Bomar Practix 285.230 G Pulldown User manual

Series Practix
Practix 285.230 G
Manual/Pulldown
Operating instructions
Before transporting and using the machine,
please read the instructions thoroughly!
Seriové číslo / Serien Nummer / Serial Number ___________________

2 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Service and information
Your BOMAR dealer
:
Direct BOMAR contact:
BOMAR spol. s r.o.
Těžební 1236/1
62700 Brno
Czech Republic, EU
Phone: +420 – 533 426 100
Fax: +420 – 533 426 109
e-mail: [email protected]
www: http://www.bomar.cz
We are available:
Mondays to Fridays 700 – 1600
Version:
1.03 / Feb. 2010
rev. 1
BOMAR, spol. s r.o. ©– Subject to modifications and amendments.

3

4 Manual version: 1.03/ Feb. 2010
Manual rev.: 1

5

6 Manual version: 1.03/ Feb. 2010
Manual rev.: 1

7
Content
1.SAFETY NOTES ........................................................................9
1.1.Band saw using......................................................................................................................................................................... 11
1.2.Protective suit and personal safety..............................................................................................................................11
1.3.Safety notes for machine operator ..............................................................................................................................12
1.4.Safety notes for the servicing and repairs ...............................................................................................................12
1.5.Safety machine accessories .............................................................................................................................................. 13
1.5.1.TOTAL STOP button...........................................................................................................................................13
1.5.2.Saw arm cover .......................................................................................................................................................13
1.5.3.Saw band cover ....................................................................................................................................................13
1.5.4.Koncový spínač pohonu pásu u stroje typu manual....................................................................13
1.6.Safety notes for cooling system..................................................................................................................................... 14
1.6.1.Instructions for first help .................................................................................................................................14
1.7.Umístění štítku stroje / Maschinenschild position / Position of machine label ..............................14
1.8.Umístění bezpečnostních značek / Verteilung der Sicherheitszeichen / Position of safety
symbols.......................................................................................................................................................................................... 15
2.MACHINE DOCUMENTATION................................................17
2.1.Technická data / Technische Daten / Technical data ......................................................................................19
2.2.Rozměrové schéma / Aufstellzeichnung / Installation diagram – Practix 285.230 G Manual 20
2.3.Rozměrové schéma / Aufstellzeichnung / Installation diagram – Practix 285.230 G Pulldown21
2.4.Popis / Beschreibung / Description – Practix 285.230 G Manual ............................................................. 22
2.5.Popis / Beschreibung / Description – Practix 285.230 G Pulldown......................................................... 23
2.6.Transportation and stocking............................................................................................................................................ 24
2.6.1.Conditions for transportation and stocking.......................................................................................24
2.7.Transport and stocking preparations ......................................................................................................................... 24
2.8.Transport and stocking........................................................................................................................................................24
2.9.Kotevní plan / Verankerungsplan / Grounding plan......................................................................................25
2.10.Activation......................................................................................................................................................................... 26
2.10.1.Machine working conditions................................................................................................................26
2.10.2.Band saw unpacking and assembling ............................................................................................26
2.11.Machine installing and levelling .......................................................................................................................26
2.12.Machine disposal after lifetime..........................................................................................................................26
2.13.Electrical connection............................................................................................................................................... 26
2.13.1.Check the direction of the saw band ..............................................................................................27
2.14.Filling of the cooling system ............................................................................................................................... 27
2.15.Check machine function........................................................................................................................................ 28
2.16.Saw band.......................................................................................................................................................................... 28
2.16.1.Saw band size .................................................................................................................................................28
2.16.2.Selection of the saw band tooth system.......................................................................................28
2.16.3.Saw band running-in .................................................................................................................................29
2.16.4.Tables for teeth selection........................................................................................................................30
3.MACHINE CONTROL..............................................................31
3.1.Control elements for Practix 285.230 G Manual..................................................................................................33
3.2.Control elements for Practix 285.230 G Pulldown ............................................................................................. 33
3.3.How to use band saw...........................................................................................................................................................34
3.3.1.Cutting........................................................................................................................................................................34
3.3.2.Interruption in cutting with Emergency button TOTAL STOP................................................35
3.3.3.Setting of cutting speed .................................................................................................................................35
3.3.4.Angular cut setting.............................................................................................................................................35
3.3.5.Optimal adjusting of the guide cubes span.......................................................................................36
3.4.Material insertion..................................................................................................................................................................... 36
3.4.1.Handling agent selection...............................................................................................................................36
3.4.2.Insertion.....................................................................................................................................................................36
3.4.3.Bundle material cutting...................................................................................................................................37
4.MACHINE SERVICE ................................................................39
4.1.Saw band dismantling ......................................................................................................................................................... 41
4.2.Saw band installation............................................................................................................................................................ 41
4.3.Saw band stretching and inspection.......................................................................................................................... 41
4.3.1.Saw band stretching..........................................................................................................................................41
4.3.2.Saw band inspection.........................................................................................................................................42
4.4.Cooling agents and chips disposal..............................................................................................................................42
4.4.1.Coolant device inspection.............................................................................................................................42
4.4.2.Chips disposal........................................................................................................................................................43
4.5.Greases and oils........................................................................................................................................................................ 43
4.5.1.Gearbox oils.............................................................................................................................................................43
4.5.2.Lubricant greases.................................................................................................................................................44
4.6.Machine cleaning.................................................................................................................................................................... 44

