Bolens 15FE-01 User manual

BOLENS PRODUCTS DIVISION
Food Machinery& ChemicalCorporation
0 PortWashingtoi^Wisconsin

TOYOUTHE OWNER
ThisOwnersManualhasbeenespeciallyprepared
tobringtoyourattentionallinformationneededto
operateandmaintainyourEconomytractorwith
maximumefficiency.Readtheseinstructionscare-
fullybeforeassemblingoroperatingthetractor.
Throughpropercareandoperation,asexplained
inthismanual,youwillobtainlong,efficientservice
andtroublefreeoperationfromit.
Informationregardingoperationandmaintenanceof
thetractorengineisnotincludedinthismanual.
Aseparateengineinstructionmanualisincludedwith
eachtractorandshouldbeconsultedforallinfor-
mationconcerningadjustmentsandoperation.
REGISTERYOUR TYPEANDSERIALNUMBER
Registeryourtractortypenumber,serialnumber
andengineserialandtypenumberinthespace
providedbelowandalwaysrefertothemwhenwrit-
ingforinformationororderingparts.Complete
theregistrationcardreceivedwiththetractorand
returntothefactory.A nameplateshowingtype
andserialnumberofthetractorisattachedtothe
frame.Theenginetypeandserialnumberison
theenginenameplate.
TRACTORTYPENO,
TRACTORSERIALNO
ENGINETYPENO
ENGINESERIALNO
SPECIFICATIONS
Engine: FourcycleaircooledClin-
tonModel700Engine.2
H.P.at3600RPM(max.
groundspeed)equippedwith
ropestarterandrotatingair
intakescreen.
Wheels: Reversiblesteelflange
wheelswith4 inchrim.
Tires:
5-12TractiontypeGarden
Tractortires,airfilled.
6lbairpressurerecom-
mended.
FinalDrive: Enclosedstampedsteel,
greasefilledgearcasewith
machinedandsteelgear
train.Casesealedtoex-
cludedirtandmoisture.
Castironwheelhubsdriven
bydoubleactingratchet
pawls.
PrimaryDrive: V-Beltwithballbearing,
beltidlertype,clutchoper-
atedbya squeezegrip
clutchcontrolontheL.H.
handlebar.
Bearings: Needletypeprecisionrol-
lerbearingsinentiredrive
exceptingwheelhubs.
HandleBars: Handlebarsareadjustable
toconvenientheightforop-
eration.
2
FrontHitch: Patented"SnapHitch."No
toolsrequiredforattaching
implementsonlooseparts.
RearHitch: "TriggerHitch."Notools
requiredforattachingim-
plements,nolooseparts.
PowerTakeOff:
Forfrontmounted
attachments 2-1/2incheffectiveoutside
diametersemi-deepgroove
sheave.Adjustablebeltfin-
gerstogivebetterdeclutch-
ingoftheattachmentdrives.
Attachmentidlerclutchcon-
trollinkageisadjustable
andisa partofthetractor
itself.
CropClearance 9-3/16inches
FuelCapacity: 2qt.
Speeds: Forwardonly.Variable
1.5to2.9M.P.H.at3600
RPM(max.governedengine
speed.)Lowerspeedsmay
beattainedbyreducingen-
ginespeed.
WidthDimensions:
Overalloverwheels
Wheelssetin
Wheelssetout
Overallincluding
offsethandlebars
22.5inches
23.24inches
Wheelssetin29.4inches
Wheelssetout32.24inches
TreadWidth:
Wheelssetin
Wheelssetout 17.5inches
24inches

INTRODUCTION
The 15 FE Tractor is powered by a2 H.P.,four
t^^^ cycle, air cooledenginewithropestarterandrota-
^atir^screen.
Power is transmittedfrom the engine by V-belt to
anenclosedstampedsteel,greasefilledgearcase
withmachinedsteelgearsdriving in therearaxle.
Castironwheelhubs are driven by doubleacting
ratchetpawls.
Thetires are5-12 tractiontype,carrying 6 lbs.
pressure,mountedon4 inchreversiblesteelwheels.
Clutchcontrol,frontattachmentleverandthrottle
control are mounted on upperhandleassembly for
convenience of the operator.
Frontattachments are mountedwithBolen'sSnap
Hitch and rearattachments by use ofa Trigger
Hitch.Bothoperations canbe donequickly and
easilywithout theuse of tools.
Thewheels are reversibleandcanbedishedinward
oroutwardgivingwheelsettings of 17-1/2inches
or 24 inchesfromcenter to center of tires.
CONTROLLEVER
IDLER PULLEY
Figure 1
3

