Modular Drawer Cabinets
Installation Instructions
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Read all instructions before proceeding with installation or
drawer loading. Vital product information pertaining to
proper set-up and cautions are included. Failure to follow
these instructions may cause failure which may result in
personal injury or property damage.
——————IMPORTANT——————
PRODUCT LIABILITY INFORMATION

Borroughs Document Number: MDC-0730 www.borroughs.com
MDC FLOOR ANCHORING
Cut out supplied paper template and
layout hole locations. Please note, it is
only necessary to floor anchor the rear
of the cabinet.
Drill holes as specified on template.
Drop in floor anchors or thread lag
bolts partially into the floor.
Push cabinet back, engaging
hardware.
Remove bottom drawers (reference this
document), and from the inside of the
cabinet, tighten hardware via access
holes in bottom pan.
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730
DRAWER REMOVAL
Open drawer.
Release both safety clips
by applying a downward
force. Drawer may now
be removed by lifting up
as you pull drawer from
slides.
Lift the front of drawer as
you close. Closing the
drawer fully will automati-
cally lock the safety clips.
Locate safety clips on
both sides of slide profile.
To reinstall drawer, first
ensure that both safety
clips are in the released
state, then align drawer
rails with the slide rollers.
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730
DRAWER LABEL REPLACEMENT
AND LOCK REMOVAL
To remove the labels in the alu-
minum drawer handle, simply push
the label up within the handle and
slide to the right. To reinstall, ensure
the label has been moved fully to the
left and dropped behind the catch in
the end cap.
7/8” retaining nut
To remove lock, pull the top few
drawers to gain access to the back of
the lock. The lock is held in place by
a threaded retaining nut. Use a 7/8”
open ended wrench to remove, than
pull out lock from front of cabinet.
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730
LINKING MULTIPLE CABINETS
Optional: For additional stability or seismic
zones, pre-drill floor for anchoring.
Remove top and bottom drawers to access the
floor anchoring and mounting holes.
Replace Drawers
Use punch to remove knockouts (A) when
stacking multiple cabinets.
Using supplied hardware, fasten cabinets
together. Link adjacent cabinets (B) before
stacking (C) multiple units.
QTY (4) 3/8-16X1 flanged cap
screw
QTY (4) 3/8-16 serrated
flanged locknut
QTY (4) 3/8-16X1 flanged cap
screw
QTY (4) 3/8-16 serrated
flanged locknut
QTY (4) 3/8x1-1/4 fender
washer
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730 www.borroughs.com
MDC LOCK CORE REMOVAL
Use standard or master key to ensure
MDC cabinet is in the un-locked state
Insert the core removal key
Ensure core key is fully seated While pressing on joint between core
and key, pull-out and Remove core.
Reverse steps to install new core
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730
MDC BASE CAP INSTALLATION
Locate base cap and place in front
of cabinet, ensure the base cap
notch is at top.
Insert one end of base cap
completely into the le forkli
channel.
Push base cap in and slide into the
right fork li channel.
Kick plate notches should integrate
with forkli channels and snap
into place.
Duplicate process at back of
cabinet, if necessary.
Notch at top
NOTE: To remove, reverse process.
(A at screw driver may be required to disengage)
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730
DRAWER LATCHING MECHANISIMS
The Multiple Drawer Access (MDA)
mechanism allows multiple drawers
to be open at the same time. The
mechanism attaches to the universal
latching mount at the back of the
cabinet. The mechanism can be
dis-assembled by removing the lock
and lock rod, then removing the torx
head screws (T15 bit) that hold on
the rest of the mechanism to the
universal latch mount.
The Single Drawer Access (SDA)
mechanism limits access to one
drawer at a time. This also acts as an
anti-tipping mechanism when mobile
or high loads are of concern. The
mechanism attaches to the universal
latching mount and can be dis-
assembled by removing the lock and
lock rod, then removing the torx head
screws (T15 bit) that hold the SDA
latch assembly to the universal latch
mount.
MDA Latch Channel
SDA Latch Assembly
Universal Latch Mount
Lock Rod
Lock Cylinder
Lock Rod Support
Channel Support
Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730 www.borroughs.com
Borroughs Document Number: MDC-0730 www.borroughs.com
NOMINAL
CABINET
WIDTH
ACTUAL
CABINET
WIDTH A
23 WIDE 22-13/16” 18-3/16”
30 WIDE 30” 25-3/8”
45 WIDE 45-3/16” 40-9/16”
60 WIDE 60-3/8” 55-3/4”
CUT ALONG DASHED LINE
2 5/16
1 17/32
BACK SIDE OF CABINET
CENTER
OF HOLE
TO BE
DRILLED
CENTER
OF HOLE
TO BE
DRILLED
LEFT SIDE
OF CABINET
RIGHT SIDE
OF CABINET
2 5/16
A
DRILLING TEMPLATE
For concrete floors:
Drill (2) 3/8” diameter holes
2” deep
For wooden floors:
Drill (2) 1/4” diameter holes
1-3/4” deep

Borroughs Document Number: MDC-0730 www.borroughs.com

Borroughs Document Number: MDC-0730 www.borroughs.com
Ax Serial# Scker Here
(from inside top drawer or shelf)
FINAL INSPECTION CHECK LIST
Cabinets
PRE-PACKAGING__________________________________________
Verify drawer / door conguraon matches trailer drawing.
Verify drawer interiors / door-shelf conguraon matches trailer drawing.
Verify housing and drawer color matches trailer drawing.
Verify cabinet / door lock style matches trailer drawing.
Operate cabinet / door locks for proper latching.
Verify single drawer operaon for SDA lock style.
Operate drawers / door to full extension stop insuring smooth operaon.
Close each drawer within 1” to insure “self-closing”.
Verify drawer fronts / door are true, in-line, and surrounding gaps are nominal.
Verify that parons are screwed to drawer body.
Verify that drawer labels have been installed.
Verify plasc clips are installed on shelves.
Clean any ngerprints on painted surfaces.
PACKAGING______________________________________________
Verify that base caps have been packed.
Verify key envelope is inside top drawer.
Verify hardware bag is inside top drawer.
Mark inspecon label with serial# (yr-mo-dy) and sign.
Apply inspecon scker to inside-front-right corner of top drawer or on shelf.
Place this owner’s manual in top drawer or shelf of cabinet.
Tie key bag through slot in the top drawer, hold key bag outside and close drawer.
Lock cabinet and place second key bag.
Apply trailer drawing to cabinet during stretch-wrapping process.
Borroughs Document Number: MDC-0730 www.borroughs.com