8 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
5.TROUBLESHOOTING .............................................................45
5.1.Mechanical problems........................................................................................................................................................... 47
5.2.Electrical problems................................................................................................................................................................. 49
6.SCHÉMATA / SCHEMAS / SCHEMATICS ...............................51
6.1.Elektrické schema / Elektroschema / Wiring diagrams – Practix 285.230 G Manual.................... 52
6.1.1.Kusovník elektrosoučástí / Stückliste der Elektroteilen / Piece list of elektroparts –
Practix 285.230 G Manual.....................................................................................................................................................54
6.2.Elektrické schema / Elektroschema / Wiring diagrams – Practix 285.230 G Pulldown ............ 55
6.2.1.Kusovník elektrosoučástí / Stückliste der Elektroteilen / Piece list of elektroparts –
Practix 285.230 G Pulldown ................................................................................................................................................57
7.VÝKRESY SESTAV PRO OBJEDNÁNÍ NÁHRADNÍCH DÍLŮ /
ZEICHNUNGEN FÜR BESTELLUNG DER ERSATZTEILE / DRAWING
ASSEMBLIES FOR SPARE PARTS ORDER .......................................59
7.1.Pila / Säge / Saw – Practix 285.230 G Manual........................................................................................................ 60
7.2.Kusovník / Stückliste / Piece list Pila / Säge / Saw – Practix 285.230 G Manual .............................61
7.3.Pila / Säge / Saw – Practix 285.230 G Pulldown................................................................................................... 62
7.4.Kusovník / Stückliste / Piece list Pila / Säge / Saw – Practix 285.230 G Pulldown......................... 63
7.5.Rameno / Arm / Arm – Practix 285.230 G Manual ............................................................................................. 64
7.6.Kusovník / Stückliste / Piece list Rameno / Arm / Arm – Practix 285.230 G Manual .................... 65
7.7.Rameno / Arm / Arm – Practix 285.230 G Pulldown......................................................................................... 66
7.8.Kusovník / Stückliste / Piece list Rameno / Arm / Arm – Practix 285.230 G Pulldown ..............67
7.9.Podstavec / Untergestell / Piedestal – Practix 285.230 G Manual............................................................ 68
7.10.Kusovník / Stückliste / Piece list Podstavec / Untergestell / Piedestal – Practix 285.230
G Manual....................................................................................................................................................................................... 69
7.11.Podstavec / Untergestell / Piedestal – Practix 285.230 G Pulldown .......................................... 70
7.12.Kusovník / Stückliste / Piece list Podstavec / Untergestell / Piedestal – Practix 285.230
G Pulldown.................................................................................................................................................................................. 71
7.13.Svěrák / Schraubstock / Vice................................................................................................................................ 72
7.14.Kusovník / Stückliste / Piece list Svěrák / Schraubstock / Vice ..................................................... 73
7.15.Napínání pásu / Sägebandspannung / Saw band tensing.............................................................. 74
7.16.Kusovník / Stückliste / Piece list Napínání pásu / Sägebandspannung / Saw band
tensing ........................................................................................................................................................................................... 75
7.17.Vedení pásu / Bandführung / Band guiding............................................................................................. 76
7.18.Kusovník / Stückliste / Piece list Vedení pásu / Bandführung / Band guiding................... 77
7.19.Pohon / Antrieb / Drive........................................................................................................................................... 78
7.20.Kusovník / Stückliste / Piece list Pohon / Antrieb / Drive ................................................................ 79
7.21.Konzola / Konsole / Console................................................................................................................................ 80
7.22.Kusovník / Stückliste / Piece list Konzola / Konsole / Console ..................................................... 81
7.23.Chlazení / Kühlung / Cooling.............................................................................................................................. 82
7.24.Kusovník / Stückliste / Piece list Chlazení / Kühlung / Cooling ................................................... 83

