Products Outline & Features
1. Product Outline
BON HD Digital Monitor series are a Multi-Format HD Monitors with high core technology to display
various kind of digital video input signals. It supports HD/SD-SDI, Composite/YC/YPbPr/RGB/DVI/PC-
RGB/HDMI(HDCP) Signals.
2. Functions and Features
• 2ch HD/SD-SDI I nputs(2K Format) & 1ch Selective Through output
• HDMI (HDCP) input
• Analog Component & DVI – I input
• 2ch Composite input
• 12bit fully Signal Processor
• Pixel Zoom (*2, *4, *8)
• Precision 8~16ch Audio Level Meter
• Various Markers Display (EBU, Variable)
• Precision Monitoring (H/V Delay, R, G, B, Mono)
• Closed Caption (608(ANC), 608(Line21), 708)Display
• Time Code Display (VI TC)
• Input mode & Signal Status I nformation Display
• Waveform Monitoring Display (Y, Pb, Pr Selected, Line Selected)
• Video Range Check Display
• Vector Display (75% / 100%)
• Remote GPI control (RJ-45)
• USB Port (Update)
• RS-422, Serial Control Port, (RJ-11)
• Built-In Speaker
• 3 Color TALLY Lamp
• Analog Audio Input/ De-embedded Output
• Wide Viewing Angle
• UMD/IMD Mode
• Teletext (Option)
• Lock Type of Esay Picture Adjustment
• Hard Coating & Anti Glare Panel & ND Filter (Option)
• Rack & VESA Mount 대응 (Rack Mount Option)
Please refer to Specificat ion Sheet for Detailed information.
!

-- 9 --
Multi Format LCD Monitor
3. Controls and Functions
3.1. Front Panel
BXM Front Buttons
①STANDBY
Power ON/OFF Button. This Button is operated after being pressed about 3 seconds.
② SDI 1, SDI 2 I NPUT SELECT :
This is for selecting SDI Input. Additional OSD LOGO is displayed.
③CVBS 1, CVBS 2, YC I NPUT SELECT
This is for selecting CVBS1,2, Input and selecting YC Input. Each time user press this button, it
converts CVBS1,2, Y,C Mode.
④SCAN
This Button is used to convert output picture status into Zero Scan, Under Scan, Over Scan, Zoom,
Pixel to Pixel Mode. Each time user press this button, it converts above Mode.. (SCAN LED is
ON when Over Scan.)
⑤DVI / VGA I NPUT SELECT
This is for selecting DVI / VGA Input. Each time user press this button, it converts DVI, VGA Mode.
⑥HDMI I NPUT SELECT
This is for Selecting HDMI input.
⑦COMPONENT-YUV, RGB I NPUT SELECT
This is for selecting Components Input. Each time user press this button, it converts YPbPr, RGB
Mode.
⑧W -FORM / VECTOR(▼)
Input signal is shown as a format of Wave form or Vector Scope. Each time this button is pressed,
it converts each mode. (This mode is available only in follow mode => SDI, CVBS, S-Video,
YPbPr Mode)
①
② ③ ④
⑤ ⑥ ⑦ ⑧
⑨ ⑩ ⑫
⑪ ⑬
⑭

-- 10 --
Multi Format LCD Monitor
⑨FUNCTI ON 1 (F1, F2, F3, F4)
These two Function buttons carries out the item selected in the SYSTEM Menu.
⑩MENU
When selected this button, OSD Menu is activated. Please refer to category 6.
⑪ENTER , ⑪* ENTER/STATUS
1) When sets the OSD Menu used as Enter button. Please refer to category 6 for detailed
information.
2) If the OSD Menu is not activated used for the input signal’s information display.
⑫R. G. B. GRAY(▲)
1) When this button is pressed, Display Color is shown as a format of Wave form or Vector Scope.
Each time this button is pressed, it converts each mode.
These functions are available only in SDI, CVBS, S-Video, Y Pb Pr mode
2) When the OSD MENU is activated, used for Up (▲) button
⑬MARKER(▼)
1) Used for Marker On/Off.
2) When the OSD MENU is activated used for down(▼) button.
⑭ADJUST
Possible to control these functions .(Brightness, Contrast, Saturation, Phase, Volume)
Brightness
Contrast
Chroma
Phase
Speaker Volume
Selectable these items
!When the OSD MENU is activated this VOLUME button can be used for Up(▲),
Down(▼) and ENTER.

