Bosch IMSA Prototype Classes Scrutineering System User manual

IMSA Prototype Classes Scrutineering
System
Manual
V1.2.5 1/28/2019

Table of Contents
2 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
Table of Contents
Manual ...................................................................................................................................................................................1
Table of Contents .................................................................................................................................................................2
1Scope................................................................................................................................................................................. 4
2Contact.............................................................................................................................................................................. 4
2.1 Sales.................................................................................................................................................................................................................4
2.1.1 Track Sales...........................................................................................................................................4
3Components..................................................................................................................................................................... 5
3.1 LMP2 Architecture......................................................................................................................................................................................5
3.2 Electronic Hardware ..................................................................................................................................................................................5
3.2.1 DDU9...................................................................................................................................................6
3.2.2 PBX90..................................................................................................................................................6
3.2.3 IMU –MM5.10....................................................................................................................................7
3.2.4 LT4 (DPi Only)......................................................................................................................................7
3.2.5 GPS......................................................................................................................................................7
3.2.6 USB Stick .............................................................................................................................................8
3.2.7 X2 Transponders .................................................................................................................................8
3.2.8 Leaderlight Controller.........................................................................................................................9
3.2.9 Pro/Am Light.......................................................................................................................................9
3.2.10 Delphi Yellow Light System ...........................................................................................................9
3.3 Sensors ........................................................................................................................................................................................................ 10
3.3.1 1 Bar Pressure...................................................................................................................................11
3.3.2 3.5 Bar Boost Pressure......................................................................................................................11
3.3.3 Pitot Tube..........................................................................................................................................12
3.3.4 Laser Ride Height ..............................................................................................................................12
3.3.5 Temp Sensor .....................................................................................................................................12
3.3.6 LSU 4.9 Lambda Sensor.....................................................................................................................13
3.3.7 Engine Speed Sensor.........................................................................................................................13
3.3.8 Fuel Flow Meter............................................................................................................................1413
3.4 Sensor Declaration Form................................................................................................................................................................. 1415
3.5 Component Seals ............................................................................................................................................................................... 1415
4System Architecture ................................................................................................................................................ 1516
4.1 Team CAN ............................................................................................................................................................................................. 1516
4.1.1 Team Connector ................................................................................................................................................................................. 1516
4.1.2 Team CAN 1.......................................................................................................................................................................................... 1516
4.1.3 Team CAN 2.......................................................................................................................................................................................... 1617
4.1.4 Driver ID ................................................................................................................................................................................................. 1617
4.2 Power Supply ....................................................................................................................................................................................... 1718
4.3 Harness................................................................................................................................................................................................... 1819
5Loom Certification ................................................................................................................................................... 1920

Bosch Motorsport IMSA Prototype Class Scrutineering Logger 3 / 47
6CAN Specification .................................................................................................................................................... 2021
6.1 Team Transmitted Channels .......................................................................................................................................................... 2021
6.2 Team Received Channels................................................................................................................................................................. 2122
6.3 Message Bus......................................................................................................................................................................................... 2223
6.4 DBC file................................................................................................................................................................................................... 2223
7Display Pages............................................................................................................................................................ 2223
7.1 Driver Page............................................................................................................................................................................................ 2223
7.1.1 Standard................................................................................................................................................................................................. 2223
7.1.2 Alerts ....................................................................................................................................................................................................... 2324
7.2 Mechanic Page .................................................................................................................................................................................... 2526
8Loom Layout ............................................................................................................................................................. 2627
9Appendix ................................................................................................................................................................... 2930
a. DDU9....................................................................................................................................................................................................... 2930
b. PBX90 ...................................................................................................................................................................................................... 3031
c. IMU........................................................................................................................................................................................................... 3132
d. LT4............................................................................................................................................................................................................ 3233
e. GPS........................................................................................................................................................................................................... 3334
f. 1 Bar Pressure ...................................................................................................................................................................................... 3536
g. 3.5 Bar Pressure................................................................................................................................................................................... 3637
h. Pitot Tube .............................................................................................................................................................................................. 3738
i. Temperature......................................................................................................................................................................................... 3839
j. Lambda................................................................................................................................................................................................... 3940
10 Vibration Profile 1.................................................................................................................................................... 4041
11 Order Form................................................................................................................................................................ 4142
12 Revisions.................................................................................................................................................................... 4546

Table of Contents
4 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
1Scope
This document contains application notes on the installation and operation of the
IMSA Prototype Classes Scrutineering System.
2Contact
For technical information please contact:
Erich Ohlde
[email protected]ch.com
Tel: [phone]
Or
Aaron Pfeifer
[email protected]ch.com
Tel: [phone]
2.1 Sales
Sales will be performed through Bosch Motorsports using the included order form.
2.1.1 Track Sales
Customers requiring spare parts purchased and delivered at the racetrack are
subject to a 10% service fee.

