Boneco H680 User manual

H680
MANUAL

Instructions for use 4
Instructions d’utilisation 35
Instrucciones para el uso 68

4
en
INSTRUCTIONS FOR USE
BONECO H680

5
en
TABLE OF CONTENTS
Technical Data 38
Introduction 39
Relief from allergies 39
Valuable information about humidity 39
Items included 39
Overview and part names 40
Start-up 42
Safety instructions 42
First cleaning 42
First water change 42
Indicators on the display 46
Keypad and remote control 47
Two types of operation 47
The “Hybrid” operating mode (air humidification and air purification) 48
Operating mode at initial start-up 48
Using the “Hybrid” operating mode 48
Air quality indicator 48
Basic settings 48
Only air humidification / Only air purification 49
“Air humidification” operating mode 49
“Air purification” operating mode 49
Selecting the various comfort modes 50
Comfort modes 50
Switching the comfort mode 50
“AUTO” comfort mode 50
“SLEEP” comfort mode 50
“BABY” comfort mode 50
Manually regulating humidity and fan level 51
Perfect humidity 51
Controlling humidity 51
Maximum humidification 51
Regulating the fan level 51
Power mode (P) 51
Timer function 52
Setting the OFF timer 52
Setting the ON timer 52
Display lock 53
Activating the display lock 53
Deactivating the display lock 53
Using fragrances 54
Using fragrances 54
Adding fragrances 54
Descaling 56
Preparing for first use 56
Descaling 57
Cleaning the interior parts 57
Changing the descaling time 57
Cleaning the interior parts 58
Important notes 58
Water tank 58
Water base 58

6
en
Drum 59
Evaporator mat (handwashing) 59
Evaporator mat (washing machine) 59
General cleaning 60
Cover 60
Pre-filter 60
HYBRID filter 60
Filter holder 61
Fan blade 61
Housing 61
Particle sensor 62
Assembling the appliance 62
Replacing the HYBRID filter 64
Replacing the HYBRID filter 64
Replacing the Ionic Silver Stick® 65
Replacing the Ionic Silver Stick® 65
Malfunctions and troubleshooting 66

7
en
TECHNICAL DATA
Type designation BONECO H680
Mains voltage 100–240 V, 50–60 Hz
Power consumption 30 W
Humidity output 1000 g/h* (6.340 gal/day)
Air purification performance 190 m3/h (112 CFM) (CADR)
For rooms up to 100 m2(1080 sq ft)
Water capacity 10 l (2.64 US gal)
Dimensions L 347 × W 435 × H 490 mm (13.6” × 17.1” × 19.3”)
Operating noise level < 25 dB(A)
Weight (empty) 10.4 kg (22.3 lbs)
Accessories Ionic Silver Stick®A7017, HYBRID filter
* For operation without HYBRID filter depending on temperature and humidity

8
en INTRODUCTION
DEAR CUSTOMER,
Congratulations on your purchase of the BONECO H680.
Its hybrid design cleans and humidifies room air in one
step. Its smart control system keeps operating noise
level to a minimum, even allowing you to use the BONECO
H680 in a bedroom or baby's room.
The BONECO H680 is designed for convenient, fully
automated operation. However, you can adjust all of its
features according to your preferences and requirements.
This manual shows you how you can create your own
comfortable climate.
RELIEF FROM ALLERGIES
The BONECO H680 is equipped with a triple filter system
that rids the air of odors as well as dust, pollen and con-
taminants. The HYBRID filter also effectively alleviates
many forms of discomfort caused by allergies, such as
hay fever or allergic reactions to dust mites and house-
hold dust.
VALUABLE INFORMATION ABOUT HUMIDITY
The right humidity is very important for our health. Dry
room air in winter leads to skin that cracks and itches. It
makes your eyes and throat feel dry while significantly af-
fecting physical comfort. Not only does this affect adults,
it is especially true for babies, small children and even
pets. Dry mucous membranes in winter also make us
more prone to colds and other infections.
The BONECO H680 makes these problems a distant
memory. Its intelligent automatic controls always keep
the air clean and the humidity at the ideal level, even in
large rooms with an area of up to 100 square meters
(1080 square feet).
Regardless of whether it is summer or winter: You
will not want to give up your newly gained comfort.
ITEMS INCLUDED
BONECO H680
with HYBRID filter
Power supply unit with
country-specific adapter
OOOOOOO
OOOO
“CalcOff” cleaning and des-
caling powder A7417
CD with manuals in other
languages
Remote control
including CR 2025 battery