-- 11 --
Multi Format LCD Monitor
3.2. Rear Panel
Rear of BXM
1. USB 2. RJ-45(GPI) 3. RJ-11 x 2 4. earphone

-- 12 --
Multi Format LCD Monitor
①: USB Update Port
You can update Firmware by this USB port. Please refer to category7 for detailed information.
②: REMOTE Port ,RJ-45 Jack – Through (RJ-45) Port
Terminal for controlling the monitor by an external control. (Make/Trig Type)
Please refer to cagegory8 for detailed information.
③: UPDATE Por t (RJ-11 Jack)
Serial Communication Port
This port is used to modify monitor program or to control Monitor.
Please refer to category for detailed information.
④: AUDIO IN/OUT
Input/Output terminal for the external Audio and Embedded Audio Signal.
⑤: SDI 1 , SDI 2 input .
⑥: LOOP OUT jack (Selected Active Thr u out )
⑦: Component input
Y,U,V (Y,Pb,Pr) and R,G,B
⑧: Component LOOP OUT
Component Loop Out port
To set Component Loop Out, set Analogue Loop into “ON” in the MENU/VIDEO
⑨: Composite / Y/ C(S-Video) I nput
⑩: Composite LOOP OUT
Composite Loop Out port
To set Composite Loop Out, set Analogue Loop into “ON” in the MENU/VIDEO
⑪: DVI -I input jack
⑫: HDMI input jack
⑬: PLD Updat e Port
Used for PLD Update port.
⑭: AC I NPUT (AC 100V~220V)

-- 13 --
Multi Format LCD Monitor
3-3. Tally & Audio
1) Tally Display
Tally Colors are 2types(Red, Green), and can be selected by external contact
terminal.
Tally Lamp
①Analog Audio L/ R ter minal (St ereo Pin Jack)
The external audio signal is available through the speaker by a Menu setting.
②Analog Audio L/ R Output (Ster eo Pin Jack)
Terminal for output of De-embedded Analog Audio signal from SDI.
The 16ch Audio Signal output is available by a Menu Setting. Please refer to 6-6
Embedded Audio Setup for detailed
information.
2) AUDIO Input/Output

-- 14 --
Multi Format LCD Monitor
3-4. Function Button for F1, F2, F3, F4
Used to select the functions to be assigned to individual buttons F1 ~F4(front-panel buttons).
Function
1. PC SCAN Aspect/Fill
2. Aspect Native/16:9
3. Pixel to Pixel On/Off
4. Anamorphic On/Off
5. PaP On/Off
6. PiP On/Off
7. Fast Mode On/Off
8. Time Code Display On/Off
9. Marker On/Off
10. Caption Display On/Off
!
H/V Delay is available only
below mode.
1) SDI-1, SDI-2 input
2) CVBS1, CVBS2 input
3) S-Video
4) YPbPr, RGB input
4. STATUS DISPLAY
Used to confirm the operating status. Some functions are not supported depending on the
installed options. .
11. Audio Display On/Off
12. Audio Mute On/Off
13. H/V Delay On/Off
14. Freeze Main On/Off
15. Freeze sub On/Off
16. Front Button LED On/Off
17. Video Loss Tally
18. Video Loss Alarm
19. Video Range Check
20. Focus Peaking Display
Displays up to 16channels(L/R each 8channels) of audio
level by De-Embedded of HD/SD-SDI’s serial Audio Signal.
Time Code
Display Displays selected input signal
format information on the screen
Display Left
CH-1,3,5 ~ 15
Display Right
CH-2,4,6 ~ 16
Video
Waveform

-- 15 --
Multi Format LCD Monitor
5. INPUT SELECT
1) Audio Level Display Mode.
You can set Audio Level Display On/Off and display position.
2) Waveform Monitor Display
You can set Waveform Monitor Display On/Off and display position by OSD Menu.
< Input Button >
!• Time Code Displaying is available SDI input only.
3) Time Code Display
You can set Time Code display On/Off and display position by OSD Menu.
!Wave form is not available in YPbPr 1080p input.

