Bogen KFLDS30T User manual

• Self-aligning, field-replaceable diaphragm
• High-intelligibility and efficiency
• Screw terminals for easy audio line connection
• Plastic cover protects connectors and tap selector
switch, also provides strain relief for the audio line
• Optional terminal and tap selector fitting (Model
TCSPT1) allows placement of rigid or flex conduit
to wrap to back of horn
• Banding slots on mounting bracket permit mount-
ing on beams or pillars, or with a beam clamp
(BC1, sold separately)
• Textured mocha enamel finish on aluminum, match-
ing polycarbonate horn flare
• Lifetime limited warranty
The Bogen KFLDS30T is a wide dispersion, high-intelli-
gibility, reentrant-type horn loudspeaker designed for
applications where wide angle projection and directivi-
ty is a necessity.
The flare-shaped horn can be rotated to project wider
dispersion in either the horizontal or vertical plane.The
speaker’s all-purpose tilt-and-swivel base simplifies
installation and positioning.
Its sturdy, weatherproof, polycarbonate and aluminum
construction is ideal for both indoor and outdoor use.
Screw terminals make installation fast and easy.A plas-
tic cover protects the connectors and 70V/25V tap
selector switch, as well as provides strain relief for the
audio line.
• 30 Watts max. @ 70 volts or 15 Watts max.
@ 25 volts
• Weatherproof polycarbonate and aluminum
construction
• Driver enclosed in waterproof housing
• 70° × 95° dispersion with rotatable horn flare
• All-purpose mounting bracket provides precise
positioning in the vertical and horizontal planes
with a single adjustment
• Seven-position, weather-sealed tap selector switch
• Rotary switch-selected power taps
• Tap settings for 70V: 30, 15, 7.5, 3.7, 1.8;
for 25V: 15, 7.5, 3.7, 1.8, 0.9, 0.5, 0.25
Features
Description
Wide Dispersion
Reentrant Horn
Loudspeaker
Model KFLDS30T
Specifications subject to change without notice.
© 2005 Bogen Communications, Inc.
Part No. 54-8023-27B 0802

Power Rating (RMS): 30 Watts continuous (70V amplified systems);
15 Watts continuous (25V amplified systems)
Frequency Response: 300 Hz to 12 kHz
Impedance: 25/70 volts
Power Taps: 70V: 1.8, 3.7, 7.5, 15, or 30 Watts
25V: 0.25, 0.5, 0.9, 1.8, 3.7, 7.5, or 15 Watts
Sound Pressure Level: 119 dB @ 1m on axis @ 30 Watts (avg 400 Hz -3 kHz)
104 dB @ 1m on axis @ 1Watt (avg 400 Hz -3 kHz)
Dispersion: 70° x 95°, rotatable horn flare
Dimensions: 14-3/8" W × 8-1/4" H × 12-7/8" D
Shipping Weight: 8 lb.
Finish: Textured mocha enamel finish on aluminum, matching
polycarbonate horn flare
Technical
Specifications
The loudspeaker shall be a Bogen Model KFLDS30T. It
shall be a wide dispersion, reentrant-type horn loud-
speaker. The frequency response shall be 300 Hz to 12
kHz. Rated power output shall be 30 Watts RMS con-
tinuous when driven by a 70V amplified system and 15
Watts RMS when driven by a 25V amplified system.
Dispersion shall be 70° × 95° with the rotatable horn
flare allowing control of the dispersion orientation.
Sound pressure level, measured 1meter on axis at 30
Watts input, shall be at least 119 dBspl.
The unit shall incorporate a seven-position weather-
sealed switch to allow selection of output power taps.
Power tap capacity shall be adjustable at 70V to 1.8, 3.7,
7.5, 15, or 30 Watts; and at 25V to 0.25, 0.5, 0.9, 1.8, 3.7,
7.5, or 15 Watts.
The loudspeaker shall be of weatherproof aluminum
construction with polycarbonate horn flare. The driver
shall be enclosed within a waterproof housing.The loud-
speaker shall include a self-aligning, field-replaceable
diaphragm.
Screw terminals shall be provided for connection to the
audio line. A plastic cover shall be provided to protect
the connectors and tap selector switch, and provide
strain relief for the audio line. An optional terminal and
tap selector fitting (Model TCSPT1, sold separately)
shall allow placement of rigid or flex conduit to wrap to
back of horn.
An all-purpose mounting bracket shall provide precise
positioning in the vertical and horizontal planes with a
single wingnut adjustment. The bracket shall include
banding slots to permit mounting the loudspeaker on
beams or pillars and provisions for use of a Bogen BC1
beam clamp.
Bracket and horn loudspeaker shall be finished in
mocha.The unit shall measure 14-3/8" W × 8-1/4" H ×
12-7/8" D. Shipping weight shall be 8 lb.
Architect
and Engineer
Specifications
50 Spring Street, Ramsey, NJ 07446, U.S.A.
201-934-8500 FAX: [phone]
Web Site: www.bogen.com