9
en
OVERVIEW AND PART NAMES
1 2 3 4
5
1110 12 13 14
6 8 97 1Front cover
2Pre-filter
3HYBRID filter
4Filter holder
5Drum
6Evaporator mat
7Ionic Silver Stick®
8BONECO H680
9Water tank
10 Fragrance container
11 Water base
12 Remote control
13 Fan blade
14 Power supply

10
en
START-UP AND USE

11
en
FIRST WATER CHANGE
24 hours after the first use, the “Water change” symbol
will illuminate:
Change the water in the water tank and in the water base.
The “Water change” symbol will automatically go out as
soon as the water has been replaced.
START-UP
SAFETY INSTRUCTIONS
Before using the device, carefully read through the
enclosed safety notes and operating manual and
keep them for later use.
FIRST CLEANING
Production-related residue on the water tray and water
tank may lead to foaming, and thereby to water escaping.
For this reason, before the first use, both elements must
be cleaned with warm water and dishwashing detergent
(see Figure 5 on the right side). Thoroughly rinse the parts
under running water.

12
en START-UP (CONTINUED)
Remove the water tank.
Pull out the water tray along with the drum.
Remove the front cover. Take off the filter holder along with the filters.
1
4
2 3
Clean the water tank and water tray.
5
Insert the water tray with the drum into the appli-
ance.
6

13
en
START-UP (CONTINUED)
Insert the HYBRID filter
(note the direction the arrow is pointing). Insert the pre-filter.
11 12
Take off the pre-filter.
Remove the protective covering of the HYBRID filter.
9
10
Insert the filter holder.
8
Insert the water tank filled with tap water.
7

14
en START-UP (CONTINUED)
15
Connect the power supply to the BONECO H680 first
and then to the power outlet.
Reattach the front cover. Switch the appliance on with the button.
1413

15
en
INDICATORS ON THE DISPLAY
Overview of all indicators on the display Indicators for air purity (left) and fan level (top) Indicator for humidity (right, middle) and fan level (top)
Indicator Meaning
Current or desired humidity 20
Fully automated operation 19
Low-noise nighttime mode 19
Perfect for use in a nursery or baby's room 19
Timer function 21
Value shows the current humidity 20
Value shows the desired humidity 20
Display lock has been activated 22
Indica-
tor Required action
Refill the water 12
Change the water in the appliance 35
Replacing the Ionic Silver Stick®*34
HYBRID filter used up, replace* 33
HYBRID filter missing, insert 18
Cleaning required* 25
The symbols for the actions marked with an * can be turned off manually if you
simultaneously press and hold the and buttons on the appliance for 5 seconds.

16
en
TWO TYPES OF OPERATION
The BONECO H680 can be controlled using the integrated
keypad or the included remote control. Operation remains
the same in both cases.
KEYPAD AND REMOTE CONTROL
Remote controlKeypad on the appliance
Indicator Function
Regulating the fan level 20
Toggling between modes (on the remote control) 19
Toggling between modes (on the appliance) 19
Activating the “Display lock” 22
Calling up the timer function 21
Changing air humidity / timer / fan levels 20, 21
Switch the appliance on and off / start cleaning 25
Toggling between operating modes 18

17
en
AIR QUALITY INDICATOR
After being switched on, the BONECO H680 carries out
an initial air measurement and the symbol flashes.
After measuring the air, the display shows the current air
quality (see figure below).
The cleaner the air is, the more segments are shown in
white.
OPERATING MODE AT INITIAL START-UP
The BONECO H680 uses the “Hybrid” operating mode
when being switched on for the first time: This operating
mode cleans the air while humidifying it at the same time.
The humidity can be regulated at will (see page 20).
Air purification works automatically and without user
interaction.
The fan level is controlled by the electronics and adapts
to the environment to ensure the most efficient cleaning
and/or humidification possible.
Fan noise may be clearly audible at first; it will decrease
after a few minutes, however, once the humidity gets
closer to the desired value.
USING THE “HYBRID” OPERATING MODE
1. Switch the appliance on by tapping the button once.
The particle sensor automatically begins measuring the
amount of dirt in the air. The appliance starts the hu-
midifying process automatically if humidity is below 50%.
BASIC SETTINGS
The BONECO H680 saves all of the settings if you switch
off the appliance using the button.
The basic settings described here (“Hybrid” operating
mode, “AUTO” comfort mode, etc.) can be restored at
any time. Disconnect the appliance from the power outlet
for about 10 seconds by unplugging the power cord from
the power outlet.
THE “HYBRID” OPERATING MODE (AIR HUMIDIFICATION AND AIR PURIFICATION)