-- 16 --
Menu Setup
▪Bright ness : Adjusts brightness.
▪Contr ast : Adjusts Contrast.
▪Chr oma : Adjusts Chroma.
▪Phase(Hue): Adjusts Phase.
▪Shar pness : Adjusts Sharpness.
▪NTSC Set up : Selectable among 0 IRE,7.5 IRE
7.5 IRE -> -> Operates at NTSC or YUV Mode .
▪Dithering : sets gradation effect.
ON -> makes screen gradation smooth
(Recommended to turn Dether ON if 8bit output)
Off -> without gradation effect, it outputs into screen
▪ VGA Color Set ▪ VGA Display Set :
Activates only in VGA Input. mode. There are Default
mode and User Adjust Mode.
!VGA Color Set : You can control each value of R.G.B among YPbPr, RGB, VGA input
mode only.
VIDEO MENU
6-1. VI DEO Setup
This menu is applied VGA input mode only.
▪Red Gain : Controls Gain of Read input.
▪Green Gain : Controls Gain of Green input.
▪Blue Gain: Controls Gain of Blue input.
▪Red Bias ▪Green Bias▪Blue Bias : Controls offset
of each Bias.
6-1-1. VGA COLOR setup
6. OSD MENU

-- 17 --
Menu Setup
This Menu is displayed VGA Mode Only.
▪V -Position ▪H -Position : You can adjust V and H
position in PC-RGB input mode.
▪Phase: You can adjusts Phase
▪Auto Adj ust : You can adjust screen position
automatically..
▪ PC SCAN : You can select display mode among Fill and
Aspect.
▪Aspect : Sets picture ratio as 16:9 or as Native
ration in SD mode, 2k mode.
▪Pixel to Pix el(1:1) : This function is available only in
7” and 20” model. Displays native signal inputted in HD-
SDI, 1920 x 1080 without scaling down. The active display
can be set to Left Upper, Right Upper, Left Bottom, Right
Bottom, and Center.
6-1-2. VGA Display Setup
6-2. Display
▪Anamor phic : Makes vertical resize to see Anamorphic screen(2.35:1) on 720/50P 59.94P mode.
▪Fast Mode : Used select Fast, Normal Mode
Fast mode minimize the delay time as it outputs Interlaced scanning Input not converting into
progressive scanning method. Normal Mode is used to output Interlaced scanning signal as
progressive scan.
▪Back Light : Controls brightness of LCD backlight.
▪Test Pat tern : Without additional Input signal, it provides internal Test Pattern of 1920 x1080 30p
format on the screen. (Off, Blue, Green, Red, 0~100% White)

-- 18 --
Menu Setup
Sets Screen size mode or display status.
▪PIP & PAP Main : Selects input of Main.
▪PIP & PAP Sub : Selects input of Sub.
▪Dual Display Type : In the Dual Display Mode, you can
adjusts position and sized of picture.
▪PiP Position : You can select position of Sub.
▪ W .F Display Mode : Selects W.F display Mode.
▪ W .F Line Select : Display selected line’s W.F and you can select the line by UP ▲DOWN ▼ button.
▪ W .F Select : Used to display desired Video waveform -> Y(Green), Cr(Red), Cb(Blue)
▪ W .F Position : Used to set the position of Waveform Display -> Left Top, Left Bottom, Right Top, Right
Bottom
▪ Vector Position : Used to set the position of Vector scope among->Left Top. Left Bottom. Right Top.
▪ W .F & Vector Blend : Used to adjust transparency of W.F and Vector scope.
6-2-1. Display
6-2-2. Display Setup
▪Video Range Check : Video Range Check On/Off
▪Y Range Max : Used to set Maximum value of Y.
▪Y Range Min : Used to set Minimum value of Y.
▪C Range Max : Used to set Maximum value of C.
▪C Range Min : Used to Set Minimum value of C..
▪Blink Color : Used to set the Blink Color when the Video Range Check On. There are Black/ Blue/
Green/ Red.
▪Blink Time : Used to set the Blink time when the Video Range Check ON.
▪Focus Peaking Display : Camera Focus Assistance On/Off.
▪Peaking Color : Used to set the peaking color of Focus Assistance.
▪Peaking Width : Used to set the peaking width of Focus Assistance.

