Onespace 50-LD0101SHLF User manual

For fastest service on claims, requests for replacment parts,
www.comfortproducts.net/support
ten.stcudorptrofmoc@ecivresremotsuc:liam-e
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
or questions, please visit our website at:
Essential Book Case, White
SUPPLIER CODE: LDCZ
ASSEMBLY INSTRUCTIONS
MODEL 50-LD0101SHLF
OneSpace is a Trademark of Comfort Products, Inc.
™

Overview

Parts List
A
B
C
D
E
F
G
H
I
J
ITEM STOCK#
DESCRIPTION
Top
Front Trim
Left Wall
Right Wall
Back Trim
Bracing Shelf
Bottom Shelf
Bottom Trim
Back Panel (x5)
Shelf (x3)
51-LD0101SHLFA
51-LD0101SHLFB
51-LD0101SHLFC
51-LD0101SHLFD
51-LD0101SHLFE
51-LD0101SHLFF
51-LD0101SHLFG
51-LD0101SHLFH
51-LD0101SHLFI
51-LD0101SHLFJ

1
2
3
4
5
6
24
24
12
12
4
4
ITEM# DESCRIPTION QTY
HARDWARE KIT
51-LD0101SHLFHA
Calm Bolt
Cam Lock
Dowel
Feet Tacs
Backing Tape
Peg

1
STEP
Turn nine Cam Bolts (1) into the Left Wall and Right Wall each (C and D).
Insert six Pegs (3) into each wall.
Insert Feet Tacs (5) into the bottom of each wall.
5
1
1
1
1
C
D
1
1
1
1
1
1
4
4
1
1
4
4
4
4
1
1
1
1
4
4
4
4
4
4
1
1
5
5
5

2
STEP
Inset four Dowels (3) into the ends of the Top, Bottom Shelf, and Bracing Shelf (A, G, F).
Turn four Cam Bolts (1) into the Top (A) and two Cam Bolts into the Bottom Shelf (G).
1
1
1
1
1
1
3
3
3
3
3
3
3
3
3
3
3
3
A
G
F

3
STEP
Push two Cam Locks (2) into the Front Trim, Back Trim, and Bottom Trim (B, E, and H).
Place the Front and Back Trim (B and E) onto the Cam Bolts onto the Top (A).
Place the Bottom Trim (H) onto the Bottom Shelf (G).
Tighten cams by turning the Cam Lock 180 degrees using a screw driver.
A
G
2
2
B
E
H
2
2
2
2
CAUTION:
Do not overtighten
cams.
2
1

4
STEP
Push Cam Locks (2) into one end of the Top, Bracing Shelf, and Bottom Shelf each, and into
the attached Trim Pieces as shown.
Then place onto the Cam Bolts in the Right Wall (D) as shown, and tighten.
A
F
G
D
2
2
2
2
2
2
2
2
2
CAUTION:
Do not overtighten
cams.
2
1
FRONT

5
STEP
Insert the Back Panels (I) into the provided slots, as shown.
I
I
I
I
I

6
STEP
2
2
2
2
2
2
22
2
5
5
5
5
C
Push Cam Locks (2) into the remaining holes as shown, then set the Left Wall (C) onto the
shelf and tighten the Cam Locks.
Next, apply the four strips of Backing Tape (5) where the Back Panels meet, to secure them
together.

7
STEP
Mount the Drawer Sides (J and I) onto the Drawer Front (G) by first inserting two Cam
Locks (3) each, and then sliding the Drawer Sides onto the Cam Bolts on the Drawer Front.
J
J
J

7
FINISHED

•
•
•
•
DO NOT stand on the desk. Do not use the desk as a stepladder.
ed.
Every 6 months, check all bolts and screws to ensure they are tight.
This product is California 93120 Compliant for Formaldehyde.
Comfort Products, Inc.
122 Gayoso Avenue
Memphis, TN 38103
PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION
Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year. This warranty is made by
Comfort Products only to the original end-user customer acquiring the product directly from Comfort Products’ authorized dealers
as shown by the original sales receipt. The end-user customer remedy pursuant to this warranty is limited to repair or replacement of
parts at Comfort Products’ option within a reasonable amount of time. Comfort Products reserves the right to require damaged parts to
be returned to Comfort Products upon request. Consent from Comfort Products must be obtained before any warranty work is
performed. This warranty applies under conditions of normal use and is not subject to defects caused by improper assembly or
disassembly; defects occurring after purchase due to product modification, intentional damage, fire, misuse, negligence, or exposure to
the elements; labor or assembly cost. This warranty does not cover the cost of transportation or labor. In no event shall Comfort
Products be liable in either tort or contract for any loss or direct, special, incidental, consequential or exemplary damages. This Limited
Warranty is NOT applicable to end-user customers who use Comfort Products for rental purposes. This warranty applies only to end-user
customers in the United States. All warranties are limited to the original purchaser for normal use. The weight capacity is defined as 44
pounds for the desktop and 44 lbs for each shelf. For claims or questions concerning this warranty, please visit:
www.comfortproducts.net or email us at: [email protected]
MODEL: # 50-LD0101SHLF
www.comfortproducts.net
[email protected]