9
Bezpečnostní pokyny Sicherheitshinweise Safety notes
1. Safety notes

10 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Bezpečnostní pokyn
y
Sicherheitshinweise
Safety notes

11
Bezpečnostní pokyny Sicherheitshinweise Safety notes
The operating instructions must be read by the person, who keeps in touch with the
machine before transportation, installation, using, servicing, reparation, stocking or
removal!
The operating instructions include relevant information. The operator must familiarise
himself with the install and operation, safety notes and machine servicing, because
reliability and service life must be reached. The operating instructions must avoid risks,
which are linked to work on the machine. Before transporting and using of the
machine, please read the instructions thoroughly!
1.1. Band saw using
The band saw Practix 285.230 G Manual or Practix 285.230 G Pulldown is used for
cutting and shortening of rolled bars and drawn bars and profiles from steels, stainless
steels, non-ferrous metals and plastics with cutting angles from 0° to 60°.
Combustible materials are excepted for cutting!Any other usage and operation
outside this range are unauthorized and the manufacturer/supplier does not accept
any responsibility for any damages resulting from such misuse. The operator has full
responsibility!
The machine is equipped with safety and protective guarding for operator and
machine protection. Nevertheless, this safety and protective guarding cannot prevent
injury. Service personnel must read this chapter and comprehend it, before he starts to
work on the machine. Always keep instructions about work safety! Service personnel
must take into account other aspects of the risk, which refer to the ambient conditions
and the material.
1.2. Protective suit and personal safety
Wear tight fitting overalls! Loose fitting clothes may be caught with machine parts
and cause serious injury.
Wear protective gloves! Material cuts and saw band have sharp edges and may cause
serious injuries.
Wear protective shoes with non-skid soles! The unsuitable shoes may cause balance
loss and following injury. Falling work pieces may cause serious injuries too.
Wear protective goggles! Chips and cooling liquid may damage your eyes.
Always wear ear protections! Most of the machines emit up to 80 dB and may
damage your hearing.
Do not wear jewellery and always tie back long hair! Moving machine parts can
catch jewellery or loose hair and may cause serious injuries.
Operate the machine only when you are fit enough to work. Illnesses or injuries
diminish concentration. Avoid machine work, which may compromise the safety of you
and your colleagues!
Attention!
The operating instructions must be available at the machine!
Keep the operating instructions in good condition!
Attention!
Consider the safety signs on the machine. Do not remove or
damage them!
Attention!
Gloves you can use only at working material replacement (saw
band)! The machine and accessories must be inactive!
If the machine is running, you must not wear gloves! It is
dangerous, because some parts of the machine can catch
gloves!

12 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Bezpečnostní pokyn
y
Sicherheitshinweise
Safety notes
1.3. Safety notes for machine operator
Machine can be operated only by one person. Machine operator is responsible for
presence of other persons by the machine.
Close covers before the machine starting and check, if the covers are not damaged.
Damaged covers must be repaired or changed. Do not start the machine, if the cover is
removed! Check, if the electric cables are not damaged.
•Do not hold the material for clamping to the vice and for cutting!
•Do not operate with the buttons and the switches on the control panel, if you
have gloves!
•For machine starting take care, that there is nobody in the working area of the
machine (it means in the working area of the vice, the saw band, the saw arm etc.).
•In no circumstances touch the rotating elements.
•Work on the machine only when the machine is in good condition!
•Check at least once in a shift, if the machine is not damaged. If the machine is
damaged, you must bring the machine in order and you must inform your
superior!
•Keep your working area clean!
•Ensure sufficient lighting in the working area.
•Take off the spilt water or the oil from the floor and dry it! Do not touch the
cooling liquid with bare hands!
•Do not set the nozzle of the cooling liquid, when the machine is started on!
•Do not remove the chips from the working area of the machine, when the
machine is started on!
•Do not use the compressed air for the machine cleaning or for the chips
removing! Use the protective instruments for chips removal!
1.4. Safety notes for the servicing and repairs
Switch off the main switch and lock it, before you start service work! When repair
machine remove power cord from the outlet. Otherwise, there is possibility of
hazardous machine starting.
Attention!
Machine can be operated by person older than 18 years!
Machine can be operated only person physically and mentally
fit for this activity.
Keep instructions and orders about work safety!
Read the operating instructions, before you start to work on
the machine! Keep the operating instructions in good
condition!
Do not connect the machine to electricity if the covers are
removed. Do not touch the electrical equipment.
Attention!
Only a qualified professional can carry out the servicing and
repairs of the electric equipment! Take special care during the
work with electrical equipment. High voltage shock can have
fatal consequences! Always keep notes about work safety!
Otherwise, there is possibility of heavy injury.

