BonsenKitchen HB8901 User manual

www.bonsenkitchen.com
OperationInstructions
Model: HB8901
Hand Blender

Contents
IMPORTANT SAFEGUARDS
NOTES ON THE CORD PLUG
PACKAGE CONTENTS
KNOW YOUR HANDLE BLENDER
TECHNICAL DETAILS
INITIAL USE
INSTRUCTION FOR BLENDER
INSTRUCTION FOR CHOPPER
INSTRUCTION FOR EGG WHITE BEATER
CLEANING AND MAINTENANCE
WARRANTY CLAIM PROCEDURE
ENVIRONMENT FRIENDLY DISPOL
1-2
3
3
4
4
4
5-6
6-9
9-10
11
12
12
........................................................................................
..................................................................................................
.................................................................
.................................................................................................
....................................................................................
......................................................................................
.................................................................................................................
...............................................................................
.............................................................................
...........................................................................
..............................................................................
...................................................................................

1
IMPORTANT SAFEGUARDS
Before using the electrical appliance, the following basic precautions should
always be followed including the following:
1. Read all instructions.
2. Before using check that the voltage of wall outlet correspond to the one
shown on the rating plate.
3. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
electrical or mechanical adjustment.
4. If the supply cord is damaged it must be replaced by the manufacturer or a
authorized service agent or a qualified technician in order to avoid a hazard.
5. Always disconnect the blender from the supply if it is left unattended and
before assembling, disassembling or cleaning.
6. Do not let cord hang over edge of table or hot surface.
7. Do not immerse upper part of blender into water as this would give rise to
electric shock.
8. Close supervision is necessary when your appliance is being used near
children or infirm persons.
9. Avoid contacting moving parts.
10. Keep hands and utensils out of container while blending to reduce the risk of
severe injury to persons or damage to the blender. A scraper may be used but
must be used only when the blender is not running.
11. The appliance cannot be used for chopping ice or blending hard and dry
substance, otherwise the blade could be blunted.
12. To reduce the risk of injury, never place cutting blade on base without first
putting bowl properly in place.
13. Be sure chopper lid is securely locked in place before operating appliance.
14. The use of accessory not recommended by the manufacturer may cause
injuries to persons.

2
15. Do not operate the appliance for other than its intended use.
16. Children should be supervised to ensure that they do not play with the
appliance.
17. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older than 8 and
supervised.
18. Save these instructions. HOUSEHOLD USE ONLY
19. The use of accessory not recommended by the manufacturer may cause
injuries to persons.
20. Before removing the lid from the jar, release the button and unplug the
appliance, wait until the blades have come to a complete stop.
21. Always remove the blade assembly before pouring contents from jar.
22. Be sure to switch off the appliance after each use of your food processor.
Make sure the motor stops completely before disassembling.
23. The metal blades are extremely sharp,please handle carefully.
24. Always hold the blade stem instead of cutting edge when handling and
cleaning the blade.
25. Be care of potential injury from misuse.

3
NOTES ON THE CORD PLUG
PACKAGE CONTENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug will fit in a polarized outlet only one way. If the
plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not modify the plug in any way.
1 motor unit
1 blend rod
1 chopper lid
1 knife blade
1 egg whisk
1 blending jar
1 chopper bowl
Operating instructions
Check the delivery contents for completeness immediately after unpacking.
Remove all packaging materials and plastic film from the appliance.

1. Top lid
2. Speed knob
3. Low speed button
4. High speed button (turbo button)
5. Motor unit
6. Coupler
7. Blend rod
8. Chopper lid
9. Kinfe blade
10. Egg whisk
11. Chopper bowl
12. Blending jar
KNOW YOUR HANDLE BLENDER
1
3
4
5
6
2
7
10 11
812
TECHNICAL DETAILS
INITIAL USE
120V~60Hz, 225W
Before the first use, clean the blender according to the section of “quick cleaning”.
The time running unit without load can’t exceed 15s.
Important: Blades are very sharp, handle with care. Ensure that the hand-held
blender is unplugged from the power outlet before assembling or removing
attachments.
4

5
INSTRUCTION FOR BLENDER
Max operation duration per time should less than 1 minute, and 3 minutes rest
time must be maintained at two consecutive cycles.
1) To assemble the blend rod
with the motor unit.
3) Simply plug the hand-held
blender to power outlet.
2) Turn the shaft anti-clockwise direction
until tightened. To unlock, just turn it
in the adverse direction.
4) Place food into the blending jar.
Note: When blending carrot, cut small piece,
and place it into small chopper bowl, then
add water, the max quantify of carrot can't
exceed 280g, water, 420g, in every blending.
lock
( IT IS SUITABLE FOR BLENDING VEGETABLE AND FRUIT )