3 | Components
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 5 / 47
3Components
3.1 LMP2 Architecture
LMP2 classification cars will not utilize the LT4 and LSU 4.9 lambda sensors or any
engine sensor, at this time. The chassis loom of the LMP2 cars must include wiring
for these components. The engine loom is not required to include provisions for
these components in LMP2 cars.
3.2 Electronic Hardware
Component List:
Part Number
Mating Connector
Name
Description
F02U.V0U.290-01
AS616-35 SN
DDU9
P Scrutineering Logger
F02U.V01.794-05
F02U.B00.760-01
F02U.B00.761-01
F02U.003.574-01
PBX90
PowerBox
F02U.V01.511-02
F02U.B00.435-01
IMU
5 axis IMU
1271.032.390
IMU Plate
IMU mounting plate
F01T.A20.070-09
AS114-35PN
LT4
Lambda controller
F02U.V0U.203-01
or
F02U.V0U.268-01
ASU603-03SN
GPS
10 Hz GPS unit
F02U.V0U.267-01
ASL106-05SD
1 Bar Pressure
Air pressure sensor
F02U.V0U.205-01
ASL106-05SB
3.5 Bar Pressure
Boost pressure sensor
F02U.V02.356-01
ASL106-05SN
Temperature Sensor
Air temperature sensor
F02U.V0U.264-01
ASL106-05SE
Pitot Tube
Pitot Tube
F02U.V01.342-01
02W08 F004S BK1 E1AA
USB Stick
Scrutineering data USB
0258.988.001
D261.205.356-01
LSU 4.9
Lambda Sensor
AS108-35SN
Leaderlight panel*
Position display
ASU603-05SN
X2 Transponder*
Timing Transponder
ASL106-05SA-HE
Engine Speed**
RPM sensor
ASDD606-09SD-HE
Fuel Flow*
Fuel flow sensor
ASL606-05SC
Ride Height**
Laser ride height sensor
DTM06-2S-E007
Delphi System*
Yellow light system
DTM06-2S-E007
TV/Video*
Series camera power
DTM06-2S-E007
Pro/Am Light**
Pro/Am indicator
* Denotes component available from IMSA or other spec suppliers
** Denotes component supplied by team

3 | Components
6 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.2.1 DDU9
Functional Description: Logger and Marshalling Display for IMSA Prototype Class
Scrutineering System
Mounting Note:
This device must be fitted in the cockpit in an easily accessible IMSA
approved location.
This device must be mounted away from heat sources. Note maximum
temperature range below.
This device should be mounted so that the display can be easily seen by
the driver while on course.
This device should be mounted to sustain vibrations within the Vibration
Profile 1 defined in the appendix.
Brightness Control: Brightness must be commanded via CAN by a value of 1-6,
message details found in the DBC.
Part Number: F02U.V0U.249-01
Temperature Range: -20 to 70 °C
3.2.2 PBX90
Functional Description: Powerbox for IMSA Prototype Class Scrutineering System
Mounting Note:
This device must be fitted in the cockpit in an easily accessible IMSA
approved location.
This device must be mounted away from heat sources. Note maximum
temperature range below.
This device should be mounted so that the device can be easily accessed.
Part Number: F02U.V01.794-05
Temperature Range: -20 to 85 °C

3 | Components
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 7 / 47
3.2.3 IMU –MM5.10
Functional Description: 5 axis inertial measurement unit
Mounting Note:
This device must be fitted in the cockpit on the centerline of the
longitudinal axis of the vehicle in an easily accessible IMSA approved
location. Use of the mounting bracket listed below is required.
Device to be mounted with connector receptacle facing to the back of the
vehicle and product sticker facing vertically ‘up’. Mounting plate to be
aligned within +/-0.5° of vehicle axes.
Part Number: F02U.V01.511-02
Mounting Bracket Part Number: 1271.032.390
Temperature Range: -20 to 85 °C
3.2.4 LT4 (DPi Only)
Functional Description: 4 channel lambda sensor controller
Mounting Note:
This device must be fitted securely in the cockpit in an easily accessible
location.
This device should be mounted to sustain vibrations within the Vibration
Profile 1 defined in the appendix.
Part Number: F01T.A20.070-09
Temperature Range: -20 to 85 °C
3.2.5 GPS
Functional Description: 10 Hz GPS unit
Mounting Note:
This device must be fitted to the top surface of the vehicle in an IMSA
approved location.
Part Number: F02U.V0U.203-01 OR F02U.V0U.268-01