ASSEMBLY
Thetractor is shipped in fourparcels; a carton
containingtheengine, a cartoncontainingthechassis,
abundleconsisting of handleassemblywithcontrol
rod anda bundle of wheels. A smallcartoncon-
taininghardwareparts is includedwithchassis.
Removepartsfromcartons.
Removeattachmentcontrolrodwiredtomainhandle
assembly.Positionlowerends of handleassembly
overrear of tractorframe(Fig. 2). Alignupper
holes in handleswithupperholes in frame andin-
sert3/8-16 X 1-1/2capscrews,lockwashersandnuts
but donot tightencompletely.Pivothandleassem-
bly so lowerholesalignwithcenterholesintractor
frame and securewith3/8-16 x 7/8 capscrews,
lockwashers and nuts.Tightenuppercapscrews.
BELTSTOPS
ENGINE SHEAVE
DRIVE SHEAVE
Figure 2
Positionwheels on tractorhubs in such a manner
thateachwheelwillrotate inthe direction in-
dicated by arrow on tire.Secureeachwheelwith
3hubboltsprovided.
Mountengine to front of chassiswith5/16-18 x
3/4capscrews,lockwashers and nuts.Tighten
capscrewssecurely.
Toinsurelongbeltlife itis essential the inside
section of enginesheave and tractordrivesheave
areproperlyaligned as shown inFig.3.Ifad-
justment is necessary,loosen set screwsinengine
sheave,movesheaveinward or outward to obtain
properalignmentwithtractorsheave and retighten
setscrews.Installdrivebeltaroundinnersection
ofenginesheave,betweenupper and lowerbelt
stops, overidlerpulley and arounddrivesheave.
The two wirebeltstops are usedonlywithbelt
drivenfrontattachments and require no adjustment
fortractoroperation.
Figure 3
Unwindthrottlecableassemblyfromaroundengine.
Runcablebackward and upwardalonglefthandle
andundercrosshandle.Alignholes in throttlelever
withhorizontalholesinsidetractorhandle.Insert
10-24 X 1-1/4machinescrewsthroughthrottlelever
andhandle and secure on outsidewithacornlock
nuts(Fig. 4).
Thread oneofthe10-24 locknuts on free endof
clutchcableapproximately 1/2 inch.Nextinsert
theend of cablethroughhole in bracketdirectly in
front of clutchleverandsecurebyturningtheother
10-24lock nuton cable.Loosenscrew in clamp
onclutchlever.Insertclutchwireintohole in
clamp and retightenscrew(Fig. 4).
Secureclutch and throttlecables to tractorhandle
withtwoclipsprovided.
CONTROL
LEVER
THROTTLE
CONTROL
LEVER
LATCH
Figure 4
4

ASSEMBLY
Removecotter pin andbearingpinfromend of
attachmentcontrollever.Positionleverinbracket
\oncenter of handlecrossbarandreplacebearing
pinandcotterpin(Fig. 4).
Insertbottomformedend of controlrodthrough
hole in swivellinkfrominsideandsecurewith
springclip.
ThelowerattachmentcontrolrodIncludedInchassis
cartonshouldbeinstalledonlywhen a frontmounted
attachment is beingused.Whenneeded, it should
beinstalledoverthelowerend of thelongcontrol
rodandtotheoutsideofswivelcontrollink(Fig. 5).
Thefrontend of thelowerrod is thensecured to
theattachmentidlerassembly.
Figure 5
LUBRICATION
Thetractor is equippedwithsixgreasefittings
located as follows: (2) one on eachwheelhub(1)
idlerpulley, (1) transmissionhousing, (1) axle
housingbeneathframe, (1) countershafthousing
beneathframe.Thesefittingsareproperlygreased
whenunitleavesfactorybutcompletegreasingwith
regularpressuregreaseisrecommendedforapprox-
imatelyevery10hours of operation.
Thetransmissionhousing is lubricatedwitha liquid
geargrease atthe factorywhichwilllast a con-
siderablelengthoftimeunless a leakshoulddevelop.
It is recommendedthat asa precautionarymeasure
asmallamount of regulargrease be addedeach
time the tractor is lubricated.Theplugonside
ofcover is not anoil levelplugbut is provided
forremoval of geartrainshaft.
OPERATION
IMPORTANT:THEENGINECRANKCASEISWITH-
OUTOILWHENSHIPPEDFROMFACTORY. BE-
FORESTARTINGENGINEBESURETOFILLTHE
CRANKCASE WITHLUBRICANTSPECIFIED IN
ENGINEMANUAL.Furtherinstructionspertaining
totheengine,itscareandoperationarecontained
intheenginemanual.Readtheseinstructionscare-
fully.
Theclutchleverlocatedbelowthelefthandleassem-
blyoperatestheidlerpulleywhich in turnengages
anddisengagesthedrivebelt.Todisengagedrive
belt,drawclutchleverupwarduntilthelatchcatches
andlockslever in position. To disengagedrive
belt,applyupwardpressure on clutchlever so
latchcanbereleasedandthenslowlyreleaseclutch
leverfully.
Beforestartingtheenginebesuretheclutchlever
isdisengaged. The attachmentcontrollever on
handlecrossbarshouldbeinforwardordisengaged
position if a frontmountedattachmentisbeingused.
ADJUSTMENT
Thehandlesare at mediumheight as assembled in
previousinstructions. If desired,they maybe
raised or lowered by placingcapscrews in handle
ends in upper or lowerholes in tractorframe.
ForsatisfactoryperformanceitIsimportantthebelt
tension be carefullyadjusted.Thisadjustment is
madebymovingtheclutchwireinward or outward
inclamponclutchlever.Whenproperlyadjusted,
thetop of thebeltshoulddepressapproximately
1/2inchunderslightthumbpressurewhenclutch is
engaged.
5

