Bogen MIC2S User manual

MIC2S
Microphone Input
Module
Features
• Electronically-balanced
• Screw terminal connections
• Phantom power
• Gain/Trim control
• Hi- and Lo-cut filters
• Adjustable voice enhancer
• Audio gating with threshold adjustment
• Variable signal limiter
• 4 levels of available priority
• Can be muted from higher priority modules
• Can mute lower priority modules
Printed in Taiwan. 0208
© 2002 Bogen Communications, Inc.
54-2078-01R3
Specifications subject to change without notice.
50 Spring Street, Ramsey, NJ 07446, U.S.A.
201-934-8500; Fax: [phone]
www.bogen.com
Block Diagram

J5 J6
J7
J4
J3
Gain
Provides control over the level of input signal that can be applied to the
internal signal buses of the main unit. Allows a way to balance the input lev-
els of various devices so that the main unit controls can be set to relative-
ly uniform or optimum levels.
Hi-Cut
Allows a reduction in the amount of treble frequencies above 8 kHz.This is a
cut only filter and does not allow boosting treble. Clockwise rotation increas-
es the amount of cut.
Gate
Controls the minimum necessary input signal level to turn the module’s out-
put on and apply signal to the main unit's buses. Clockwise rotation increas-
es the necessary signal level required to produce output as well as the sig-
nal threshold necessary to cause the module to mute other modules.
Enhance
Controls the amount of intelligibility enhancement applied to microphone sig-
nal. Intelligibility enhancement provides a crisper sounding signal that is easier
to understand over background noise. Clockwise rotation increases the effect.
Limiter (Limit)
Sets the signal level threshold at which the module will begin to limit the
level of its output signal. Clockwise rotation will allow more output signal
before limiting, counterclockwise rotation will allow less.The limiter moni-
tors the module’s output signal level,so increasing Gain will affect when lim-
iting takes place.
Connections
Uses a screw terminal block to make connections to the module’s input. The
input is low-impedance, electronically-balanced for excellent noise immunity.
Connect signal to + and - terminals and cable shield to G terminal.
Jumper Selections
Priority Level*
This module can respond to 4 different levels of priority.
Priority 1is the highest priority. It mutes modules with
lower priorities and is never muted. Priority 2 can be muted
by Priority 1modules and mutes modules set for 3 or 4.
Priority 3 is muted by either Priority 1or 2 modules and
mutes Priority 4 modules. Priority 4 modules are muted by
all higher priority modules.
*The number of priority levels available is determined by the
module capacity of the amplifier the modules are used in.
Gating
Gating can help reduce noise in systems with multiple mic
inputs. You can disable gating (turning off) of the module’s
output when insufficient audio is present at the input.
Detection of audio for the purpose of muting lower priori-
ty modules is always active regardless of this jumper setting.
Phantom Power
24V phantom power can be supplied to condenser micro-
phones when jumper is set to On position. Leave off for
dynamic mics.
Bus Assignment
This module can be set to operate so that the MIC signal
can be sent to the main unit’s A bus, B bus, or both buses.
Module Installation
1. Turn off all power to the unit.
2. Make all necessary jumper selections.
3. Position module in front of desired module bay
opening, making sure that the module is right-
side up.
4. Slide module on to card guide rails. Make sure
that both the top and bottom guides are
engaged.
5. Push the module in to the bay until the faceplate
contacts the unit’s chassis.
6. Use the two screws included to secure the mod-
ule to the unit.
WARNING:
Turn off power to unit and make all jumper
selections before installing module in unit.
Lo-Cut
Allows a reduction in the amount of bass frequencies below 100 Hz.This is a
cut only filter and does not allow boosting bass. Clockwise rotation increases
the amount of cut.