3 | Components
8 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.2.6 USB Stick
Functional Description: IMSA Scrutineering USB Stick
Mounting Note:
This device must be fitted in a plainly visible IMSA approved location.
Device must be mounted beside the IMSA Diagnostic port on a bulkhead
style plate. An example is shown below.
Temperature Range: -40 to 85 °C
USB Stick Possession: IMSA will distribute and collect USB Sticks at every race,
teams will not receive sticks with scrutineering components nor are they required to
purchase these separately.
3.2.7 X2 Transponders
Functional Description: CAN based transponder for IMSA Prototype Class
Scrutineering System
Mounting Note:
Each car will carry two X2 Transponders.
These devices must be mounted in an IMSA approved location. See IMSA
Bulletins for mounting information.
Temperature Range: 0 to 60 °C

3 | Components
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 9 / 47
3.2.8 Leaderlight Controller
Functional Description: Leaderlight controller boxes and panels
Mounting Note:
This device(s) must be fitted securely.
3.2.9 Pro/Am Light
Functional Description: Pro/Am driver light indicator
Mounting Note:
This device must be mounted away from heat sources.
This device must be mounted in the IMSA specified location specified in
IMSA technical regulations.
Harness Pinout:
Connector DTM06-2S-E007
Pin Description
1 12V PWR
2 GND
3.2.10 Delphi Yellow Light System
Functional Description: Delphi yellow light track condition light system
Mounting Note:
This device must be mounted in a dry location using IMSA supplied Anti-
Vibration Plate in the IMSA specified location.
Antenna must be mounted following IMSA instructions.

3 | Components
10 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.3 Sensors
This section declares sensors that must be directly connected to the IMSA
scrutineering system. IMSA will define required engine sensors and locations for
each engine application. These signals will be fed back to the teams via CAN.
All Prototype cars must run:
Cockpit temperature
Pitot tube
Laser Ride Height sensors (if used)
In addition, DPi cars must run:
Engine Sensors
oIntercooler Upstream temperature(s) (Turbo only)
oPlenum pressure(s) (NA only)
oPlenum temperature(s) (NA only)
oInlet Port pressure(s) (NA only)
oBoost pressure(s) (Turbo only)
oInlet Port temperature(s)
oRestrictor Throat pressure(s) (NA only)
oLambda(s)
oFuel flow meter
oEngine speed sensor
Sensors must be installed in an IMSA approved location as identified in
Scrutineering System homologation documentation.

3 | Components
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 11 / 47
3.3.1 1 Bar Pressure
Functional Description: Air pressure sensor
Use Case:
Plenum Pressure (NA engines):
Inlet Port (NA engines):
Restrictor Throat Pressure (NA engines):
Callout: Driver’s left bank will be Sensor #1
Part Number: F02U.V0U.267-01
Pressure Range: 0.1 –1.15 bar
Temperature Range: -40 to 125°C
3.3.2 3.5 Bar Boost Pressure
Functional Description: Boost pressure sensor
Use Case:
Boost Pressure (Turbo engines):
Callout: Driver’s left bank will be Sensor #1
Part Number: F02U.V0U.205-01
Pressure Range: 0.5 –3.5 bar

3 | Components
12 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.3.3 Pitot Tube
Functional Description: Temperature and pressure sensor
Use Case:
Dynamic Conditions:
oMeasure dynamic conditions of air flowing over the car.
Mounting Note:
oPitot sensor must be mounted in the IMSA homologated position.
No other pitot tubes are permitted on the car.
Part Number: F02U.V0U.264-01
3.3.4 Laser Ride Height
Functional Description: Dynamic ride height measurement
Use Case:
Ride Height:
oMeasure dynamic ride height of car in multiple locations.
oEach manufacturer may select a sensor to be approved by IMSA.
Mounting Note:
oRide height sensors must be mounted in the IMSA homologated
position connected to the scrutineering system if run. No other ride
height sensors are permitted on the car.
Harness Pinout:
Connector
ASL606-05SC
Pin
Description
1
12V+ KL.30
2
GND
3
Signal
4
5
3.3.5 Temp Sensor
Functional Description: Temperature sensor
Use Case:
Plenum Temperature (NA engines):
Intercooler Upstream Temperature (Turbo engines):
Inlet Port Temperature:
Cockpit Temperature:
Callout: Driver’s left bank will be Sensor #1
Part Number: F02U.V02.356-01
Temperature Range: -55 to 300 °C
Thread: M6 x 1
Installation Torque: 8 Nm