EXPLODED DRAWING

PARTS LIST
Ref.
Part
No.
Ref.
Part
No.
No. No. Description Req'd. No. No. Description Req'd.
1 1701393 Wheel
2 49
1703055 Gasket
1
2 1118554 RetainingRing 2 50 1703054 Seal 1
3 1703073 ThrustWasher 6 51 1702917 Gear 1
4 1706012 Hub 2 52 1703942 ClusterGear(W/Bearlngs) 1
5 101085 WheelBolt 6 53 1702951 StudBolt 1
6 1104954 GreaseFitting 5 54 1702953 Shaft 1
7 1703072 Pin 2 55 1185001 Sq.Key1/8x 1 1
8 1705119 BowedWasher 2 56 1703052 Washer 2
9 1702857 Drive Hub 2 57 1185165 Bearing 2
10 1705108 Washer 2 58 1185074 Bearing 2
11 1702961 Hub Pawl 2 59 1702907 GearCase 1
12 1703066 Roll Pin 4 60 1705117 CountershaftSeal 1
13 1705106 Drive Pin 2 61 1705118 AxleSeal 1
14 1705281 Pawl andHub Assy (7 thru 62 1703083 Sheave 1 Pawl andHub Assy
13) 63 1701074 Washer As
15 1703071 FrictionSpring 2 Req'd.
16 1703070 Flange 2 64 1118808 RetainingRing 1
17 1185164 Screw 6 65 1706269 Handle 1
18 1185300 Bearing 2 66 1703539 Grip
19 1181093 Woodruff Key1/4x 1-1/8 1 67 1703854 UpperControl Rod 1
20 1706449 Axle 1 68 308878 ThrowoutLever 1
21 1703053 Key 1 69 180886 Grip 1
22 1703061 Pin 1 70 130147 Pin 1
23 1703060 Pin 1 71 182694 ThrottleAssy 1
24 1703057 Latch 72 1701079 ControlWire 1
25 1703058 Spring 1 73 1701080 ControlWireHousing 1
26 1704699 Frame 1 74 1702023 ClutchLever 1
27 1703653 Sleeve 1 75 1701993 Latch 1
28 1700984 Clin 1 76 1702036 Lever Pin 1
29 1703643 ControlLinkBracket 1 77 149925 CableClip
30 1703642 ControlLink 1 78 1703568 Control Rod 1
31 1703635 Bracket 1 79 1703011 SpringClip
32 1702870 Draw Bar Assy 1 80 1110094 SelfLocking Nut 1
33 1703963 LowerPivotHinge 1 81 1703051 Bolt 2
34 1703059 Latch Rod 1 82 HexHd Capscrew 3/8-16 x
35 229358 HandWheel 1 3/4 2
36 Engine - ClintonA2100 1 83 HexHd Capscrew 7/16-14
37 1104333 SqKey3/16x 1 1 X1-1/4 2
38 1706728 Sheave 1 84 HexHd Capscrew 5/16-18
39 Set Screw 5/16-18 x 5/8 x3/4 6
40 1706729 BeltGuard 1 85 1703663 ClutchWire 1
41 1704260 BeltStop 1 86 1703664 WireHousing 1
42 1108473 DriveBelt 40" 1 87 ( RdHdMachScrew10-24x1-1/4 2
43 1185045 Bearing
87
\1703554 Acorn Nut 2
44 1703081 IdlerPulley 1 88 1185106 Lock Nut 2
45 1703638 IdlerBracket 1 89 1104957 GreaseFitting 1
46 1703615 Spring 1 90 1703540 BeltStop 1
47 1703056 PlugButton 1 91 1185251 Screw 10-32x 1/2 8
48 1702909 GearCover 92 1706726 Support 1
7

NATIONWIDi
SERVICE
QemkB
PIONEER MANUFACTURERS
OFGARDENTRACTORS
AND EQUIPMENT
TheBolensProductsDivision of FoodMachin-
eryandChemicalCorporationhasestablished
anationwidereputation for qualityproducts.
Thisreputation,gainedthroughadvanced en-
gineeringandefficientmanufacturingmethods
isimportanttorememberwhenbuyingreplace-
mentparts.
GenuineBolenspartsassure the continued
highperformanceoriginallybuiltintoyour
equipment.Bolensdealers are appointed on
theirability to providepromptefficientser-
vice, andare backed by the Bolensservice
organization.Whenreplacingpartsconsult
yournearestBolensdealer for GENUINE
BOLENSSERVICEPARTS,
Whenbuying new equipment,remember the
protectiveserviceofferedthrough the Bolens
dealer in yourcommunity.
Bifkns Products Division
FOOD MACHINERYANDCHEMICALCORPORATION
PORTWASHINGTON,WISCONSIN
KEN COOK L.ITHO U.S.A.
FormNo.550787