13
Bezpečnostní pokyny Sicherheitshinweise Safety notes
Only qualified person can do the servicing and repairs. For parts changing, use only
parts, which are identical with the originals. Otherwise, there is possibility of health
hazard.
Use only recommended type of the hydraulic oils and oils and lubricants.
Do not remove or do not lock the limit switches or safety equipments! Any use of the
saw, accessories or machine parts other than that intended by the BOMAR, spol. s r.o.
company is not permitted.
The guarantee on this product will be afterward lost and BOMAR, spol. s r.o. takes no
responsibility for caused damages!
1.5. Safety machine accessories
The machine is equipped with safety accessories. It protects the operator from injuries
and the machine before damage. The safety accessories are blocking accessories,
emergency switches and covers. Check once in a week the function of the safety
accessories. If the safety accessories are functionless, you must stop work and repair or
change the safety accessories.
1.5.1. TOTAL STOP button
TOTAL STOP button is used for emergency switching – off the machine in case defect
or health hazard. By pressing TOTAL STOP button is interrupted the supply of the
electrical power.
Release the pressing button is possible by twisting of the upper part of the button.
1.5.2. Saw arm cover
The band saw is stated to the operation, when the cover is closed!
1.5.3. Saw band cover
This protective cover envelops the saw band in the area from guiding cube to the arm.
Never switch the saw band on if this cover is not mounted!
1.5.4. Koncový spínač pohonu pásu u stroje typu manual
Verze stroje typu Manual obsahuje koncový spínač pohonu pásu, který odpojí pohon
pilového pásu po dořezání materiálu a klesnutí ramene do spodní polohy.
Enhanced risk!
Do not come into or intervene in the cutting area.
Otherwise, there is possibility of heavy injury.
If any damages or fault appears, immediately press TOTAL
STOP button!

14 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Bezpečnostní pokyn
y
Sicherheitshinweise
Safety notes
1.6. Safety notes for cooling system
1.6.1. Instructions for first help
1. Pull off and safely remove polluted, soaked clothing.
2. For breathing, go out in the fresh air or look for first aid treatment.
3. Wash with water or use crèmes for contact with the skin.
4. Flush with water for eyes and look for first aid treatment.
5. For swallowing – drink a lot of water and induce vomiting. Look for medical help.
1.7. Umístění štítku stroje /
Maschinenschild position /
Position of machine label
Štítek stroje umístěn na pilovém rameni, v blízkosti šroubu napínání pásu.
Attention!
Keep notes about work safety for handling cooling liquid!
When handling cooling agents always wear hazardous fluid-
proof gloves!
Wear protective goggles! Cooling liquid can get in contact
with your eyes and may cause permanent severe injuries.

15
Bezpečnostní pokyny Sicherheitshinweise Safety notes
1.8. Umístění bezpečnostních značek /
Verteilung der Sicherheitszeichen /
Position of safety symbols