3 | Components
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 13 / 47
3.3.6 LSU 4.9 Lambda Sensor
Functional Description: Exhaust gas lambda sensor
Use Case:
See Appendix for required sensor mounting information.
One sensor per cylinder bank is required.
Callout: Driver’s left bank will be Sensor #1
Part Number: 0258.988.001
Thread: M18 x 1.5
Installation Torque: 40 to 60 Nm
3.3.7 Engine Speed Sensor
Functional Description: Hall effect speed sensor
Use Case:
Each manufacturer may select a sensor to be approved by IMSA.
This sensor must be fitted in an IMSA approved location.
Missing/extra tooth configurations are NOT supported
Recommendation:
Bosch P/N: HA-N F.02U.V0U.714-01
20 tooth symmetrical wheel, no missing teeth
Trigger Wheel Requirements (for HA-N above):
Diameter > 80mm
Slot Width > 10mm
Tooth Width > 5mm
Height of tooth >5mm
Thickness > 8mm
Harness Pinout:
Connector
ASL106-05SA-HE
Pin
Description
1
12V+ KL.30
2
GND
3
Signal
4
5

3 | Components
14 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
3.3.8 Fuel Flow Meter
Functional Description: CAN based fuel flow meter for IMSA Prototype Class
Scrutineering System
Mounting Note:
This device in an IMSA approved location. See IMSA tech bulletin for
mounting information.
Temperature Range: 0 to 85 °C
3.4 Sensor Declaration Form
Prior to each event weekend, a Sensor Declaration Form must be submitted via
the IMSA TIMS system.
3.5 Component Seals
All Scrutineering system primary components (DDU9, PBX90, and LT4) units must
have an IMSA Scrutineering Seal. Each device ordered through Bosch Motorsport
NA using the attached order form will be delivered with the seal in place. This seal
is not to be removed or transferred.

4 | System Architecture
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 15 / 47
4System Architecture
4.1 Team CAN
4.1.1 Team Connector
The pinout of the Team Connector is shown in the table. No changes are allowed to
this arrangement. Termination of the CAN busses must be done in the car’s loom as
depicted in 4.1.2 and 4.1.3.
Team Harness Connector: AS(0/1)08-35SN
Scrutineering Harness Connector:
Connector AS608-35PN
Pin Description
1 CAN1_H
2 CAN1_L
3 CAN2_H
4 CAN2_L
5 Driver ID Signal
6 Driver ID GND
4.1.2 Team CAN 1

4 | System Architecture
16 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
4.1.3 Team CAN 2
NOTE:
One termination resistor will be built into the scrutineering loom. The other
termination resistor must be present in the team wiring of the CAN
connection, external of the scrutineering loom.
CAN buses must be laid out in a linear fashion, with a termination resistor
(120 ohm) at each physical end of the bus.
4.1.4 Driver ID
The Driver ID will be an input on the same connector as the team CAN connections.
The Driver ID signal will be controlled by a different resistance value for each driver.
The resistor will go between the two pins for Driver ID with nothing else in the
circuit. The Driver ID and resistor value pairings are in the table below:
ID
Resistor Value (Ohm)
1
0
2
820
3
2.2K
4
4.7K
5
12K

4 | System Architecture
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 17 / 47
4.2 Power Supply
The following notations for power signals are used:
▪KL 30 is a main relay switched battery positive rail. KL 30 must go directly to the
car master relay. It may not be connected through a power box or other device.
▪KL 31 is an un-switched ground rail (same as battery negative terminal)

4 | System Architecture
18 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
4.3 Harness
The scrutineering system harness has two major parts. The major pieces are the
engine harness and the chassis harness. These two meet with a bulkhead connector
located at the rear of the cockpit. The engine harness has an optional connector, if
used the smaller rear portion must be certified. An example layout is shown in
section 7. This layout may be deviated from; however, the components must remain
on the same harness and use the same connector. Contact an approved harness
builder for more information and specifics for individual applications.
All harness pieces must be certified individually and marked as such by a Bosch
Motorsport approved dealer. Harnesses must be purchased through a Bosch
Motorsport approved builder.
Initial harness builds may have extended lead times of 4-6 weeks or longer. Teams
and manufacturers are responsible for ensuring their harnesses are ordered with
time to be built for the first event it is to be used.
Approved builders:
DC Electronics
Address: 119 Poplar Pointe Drive
Mooresville, NC 28117
Phone : [phone]
Email : ja[email protected]
Sakata Motorsports Electronics, Inc.
Address: 1241 N. Patt ST.
Anaheim, CA 92801
Phone : [phone]
Email : [e-mail]
Bosch Motorsport DE
Address: 1 Robert-Bosch-Allee
74232 Abstatt, Germany
Contact : Aaron Pfeifer or Erich Ohlde

