Borum BAJ2080 User manual

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
OWNER’S MANUAL
PRODUCT CODE: BAJ2080
10,000-25,000-50,000kg AIR/HYDRAULIC
GARAGE JACK
1st Stage
Lifting
Capacity
2nd Stage
Lifting
Capacity
3rd Stage
Lifting
Capacity
Max Lift
Height
Min Lift
Height
Air Supply
Pressure
Package Size
(mm)
50,000kg
25,000kg
10,000kg
300mm
150mm
100-145psi
710x370x290

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this equipment. Do not allow anyone to use or operate this equipment until
they have read this manual and have developed a thorough understanding of how this
equipment works. Failure to observe any of the instructions contained in the manual could
result in severe personal injury to the user or bystanders, or cause damage to the equipment
and property. Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .....................................................................................................................................2
CONTENT ......................................................................................................................................2
SAFETY INSTRUCTIONS .................................................................................................................3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE..............................................................4
TROUBLESHOOTING .....................................................................................................................7
WARRANTY .................................................................................................................................10

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
SAFETY INSTRUCTIONS
WARNING
FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL
INJURY
Support load by appropriate means after
lifting
Do not exceed rated capacity
Centre load on the jack
Only use attachments and/or adapters
supplied with or sold specifically for the
jack
Only lift areas of the vehicle designated by
the vehicle manufacturer.
Use as lifting device only
Use only on hard, level surface
Do not modify jack
SAFETY OPERATNG INSTRUCTIONS
This jack should be used for lifting and lowering only. The raised vehicle should be
supported on approved vehicle stands. No person should get any part of the body
under a vehicle that is supported by this jack.
Position the jack to only lift on the areas of the vehicle specified by the vehicle
manufacturer.
Use support stands –after lifting the vehicle always support the load with
appropriately rated vehicle support stands before working on the vehicle.
Do not overload this jack beyond its rated capacity. Overloading this jack beyond its
rated capacity can cause damage to or failure of the jack.
Use only on hard level surfaces capable of sustaining the load. Use on other than
hard level surfaces can result in jack instability and possible loss of load.
Centre load on jack saddle before lifting vehicle.
Off centre loads and loads lifted when the jack is not level can cause loss of load or
damage to the jack.
Keep hands & feet clear of the jack hinge mechanism & ground contact area when
lowering the load.
THIS JACK IS A LIFTING DEVICE ONLY & IS DESIGNED FOR LIFTING PART OF THE TOTAL
VEHICLE. DO NOT MOVE OR DOLLY THE VEHICLE WHILST THE VEHICLE IS ON THE JACK.

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
2. The Borum Air/Hydraulic garage jack utilises compressed air to activate a booster
cylinder, to move hydraulic oil within the cylinder up & down. It adopts a industrial
hydraulic design combination of compressed air and hydraulic pressure, to create, strong
jacking capacity and low lifting clearance in one jack. This floor jack lets you really get
under your loads with a 150mm minimum height. Designed to lift buses and other large,
low-clearance vehicles with maximum stability.
3. ASSEMBLY
Assembly of Handle: After removing from the packing material, make sure the product is
in perfect condition and that there are no visible damaged parts. Dispose of the packaging
material responsibily.
1. Unscrew the wheels from the jack, and assemble the handle fork between the
wheels and jack body by bolts and washers.
2. Connect the red air hose in the handle to the hose coupler with red hose end, and
the blue one to the coupler with blue end.
3. Open the ball valve (Part #23) by turning the knob counter-clockwise.
Bleed Air from the Garage Jack: Air can accumulate within a hydraulic system during
shipment or after prolonged use. This entrapped air causes the jack to respond slowly or
feel “spongy”. To remove the air:
1. Move the control lever to DOWN position, and hold it there for a few seconds.
2. Move the control lever to UP position to complete the load-free lifting cycle.
3. Move the control lever to DOWN position to retract the jack pistons. The pistons
should react in a smooth motion. If not, repeat steps 1-3.
4. If the jack does not immediately respond, repeat steps 1-3
4. BEFORE USE
Prior to each use conduct a visual inspection checking for abnormal conditions, such as
cracked welds, leaks, and damaged, loose, or missing parts.
Consult the vehicle owner’s manual to determine the location of lift points.
Be sure to set the vehicle in park with the emergency brake on and wheels securely
chocked.
Be sure that the vehicle and the jack are on a hard, level surface.