16 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Bezpečnostní pokyn
y
Sicherheitshinweise
Safety notes
Poz.
Pos.
Pos.
Obj. číslo
Bestell - Nr.
Reference No.
Název položky
Bezeichnung
Item
ks
Mng.
Pcs.
1 99.900.039
Samolepka /
Aufkleber /
Self-adhesive label
NS – Nebezpečí
stlačení /
Pressunggefahr /
Crushing hazard
1
2 99.900.040
Samolepka /
Aufkleber /
Self-adhesive label
NR – Nebezpečí
říznutí /
Schnittgefahr /
Cutting or severing
hazard
2
3 99.900.045
Samolepka /
Aufkleber /
Self-adhesive label
NE – Nebezpečí
úrazu elektrickým
proudem /
Verletzunggefahr
vom elektrischen
Strom / Electrical
hazard
1
4 99.900.047
Samolepka /
Aufkleber /
Self-adhesive label
OBS – Noste
ochranné brýle a
sluchátka / Tragen
Sie eine Schutzbrille
und Gehörschutz /
Wear protective
googles and
headphones
1
5 99.900.048
Samolepka /
Aufkleber /
Self-adhesive label
PO – Noste pevnou
pracovní obuv /
Tragen Sie
Sicherheitsschuhe /
Wear fixed
protective shoes
1
6 99.900.049
Samolepka /
Aufkleber /
Self-adhesive label
CZ – Přečíst návod
k použití /
Bedienungsanleitun
g lesen / read the
operating
instructions
1
7 99.900.050
Samolepka /
Aufkleber /
Self-adhesive label
SOL – Směr otáčení
doleva /
Drehrichtung nach
links / direction of
rotation left
1
8 99.900.051
Samolepka /
Aufkleber /
Self-adhesive label
SOL – Směr otáčení
doprava /
Drehrichtung nach
rechts / direction of
rotation right
1
99.900.053
Samolepka /
Aufkleber /
Self-adhesive label
Směr pohybu /
Bewegungsrichtung
/
Direction of motion
1

17
Dokumentace stroje Dokumentation der Maschinen Machine documentation
2. Machine
documentation

18 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Dokumentace stroje
Dokumentation der Maschinen
Machine documentation
Sf

19
Dokumentace stroje Dokumentation der Maschinen Machine documentation
2.1. Technická data /
Technische Daten /
Technical data
Hmotnost stroje / Maschinengewicht / Machine weight:
•Hmotnost / Gewicht / Weight Manual 215 kg / Pulldown 225 kg
Rozměry stroje / Maschinengröße / Machine size – Practix 285.230 G Manual:
•Délka / Länge / Lenght
•Šířka / Breite / Width
•Výška / Höhe / Height
1410 mm
915 mm
1270 mm
Rozměry stroje / Maschinengröße / Machine size – Practix 285.230 G Pulldown:
•Délka / Länge / Lenght
•Šířka / Breite / Width
•Výška / Höhe / Height
1410 mm
920 mm
1520 mm
Akustický tlak / Schalldruckpegel / Acoustic pressure:
•Practix 285.230 G Manual
•Practix 285.230 G Pulldown
LAeqv = 62,6/69,4 dB … 35 m.min-1 / 72 m.min-1
LAeqv = 59,5/65,4 dB … 35 m.min-1 / 72 m.min-1
Virbrace / Vibration / Vibration:
•Practix 285.230 G Pulldown 0,08/0,2 m.s-2 … 35 m.min-1/72 m.min-1
Pohon / Atrieb / Drive:
•Typ / Typ / Type
•Napájení / Versorgungsspannun / Supply voltage
•Výkon / Leistung / Output
•Jmenovité otáčky / Motornenndrehzahl / Nominal speed
MSD90L-8/4
~3×400 V, 50 Hz
0,7/1,1 kW
1400/690 min-1
Chladící zařízení / Kühlmiteleinrichtung / Cooling equipment:
•Typ / Typ / Type
•Napájení / Versorgungsspannun / Supply voltage
•Obsah nádrže / Volumen vom Kühlmittel / Capacity
S1
~ 1×230V, 50Hz
15 l
Rozměr pásu / Sägebanddimension / Band size:
2720×27×0,90 mm
Řezná rychlost / Schnittgeschwindigkeit / Cutting speed:
35/72 m.min-1
Řezné rozsahy / Schnittbereiche / Cutting size:
0° Ø225 mm 280×70 mm 245×225 mm 225×225 mm
R 45° Ø180 mm 180×125 mm 200×170 mm 170×170 mm
R 60° Ø120 mm 115×95 mm 95×95 mm 95×95 mm
Level of acoustic pressure – Practix 280.230 G:
Equivalent level of acoustic pressure A (noise) at operator position are LAeqv=62,6 / 69,4 dB for
35 m.min-1 / 72 m.min-1 for Manual version and LAeqv= 59,5 / 65,4 dB for 35 m.min-1 / 72 m.min-1 for
Pulldown version. Mentioned values are levels of emission which doesn’t have to represent safe
levels. Factors which influence real level of acoustic pressure on machine operator are: working place
characteristics, cut material, saw band. These factors have significantly influence on acoustic pressure.

20 Manual version: 1.03/ Feb. 2010
Manual rev.: 1
Dokumentace stroje
Dokumentation der Maschinen
Machine documentation
Sf
2.2. Rozměrové schéma /
Aufstellzeichnung /
Installation diagram – Practix 285.230 G Manual