-- 19 --
Menu Setup
▪ Color Temper atur e
: Sets color temperature on screen among
3200°K,5400°K,6500°K, 9300°K의
▪ Adj ust Temper atur e
: Activates when User is set in Color Temperature
RGB Gain and Bias are possible to control
▪ R,G,B Gain : Control each R,G, B Gain in USER mode
▪ R,G,B Bias : Control each R,G,B Bias in USER mode
▪ Mar ker 16:9
Used to set the type of Marker in 16:9 HD Signal.
-> 4:3,15:9,14:9,13:9,1.85:1,2.35:1,User,Off
▪ Safety Area 16:9
Used to set the safety area in 16: 9 HD signal
-> EBU ACT 16:9/14:9/4:3, EBU GRA 16:9/14:9/4:3,
Off, 80% ,85%,88%,90%,93%,95%
▪ Safety Area 4:3
Used to set the safety area in 16:9 HD signal input
-> EBU ACT 16:9/14:9/4:3, EBU GRA 16:9/14:9/4:3,
Off, 80% ,85%,88%,90%,93%,95%
▪ Cent er Marker : Center Marker On/Off
6-3. COLOR
6-4. MARKER
▪ Timecode Display :Timecode Display ON/OFF
▪ Timecode Position :Used to set position of Time
Code.
▪ Menu Display Time :Sets Menu and
Information.
-> Select one of off, 0(continute)~60
seconds.
▪ Menu Blend : Set transparency of menus and
indication windows on the screen
-> Selects 0~15 levels
6-5. OSD
▪ Mar ker Color : Selects Marker Color.-> Black, Red, Green, Blue, White, Gray
▪ Mar ker Thickness : Set Marker Thickness as Pixel unit. (1~10 Pixels)
▪ Mar ker Back Color : Sets background transparency between Normal and Half, excluding
Safety area. -> Normal, Half
▪ User Mar ker H1,2/ V1,2 : Sets H,V Position of User Marker
(Depending on inch, user can be set the maximum resolution which are supported in the LCD Panel.)

-- 20 --
Menu Setup
▪ MENU Position : Select for Center, Left Top, Right Top, Left Bottom, Right Bottom.
▪ Closed Caption : This function is available in Composite, YPbPr,l and Digital(HD/SD-SDI) signal. There
are three selectable mode : OFF, CC 708, CC 608 (Transcoded, VANC, Line 21 Line), . This function
displays character information included in CC signal on the screen..
▪ CC608 Start Line : Used to set the start line of CC608 on screen In 608 Sine 21 Mode,
Menu Position: Left-Top, Left-Bottom, Right-Top, Right-Bottom, Center
Closed Caption Display : Standard 608(CVBS & SDI : NTSC/PAL)
Digital 708(SD/HD-SDI)
▪ Play Channel (L)
Designates extracted sound signal from Speaker
Source into Left Output Channel.
▪ Play Channel (R)
Designates extracted sound signal from Speaker Source
into Right Output Channel .
▪ Audio Level Met er : Displays the level of inputted
Audio signal as Level Bar on the screen .
▪ Level Meter Position : Selects the position of Audio
Level Meter either Upper or Lower.
▪ Speaker Sour ce : Selects Speaker Output among Auto / SDI1,2 / LINE IN input
▪ Speaker Volume : Sets Speaker Output Level.
6-6. AUDI O
