the packaging with rubber bands or its
shipping tape and wrap the ends before assembly STEPS.
PRE ASSEMBLY TIP #3 – “ Fill-the-Gap ”
During multiple assembly STEPS hardware can be easily dropped
into the main frame. For extra insurance to keep the assembly
process quick and less stressful, place extra packaging bags under
assembly areas to catch hardware if accidentally dropped.
11
11
Very stable and safe to start the Assembly STEPS.
This will ensure a happier and longer life or at least
during the rest of the assembly process!

Product Assembly
STEP 1 – Remove Packing Tube
Follow the left drawing to remove the Packing Tube (167) by unscrewing 4pcs Washers (122)
and 2pcs Nuts (129).
STEP 2 – Leveler (11) & Main Frame Assembly
Follow the below drawing to attach 2 pcs Levelers (11) under the Main Frame’s Front Stabilizer
(transportation wheels on the front). Screw levelers down to frame with no threads showing.
NOTE: This step could require two people.
TIP: Easy to install the front
Levelers with Main Frame leaning
forward on packaging material
provided.
Many Images shown are GENERIC for both the E1200 and E1000
Ellipticals on most assembly STEPS
TIP: Easy to install the front
Levelers with Main Frame leaning
forward on packaging material
provided.
NOTE: DO NOT REUSE THIS HARDWARE & PACKING TUBE,
PLEASE RECYCLE.
12

Product Assembly
TIP: Easy to assemble Base Frame with Main Frame leaning
forward on packaging material provided. Shown assembled.
STEP 4 – OVERVIEW Base Frame (48) Assembly
STEP 3 – Leveler (11) & Base Frame (48)
Assembly
Follow the drawing on the right to attach 3pcs
Levelers (11) under the Base Frame (48). Screw
levelers down to frame with no threads showing.
NOTE: Flip upside down and install the levelers.
Then flip over with levelers (11) touching the ground
for next STEP.
13
Part # Description Qty
E1K1-011 Leveler 3
E1K1-048 Base Frame Assembly 1

Product Assembly
TIP: Easy to assemble Base Frame
with Main Frame leaning forward
on packaging material provided.
STEP 4 – Install Base Frame Assembly to Main Frame Assembly
Please confirm all bolts/nuts are tightened at this time,
then continue to next Step.
c. “Torque Time” - Tighten the Hex Bolts (156) and
Thin Nylon Nuts (135) to the recommended 20 ft-lbs +/- 2 lbs.
20 ft-lbs
+/- 2 lbs
14
Part # Description Qty
E1K1-001 Main Frame Assembly 1
E1K1-048 Base Frame Assembly 1
E1K1-115 Lock Washer (M8) 2
E1K1-121 Washer (M8 × 30 × 2.0t) 2
E1K1-123 Washer (M10 × 23 × 2.0t) 2
E1K1-135 Thinner Nylon Nut (M10 × p1.5) 2
E1K1-156 Bolt (M8 × p1.25 × 55mm) 2

Product Assembly
STEP 5 – Adjust the Handlebar & Remove Upper Cover (30)
a. First Rotate the Fixed Handlebar
(85) upward as shown.
b. Then remove the Upper Cover (30) by first
removing Screws (147).
NOTE: Place the screws in a safe place for
later installation during STEP 11.
PHILLIPS SCREWDRIVERS #2
w/ Magnetic TIP
Recommended Tool:
PHILLIPS SCREWDRIVERS #2
w/ Magnetic TIP
Recommended Tool:
TIP: When lifting the Upper
Cover (30), stop after 5” to
disconnect the two electrical
connections (107) (108). EASY
to damage cable & connectors
during installation.
* Not covered under warranty
if damaged during assembly.
15
c. Then completely remove the Upper Cover
(30) and place in a safe place for later
installation during STEP 11.