5 | Loom Certification
Bosch Motorsport IMSA Prototype Class Scrutineering Logger 19 / 47
5Loom Certification
All scrutineering looms will come certified and serialized from the builder. IMSA
reserves the right to require an additional HiPot inspection at any time.
The engine or chassis loom pieces may be certified individually without the
presence of the rest of the harness components. If a loom has additional
connectors all components of the loom to include all connectors shown in the
layout must be supplied for certification. Cost of additional inspections or re-
certification to be $200 per loom.

6 | CAN Specification
20 / 47 IMSA Prototype Class Scrutineering Logger Bosch Motorsport
6CAN Specification
There are two IMSA CAN interfaces that may be used for communication, on these
buses the team is required to send the “Team Transmitted Channels”.
Teams will be responsible for informing IMSA and Bosch which buses will be used
for ECU and team communications. These messages may be on the same bus.
CAN Buses:
The CAN buses will be used to transfer vital information between the team and the
Scrutineering System. The buses are required to be 1 Mbit and conform to CAN
2.0B specifications.
6.1 Team Transmitted Channels
Channel Name
Short
Name
Raster
(ms)
Notes
Engine Revs
nmot
10
Engine revolutions per minute
Ignition Timing
ign_out
10
Crank angle of ignition event
Fuel Injector Mass
fuel_mass
10
Fuel mass injected per 2 engine revolutions
Fuel Rail Pressure
prail
10
Pressure measured in the high pressure fuel rail
Gearbox Drum Position
gear_drum
20
Voltage of gearbox drum angle sensor
Gearbox Flag
shift_*
20
Flag denoting, up/down shift, shift error, and
shift strategy active
Gear
gear
20
Engaged gear in transmission
FL Wheelspeed
vwheel_fl
20
Speed of FL wheel
FR Wheelspeed
vwheel_fr
20
Speed of FR wheel
RL Wheelspeed
vwheel_rl
20
Speed of RL wheel
RR Wheelspeed
vwheel_rr
20
Speed of RR wheel
Throttle Pedal
aps
50
Throttle pedal percentage
Engine Throttle(s)
ath(2)
50
Throttle blade open percentage
FL Brake Pressure
pbrake_fl
20
If only axle pressure is available, send on both L & R
FR Brake Pressure
pbrake_fr
20
If only axle pressure is available, send on both L & R
RL Brake Pressure
pbrake_rl
20
If only axle pressure is available, send on both L & R
RR Brake Pressure
pbrake_rr
20
If only axle pressure is available, send on both L & R
Mixture Map
mappos
100
Value of engine mixture map selection switch
Boost Map
bmap
100
Value of engine boost map selection switch
Display Brightness
display_b
1000
Desired scrutineering display brightness (1-6)
Fuel Consumption
Calculation
fuelcons
100
Counter starts from 0 each session
Does NOT reset during session/race
Steering Angle
steer
20
Angle of steering wheel from center
Clutch Pressure
pclutch
20
Pressure in the clutch disengagement system
Cam Angle Left Bank
Intake
Cam1Int
100
Angle of the drivers left bank intake CAM from park
Cam Angle Left Bank
Exhaust
Cam1Exh
100
Angle of the drivers left bank exhaust CAM from park
Cam Angle Right Bank
Intake
Cam2Int
100
Angle of the drivers right bank intake CAM from park
Cam Angle Right Bank
Outlet
Cam2Exh
100
Angle of the drivers right bank exhaust CAM from
park
Tire Pressure FL
ptireFL
1000
TPMS system reported absolute air pressure in FL tire
Tire Pressure FR
ptireFR
1000
TPMS system reported absolute air pressure in FR
tire
Tire Pressure RL
ptireRL
1000
TPMS system reported absolute air pressure in RL
tire
Tire Pressure RR
ptireRR
1000
TPMS system reported absolute air pressure in RR
tire
Fuel Probe Flag
b_fuelprobe
20
Fuel Probe sensor: 0 = not connected, 1 = connected
