BOERPLAY PB Picnic Table model 321 User manual

PB Picnic Table model 321
PKNE103.210
Powered by TCPDF (www.tcpdf.org) 1 / 1

Benaming
Title
Opmerking
Comment
Datum
Date
Tekening
Drawing
TOE PKN 103 210
Picknicktafel
Rebo
26-10-2015
BOER
SPEELTOESTELLEN
Hoofdafmetingen Main dimensions
0,75m
1,95 m
0,70m

Benaming
Title
Opmerking
Comment
Datum
Date
Tekening
Drawing
TOE PKN 103 210
Picknicktafel
Rebo
26-10-2015
BOER
SPEELTOESTELLEN
Bodemplan Groundplan
0,50m
0,65m
0,15 m 1,08 m 0,15 m
Grondmarkering
Ground level marker

Benaming
Title
Opmerking
Comment
Datum
Date
Tekening
Drawing
TOE PKN 103 210
Picknicktafel
Rebo
26-10-2015
BOER
SPEELTOESTELLEN
Modules Modules
Opmerking
BenamingRev.Bew.
Volgnr
Progr.Type#Nr
Rebo
Poot picknicktafel
210103
PKN
MOD2
1
ReboBlad picknicktafel
211103
PKN
MOD12
Geleverde modules:
Zie tabel
Montageinstructie:
- De modules kunnen correct geassembleerd worden met de voorgeboorde gaten.
Montagevolgorde:
1 - Graa de gaten volgens het bodemplan
2 - Assembleer en plaats ta el
3 - Controleer o het toestel voldoet aan de a metingen zoals op blad 'a metingen'
4 - Dicht de gaten en verdicht het zand
Controles:
1 - Correcte opbouw en alle bevestigingsmiddelen
Supplied modules:
See table
Assembly instruction:
- The modules can be assembled correctly using the predrilled holes.
Assembly sequence:
1 - Dig the holes according to the ground plan
2 - Assemble and place table
3 - Check that the equipment con orms to the dimensions shown on sheet 'dimensions'
4 - Close the holes and compact the sand
Checks:
1 - Correct assembly and all the asteners
1
1
2

LOGBOOK
Type indication Straatmeubilair
Article number PKNE103.210
Product Name PB Picnic Table model 321
Maximum fall height nvt
Construction year 2023
Certificate 0183402366
Inspection body NVT
Manufacturer name Boer Speeltoestellen
Hyacintstraat 2 - 4255 HX Nieuwendijk
Phone: [phone]
Fax: [phone]
Installer name _______________________________________________________
_______________________________________________________
_______________________________________________________
Playground location _______________________________________________________
Information about the owner of the playground
Name: _______________________________________________________
Address: _______________________________________________________
Zipcode and city: _______________________________________________________
Contact: _______________________________________________________
Phone number: _______________________________________________________
Information about the manager of the playground
Name: _______________________________________________________
Address: _______________________________________________________
Zipcode and city: _______________________________________________________
Contact: _______________________________________________________
Phone number: _______________________________________________________
Powered by TCPDF (www.tcpdf.org)

LOGBOOK
Inspection and maintenance
Date of
inspection
maintenance
Time of
inspection
maintenance
Name
executor of
inspection
Name
executor of
maintenance
Found defects Parts to be
replaced
Accidents
Date
accident
Age of
victim Probable cause of injury Occurred injury Measures taken after accident