STEP 7 – Install Upper Handlebars Assemblies to the Back Swing Arms
Product Assembly
a. Attach the Upper & Bottom
Adjustment Covers (81, 82) to the
Adjustment Bracket (83) and fully
tighten with 1pcs Phillips Truss Screw
(M4 x 20mm) (141).
b. Repeat STEP 6a for Left side.
a-b: Image show below for Right Side, repeat for Left Side.
STEP 6 – Base Frame (48) Assembly
c. “Torque Time” - Tighten the Hex Bolts (156) to the recommended
….20 ft-lbs +/- 2 lbs.
20 ft-lbs
+/- 2 lbs
PHILLIPS SCREWDRIVERS #2
w/ Magnetic TIP
Recommended Tool:
16
STEP 6 – Assembly Hardware Pack & 13mm Wrench (supplied) TIP
a. Fully unpackage the Assembly
Hardware Pack and label the hardware
number on cardboard in front of each
type, for an easy assembly process from
STEP 7 till STEP 16.
b. If using the supplied
13mm Wrench, find
the soft packaging
material that is in the
shipping box, and
place wrapping with
extra clear shipping
tape on the end.
NOTE: EXTREMELY sharp edges that could
cut your hand or scratch the paint.
071
Part # Description Qty
E1K1-066 Left Upper Handlebar Assembly 1
E1K1-067 Right Upper Handlebar Assembly 1
E1K1-168 Bolt (M8 × p1.25 × 16mm) 8

Product Assembly
STEP 7 – (Continued) Install Rotator Cuffs (plastic covers)
STEP 8 – OVERVIEW Stationary Handrail (74, 75) & Rear Support Tube (102, 103)
Assembly
Overview image for
STEP 8a thu STEP 8i
PHILLIPS SCREWDRIVERS #2
w/ Magnetic TIP
17
PHILLIPS SCREWDRIVERS #2
w/ Magnetic TIP
Recommended Tool:
d-e: Image show below for Rt Side,
repeat for Lt Side.
Part # Description Qty
E1K1-063 Front Rotator Cuff 2
E1K1-064 Back Rotator Cuff 2
E1K1-147
Screw (M5 × p0.8 ×
15mm) 8

Product Assembly
a.. Remove all PREASSEMBLED hardware from
Rear Support Tubes.
NOTE: Save them for STEP 8c.
STEP 8 – (Continued) a thru c.
b-c: Attach the Stationary Handrails Lt &
Rt Sides to the Rear Support Tubes.
Please Hand Tighten All Bolts Until STEP 9
18
Allen Wrench 5mm
Recommended Tool:
Part # Description Qty
E1K1-074 Left Stationary Handrail 1
E1K1-075 Right Stationary Handrail 1
E1K1-102 Left Rear Support Tube 1
E1K1-103 Right Rear Support Tube 1
E1K1-151 Bolt (M8 × p1.25 × 15mm) 8
Part # Description Qty
E1K1-151 Bolt (M8 × p1.25 × 15mm) 8

Product Assembly
d. Remove all PREASSEMBLED hardware from Stationary
Handrails both Rt & Lt Sides and save for STEP 11.
e. Remove all PREASSEMBLED hardware from the Base Frame Assembly both Rt & Lt Sides
and save for STEP 8h.
STEP 8 – (Continued) d thru e.
Please Hand Tighten All Bolts Until STEP 9
19
Part # Description Qty
E1K1-074 Left Stationary Handrail 1
E1K1-075 Right Stationary Handrail 1
E1K1-102 Left Rear Support Tube 1
E1K1-103 Right Rear Support Tube 1
E1K1-116 Lock Washer (M10) 4
E1K1-122 Washer (M10 × 19 × 1.5t) 4
E1K1-147 Screw (M5 × p0.8 × 15mm) 4
E1K1-158 Bolt (M10 × p1.5 × 20mm) 4
Part # Description Qty
E1K1-116 Lock Washer (M10) 4
E1K1-123 Washer (M10 × 23 × 2.0t) 8
E1K1-134 Nylon Nut (M10 × p1.5) 4
E1K1-147 Screw (M5 × p0.8 × 15mm) 4
E1K1-158 Bolt (M10 × p1.5 × 20mm) 4

Product Assembly
STEP 8 – (Continued) Assembly of Stationary Handrail, f thru g.
Please Hand Tighten All Bolts Until STEP 9
f-g:. Attach the Stationary Handrails on both Rt & Lt Sides to the Main
Frame Assembly.
TIP – “ Fill-the-Gap ”
During STEP 8 thru STEP 15 hardware can be easily
dropped into the main frame. For extra insurance to keep
the assembly process quick and less stressful, place extra
packaging bags under assembly areas to catch hardware if
accidentally dropped.
20
Part # Description Qty
E1K1-074 Left Stationary Handrail 1
E1K1-075 Right Stationary Handrail 1
E1K1-102 Left Rear Support Tube 1
E1K1-103 Right Rear Support Tube 1
E1K1-116 Lock Washer (M10) 8
E1K1-122 Washer (M10 × 19 × 1.5t) 8
E1K1-158 Bolt (M10 × p1.5 × 20mm) 8