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
5. OPERATION
1. Verify the control level is in the neutral position.
2. Connect compressed air supply to the jack. (Compressed air should be clean, dry,
and regulated at 100-145psi). Install an air filter/lubricator in the shop air line,
because water in the air line will damage the jack.
3. Make sure the jack and vehicle are on a hard level surface.
4. Always set the vehicle parking brake and block the wheels.
5. Move the control lever to UP to raise the saddle to the contact point. Move the
control level to neutral position.
6. Check the placement of the jack. The load must be centered on the jack saddle.
Avoid jack wheel obstructions such as gravel, tools, or uneven expansion joints.
7. Position the jack under the vehicle using the manufacturer's recommended lifting
points on the chassis.
8. Move the control lever to UP to finish lifting the vehicle.
9. Always immediately position approved jack stands under the vehicle at points that
will provide stable support in accordance with the vehicle manufactures
recommendations.
10. Always lower the vehicle slowly onto the jack stands by pushing the control lever to
the DOWN position.
6. INSPECTION
Prior to each use conduct a visual inspection checking for abnormal conditions, such
as cracked welds, leaks, and damaged, loose, or missing parts.
The jack shall always be maintained in accordance with the maintenance instructions
(Section 7). No alterations or modifications shall be made to this Jack.
Inspections shall be performed in accordance with this owner’s manual.
The jack must be inspected immediately if it is believed to have been subjected to
abnormal load or shock.
Owners and /or operators should be aware that repair of this product may require
specialised equipment and knowledge (refer to maintenance section).
7. STORAGE
This jack should always be stored in a dry location on a level surface with the lift ram
pistons in the fully retracted position, where it will not be exposed to corrosive vapours,
abrasive dust, or any other harmful elements.

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
8. MAINTENANCE
Monthly maintenance is recommended. Lubrication is critical to jacks as they support
heavy loads. Any restriction due to dirt, rust, etc, can cause either slow movement or
cause extremely rapid jerks damaging the internal components. The following steps are
designed to keep the jack well maintained and operational.
Important: Dirt is the greatest single cause of failure in hydraulic units. Keep the jack
clean and well lubricated to prevent foreign matter from entering the system. If the jack
has been exposed to rain, snow, sand, or grit it must be cleaned before it is stored or
used.
Only use replacement parts that are approved by the manufacturer. Disconnect the
air supply before performing any maintenance operation.
Lubricate the ram, linkages, saddle, wheels and pump mechanism with light oil.
Visually inspect for cracked welds, bent, loose, missing parts or hydraulic oil leaks.
Any hydraulic jack found to be damaged, worn or operates abnormally must be
removed from service until repaired by an authorised service representative.
Regularly clean all surfaces and maintain all labels and warnings.
Check and maintain the hydraulic ram oil level.
Check the ram every three months for any sign of rust or corrosion. Clean as needed
and wipe with an oily cloth. When not in use always leave the saddle and ram all the
way down.
Always store your jack in the fully retracted position. This will help protect critical
areas from corrosion. Do not use brake or transmission fluids or regular motor oil as
they can damage the seals.
ONLY USE HIGH QUALITY HYDRAULIC FLUID –ISO68
9. SERVICE & REPAIR
Any jack found damaged in any way, or found to be worn or operates abnormally should
be removed from service until repaired by an authorised service agent. Owners and / or
operators should be aware that repair of this product may require specialised equipment
and knowledge. Only authorised parts, labels, decals shall be used on this equipment.
Annual inspection of the jack is recommended and can be made by an authorised repair
facility to ensure that your equipment is in optimum condition and that the equipment
has the correct decals and safety labels specified by the manufacturer.