18
en
“AIR HUMIDIFICATION” OPERATING MODE
Use of the HYBRID filter is optional in the “Air humidifica-
tion” operating mode.
1. Press the button until just the indicator for humidity
and the fan level are shown.
2. To switch back to the “Hybrid” operating mode, press
the button until the air purifier and humidifier are
both shown as active at the same time.
The BONECO H680 can also be used without a HYBRID
filter in the “Air humidification” operating mode. When
switching to the “Hybrid” or “Air purification” operating
mode, the following symbol flashes on the display if a
HYBRID filter is not inserted:
“AIR PURIFICATION” OPERATING MODE
The air is not humidified in the “Air purification” operat-
ing mode.
1. Press the button until just the indicator for air qual-
ity and the fan level are shown.
2. To switch back to the “Hybrid” operating mode, press
the button until the air purifier and humidifier are
both shown as active at the same time.
The BONECO H680 can also be used without water in
the “Air purification” operating mode. When switching to
the “Hybrid” or “Air humidification” operating mode, the
following symbol flashes on the display if the water tank
is empty:
ONLY AIR HUMIDIFICATION / ONLY AIR PURIFICATION

19
en
COMFORT MODES
There are three different comfort modes available in each
of the three “Hybrid”, “Air purification” and “Air humidifi-
cation” operating modes: , and .
SWITCHING THE COMFORT MODE
1. Switch between the , and comfort
modes by either:
• Pressing the button on the remote control repeat-
edly
• Pressing the button on the keypad on the appliance
repeatedly
“AUTO” COMFORT MODE
In comfort mode, the BONECO H680 uses all of the
fan levels between 1 and 6. The preset humidity is 50%.
“SLEEP” COMFORT MODE
In comfort mode, the BONECO H680 can even be
used in a bedroom at night. The appliance automatically
operates at the lowest fan level of 1 to keep operating
noise level to a minimum. The preset humidity is 45%.
“BABY” COMFORT MODE
The comfort mode uses fan level 1 through 4 and
increases the humidity to 60 %. This value is ideal for
use in a nursery or baby's room since higher humidity
is recommended for babies and small children. The fan
also operates quietly enough that it will not trigger a baby
monitor.
SELECTING THE VARIOUS COMFORT MODES

20
en MANUALLY REGULATING HUMIDITY AND FAN LEVEL
PERFECT HUMIDITY
The recommended humidity level is between 40% and
60%. The default setting is 50%. The indicator for current
humidity should ideally be within the “OK” range:
The humidity you set then stays saved if you switch off
the appliance.
CONTROLLING HUMIDITY
1. Press the and buttons to set the humidity as de-
sired.
The notice is shown on the display. Once you
stop pressing the arrow keys, the notice switches to
after a few seconds. Now the display now
shows the current humidity again.
MAXIMUM HUMIDIFICATION
Press the button until the notice “Co” (for “Continu-
ous”) is displayed. Now the humidifier operates indepen-
dently of the measured humidity.
REGULATING THE FAN LEVEL
1. Press the button once. The indicator for the fan
level flashes.
2. Press the and buttons to adjust the fan level.
3. To switch back to the comfort mode, press the
button on the appliance until the notice is shown
on the display. Alternatively, you can also use the
button on the remote control.
POWER MODE (P)
The maximum power mode (P) can only be selected man-
ually. We recommend using it when room air has to be
cleaned and/or humidified in the shortest possible time.
To activate the maximum power level, press the button
repeatedly until the fan level “P” is shown in the indicator
(see figure in the left column).