Inspection and maintenance intervals
Nr Inspection Maintenance
months
between
inspections
1
Verify equipment's stability, junctions and
missing parts Inspect bolts, screws and nuts for
absence, jams, corrosion and wear
Add missing parts, secure joints, apply
missing fixing agent and replace
corroded parts
1
2
Check suspension for wear Replace worn parts and/or remove non-
functioning parts
1
3
Inspect rotating parts such as hinges, rolling-
element bearings, etc for wear and acceptability
Replace worn parts and/or remove non-
functioning parts
1
4
Check wood for splinters, unacceptable damage
and signs of rot, especially at ground level
Repair damage Replace affected wood
Smoothen splintered wood and sharp
edges
1
5
Inspect foundation for stability, tearing and
coverage
Restore foundation and covering
material
3
6
Examine rubber and synthetic parts for wear,
damage and breakage Replace for OEM original parts
3
7
Examine fibre reinforced plastic parts, especially
slides, for wear
Replace for OEM parts if the fibres are
visible
6
8
Inspect metal for corrosion and damage in the
coating
Restore any damaged coating (after
removing rust and applying primer)
6
9
Check ropes, cables, chains and nets for wear
and damage Steel cables and nets which are
tensioned must be checked for tension
Replace parts where necessary Steel
cables and nets must be tensioned
3
10
Inspect equipment for unsafe changes and
additions
Remove unsafe additions and correct
unsafe changes
1
11
Inspect safety surfaces Restore and repair where necessary
1
Remarks
1 If used intensively, all points require extra attention
2 Extreme weather conditions and locations may require a higher inspection frequency Discuss this with the
supplier
3 Vandalism-sensitive locations require stricter inspections, possibly daily
4 Re-tighten all connections in Robinia equipment two months after first use
5 Re-span spatial networks two months after first use
6 Check the terrain regularly for items that do not belong there, are unsafe or may be used wrongly Examples
are poisonous plants, glass shards, etc Frequency depends on strain

7 Remember that bad maintenance leads to unsafe conditions and notably faster impoverishment of the
playground area
8 Replacement parts can be ordered at the manufacturer with the OEM part numbers on the module drawing
Drawings can be found in the user guide
9 The impact area shall be provided with impact attenuating surface according to the specified falling height
•Up to 0,6m height of fall: no requirements regarding impact attenuation
•Turf, topsoil: suitable up to 1000mm height of fall
•Loose fill (sand, gravel, bark, woodchips): up to 3000mm height of fall Layer thickness is height
of fall / 10 +100mm, with a minimum of 300mm
•Synthetic surfaces (Rubber tiles, artificial turf, wetpour, tigermulch etc ): height of fall and layer
thickness according to the information of the supplier
10 This list is conform the CEN-standard "playground equipment and surfacing NEN-EN 1176-7"
Improving the
foundations
(for equipment without concrete in the standard
foundation)
If the impact area is loose fill (sand, gravel, bark,
woodchip, etc ), or if the soil itself does not add to
stability of the equipment (i e sand, pumice, peat soil)
pour 50l of concrete per post
For instance:
Square: 0,6 x 0,6 x 0,16m
Round: ø0,35 x 0,5m
Round: ø0,50 x 0,2m

Dit toestel is geen speeltoestel conform het warenwetbesluit attractie- en speeltoestellen,
en is dus niet als zodanig gecertificeerd.
This equipment is not playground equipment, so it has not been certified as such.

Benaming
Title
Opmerking
Comment
Datum
Date
Tekening
Drawing
MOD PKN 103 210
Poot picknicktafel
Rebo
26-10-2015
BOER
SPEELTOESTELLEN
Samenstelling module Assembly module
Opmerking
BenamingRev.Bew.
Volgnr
Progr.Type#
Nr
M12 - VZ 8.8
Zeskantmoer
010012017B V71
M12 x 160 - VZ 8.8
lotbout
160012026B V12
M12 x 120 - VZ 8.8
lotbout
120012026B V23
M12 - VZ 8.8
luitring
003012030B V
74
M12 - VZ 8.8
Veerring
002012032B V
75
M12 x 610 - VZ 8.8Draadeind 610012060B V26
Rond 36Meubeldop
090036DOPK T
77
1
34
57
12
4
57
13
4
57
1
4
5
7
145 7
6

Benaming
Title
Opmerking
Comment
Datum
Date
Tekening
Drawing
MOD PKN 103 211
Blad picknicktafel
Rebo
26-10-2015
BOER
SPEELTOESTELLEN
Samenstelling module Assembly module
Opmerking
BenamingRev.Bew.
Volgnr
Progr.Type#
Nr
M6 x 35 - VZ 8.8
Metaalsch oef
035006071BSV
4
1
Rond 36Meubeldop 090036DOPKST
4
2
L= 20 mmBuis 42x36 906076
PKN
OME423
L= 1900 mmBuis 31.8x2.6 372190318OME2
4
3 4
2
1
(18x)
ORE.PKN.070.005
ORE.PKN.150.011
ORE.PKN.070.004
ORE.PKN.150.011
ORE.PKN.070.005