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 7
Visit us at www.tqbbrands.com.au
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
ACTION
Jack will not lift
Control valve in wrong position.
Low/no oil in reservoir.
Air-locked system.
Load is above capacity of jack.
Delivery valve and/or bypass valve
not working correctly.
Seals worn out or defective.
Move control valve to UP
position.
Fill with oil and bleed system.
Bleed system.
Use correct equipment.
Clean to remove dirt or foreign
matter. Replace oil.
Install appropriate seal kit.
Jack lifts only
partially
Too much or not enough oil
Check oil level
Jack advances slowly
Pump not working correctly
Leaking seals
Install seal kit, or replace
power unit
Install seal kit
Jack lifts load, but
doesn’t hold
Cylinder packing is leaking
Valve not working correctly
(suction, delivery, release or
bypass).
Air-locked system
Install seal kit
Inspect valves. Clean and
repair seat surfaces
Bleed system as per
instructions
Jack leaks oil
Worn or damaged seals
Install seal kit
Jack will not retract
Control valve in wrong
position
Move Control valve to
DOWN position
Jack retracts slowly
Cylinder damaged internally
Send jack to authorised
service centre

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 8
Visit us at www.tqbbrands.com.au
Part #
Description
QTY
Part #
Description
QTY
1
Guild Ring A
1
42
Adjusting Screw
1
2
Nylon Gasket A
1
43
Safety Valve Seal
1
3
Y-Ring
1
44
Safety Valve Screw
1
4
Cover Board
1
45
Spring
1
5
O-Ring
1
46
Spring
1
6
Nylon Gasket B
1
47
Copper Washer B
1
7
O-Ring
1
48
Allen Screw
3
8
Bolt
8
49
Copper Washer C
1
9
Steel Ball
2
50
Release Valve
1
10
Adaptor
1
51
Oil Flow Valve
1
11
Guild Ring B
1
52
Coupler G 1/4-6
3
12
Nylon Gasket C
1
53
Elbow Coupler
1
13
Y-Ring B
1
54
Multi-Routine Valve
1
14
Outer Ram
1
55
Elbow Coupler
2
15
Retainer
1
56
Allen Screw
1
16
Guild Ring C
1
57
Vacuum Valve
1
17
Nylon Gasket D
1
58
Elbow Coupler
1
18
Y-Ring C
1
59
Elbow Coupler
1
19
Middle Ram
1
60
Connection Bracket
1
20
Guild Ring D
1
61
Saddle Adaptor
2
21
Inner Ram
1
62
Allen Screw
9
22
Guld Ring E
1
63
Bushing
2
23
Handle Grip
1
64
Bushing
2
24
Clip
2
65
Wheels
2
25
Pin
2
66
Flat Washer
2
26
Jack Base
1
67
Allen Screw
2
27
Coupler G1/4-8
1
68
Spring
1
28
Ball Valve
1
69
Handle
1
29
Allen Screw
1
70
Control Rod
1
30
O-Ring
1
71
Handle Grip
1
31
O-Ring
1
72
Handle Sleeve
2
32
Air Motor
2
73
Control Valve
1
33
Copper Washer A
1
74
Valve Board
1
34
Valve Block
1
75
Screw
3
35
Steel Ball
2
76
Muffler
2
36
Spring
1
77
Air Inlet Coupler
1
37
Copper Washer B
2
78
Lock Pin
1
38
Spring Seat
1
79
Lock Pin
1
39
Steel Ball
1
80
Saddle A
1
40
Ball Valve Seat
1
81
Saddle B
1
41
Safety Valve Spring
1
82
SaddleC
1
83
Cover
1

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 9
Visit us at www.tqbbrands.com.au

Product Code: BAJ2080
Made in China to TQB Brands Pty Ltd specifications Page 10
Visit us at www.tqbbrands.com.au
WARRANTY
Borum products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is
ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[email protected].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accident, or repairs attempted or made by any personnel other than the
authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a
dated receipt or invoice to verify your proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