6
5) Lower the hand-held blender into
food.Then press and hold the low
speed button or high speed button
to start operating.
6) To stop the hand-held blender by
releasing the low speed button or
high speed button.
INSTRUCTION FOR CHOPPER
Max operation duration per time should less than 30 second, and 3 minutes rest
time must be maintained at two consecutive cycles.
1) Place the chopper bowl on a
clean, level surface.
2) Assemble the stainless chopping
blade into the chopper bowl.
( USING FOR CHOPPING MEAT AND MAKING GARLIC PASTE )

3) Place food into the chopper bowl.
5) Insert the motor unit into the hole
of the chopper lid.
4) Attach the lid onto the chopper bowl
by pressing it down. To detach the lid
by lifting it up.
6) Lower the hand-held blender into
food. Then press and hold the low
speed button or high speed button
to start operating.
Note: remove the bone of the meat, cut
small piece, then place the meat into
bowl, the max quantity of meat can’t
exceed 200g in every blending.
7

8
7) To stop the appliance by releasing
the low speed button or high speed
button of the motor unit.
9) Then remove the motor unit from
the chopper lid by turning it in
anti-clockwise.
8) After finishing chopping, unplug the
power outlet firstly,
10) Open the chopper lid by turning it
in anti-clockwise and remove the
chopped food.

- To reduce the risk of injury, never place cutting blade on base without first
putting bowl properly in place.
- Be sure chopper lid is securely locked in place before operating appliance.
- During operating or after chopping, for safety, you shall disassemble the motor
unit from the chopper lid firstly, then remove the chopper lid. Never remove the
chopper lid with the motor unit in place.
Caution:
INSTRUCTION FOR EGG WHITE BEATER
Max operation duration per time cannot exceed 1 minute, and 3 minutes rest
time must be maintained at two consecutive cycles.
1) To assemble the egg white beater
with the motor unit, turn the whisk
anti-clockwise direction until
tightened. To disassemble, just turn
in the adverse direction.
2) Simply plug the hand-held
blender to power outlet.
( FOR MIXING EGG WHITE )
lock
9

3) Place egg white into the cup,
generally, two eggs white is enough.
5) Then press and hold the low speed
button or high speed button to start
operating.
4) Lower the hand-held blender
into food.
6) To stop the hand-held blender by
releasing the low speed button or
high speed button of the motor unit.
The jar can be only used for blending food, please clean it immediately after each
use. Never use it to store food.
Note:
10

CLEANING AND MAINTENANCE
1. Unplug the appliance and remove the detachable stem.
Do not immerse the detachable stem of the blender in water because Note:
overtime the lubrication on the bearings may wash away.
2. Wash the detachable stem under running water, without the use of abrasive
cleaner or detergents. After finishing cleaning the detachable stem, place it
upright so that any water which may have got in, can drain out. The stem is
dishwasher safe component.
3. Wash the cup, bowl, beater and blade in warm soapy water. The bowl and the
beater are not recommended to place in dishwasher as the plastic component
deteriorates through prolonged use of dishwasher cleaning.
4. Wipe the motor unit with a damp cloth. Never immerse it in water for cleaning
as a electric shock may occur.
5. Dry thoroughly.
Blades are very sharp, handle with care.Caution:
Quick cleaning
Between processing tasks, hold the hand-held blender in the cup half filled with
water and turn on for a few seconds.
11

WARRANTY CLAIM PROCEDURE
To ensure quick processing of your case, please observe the following instructions:
Please have the till receipt and the item number (S/N: 12345) available as proof
of purchase.
You will find the item number as a sticker on the rear or bottom of the appliance.
If malfunctions or other defects occur, please contact our customer service listed
either by telephone or by email.
If you request any further assistance, please contact us:
Customer service: 1-888-965-8032
[e-mail]
This product must not be disposed together with the domestic waste. This product
has to be disposed at an authorized place for recycling of electrical and electronic
appliances. By collecting and recycling waste, you help save natural resources, and
make sure the product is disposed in an environmental friendly and health way.
ENVIRONMENT FRIENDLY DISPOL
12

Register your product at www.bonsenkitchen.com
to get more perks!
: 5805C Peachtree Corners East
Norcross, GA, 30092
: 1-888-965-8032
: [email protected]
Follow us @bonsenkitchen
Bonsen Electronics Inc.
